802.11ac WiFi Module
Model Number: 802R8822
PRODUCT SPECIFICATION

2of 9
Document revision history
Revision
Date
Approved by
Remarks
Version 1.0
2019-03-04

3of 9
FCC Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does
not cause harmful interference (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliancecould void the
user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception,which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit differentfrom that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated
with minimum distance between 20cm the radiator your body: Use only the supplied antenna.

4of 9
This device is intended only for OEM integrators under the
following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna and users,
and
2) This device and its antenna(s) must not be co‐located with any other transmitters except
inaccordance with FCC multi‐transmitter product procedures. Referring to the multi‐transmitterpolicy,
multiple‐transmitter(s) and module(s) can be operated simultaneously without C2P.
3) For all products market in US, OEM has to limit the operation channels in CH1 to CH11 for 2.4G band
& CH36 to CH165 for 5G band by supplied firmware programming tool. OEM shall not supply any tool or
info to theend‐user regarding to Regulatory Domain change.
USERS MANUAL OF THE END PRODUCT:
In the users manual of the end product, the end user has to be informed to keep at least 20cm
separation with the antenna while this end product is installed and operated. The end user has to be
informed that the FCC radio‐frequency exposure guidelines for an uncontrolled environment can be
satisfied. The end user has to also be informed that any changes or modifications not expressly
approved by the manufacturer could void the user's authority to operate this equipment.
If the size of the end product is smaller than 8x10cm, then additional FCC part 15.19 statement
isrequired to be available in the users manual: This device complies with Part 15 of FCC rules.
Operation is subject to the following two conditions: (1) this device may not cause harmfulinterference
and (2) this device must accept any interference received, includinginterference that may cause
undesired operation.
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following " Contains
FCCID:LNQ802R8822". If the size of the end product is larger than 8x10cm, then the following FCC part
15.19 statement has to also be available on the label: This device complies with Part 15of FCC rules.
Operation is subject to the following two conditions: (1) this device may not causeharmful interference
and (2) this device must accept any interference received, includinginterference that may cause
undesired operation.

5of 9
1. General Description
This document is to specify the product requirements for 802.11a/b/g/n/ac PCI-e Module. This
Card is basedon Realteak RTL8822BEH chipset that is a highly integrated single-chip that support
2-stream 802.11ac solutions with Multi-user MIMO (Multiple-Input, Multiple-Output) with Wireless
LAN (WLAN) PCI Express network interface controller and HS-UART mixed interface.
The RTL8822BE provides a complete solution for a high-performance integrated wireless and
Bluetooth device.
The RTL8822BEH-VR-CG baseband implements Multi-user Multiple Input, Multiple Output
(MU-MIMO) Orthogonal Frequency Division Multiplexing (OFDM) with two transmit and two receive
paths (2T2R). Features include two spatial stream transmissions, short Guard Interval (GI) of 400ns,
spatial spreading, and support for variant channel bandwidth. Moreover, RTL8822BEH-VR-CG
provides one spatial stream space-time block code (STBC), Transmit Beamforming (TxBF) and Low
Density Parity Check (LDPC) to extend the range of transmission. At the receiver, extended range
and good minimum sensitivity is achieved by having receiver diversity up to 2 antennas. As the
recipient, the RTL8822BE also supports explicit sounding packet feedback that helps senders with
beamforming capability.
For legacy compatibility, Direct Sequence Spread Spectrum (DSSS), Complementary Code
Keying (CCK) and OFDM baseband processing are included to support all IEEE 802.11b, 802.11g
and 802.11a data rates. Differential phase shift keying modulation schemes, DBPSK and DQPSK
with data scrambling capability are available, and CCK provides support for legacy data rates, with
long or short preamble. The high speed FFT/IFFT paths, combined with BPSK, QPSK, 16QAM,
64QAM and 256QAM modulation of the individual subcarriers, and rate compatible coding rate of
1/2, 2/3, 3/4, and 5/6, provide up to 866.7Mbps for IEEE 802.11ac MIMO OFDM.
2. Features
Compatible with IEEE 802.11a standard to provide wireless 54Mbps date rate.
Compatible with IEEE 802.11g standard to provide wireless 54Mbps date rate.
Compatible with IEEE 802.11b standard to provide wireless 11Mbps date rate.
Compatible with IEEE 802.11n standard to provide wireless 300Mbps date rate.
Compatible with IEEE 802.11ac standard to provide wireless 866.7Mbps date rate.
Operation at 2.4~2.5GHz and 5.15~5.825GHz frequency band to meet worldwide regulations
Provides simple legacy and 20MHz/40MHz/80MHz co-existence mechanisms to ensure
backward andnetwork compatibility.
Supports infrastructure networks via Access Point and ad-hoc network via peer-to-peer
communication
Supports IEEE 802.11i(WPA and WPA2), WAPI, enhanced security
Friendly user configuration and diagnostic utilities
PCIe 2.0 interface, Mini PCIe
ROHS compliant

6of 9
3. General Requirements
3.1 IEEE 802.11b Section
Feature
Detailed Description
3.2.1.1
Standard
● IEEE 802.11b
3.2.1.2
Radio andModulation
Schemes
● DQPSK, DBPSK, DSSS, and CCK
3.2.1.3
OperatingFrequency
● 2400~2483.5 MHz ISM band
3.2.1.4
Channel Numbers
● 11 channels for United States
● 13 channels for Europe Countries
3.2.1.5
Data Rate
● 11,5.5,2,and 1Mbps
3.2.1.6
Media AccessProtocol
● CSMA/CA with ACK
3.2 IEEE 802.11g Section
Feature
Detailed Description
3.2.2.1
Standard
● IEEE 802.11g
3.2.2.2
Radio andModulation Type
● QPSK , BPSK , 16QAM ,64QAM with OFDM
3.2.2.3
OperatingFrequency
● 2400~2483.5MHz ISM band
3.2.2.4
Channel Numbers
● 11 channels for United States
● 13 channels for Europe Countries
3.2.2.5
Data Rate
● 6,9,12,18,24,36,48,54Mbps
3.2.2.6
Media AccessProtocol
● CSMA/CA with ACK
3.3 IEEE 802.11a Section
Feature
Detailed Description
3.2.3.1
Standard
● IEEE 802.11a
3.2.3.2
Radio andModulation Type
● QPSK , BPSK , 16QAM ,64QAM with OFDM
3.2.3.3
OperatingFrequency
● 5.15~5.35GHz and 5.47~5.825GHz for US
● 5.15~5.35GHz and 5.47~5.725GHz for Europe
3.2.3.4
Channel Numbers
● 24 non-overlapping channels for US and Canada
● 19 non-overlapping channels for Europe
3.2.3.5
Data Rate
● 6,9,12,18,24,36,48,54Mbps
3.2.3.6
Media AccessProtocol
● CSMA/CA with ACK

7of 9
3.2.4 IEEE 802.11n Section
Feature
Detailed Description
3.2.4.1
Standard
● IEEE 802.11n
3.2.4.2
Radio and
Modulation Type
● QPSK , BPSK , 16QAM ,64QAM with OFDM
3.2.4.3
OperatingFrequency
●2.4GHz band:2400 ~ 2483.5MHz
●5GHz and:5150 ~ 5850MHZ
3.2.4.4
Data Rate (Mbps)
MCS
GI=800ns
GI=400ns
20MHz
40MHz
20MHz
40MHz
0
6.5
13.5
7.2
15
7
65
135
72.2
150
15
130
270
144.4
300
3.2.4.5
Media Access
Protocol
● CSMA/CA with ACK
3.2.5 IEEE 802.11ac Section
Feature
Detailed Description
3.2.5.1
Standard
● IEEE 802.11ac
3.2.5.2
Radio and
Modulation Type
● QPSK , BPSK , 16QAM ,64QAM,256QAM with OFDM
3.2.5.3
OperatingFrequency
●5GHz:5150 ~ 5850MHZ
3.2.4.4
Data Rate (Mbps)
NSS/MCS
GI=800ns
GI=400ns
20MHz
40MHz
80MHz
20MHz
40MHz
80MHz
NSS1/MCS0
6.5
13.5
29.3
7.2
15
32.5
NSS1/MCS8
78
162
351
86.7
180
390
NSS1/MCS9
180
390
200
433.3
NSS2/MCS0
13
27
58.5
14.4
30
65
NSS2/MCS8
156
324
702
173.3
360
780
NSS2/MCS9
360
780
400
866.7
3.2.4.5
Media Access
Protocol
● CSMA/CA with ACK

8of 9
4. Electrical and Thermal Characteristics
4.1 Temperature Limit Ratings
Parameter
Minimum
Maximum
Units
Storage Temperature
-55
+125
℃
Ambient Operating Temperature
0
70
℃
Junction Temperature
0
125
℃
4.2 General Section
Feature
Detailed Description
5.2.1
Antenna Type
●PCB PIFA Antenna
●Dipole Antenna
5.2.2
Operating Voltage
●DC3.3V±10%
5.2.3
Current Consumption
●＜1000mA
5.2.4
Form Factor and Interface
●PCIe interface
4.3 Software
Driver：Linux, Android
4.4 Antenna Information
PCB PIFA ANTENNA
DIAPOLE ANTENNA
2.4G
5G
2.4G
5G
Ant A
4.9dBi
5.6dBi
1.8dBi
2dBi
Ant B
3.6dBi
4.4dBi
1.8dBi
2dBi

9of 9
4.5 Mechanical Dimensions
Pin
Definition
Pin
Definition
1
WAKEn
22
PCIE_RESETn
2,24,39,41,52
VD33
23
PETn0
3,5,6,8,17,19,28,30,44,46,48
NC
25
PETp0
4,9,15,18,21,26,27,29,34,35,
37,40,43,50
GND
31
HSIN
7
CLKREQn
32
UART_TX
10,12,14,16,45,47,49,51
VDDA5_PA
33
HSIP
11
REFCLK-
36
UART_CTS
13
REFCLK+
38
UART_RX
20
WL_DIS_N
42
5GL_EN_1295
