Introduction
This guide is designed to get you quickly up and running with the Harrier 52x AF-Zoom IP Camera
(AS-CAM-52IPHD-A). This document should be read in conjunction with the datasheet and technical
reference manual for the Harrier 52x AF-Zoom IP Camera. The camera is shipped with a fixed IP address of
192.168.1.108; this can be changed once you have connected to the camera.
Figure 1. Harrier 52x AF-Zoom IP Camera
Figure 2. Harrier 23x/52x IP Camera
Evaluation Board
Figure 3. Harrier 23x/52x IP Camera
Evaluation Board

QUICK START GUIDE
HARRIER 52x AF-ZOOM IP CAMERA
Version 1.0 - October 2023
October 2023
Page 2 of 11
Evaluation Kit Contents
The Evaluation Kit for the Harrier 23x/52x IP Camera (AS-CAM-23IP4K-EVAL-A) contains all the parts
needed to evaluate the Harrier 52x AF-Zoom IP Camera. Note that the evaluation kit does not include a
camera, this needs to be ordered separately.
Please check that you have all the parts listed below:
•Harrier 23x/52x IP Camera Evaluation Board (see Figures 2 and 3).
•Fixing posts and screws to mount evaluation board on to the camera.
•36-way 0.5mm pitch FFC cable
•12V multi-standard power supply and mains socket adapters.
Mounting the Evaluation Board on the Camera (optional)
1. Connect the Harrier 23x/52x IP Camera Evaluation Board (J1) to the camera (J17) using the 36-way
0.5mm pitch FFC cable. Ensure that the cable is connected the right way round. The metal
contacts should face towards the PCB.
2. Screw the mounting posts into the back of the camera.
3. Using the screws, carefully mount the Harrier 23x/52x IP Camera Evaluation Board to the camera.
Without creasing the FFC cable, gently fold the FFC cable between the evaluation board and the
camera so it does not protrude excessively.

QUICK START GUIDE
HARRIER 52x AF-ZOOM IP CAMERA
Version 1.0 - October 2023
October 2023
Page 3 of 11
Quick Start
1. Download and install the ONVIF Device Manager from https://sourceforge.net/projects/onvifdm/
2. Configure the network adapter on a PC to have an address of 192.168.1.1 (or similar).
3. Using a Cat5/6 RJ45 cable, connect the RJ45/Ethernet port of the Harrier 23x/52x IP Camera
Evaluation Board to the network adapter of the PC.
4. Connect the 12V power supply to the barrel connector of the evaluation board.
5. When you are ready, the power supply can be plugged in and switched on; the camera will start up.
After a while the camera will have initialized and a blinking LED on the PC Ethernet port and on the
Harrier 23x/52x IP Camera Evaluation Board will indicate network activity.
6. On the PC, open the Microsoft Edge browser and browse to 192.168.1.108.
7. The camera web page will open, and you will see a login prompt.
8. Before logging in, click on the Plug-in download and install the plug-in. This will enable the video
preview to work on the web page. You may need to close the browser to install the plug-in.
9. Login using user:admin, password:123456
10. You may need to open the 192.168.1.108 site in Microsoft edge - Internet Explorer mode for the
video/pages to work properly.
11. You should see a video preview from the camera.
12. Go to the settings tab and select System Settings->Encode settings.
13. Set all streams to H.264 and save the settings. Note: The ONVIF Device Manager cannot display
H.265 encoded streams.
14. On the PC, open the ONVIF Device Manager and use it to locate the camera. Click the Refresh
button and the camera will appear on the Device List with the IP address 192.168.1.108.
15. Open the connection to the camera by clicking on the box in the left-hand pane that shows the
camera and its IP address. The panes on the right will populate and show a video preview image
and camera stream settings.
16. By clicking on the Live video menu option, you can view the streaming video from the camera (see
Figure 6).
If you select the Profiles option on the menu you will also be able to select different video streams
served by the camera (as set up in the web page encoder settings).
17. If the PTZ control menu option is selected, the camera can be zoomed using the Zoom +/- buttons
on the screen.
18. The video stream can also be opened using a media player application (e.g. VLC media player or
GStreamer). Use rtsp://192.168.1.108:554/type=0&id=1to connect to the camera.
E.g. for VLC media player (supports H.265): Select the Media menu, select Open Network Stream.
In the Open Media dialog, enter rtsp://192.168.1.108:554/type=0&id=1.
Click the Play button.

QUICK START GUIDE
HARRIER 52x AF-ZOOM IP CAMERA
Version 1.0 - October 2023
October 2023
Page 4 of 11
Figure 2. Camera Web Page login.
Figure 3. Camera Web Page encoding setting view.
Figure 4. ONVIF Device Manager video streaming screen.

QUICK START GUIDE
HARRIER 52x AF-ZOOM IP CAMERA
Version 1.0 - October 2023
October 2023
Page 5 of 11
Web Browser Compatibility
The current camera firmware was designed for use with Internet Explorer and relies on an Internet Explorer
plug-in that is downloaded from the camera. This means that the camera demo web page is unlikely to
work properly in other browsers. Fortunately, the Microsoft Edge browser can be set into Internet Explorer
compatibility mode:
•Open Edge.
•Open Settings.
•Select the Default browser section.
•Under Internet Explorer compatibility set
‘Allow sites to be reloaded in Internet Explorer mode (IE mode)’ to ‘Allow’.
•You can then ‘Add’ the camera IP address to the list of Internet Explorer mode pages.
Figure 5. Microsoft Edge Settings page where Internet Explorer compatibility mode can be enabled
Once IE mode has been enabled, you can open the Edge settings panel (click on the three dots) and select
‘Reload in Internet Explorer’ for any site. If you added the camera IP address to the Default Browser
settings, this will happen automatically whenever you open the camera demo web page.
Figure 6. Edge settings option for reloading web pages in IE mode

QUICK START GUIDE
HARRIER 52x AF-ZOOM IP CAMERA
Version 1.0 - October 2023
October 2023
Page 6 of 11
Opening the Camera Demo Web page
Open Internet Explorer (or Edge in Internet Explorer mode) and browse to the IP address of the camera.
A login page will open.
To display video the web page requires an ActiveX plug-in that is downloaded from the camera. This plug-
in works with Internet Explorer (or Edge in Internet Explorer mode) but may not work with other web
browsers.
On the login dialog you will see ‘Plug-in Download’. If you have not done this before, click on the option to
download and install the file: Setup.msi.
Figure 7. Camera demo web page login dialog
Once the plug-in is installed you can log in:
User: admin
Password: 123456 or password123
This will open the demonstration web page where you can control the camera and change the camera
settings.

QUICK START GUIDE
HARRIER 52x AF-ZOOM IP CAMERA
Version 1.0 - October 2023
October 2023
Page 7 of 11
Figure 8. Camera demo web page main screen
Changing the Network Address
The network address can be changed using ONVIF Device Manager or the camera web page. Care must
be taken when changing the address to ensure that you are always able to find the camera.
To change the network address using ONVIF Device Manager (see Figure 12):
•Open/connect to the camera by clicking on the box in the left hand panel.
•Select ‘Network settings’in the centre panel and edit the settings.
•Select ‘Apply’ and the settings on the camera will change – note you will need to refresh the view as
the camera will now be at a different IP address.
To change the network address using the Camera demo web page (see Figure 13):
•Log in to the camera demo web page
•Select the ‘Settings’ tab
•Select the ‘Network Settings’ option from the menu on the left and edit the settings.
•Select ‘Apply’ and the settings on the camera will change – note you will need to reconnect to the
camera as it will now be at a different IP address.
For more information, please refer to the camera’s Technical Reference Manual.

QUICK START GUIDE
HARRIER 52x AF-ZOOM IP CAMERA
Version 1.0 - October 2023
October 2023
Page 8 of 11
Figure 9. ONVIF Device Manager network settings
Figure 10. Camera demo web page Network Settings tab

QUICK START GUIDE
HARRIER 52x AF-ZOOM IP CAMERA
Version 1.0 - October 2023
October 2023
Page 9 of 11
SD Card Recording
Applications should use the ONVIF service to control the recording, but the demo web page can also be
used to set up recording on the SD card.
•Insert an SD card into the camera.
•Open the camera demo web page and log in.
•Open the ‘Settings’ tab and select ‘Storage Settings’ -> ‘Disk Manager’.
•Click on ‘Refresh’ and select the SD card (it will be listed as a hard drive).
•Select ‘Format’ and accept the prompts.
•The camera will re-boot, log in again and re-select the ‘Disk Manager’ to check that the card is
formatted correctly.
•Select ‘Record Settings’.
•The demo page has been designed to emulate a security system and can be set to operate at set
periods of time or with alarms.
•Set the ‘General’ tick box on Period 1, a green line will appear in the display for Sunday.
•Set the ‘Copy To All’ tick box, the green line will now appear on all days. Click on the ‘Save’ button.
This has now enabled 24 hour/7 days a week recording.
•Go to the ‘Disk Manager’ or ‘Information’->’Disk Information’ and you will see that the free space is
slowly going down as the camera records the video to the SD card.
•To stop the recording return to ‘Storage Settings’->’Record Settings’ and use the ‘Reset All’ button
to clear the recording schedule then click on ‘Save’.
Figure 11. Camera demo web page Record Settings page

QUICK START GUIDE
HARRIER 52x AF-ZOOM IP CAMERA
Version 1.0 - October 2023
October 2023
Page 10 of 11
To view the recordings:
•Select the Playback tab.
•Click on the ‘Query Terms’->’Query’ button.
•The timetable row/bar at the bottom of the frame will update to show the times where recordings
have been made (shown in green).
•Click on and slide the timetable row/bar until the recoding region you want to view is under the
green maker line shown at the centre of the timetable row/bar.
•Click on the play button and the recording will be played back to the display.
Figure 12. Camera demo web page recording Playback tab

QUICK START GUIDE
HARRIER 52x AF-ZOOM IP CAMERA
Version 1.0 - October 2023
October 2023
Page 11 of 11
Downloads
ONVIF reference documentation: https://www.onvif.org/resources/
ONVIF Device Manager: https://sourceforge.net/projects/onvifdm/
VLC: https://www.videolan.org/vlc/index.en-GB.html
GStreamer: https://gstreamer.freedesktop.org/download/
Technical Support
In case of any issues, please contact Active Silicon Technical Support by email on
[e-mail].
