Actreg ADA SERIES Quick guide

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
1
- LCIE 05 AR 022
ADA & ASR SERIES
DOUBLE ACTING
ACTUATOR
“A
DA
”
SPRING RETURN
ACTUATOR
“ASR”

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
2
REVIEW CONTROL
PROCEDURE REF. DOC. MMMACTREGDRE
Rev. Date Carried out by Approved Description
0 02-01-2006 J. Rubio J.Tejedor First Edition
1 10-12-2008 J. Rubio J.Tejedor General update
2 19-01-2012 F.Zanuy J.Tejedor General update

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
3
CONTENTS
1. Applicable Range ................................................................................... page 4 - 6
2. General Information................................................................................ page 6 - 8
3. Inspection at Delivery & Storage ............................................................ page 8
4. Installation .............................................................................................. page 8 - 9
5. Preventive Maintenance......................................................................... page 10
6. Maintenance Operations ........................................................................ page 10
7. Reasons for Parts Repair & Replacement ............................................. page 10
8. Disassembly of the Actuator................................................................... page 11
9. Assembly of the Actuator ....................................................................... page 12
10. Recommended Spare Parts ................................................................... page 14
11. Exploded view ACTREG actuator ADA 10………………………………. Page 15
12. Exploded view ACTREG actuator size ADA (20 ~ 850)......................... page 16
13. Exploded view ACTREG actuator size ASR (20 ~ 850) ........................ page 17
14. Exploded view ACTREG actuator size ADA (1200 ~ 1750)……………. page 18
15. Exploded view ACTREG actuator size ASR (1200 ~ 1750)……………. page 19
16. Exploded view ACTREG actuator size ADA (2100-4000) ..................... page 20
17. Exploded view ACTREG actuator size ASR (2100-4000) .................... page 21
18. Fault Finding ………………………………………………………………….page 22

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
4
1. APPLICABLE RANGE
The Pneumatic Actuators ACTREG use a rack and pinion sliding system that creates a linear torque
with a quarter turn operation. The range is the following:
ADA-10
ADA-20
ADA-40
ADA-80
ADA-130
ADA-200
ADA-300
ADA-500
ADA-850
ADA-1200
ADA-1750
ADA-2100
ADA-2500
ADA-4000
SPRING COMBINATIONS
ASR-20 S04 S06 S08
ASR-40 S04 S06 S08 S10 S12 S14
ASR-80 S04 S06 S08 S10 S12 S14
ASR-130 S06 S08 S10 S12 S14
ASR-200 S06 S08 S10 S12 S14
ASR-300 S06 S08 S10 S12 S14
ASR-500 S06 S08 S10 S12 S14
ASR-850 S06 S08 S10 S12 S14
ASR-1200 S06 S08 S10 S12 S14
ASR-1750 S06 S08 S10 S12 S14
ASR-2100 S06 S08 S10 S12 S14
ASR-2500 S06 S08 S10 S12 S14
ASR-4000 S06 S08 S10 S12 S14
SERIE ADA
Double Acting
SERIE ASR
Spring Return

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
5
1.1 SPRING COMBINATION BY TYPE OF ACTUATOR
ACTREG actuators use a maximum of seven springs on each side, always using a same type
of spring independently of the combination of springs that will be used.
The quantity of springs is identified as follows:
eg: S14
S = springs & 14 is the total number of springs assembled in the actuator.
1.1.1 ACTUATOR SIZE ASR-20
The actuator ASR-20 uses a minimum of 2 springs and a maximum of 4 springs on each
side, according to the diagrams below, depending on the springs combination that require to be
assembled.
1.1.2 ACTUATORS SIZES ASR-40 & 80
The actuators ASR-40 & 80 use a minimum of 2 springs and a maximum of 7 springs on
each side, according to the diagrams below, depending on the springs combination that require
to be assembled.
S04
S06
STANDARD
S08
S04
S06
S08
S10
S12
S14
STANDARD

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
6
1.1.3 ACTUATORS SIZES ASR-130 ~ 4000
The actuators ASR-130 ~4000 use a minimum of 3 springs and a maximum of 7 springs
on each side, according to the diagrams below, depending on the springs combination that
require to be assembled.
2. GENERAL INFORMATION
2.1 STATEMENT
ACTREG Actuators sizes 300 and smaller
ACTREG S.A. states that Actreg Actuators covered by this Certificate have been designed and
manufactured in accordance with the following European Directives requirements:
-European Pressure Equipment Directive 97/23/CE: classified according to Article 3, Part 3, Cat.
SEP, must not carry the CE label.
-Machines Directive 89/392/CEE.
-Directive 94/9/CE ATEX, classification Group II, Cat. 2 for use in explosive atmospheres, Zones
1,2 & 21,22. Conformity evaluation according to Appendix VIII.
Marking CE Ex II2GDc.
-EN 15714-3
Applied harmonized and non-harmonized Technical Standards:
-See ACTREG’s Catalogue & Assembly & Maintenance Procedures.
-EN 13463-1:2001, EN 1127-1.
The electrical & mechanical accessories are not covered by this statement and will have to
carry their own certificate in order to be assembled with the Actreg Actuators.
S06
S08
S10
S12
S14
STANDARD

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
7
ACTREG Actuators sizes 500 & larger
ACTREG S.A. states that Actreg Actuators covered by this Certificate have been designed and
manufactured in accordance with the following European Directives requirements:
-European Pressure Equipment Directive 97/23/CE: classified according to Category I, Module A
Evaluation Procedure of Conformity mod. A certified by the manufacturer ACTREG.
Marking CE.
-Machines Directive 89/392/CEE.
-Directive 94/9/CE ATEX, classification Group II, Cat. 2 for use in explosive atmospheres, Zones
1,2 & 21,22. Conformity evaluation according to Appendix VIII.
Marking CE Ex II2GDc.
-EN 15714-3 Pneumatic Part-Turn Actuators For Industrial Valves
Applied harmonized and non-harmonized technical Standards:
-EN 13463-1:2001, EN 1127-1.
The electrical and mechanical accessories are not covered by this statement and will have to
carry their own certificate in order to be assembled with Actreg actuators.
The suitability of the materials and design of the actuator type in terms of its working conditions
are the responsibility of the actuator’s end user.
ADA & ASR SIZES
DESCRIPTION OF THE PRESSURE EQUIPMENTS
Type Serie Size PN
10
PN-10
20
40
80
130
200
ADA Double
Acting
300
500
850
1200
1750
2100
2500
ASR Spring
Return
4000
PN-8

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
8
Material: Aluminium
Service conditions for standard actuators:
Maximum Pressure: 8 bars (Except ADA 10, 10 bars)
Minimum Temperature: -30 ºC
Maximum Temperature: +100 ºC
Agreement evaluation process used: Category I Module A
Technical Standards & applied Specifications:
Solenoid direct assembly according to Standard NAMUR VDI / VDE 3845
Accessories assembly according to Standard NAMUR VDI / VDE 3845
Connections to valves according to Standard EN ISO 5211
3. INSPECTION AT DELIVERY & STORAGE
3.1 All actuators must be examined upon delivery to ensure that they have not suffered any damage
during transport. Inform the supplier immediately if there is any damage.
3.2 As standard, actuators will leave the factory in closed position. Open position configuration must be
specially requested.
3.3 WARNING!!
Actuators must be stored under cover and protected from inclement weather conditions and
dampness with air conducts properly covered.
3.4 Actuators should not be unpacked until their definitive installation, except for inspection purposes.
4. INSTALLATION
4.1 The handling and transportation of actuators must be carried out with extreme precaution and using
the necessary and adequate means depending on their size and weight in order to avoid risks to the
operators handling them.
WARNING !!
Check the physical conditions of actuators in order to detect any damage incurred during
transport and/or handling.
4.2 Actuators should be installed in such a way that they are easy to access in order to do the periodic
inspections and corresponding maintenance operations necessary to guarantee the performance
qualities that they have been designed for.
WARNING !!
Actuators must not support unexpected stress. It is important to do the assemble with a
correct alignment and parallelism to guarantee that it is not submitted to unexpected stress.
IMPORTANT !!
After the installation carry out a final operational check of the actuator by making some opening
and closing operations to ensure that it works properly.

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
9
The use of dry air increases the lifetime of the actuators, as well as the lifetime of their
accessories, solenoids and other pneumatic accessories.
4.2.1 RECOMMENDED MINIMUM AIR QUALITY
For best possible service life and trouble-free operation, ISO 8573-1 quality class 5.4.4
should be used. This means 40 µm filter, dew point +3ºC for indoor operation (a lower dew point
should be selected for outdoor operation, Quality class 3) and oil concentration 5.0mg oil/m³.
Pollution Water Oil
Quality Class Particle size (µm) Max. concentration
(mg/m³)
Max. press. dew
point (ºC)
Max.
concentration
(mg/m³)
1 0.1 0.1 -70 0.01
2 1 1 -40 0.1
3 5 5 -20 1.0
4 15 8 +3 5.0
5 40 10 +7 25
6 - - +10 -
4.2.2 LUBRICATION
Actuators are factory lubricated for the lifetime in normal working conditions.
The standard lubricant is suitable for use from -30ºC (-22º F) up to 100ºC (212º F).
For low and high temperature execution, where special grease is required please contact
ACTREG.
For our standard execution we recommend to use Molicote B2.2 Plus grease or silimar.
WARNING !!
Actuators are lubricated during assembly and do not require any further lubrication.
4.3 Make sure that both the actuator and valve are in the same position, open or closed.
4.4 When assembling the actuator on the valve, check their alignment to ensure that the coupling parts
work perfectly aligned.
4.5 The coupling bolts, whether the actuator connects directly to the valve or uses a bracket, must be
tightened proportionally, distributing the stress, before tightening them completely.
4.6 The normal performance of the actuators is to close clockwise and to open anticlockwise.
However, this may be inverted under request.
4.7 ACTREG pneumatic actuators are provided with bi-directional pinion travel stops. Side located stops
allow a full ±5º travel adjustment between 85º and 95º. Adjustment of the counter clockwise and
clockwise rotation limits is accomplished by unscrewing the locking nuts. 1/3 turn of those locking nuts
means 1º of the stroke.
WARNING!!
Do not adjust more than 2.5º each side, designed by the manufacturer. Internal parts could
be damaged.
IMPORTANT !!
It is advisable to operate the actuator twice before fully tightening the coupling bolts in order to
ensure a good centring.

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
10
5. PREVENTIVE MAINTENANCE
5.1 This basically consists in a periodic inspection to check the actuator function.
5.2 Actuators must be operated at least once every six months. However, depending on the application of
the actuator, this may be done within shorter periods.
5.3 It is the end user’s responsibility to establish these operation plans depending on the working
conditions.
WARNING !!
Never leave the actuators opened or closed during a long period of time.
5.4 It is recommended to replace O-rings, guides and washers when an in-depth revision of the
installation is made.
6. MAINTENANCE OPERATIONS
6.1 PRECAUTIONS BEFORE DISASSEMBLY!!
6.1.1 Disconnect the actuator and its accessories from the air and electrical network.
6.1.2 Disassembly the solenoid from the actuator.
6.1.3 Disassembly the actuator from the valve and/or from its couplings.
WARNING !!
Always wear adequate protective clothing (Follow the safety guidelines established by
your company!)
Any parts replacement should be done with the original ACTREG spare parts!!
The manufacturer will not be responsible of the wrong functioning of the actuator if
original ACTREG parts have not been used.
7. REASONS FOR PARTS REPAIR AND REPLACEMENT
Parts of the actuator will have to be repaired or replaced as soon as leakage is detected through the
upper O-ring (111) or lower O-ring (110) of the pinion, through the O-ring (109) of the piston or through the O-
rings (118) of the end caps.
As soon as this happens, proceed with the disassembly of the actuator and replacement of all the O-
rings, bushings, slide guides and washers as listed in the spares parts.
8. DISASSEMBLY OF THE ACTUATOR
Once the precautions prior to the disassembly have been taken, follow the next steps:
8.1 Disassembly the end caps (4) of the actuator by un-tightening the external bolts (113).
WARNING !!
With SPRING RETURN ACTUATORS there is no danger during this operation as the
fastening bolts of the caps are designed with adequate length to absorb spring stress.

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
11
8.2 Unfasten the nuts (934) in order to remove the levelling screws (16).
8.3 Turn the pinion (3) anticlockwise to disengage the pistons (2) in normally closed actuators and
clockwise in normally open ones. Remove the pistons from the cylinder.
8.4 Disassemble the position indicator (20), the degree indicator (24), the slip washer (471), the soft pinion
washer (5) and the metallic pinion washer (8) from the upper side.
8.5 Disassemble the pinion (3) from the lower part of the body (1) of the actuator. To do this operation,
disassemble the upper pinion bearing (10) and the stop (12) through the inside of the body.
8.6 Clean all the parts of the actuator.
8.7 Examine all the parts in order to see if there is any wear due to an over-use.
WARNING!!
Carefully examine the inside of the cylinder.
8.8 If everything is in good conditions, replace the O-rings, bushings, slide guides included in the
ACTREG Maintenance kits, before reassembling the actuator.
8.9 Lubricate the parts of the actuator with Molicote B 2-2 plus grease. Apply a thin layer of grease on the
O-rings (109, 110 & 111).
9. ASSEMBLY OF THE ACTUATOR
After the disassembly, the inspection and lubrication of the different parts proceed to the assembly
following the sequence below:
9.1 Correctly assembly all the parts included in ACTREG Maintenance kits previously lubricated.
9.2 Place the pinion (3) in the body’s (1) actuator from underneath. Once the pinion appears through the
inside of the body, assemble the pinion stop (12) in its correct position and the upper pinion bearing
(10).
9.3 Place the soft pinion washer (5), the metallic pinion washer (8), the slip washer (471), the degree
indicator (24) and the position indicator (20) in the upper part of the pinion.
9.4 Assemble both pistons, checking that they engage at the same time when turning the pinion (3)
clockwise for normally closed actuators and anticlockwise for normally open actuators.
9.5 Assemble actuators end caps (4) tighten the bolts (113) adequately distributed.
9.6 Check that the open and closed positions coincide with the position indicated in the upper part of the
pinion, then assembly the cover.
IMPORTANT !!
Once the assembly is done, operate the actuator a few times.

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
12
PIPE AXIS
Closed Position Open Position
Model ADA-10
PIPE AXIS
Models 20 to 850
Models 1200 to 4000
PIPE AXIS

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
13
10. RECOMMENDED SPARE PARTS
The spare parts kit of the ADA & ASR ACTREG actuator is made up of the following parts:
Nº Quantity Name
5 1 Soft Pinion Washer
6 2 Slide Piston
8 1 Metallic Pinion Washer
10 1 Upper Pinion Bearing
24 2 Rubber Plug
25 2 Slide Guide
26 1 Lower Pinion Bearing
109 2 Piston’s O-ring
110 1 Lower Pinion’s O-ring
111 1 Upper Pinion’s O-ring
118 2 Cap’s O-ring
119 2 O-ring
471 1 Slip Washer

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
14
11. EXPLODED VIEW ACTREG ACTUATOR, SIZE ADA 10.

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
15
12.EXPLODED VIEW ACTREG ACTUATOR, SIZE ADA (20 ~ 850).

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
16
13. EXPLODED VIEW ACTREG ACTUATOR, SIZE ASR (20~ 850).

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
17
14. EXPLODED VIEW ACTREG ACTUATOR, SIZE ADA (1200 ~ 1750).

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
18
15. EXPLODED VIEW ACTREG ACTUATOR, SIZE ASR (1200 ~ 1750)..

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
19
16. EXPLODED VIEW ACTREG ACTUATOR, SIZE ADA (2100 ~ 4000).

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
20
17. EXPLODED VIEW ACTREG ACTUATOR, SIZE ASR (2100 ~ 4000).
