Acuva Arrow Series User manual

Advanced UV-LED Water Purification | acuvatech.com Page 1
Acuva Arrow
UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Acuva Technologies Inc.
Unit 1 - 3771 North Fraser Way, Burnaby, BC. Canada V5J 5G5
Telephone: [phone] | Email: [email protected]
acuvatech.com

Acuva Arrow UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 2
Summary
This document is the product manual for the Arrow UV-LED Water Purifier,
including safety, product specification, installation and maintenance information.
Table of Contents
Safety Information and Warnings
Warnings and Safety Precautions
Input Water Quality
Product Information
UV Device
UV Device Smart Features
Installation Guide
Installation Instructions
Mounting the Unit
UV Indicator Light
Optional Smart Faucet Installation
Final Installation Steps
Maintenance
Regular Maintenance
Winterizing
Trouble Shooting
Standard Terms and Conditions
Warranty
3
3
4
5
5
6
6
6
7
8
8
9
9
9
9
10
11
11

Acuva Arrow UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 3
Safety Information and Warnings
This section contains important information regarding the safe installation
and operation of the Acuva Technologies UV-LED Water Purification
Systems (the “device”). please read carefully.
Installation or operation of the device in a manner contrary to this manual
may result in property damage or personal injury.
Acuva recommends that the device be installed by a qualified technician
and shall comply with applicable state and local regulations.
Warnings and Safety Precautions
DANGER
Do not store the device in freezing conditions.
Do not allow water to freeze in the device.
Do not use the device if damaged or dropped.
Do not submerge the device under water.
Do not connect to AC power without an AC to DC power converter; this
device uses DC only.
This product is not ignition protected. Do not install in the engine
compartment or other areas where explosive vapours may be present.
WARNING
A steady blue light on the device while water is flowing is the only
indication that the water is safe to drink. If the blue light is not ON while
the faucet is open, please check the “trouble shooting” section of this
manual.
The UV device includes fragile parts, including parts made from glass.
The device should not be dropped and must be transported/carried
with sucient care.
Install the device at an accessible and visible location for continuous
monitoring of the system status using LED indicators and/or in case of
any leakage.
CAUTION
Minor condensation may occur on the device in humid weather and
with cold water temperatures (<dew point temperature). Condensation
drip may be noticed from inside the unit.

Acuva Arrow UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 4
Safety Information and Warnings Cont’d
Input Water Quality
The quality of the input water is important as it influences the eectiveness
of the system and the safety of the water.
The input water should be from a potable cold-water source. Acuva purifiers
are eective for microbial (viruses, bacteria, and protozoa) disinfection and
a 5-micron filter is needed to remove particulate contamination from water.
Do not drink or use any water that is of unknown origin or that has not
undergone adequate treatment. A 5-micron carbon filter is recommended
and included for removal of bad taste and odor from the water.
Acuva’s recommended requirements for the input water are listed in  1.
UV transmittance >93%
Temperature 1 C < T < 27 C
Hardness < 120 (mg/L)
Turbidity < 1 NTU
Manganese < 0.05 mg/L
Tannins < 0.1 mg/L
Iron < 0.3 mg/L
 1 :      

Acuva Arrow UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 5
Product Information
UV Device
Connections Input: ⁄” Female MNPT Output: ⁄” Female MNPT
Voltage 10 - 26V DC only
Power Consumption 3.33 Amps, 40 W (Active), 0.48 W (Standby)
Water Temperature Min 33.8 oF (1oC) Suggested Max. 80.6 oF (o27 C)
Operating Pressure Min 30 psi (2 bar) Suggested Max 100 psi (7 bar)
  :     
Model Flow Rate (L/min) UV-Dose (mJ/cm2) Water Source
Arrow 5 5 >16 Chlorinated
  :      -
(A) Water Inlet
(B) Water Outlet
(C) DC Power Jack
(D) Status LED Indicator
(E) Faucet Indicator Jack
The Acuva UV Device is designed for
automatic operation once the device is
properly installed and used. See Fig. 3 for
normal operation modes.
.  :   
When the device is first connected to power,
the unit will power up, turn on the blue light
for 10 seconds, and the blue light will turn
o as the system enters stand-by mode. As
soon as the faucet is opened, and water
starts to flow, a steady blue light on the unit
will indicate that the water purification is in
progress and that it is safe to drink water
from the device. When the faucet is closed,
the blue light will stay on for 4 seconds, then
goes out as the unit enters stand-by mode.
.  :  
Steady Blue Light

Acuva Arrow UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 6
Product Information Cont’d
UV Device Smart Features
Installation instructions
In order to ensure that any water passing through the Arrow system is
eectively disinfected, the system includes smart features enabled by
a micro-controller. The Arrow system has self monitoring features and
disinfection cycle completion and self sanitation cycles.
 : The Arrow measures the UV-LED health and
temperature to ensure proper function.
 : The Arrow remains active for 5 seconds after
each use to ensure that water having passed partially through the system is
disinfected.
 : The Arrow activates for 15 seconds after every 12 hours of
inactivity.
Installation Guide
Acuva systems are designed for ease of installation. The Acuva Arrow is
designed for in-line or point of use installations, with a cold-water line.
1. Find a position with access to the cold-water line feeding your desired
water fixtures and faucets for the UV device and the pre-filter to be
mounted, that will allow space for the PE tubing to be connected without
needing to bend the tube to the point where they risk pinching or folding.
2. Mount the Din-Rail that will hold the UV device with two #10 wood
screws, and the mounting clips for the pre-filter, into position.
3. To install the ½” to 3/8”OD tube reducing union with shut-o valve fitting
to the cold-water line (or a ½”x ½” x 3/8” Tee with shut-o valve fitting
if used with a dedicated drinking water faucet only), assure that the cold-
water line is not under pressure or that water flow is cut o by an
upstream shuto valve. Expect some water to drain from the cold-water
line when cut, and cut the cold-water line with a tube cutter as straight
and cleanly as possible. To fit the ½” cold-water line to the ½” end(s)
of the fitting, push the tubes into the union as far as possible and pull the
tubing outwards to create a tight seal within the fitting.
4. Attach a length of the provided 3/8” PE tubing that will connect the fitting
to the pre-filter.

Acuva Arrow UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 7
Installation Guide Cont’d
Installation Instructions Cont’d
5. To install the pre-filter, wrap the threads of the 3/8”OD – ¼” MNPT
Adapters with at least 4-5 wraps of Teflon tape and screw these adapters
into the 2 female ends of the pre-filter, connect the 3/8” PE tube from the
union into the inlet side of the pre-filter, making sure that water will flow in
the proper direction as indicated on the filter, push the tube into the
adapter as far as possible and pull the tubing outwards to assure that the
adapter is properly sealed.
6. To install the UV device, wrap 4-5 layers of Teflon tape onto the threads
of the 3/8”OD-1/4”MNPT adapters and fasten these adapters into the inlet
and outlet female ends of the UV device.
7. Snap the pre-filter to its clips and mount the UV device to the din-rail.
8. Cut a length of 3/8”PE tubing that will connect the pre-filter to the UV
device inlet and connect the tubing by pushing the tube into the adapters
as far as possible and pulling the tubing outwards to ensure a tight seal.
9. To complete the installation (If used with a dedicated drinking water
faucet, proceed to section 3.2), cut a length of 3/8” tubing and connect
to UV device outlet adapter to the second ½”-3/8”OD tube reducing
union, and connect the reducing union to the cold-water line feeding your
desired faucets and fixtures.
1. Engage the spring-loaded mechanism by hooking the clip onto the
bottom edge of the din rail and adding slight pressure upwards.
2. As bottom portion engages, tilt the upper hook towards the din rail.
3. Release the spring mechanism once the unit is mounted on the rail.
Mounting the Unit

Acuva Arrow UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 8
Installation Guide Cont’d
UV Indicator Light
No Light: Unit is not active or no power connected
Blue Light: Unit is active and sterilizing water
Blinking Red Light: Unit overheating - Allow time to cool down
Steady Red Light: Unit malfuntion - Call Acuva for support (1.604.431.9241)
Optional Smart-faucet Installation
If you have opted install the Acuva Smart Faucet with the provided 3/8” Tee
after the UV device (or with a ½”x ½” x 3/8” Tee with shut-o valve fitting
and 3/8”-1/4”OD Tube reducing union), use a short length of 3/8” tube to
connect the Tee with 3/8”-1/4”OD Tube reducing union (or for single faucet
applications, only the 3/8”-1/4”OD Tube reducing union), to connect a length
of ¼” PE tube to the drinking water faucet stem, and add the provided flow
restrictor to the ¼” line.
1. Drill a 3/4” hole into the counter top where the Smart Faucet will be
inserted.
2. Thread the faucet power cord into the 3/4” hole and insert the faucet
stem into the hole.
3. Thread the faucet power cord through the plastic spacer under the
counter to ensure that the cord is not pinched against the counter when
the faucet is fastened into place, making sure that the spacer’s O-ring
seal is facing up to seal against the counter.
4. Add the plastic threaded fastener to the faucet stem and tighten the
fastener against the spacer to secure the faucet into place. Make sure
that the faucet is positioned properly as required before tightening the
fastener.
5. To connect the ¼” water line to the faucet stem, slip the hex nut onto the
tube, followed by the plastic ferrule and plastic tube support. Press the
tube end and ferrule to the bottom of the faucet stem and tighten the hex
nut by hand, then tighten the nut with a wrench while being careful not to
over-tighten.

Acuva Arrow UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 9
Installation Guide Cont’d
Final Installation Steps
1. Connect the power supply cord to the UV chamber DC power plug.
2. Activate the cold-water pressure in the plumbing system.
3. Open the fitting valves
4. Open the downstream faucet(s) or water appliances. (When water is
flowing, the blue light on the device will come on steady which indicates
the water purification is in progress as seen in Figure 6)
5. Keep the faucet on to flush the system for 3-5 minutes to release all the
air pocket and bubbles and any loose granulated carbon form the pre-
filter and the water flows smoothly.
6. Once all the bubbles are released, turn o the faucet and the device will
automatically go into standby mode. At this point, the device is ready for
regular use.
Maintenance
The Acuva UV-LED Water Purification Systems are designed to give years
of trouble-free service. Using state-of-the-art long-life UV-LEDs, there are no
mercury bulbs to replace and dispose annually. However, there are some simple
tasks that should be performed to ensure continued trouble-free operation.
1. Check that none of the connectors are leaking annually.
2. Replace the inline 5-micron carbon filter every 2 years.
Regular Maintenance
Winterizing
WARNING
Failure to properly winterize the device before it is exposed to freezing
temperatures can lead to damage and water leakage.
To prevent freezing, pump a non-toxic antifreeze into the water system.
Open the point of use faucet connected to the Acuva device and
continue to pump non-toxic antifreeze until you see the antifreeze
coming out of the faucet. In the spring, remember to flush with fresh
water to clear the antifreeze before drinking.

Acuva Arrow UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 10
Trouble Shooting
Symptom Cause Solution
Grayish/bubbly
water
At low flow rates (1 lpm),
dissolved air may be
released into bubbles to
give a greyish color to the
water.
This is absolutely no issue with the water
quality. The bubbles will burst quickly
and water becomes clear after about 1-2
minutes.
Flashing Red
light + beeping
alarm sound
The system is over-heated
due to the high ambient/
water temperature or
excessive operation.
Turn-o the faucet and allow time for the
system to cool. Alarm sound will stop. The
flashing red light will continue until the
system cools down.
Solid Red light +
continuous alarm
sound
UV LED malfunction
detected.
Do not use the system.
Turn-o the faucet. Alarm sound will stop.
The steady red light will stay on.
Disconnect the power and reconnect
to try and clear the fault. Make sure the
power plug is properly attached to the
system.
If the red light persists, unplug the system
and contact customer service.
No Blue light
while the faucet
is open
No DC power
The minimum pressure/
flow rate required for
activating the UV system
(mentioned in section
2.2.) is not provided.
Check DC power.
Use a more powerful pump.
Check if the connection polarity is correct.
Very low flow
rate of water
The pressure in the
system is not high
enough.
The inlet and outlet
ports are connected
backwards.
A possible clog in the
water line or faucet.
Check if the pressure in the system meets
the requirements indicated in this manual.
Check if the water inlet and outlet are
properly connected to the line.
Disconnect the faucet and check for and
clear the clog.
Drips from the
device Condensation, leakage In case of extreme dripping, close the shut-o valve in the line.
Flow rate more
than the system
capacity
The flow regulator within
the system could be
damaged
Please, use a container (1-2 liters) and a
timer to measure the system’s water out-
put. In case, the flow rate is much more
than the system nominal capacity, please
contact the customer service.

Acuva Arrow UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 11
Standard Terms and Conditions
The sale and use of all Acuva products is governed by the Acuva
Technologies Inc. Standard Terms and Conditions of Sale and Use (the
“Agreement”), a copy of which is available at www.acuvatech.com.
The Agreement contains important terms that, among other things, aect
Acuva’s liability and your legal remedies against Acuva. Please read the
Agreement carefully as, by purchasing the Acuva product, you have agreed
to be bound by the entire Agreement including the limited warranty,
limitations of liability and methods of resolving disputes. In the event of any
inconsistency between this manual and the Agreement, the Agreement
shall prevail.
Warranty
As set out in the Agreement, Acuva products come with the following
limited warranty.
SCOPE AND PERIOD
Limited Warranty
Acuva warrants to you that the Product will be free from defects in
materials and workmanship under normal use for 1 year from the original
date of purchase by you (the "Warranty Period"). The limited warranty in
this Agreement (the “Limited Warranty”) is not transferable by you. All
subsequent purchasers acquire the Product "as is" without benefit of the
Limited Warranty. Where you purchased the Product from Acuva's Site
or other online vendors the date of purchase is the date of the purchase
invoice issued to you by Acuva or such online vendors by email. Where you
purchased the Product from an authorized reseller at a physical location,
the date of purchase is the date of the invoice issued to you at the physical
location.
DEFECTS
In the event Acuva determines that the Product is defective, Acuva may
in its discretion: (i) replace the defective Product with a new Product; or (ii)
refund to you the purchase price you paid for the Product. SECTION 6(b) IS
NOT APPLICABLE TO RESIDENTS OF QUEBEC.

Acuva Arrow UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 12
Warranty Cont’d
REPLACEMENT
Acuva warrants to you that the Product will be free from defects in
materials and workmanship under normal use for 1 year from the original
date of purchase by you (the "Warranty Period"). The limited warranty in
this Agreement (the “Limited Warranty”) is not transferable by you. All
subsequent purchasers acquire the Product "as is" without benefit of the
Limited Warranty. Where you purchased the Product from Acuva's Site
or other online vendors the date of purchase is the date of the purchase
invoice issued to you by Acuva or such online vendors by email. Where you
purchased the Product from an authorized reseller at a physical location,
the date of purchase is the date of the invoice issued to you at the physical
location.
DEFECTS
Where the Product is replaced during the Warranty Period, except as
otherwise prohibited by applicable laws, the warranty for the replaced
Product, as applicable, will expire upon the expiration of the original
Warranty Period. Any warranty service or support under this Limited
Warranty is conditioned upon your return of the Product to Acuva. Where
there has been a replacement of the Product, the Product, as provided
pursuant to this limited warranty, becomes your property and the Product
being replaced becomes Acuva’s property. Where there is a refund, you will
return the Product to Acuva and such Product becomes Acuva’s property.
Acuva may condition a refund or replacement on you returning the product
or require you to provide a credit card number, which will be charged only
if you fail to return the Product. SECTION 6(c) IS NOT APPLICABLE TO
RESIDENTS OF QUEBEC.
EXCLUSIONS
The limited warranty does not apply:
1. To normal wear and tear;
2. If the Product was not purchased from Acuva or its authorized retailers;
3. To damage caused by misuse, corrosion, moisture or liquids, proximity or
exposure to heat or external environment, accident, abuse, misuse,
neglect, improper installation or misapplication;
4. To physical damage to the Product;
5. To any software, whether or not supplied by Acuva.
