Genesis GEN2AIO10 User manual

GENESIS 2 O Z ONE FILTRATION
SYSTEM SER V I C E MANUAL



z

�


w
z
s
□
REVISION# 1
REVISION DATE
9 /1 7 /2020
[email protected]
watersofteners.com

Table of Contents
Application Check List and Flushing Instructions ..................................... 2
System Specifications ............................................................................... 3
Product Features and Applications .......................................................... 4
Product Dimensions and Specification .................................................... 5
Pre-installation Checklist .......................................................................... 6
Installation ................................................................................................ 7-8
Programming ............................................................................................ 9
Warranty ................................................................................................... 10
1

1. The Genesis 2 AIO system should not be used on water having an iron content above
7 ppm or 7 mg/1.
2. Free chlorine should be removed before passing water through the media.
3. The Genesis 2 AIO removes dissolved iron from water, which is present as ferrous iron.
Iron can also exist in other forms such as bacterial iron, soluble organic iron and colloidal
iron. Those forms of iron cannot be removed effectively by an Genesis 2 AIO.
4. Any sequestering agents including polyphosphates and meta-phosphate should be
added after the Genesis 2 AIO System.
5. For high iron content in feed water (> 7 ppm) it is recommended to backwash the unit
with treaded water, so as to avoid contamination of bottom portion of the bed.
6. The unit must be backwashed a specified flow rate resulting in 60% bed expansion for
effective removal of precipitated iron and suspended solids.
7. The start-up backwash and rinse prior to new service installation is critical for cleaning
media of manufacturing color, taste and any trace amine odors. We recommend 2 bed
volumes of backwash followed by 2 bed volumes of fast rinse. This timing is explained in
Schedule B.
8. The backwash frequency shall be every 12 to 24 hours for continuous operating systems.
If the unit is operating intermittently, backwash per Fe Clear recommendations in
Schedule A.
Schedule A
1 to 3 ppm Fe (Iron)
Maximum flow rate 4.0 US GPM/Ft3
Media backwash frequency: Every Three Days
4 to 6 ppm Fe (Iron)
Maximum flow rate 2.5 US GPM/Ft3
Media backwash frequency: Every Two Days
7 to 9 ppm Fe (Iron)
Maximum flow rate 2.0 US GPM/Ft3
Media backwash frequency: Daily
Schedule B
One cubic foot: Backwash is 14 minutes and fast rinse is 14 minutes.
One and one-half cubic feet: Backwash is 20 minutes and fast rinse is 20 minutes.
Two cubic feet: Backwash is 16 minutes and fast rinse is 16 minutes.
2
Application Check List and Flushing Instructions

Model*
GEN2AIO10
* Additional Sizes Available
1 - Flow Rate at 5 GPM/Cubic Foot
2 - Usage Based on Water Supply Quality; Usage ± 10%
3 - System Through-put is Based on Ferrous Iron ONLY
GEN2AIO15
Water (Gallons)
Used Per
Backwash2
Gallons Per
Backwash
< 3 PPM3
Gallons Per
Backwash
> 3 PPM3
Resin
Cubic
Feet
Overall
Height
Inches
Diameter
Inches
Flow Rate
Gallons Per
Minute1
60.9 45 75 45
59.0 47 100 60
GEN2AIO20 61.4
10
12
13
7.5
10
12.5
1
1.5
2 63 125 75
Genesis 2 AIO System Specifications
GEN2AIO25
GEN2AIO30
72.2 74 150 90
72.1 91 200 120
14
16
15
20
3
4
20 -120 PSI
1 to 5 PPM Ferrous
Control Valve Working Conditions
Transformer Input
Transformer Output
Water Pressure
Water Tempurature
Valve Wattage
120VAC - 60Hz
12VDC - 2A
24W Iron Level4
Electrical / Operational Specifications
35˚F - 125˚F
Valve Material Tank Material Meter Accuracy Clock
± 5% 12 Hour - with Battery Back-upFRPNoryl®Plastics
Additional Specifications
1-1/4˝Yes - During Regeneration2.5˝- 8NPSM
Inlet Outlet
3/4, 1˝ 3/4, 1˝
4 - For Ferric Iron and Ferous Iron Over 5 PPM, Contact PWT Technical Support
Control Valve Parameters
Base Riser Tube Hard Water BybassDrain5
1/2˝Barb
3
System Specifications

Product Features and Applications
Primary Applications
Recommended for commercial and residential softening or demineralization water treatment systems.
•Softening System Pre-Treatment
•Iron Removal System
•Ion Exchange Equipment
•Boiler Softening Water Treatment
•RO Pre-Treatment
Product Characteristics
•Mechanical Components
The Genesis 2 AIO used internal ceramic discs which are corrosion and abrasion resistant to form and hermetic
seal. Rotation of the upper disc aligns to the corresponding lower disc ports for Service, Backwash, Brine & Slow
Brine, Brine Refill and Fast Rinse modes.
•Excellent Flow Rate: Up to 20 gpm @ 15 psi drop
•365 Day Usage Memory
•Manual / Delayed Regeneration
Pressing at any time results in an immediate manual regeneration.
Pressing and holding for 3 seconds, when system is locked, results in a delayed regeneration at the
preselected time.
•Extended Power Outage Indicator
If outage exceeds 3 days, the time of day indicator " " will flash 12:12. The current time of day needs to be
re-set. All other set parameters remain stored in memory. The valve will resume to operate form the point of
the power outage.
•Three Regeneration Sequences
•Lockout Function
Keypad will lock after 5 minutes without use. To access the parameter changes press and hold and
simultaneously for 3 seconds to unlock.
•LCD Display Screen
•Maximum Day Regeneration Interval
When the valve reaches the maximum programmed service days, without reaching the set service capacity, it
will trigger a regeneration at the pre-programmed time of day. Regeneration(s) reset both the maximum day
regeneration value and the service capacity value.
•One Button to Change the Current Time
Pressing and holding the button for 3 seconds, when system is locked, allows the current time of day to be
adjusted.
•Service Alarm
When the service alarm feature counts-down and reaches set point, (Selectable 30 day min to 900 day max in
30 day increments) the alarm will activate at 8pm. The alarm will sound for 2 minutes and then shut off
automatically. To silence alarm within the 2 minute period, press any button. A service call message will then
appear on the screen as a signal for the homeowner to contact a water treatment professional for routine
service. To eliminate this message from the screen, unlock the valve programming by pressing the UP and
DOWN arrows simultaneously until the padlock in the upper left corner of the screen disappears
(approximately 3 seconds). Next, enter the programming menu by pressing the MENU/CONFIRM button once
and then pressing the BACK/REGENERATION button once. The system will then go back to normal status and
the operational days will re-start new count-down. Note: The system will operate normally when it is displaying
the service alarm message.
4

Product Dimensions and Specifications
Model Length(max) Width(max) Height (max) Regeneration Mode
Genesis 2 AIO
8.3” 8.75” 7.5”
Downflow
The valve dimensions are for reference only.
Connect Port Dimensions
Product Model Inlet Port Outlet Port Drain Port Base Riser Pipe
Genesis 2 AIO
1” NPT 1” NPT 3/4” NPT 2.5” 8NPSM 32 mm
Main Technical Parameters
Power Input 100-240VAC 50/60Hz
Power Output 12VDC @ 2A
Regeneration
Cycles
Sequence 1: Service → Backwash → Air Draw → Fast Rinse
Regeneration Mode
A-01 Meter Delay: Regeneration happens when the capacity reaches zero and the preset time of regeneration is
reached.
A-02 Meter Immediate: Regeneration happens when the capacity reaches zero.
A-03 Intelligent Meter Delay: The same delay function as A-01 but the capacity is determined by entering the total
Resin Capacity, Feed Water Hardness, and the Number of People in the household. The control valve automatically
calculates the gallons for regeneration.
A-04 Intelligent Meter Immediate: The same function as A-02 but the capacity is determined by entering the Total
Resin Capacity and Feed Water Hardness. The control valve automatically calculates the gallons for regeneration.
A-05 Remaining Compare: Compares current usage with previous 365 day daily usage to intelligently determine
when regeneration will occur. Regeneration starts at the set regeneration time.
A-06 Is Factory Default:- Do not change.
A-07 Filter Meter: Filter mode, regeneration occurs when the capacity reaches zero and the preset time for
regeneration is reached.
5

• All plumbing and electrical work should be performed by an accredited professional to ensure all
federal, state, local and municipal regulations are met.
• Do not use the system with water that is microbiologically unsafe or of unknown quality without
adequate disinfection before or after the system.
• When there is moderate to high turbidity, a filter should be installed before the water softening
system on the inlet side.
• If the water pressure exceeds 120psi, a pressure reducing valve must be installed before the
water inlet. If the water pressure exceeds 80 psi, installing a pressure reducing valve before the
water inlet is highly recommended. If the water pressure is under 20 psi, a booster pump must
be installed before the water inlet.
•Replacement parts for the Genesis 2 AIO valve should only be purchased through Discount Water
Softeners resellers. Electrical transformers are specific to the Genesis 2 AIO valve from Discount
Water Softeners.
•Regular interval monitoring of the water quality and work environment is recommended to
ensure proper operation of the valve system.
•Any modifications the Discount Water Softeners equipment, which is outside the standard scope
of supply, voids the product warranty.
•Discount Water Softeners equipment, like all modern electronic devices, can be damaged by
electrical surges or brown outs. Every effort has been taken to harden the circuits, by design, to
protect against such events. These precautions, or even additional surge protection, are not
100% effective. Therefore, equipment damage caused by abnormal electrical events is not
covered by warranty.
•Complete system must be protected from outdoor elements such as rain, moisture and direct
sunlight. Failure to do so voids warranty.
***Failure to use this product within the described conditions may void the warranty***
Pre-Installation Check List
Before installation, read through this manual thoroughly. Then obtain all materials and tools needed for installation.
This system will operate at maximum efficiency when the following conditions are considered.
Required Genesis 2 AIO Operation Conditions:
Working Conditions Working pressure 20psi - 120psi
Water temperature 35 °F - 125 °F
Working Environment
Environment temperature 35 °F - 125 °F
Relative humidity ≤95%
Power source 100 - 240VAC 50/60Hz
Inlet Water Quality
Turbidity 2FTU
Chlorine
Iron2+
0.1 mg/l or less
7 mg/l MAX
/ Iron3+
6

Installation
Installation Notice
•Before installation, read through this manual thoroughly and obtain all materials and tools needed
for installation.
•All plumbing and electrical work should be performed by an accredited professional to ensure all
federal, state, local and municipal guidelines are met.
Unit Location
• The filter should be located close to the floor drain away from direct sunlight and any heat sources.
• Protect equipment form direct sunlight and precipitation exposure.
• Install equipment in a location safe from unauthorized access or vandalism.
• Ensure that the unit is installed with enough space for operation and maintenance.
• The installation surface should be clean and level.
•Install the unit in an environment which minimizes consumer risk of loss in the event of malfunction.
• Discount Water Softeners offers many different product for many different applications, for both indoor
and outdoor environments. If you are not 100% sure the equipment purchase is suitable for the
installation application or environment, please check with a Discount Water Softeners representative, or
your local equipment provider, to ensure the proper equipment is selected. Equipment installed in
inappropriate applications or environment are not covered by warranty.
Plumbing and Mechanical Setup
Note:
1) If making a soldered copper installation, all sweat soldering should be done before connecting pipes
to the valve. Torch heat will damage plastic parts.
2) When turning threaded pipe fittings onto plastic fitting, take precaution not to cross thread or over
tighten.
Control Valve Installation
• As Figure 1-1 shows; insert a 32mm riser pipe with bottom basket
into the center of the mineral tank. If pipe is higher than the tip of
the pressure tank, mark it, remove from tank, and cut. Take care to
keep foreign material out of pressure tank. Note: The length of the
riser pipe should be below tank flange. The distance from the top of
the tank to the top of the pipe should be between 3/16" and 1/4".
The edges of the pipe should not be sharp to avoid damage to the
seal inside the Genesis 2 AIO valve.
• Install Valve Base O-ring around the neck of the valve.
• Lubricate the center hub O-ring of the Genesis 2 AIO valve.
• Install the top basket with a twist and lock action to center hub of
the Genesis 2 AIO valve.
• Place Genesis 2 AIO valve onto tank with the distribution pipe
inserted down the middle of the top basket. Rotate clockwise to
secure onto the tank. Do not overtighten! Overtightening may cause
the valve to crack and void the warranty. Figure 1-1
7

Installation- Continued
Ceramic Bypasses
Part Number 41205
Ceramic Bypass
8

Programming: Display and Instructions
Programming Instructions
Manual / Delayed Regeneration
Pressing at any time results in an immediate manual regeneration.
Pressing and holding for 3 seconds, when system is locked, results in a delayed regeneration at the preselected time.
One Button to Change the Current Time
Pressing and holding the button for 3 seconds, when system is locked, allows the current time of day to be adjusted.
Unlocking the Keypad
icon indicates the buttons are locked within 5 minutes of idle use. To unlock press and hold and for 3 seconds
until the icon is off.
Enter Key
Press button to enter the basic programming mode, modify highlighted options, and return to the main menu.
Manual Regen/Esc. Key
Press at any phase during manual regeneration to advance to the next phase or press during programming to exit
to the home screen without modifying the current highlighted option.
Up and Down Arrows
or buttons are used to scroll through the various basic programming options as well as adjust values.
Programming Modes
•Basic Programming – Allows you to adjust the time values for each phase. To enter basic programming, follow the
directions below.
∗When the icon is on, press and hold both and for 3 seconds to unlock the keypad; then press to enter the
main menu; press or to highlight each option. Press to enter that option. Press or to adjust the value.
Press
to accept changes. (Press to exit back to service status)
9
