Acuva Arrow 5 User manual

Advanced UV-LED Water Purification | acuvatech.com Page 1
Acuva Arrow 5
UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Acuva Technologies Inc.
Unit 1 - 3771 North Fraser Way, Burnaby, BC. Canada V5J 5G5
Telephone: [phone] | Email: [email protected]
acuvatech.com

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 2
Congratulations on the purchase of your Arrow 5
UV-LED Water Purification System.
This is our high performance system that is ideal suited for single faucet
applications, ice-makers, and water fountain upgrades. It fits easily under
your sink in your home, cottage, RV and boat, and provides safe drinking
water that is convenient, low maintenance and environmentally friendly.
Acuva’s system takes water purification to the next level of eciency and
convenience by utilizing two well-established and proven technologies: UV
and LED. The Acuva UV-LED chamber exposes harmful microorganisms
such as bacteria to the UV dose recommended by the regulatory Standard.
Our proprietary design allows for the UV rays to be concentrated
directionally, maximizing eectiveness.
The Arrow 5 water purification system is compatible with 12V DC or 110V
or 240V AC (using power adapter) and will be active only when system is
being used for water purification. The on-demand capabilities provided by
the built-in flow sensor will activate UV-LEDs only when water is flowing
through the system, improving energy eciency and extending the life-time
of the system.
Our mission is to provide universal access to safe drinking water and we are
proud that you have chosen our solution. Enjoy the peace of mind that your
new purifier will deliver and please contact us if you have any questions.

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 3
Summary
This document is the product manual for the Arrow 5 UV-LED Water Purifier,
including safety, product specification, installation and maintenance information.
Table of Contents
Safety Information and Warnings
Warnings and Safety Precautions
Product Information
Specifications
Overview of Your Arrow Water Purifier
Installation Guide
Mounting the Unit
UV Indicator Light
Conditioning and Powering the Unit
Maintenance
Regular Maintenance
Winterizing
Standard Terms and Conditions
Warranty
Appendix: Installation Instructions
4
4
5
5
5
6
7
7
7
8
8
8
9
9
11

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 4
Safety Information and Warnings
This section contains important information regarding the safe installation
and operation of the Acuva Technologies UV-LED Water Purification
Systems (the “device”). please read carefully.
Installation or operation of the device in a manner contrary to this manual
may result in property damage or personal injury.
Acuva recommends that the device be installed by a qualified technician
and shall comply with applicable state and local regulations.
Warnings and Safety Precautions
DANGER
Do not store the device in freezing conditions.
Do not allow water to freeze in the device.
Do not use the device if damaged or dropped.
Do not submerge the device under water.
Do not connect to AC power without an AC to DC power converter; this
device uses DC only.
This product is not ignition protected. Do not install in the engine
compartment or other areas where explosive vapours may be present.
WARNING
A steady blue light on the device while water is flowing is the only
indication that the water is safe to drink. If the blue light is not ON while
the faucet is open, please check the “trouble shooting” section of this
manual.
The UV device includes fragile parts, including parts made from glass.
The device should not be dropped and must be transported/carried
with sucient care.
Install the device at an accessible and visible location for continuous
monitoring of the system status using LED indicators and/or in case of
any leakage.
CAUTION
Minor condensation may occur on the device in humid weather and
with cold water temperatures (<dew point temperature). Condensation
drip may be noticed from inside the unit.

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 5
Product Information
Specifications
Overview of Your Arrow Water Purifier
Dose Delivery >16 mj/cm
Flow Rate 5 Liter/min
Connections Water Inlet/outlet: 3/8” OD Tube
Voltage Operate between 11-16 Volts, Direct Current
Power Consumption ~60 Watts (Active), ~0.1 W (Standby)
Maximum Water Temperature 40oC
Maximum Working Pressure 100 PSI
LED Life Time 3,000 hrs (on demand)
Power Connection
Audio Jack
(Optional Smart Faucet)
Inlet
Outlet
Indicator LED

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 6
Installation Guide
Acuva systems are designed for ease of installation. Two dierent
installation scenarios are shown below for when the arrow unit is connected
to the smart faucet or any dedicated faucet () or when it’s connected to
the main faucet ()
Item No. Description
1Tee/Shut-o Valve
23/8” OD Tube
3in-line filter
4UV-LED System
5Power Plug cable
6Smart faucet cable
7Smart faucet
() Installation with Smart Faucet () Installation without Smart Faucet

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 7
Installation Guide Cont’d
Mounting the Unit
1. Engage the spring-loaded mechanism by hooking the clip onto the
bottom edge of the din rail and adding slight pressure upwards.
2. As bottom portion engages, tilt the upper hook towards the din rail.
3. Release the spring mechanism once the unit is mounted on the rail.
UV Indicator Light
No Light: Unit is not active or no power connected
Blue Light: Unit is active and sterilizing water
Green Light: At the Initial start-up, green light turns ON on the unit for 30
sec meaning the unit is properly powered and the flow switch/smart faucet
is properly plugged to the unit. The Arrow unit will perform a self clean if
the unit is powered, but not used for 12 hrs. During the self clean mode, the
green light turns on for 30 sec.
Note: If there is an issue the indicator light will turn red or yellow and the trouble shooting
table in section 5 should be consulted
Conditioning and Powering the Unit
1. Once the Device is connected to the cold waterline, allow water to flow
through the system for 1-2 minutes until the bubbles are released from
the line. During this time, make sure all the connections are tight and sealed.
2. Connect the DC power source or AC to DC power converter to the
Arrow unit
3. Turn on the faucet, a steady blue light should appear on the device
which indicates the water purification is in progress
4. Turn o the faucet and the device will automatically go into standby mode.
5. At this point, the device is ready for regular use.

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 8
Maintenance
The Acuva UV-LED Water Purification Systems are designed to give years of
trouble-free use. Using state-of-the-art UV-LEDs, there are no mercury bulbs
to replace, however there are some simple tasks that should be performed to
ensure continued trouble-free operation.
1. Check that none of the connectors are leaking annually.
2. Replace the inline 5-micron carbon filter after winterization or as per
instruction on the filter label
3. The small quartz windows inside the unit do not reach high temperatures
to encourage mineral build-up (scaling) as with UV lamp systems. As a
result, no significant scaling or loss of performance due to scaling over
time is expected.
Regular Maintenance
Winterizing
WARNING
Frozen pipes mean cracked pipes. Failure to properly winterize the
Acuva unit before it is exposed to freezing temperatures can lead to
damage and water leakage.
If installed in a Recreational Vehicle (RV) Ensure that your RV is
winterized as per your owner’s manual.
Trouble Shooting
Indicator LED State Fault Condition Comments to User
LED OFF
(Faucet Closed) No Fault -
LED OFF
(Faucet Open) Unit is not powered
or very low flow rate
If no Blue light on the unit, verify that the unit is
connected to power. If unit is indeed connected
correctly, verify that the power line is electrified
with a voltmeter. If the voltage is as expected
and the LED indicator light does not light up,
please contact Acuva for support.
In addition, the flow sensor inside the unit
requires a minimal water flow to activate the
system (<0.3 lpm), please assure there is enough
water pressure in the line to activate the system.
Red Light LED Power out of range If persists, please contact Acuva for support.
Orange Light Low input voltage Verify that the input voltage is above 11 volts, by
using a Voltmeter

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 9
Standard Terms and Conditions
The sale and use of all Acuva products is governed by the Acuva
Technologies Inc. Standard Terms and Conditions of Sale and Use (the
“Agreement”), a copy of which is available at www.acuvatech.com.
The Agreement contains important terms that, among other things, aect
Acuva’s liability and your legal remedies against Acuva. Please read
the Agreement carefully as, by purchasing the Acuva product, you have
agreed to be bound by the entire Agreement including the limited warranty,
limitations of liability and methods of resolving disputes. In the event of
any inconsistency between this manual and the Agreement, the Agreement
shall prevail.
Warranty
As set out in the Agreement, Acuva products come with the following
limited warranty.
SCOPE AND PERIOD
Limited Warranty
Acuva warrants to you that the Product will be free from defects in
materials and workmanship under normal use for 1 year from the original
date of purchase by you (the “Warranty Period”). The limited warranty
in this Agreement (the “Limited Warranty”) is not transferable by you. All
subsequent purchasers acquire the Product “as is” without benefit of the
Limited Warranty. Where you purchased the Product from Acuva’s Site
or other online vendors the date of purchase is the date of the purchase
invoice issued to you by Acuva or such online vendors by email. Where you
purchased the Product from an authorized reseller at a physical location,
the date of purchase is the date of the invoice issued to you at the physical
location.
DEFECTS
In the event Acuva determines that the Product is defective, Acuva may
in its discretion: (i) replace the defective Product with a new Product; or (ii)
refund to you the purchase price you paid for the Product. SECTION 6(b) IS
NOT APPLICABLE TO RESIDENTS OF QUEBEC.

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 10
Warranty Cont’d
REPLACEMENT
Where the Product is replaced during the Warranty Period, except as
otherwise prohibited by applicable laws, the warranty for the replaced
Product, as applicable, will expire upon the expiration of the original
Warranty Period. Any warranty service or support under this Limited
Warranty is conditioned upon your return of the Product to Acuva. Where
there has been a replacement of the Product, the Product, as provided
pursuant to this limited warranty, becomes your property and the Product
being replaced becomes Acuva’s property. Where there is a refund, you will
return the Product to Acuva and such Product becomes Acuva’s property.
Acuva may condition a refund or replacement on you returning the product
or require you to provide a credit card number, which will be charged only
if you fail to return the Product. SECTION 6(c) IS NOT APPLICABLE TO
RESIDENTS OF QUEBEC.
EXCLUSIONS
The limited warranty does not apply:
1. To normal wear and tear;
2. If the Product was not purchased from Acuva or its authorized retailers;
3. To damage caused by misuse, corrosion, moisture or liquids, proximity or
exposure to heat or external environment, accident, abuse, misuse,
neglect, improper installation or misapplication;
4. To physical damage to the Product;
5. To any software, whether or not supplied by Acuva.

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 11
Appendix: Installation Instructions
UV-LED Device Installation
1. Find an under-counter position for the UV-LED device and pre-filter to be
mounted, allowing space for the tubing to be connected without needing
to bend the tube to the point of pinching or folding.
2. Mount the Din-Rail (Item shown in the “Mounting The Unit” diagram) that
will hold the UV device with two wood screws, and the filter clips for the
pre-filter with the two remaining screws.
3. To install the ½” - ⁄” OD Tee & shuto valve (Item no.1) to the cold-water
line, assure that the cold-water line is not under pressure, that the water
pump is not powered or that water flow is cut o by an upstream shuto
valve. Expect some water to drain from the cold-water line and cut the
cold-water line with tube cutters. Insert the ½” cold-water lines to the ½”
female ends of the Tee, push the tubes into the Tee as far as possible
and pull slightly to assure that the seal is secure.
4. Attach a length of the provided ⁄” tubing (Item no.2) that will connect
the Tee to the Pre-Filter (Item no.3), insert the tube into the female end of
the Tee, and push the tube into the Tee as far as possible and pull
slightly to assure that the seal is secure.
5. To install the Pre-Filter, depending on the type of filter straight tube
adapters may be used to change the size of the tubing from ⁄” to
¼”OD and back while making sure that water will flow in the proper
direction as indicated on the filter. Push the tube into the adapter as far
as possible and pull slightly to assure that the adapter is properly sealed.
Install the provided filter clips with screws and snap the Pre-Filter into
its clips.
6. To install the UV device, mount the UV device to the din-rail as seen in
the “Mounting the Unit” figure.
8. Cut a length of ⁄” tubing that will connect the pre-filter to the UV
device inlet tube and secure the tube into the UV device inlet push-
connect fitting as far as possible and pulling slightly to ensure that their
seal is secure.
9. Cut a length of ⁄” tubing that will connect the UV device and the smart
faucet using a straight reducer adapter (⁄”- ⁄” OD), and connect the
tubing to the desired water faucet or appliance.
