Acuva Arrow 5
UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Acuva Technologies Inc.
Unit 1 - 3771 North Fraser Way, Burnaby, BC. Canada V5J 5G5
Telephone: [phone] | Email: [email protected]
acuvatech.com

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 2
Summary
This document is the product manual for the Arrow 5 UV-LED Water Purifier,
including safety, product specification, installation and maintenance information.
Table of Contents
Product Overview
Safety Information and Warnings
Warnings and Safety Precautions
Product Information
Specifications
Overview of Your Arrow 5 Water Purifier
Installation Guide
Installation Instructions
Mounting the Unit
Conditioning and Powering the Unit
Indicator Light
Maintenance
Regular Maintenance
Winterizing
Troubleshooting
Standard Terms and Conditions
Warranty
Appendix A: Faucet Installation Instructions
3
4
4
5
5
5
6
7
8
8
9
9
9
9
10
10
11
12

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 3
Product Overview
Congratulations on the purchase of your Arrow 5 UV-LED Water Purification
System. This is our high-performance system that is ideally suited for single
faucet applications, ice-makers, and water fountain upgrades. It fits easily
under your sink in your home, cottage, RV and boat, and provides safe
drinking water that is convenient, low maintenance and environmentally
friendly.
Acuva’s water disinfection systems take water purification to the next
level of eciency and convenience by utilizing two well-established and
proven technologies: UVC disinfection and UVC-LEDs. Using patented
IntensebeamTM technology, the Arrow 5 exposes harmful microorganisms
such as bacteria and other pathogens to the UV dose recommended by the
applicable standards.
The Arrow 5 water purification system is powered by 12V DC – either
directly or via 110V to 240V AC (using a power adapter). The Arrow 5
operates on-demand, meaning its internal flow sensor will activate UV-LEDs
only when water is flowing through the system, improving energy eciency
and extending the life-time of the system.
Our mission is to provide universal access to safe drinking water and we are
proud that you have chosen our solution. Enjoy the peace of mind that your
new purifier will deliver and please contact us if you have any questions.

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 4
Safety Information and Warnings
This section contains important information regarding the safe installation
and operation of the Acuva Technologies UV-LED Water Purification
Systems (the “device”). please read carefully.
Installation or operation of the device in a manner contrary to this manual
may result in property damage or personal injury.
Acuva recommends that the device be installed by a qualified technician
and shall comply with applicable state and local regulations.
Warnings and Safety Precautions
DANGER
Do not store the device in freezing conditions.
Do not allow water to freeze in the device.
Do not use the device if damaged or dropped.
Do not submerge the device under water.
Do not connect to AC power without an AC to DC power converter; this
device uses DC only.
This product is not ignition protected. Do not install in the engine
compartment or other areas where explosive vapours may be present.
WARNING
A steady blue light on the device and smart faucet (if installed) while
water is flowing is the only indication that the water is safe to drink.
If the blue light is not lit while the faucet or other dispensing point is
open, please check the “Troubleshooting” section of this manual.
The UV device includes fragile parts, including parts made from glass.
The device should not be dropped and must be transported/carried
with sucient care.
Install the device at an accessible and visible location for continuous
monitoring of the LED indicators and/or in case of any leakage.
CAUTION
Minor condensation may occur on the device in humid weather and
with cold water temperatures (less than the dew point temperature).
Condensation drips may be noticed coming from inside the unit.

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 5
Product Information
Specifications
Overview of Your Arrow 5 Water Purifier
Power Connection
Audio Jack
(Optional Smart Faucet)
Inlet
Outlet
Indicator LED
Dose Delivery >16 mJ/cm2
Flow Rate 5 L/min
Water Inlet Fitting ⅜” OD Push-to-Connect
Water Outlet Fitting ⅜” OD Push-to-Connect
Input Voltage 11-16V DC
Power Consumption (Active) Approx. 60W
Power Consumption (Standby) Approx. 0.1W
Maximum Water Temperature 40oC
Maximum Working Pressure 100 PSI
Minimum Working Pressure 40 PSI
LED Life-time 3,000 hr (on demand)
Maximum Ambient Relative Humidity 70%

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 6
Installation Guide
Acuva systems are designed for ease of installation. Two dierent
installation scenarios are shown below: when the Arrow 5 is connected to a
dedicated smart faucet () or when it’s connected to the main faucet ()
Item No. Description Quantity
1½” PEX to ¼” OD Tee/Shut-o Valve 1
2⅜” OD Tube 1
3¼” OD Tube 1
4Filter Clip 1
5In-line Filter 1
6Arrow 5 1
7Power Plug Cable 1
8Smart Faucet Cable 1
9Smart faucet 1
10 ⅜” to ¼” Reducing Union Straight 1
() Installation with Smart Faucet () Installation without Smart Faucet

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 7
Installation Guide Cont’d
Arrow 5 Installation
1. Find an under-counter position for the Arrow 5 device and pre-filter to be
mounted, allowing space for the tubing to be connected without needing
to bend the tube to the point of pinching or folding.
2. Mount the DIN-rail (shown in the “Mounting the Unit” diagram) that will
support the device with two #10 wood screw and the filter clip
(item no. 4) for the pre-filter with the two remaining screws.
3. To install the ½” PEX-3/8” OD Tee & shuto valve (item no. 1) to the cold-
water line, ensure the cold-water line is not under pressure by turning
o the water and/or cutting the flow with an upstream valve. Expect some
water to drain from the cold-water line while cutting it. Insert the ½” cold-
water lines to the ½” female ends of the Tee, pushing the tubes into the
Tee as far as possible and pulling slightly to assure that the seal is secure.
4. Cut a length of the 3/8” tubing (item no. 2) that will connect the Tee to
the pre-filter (item no. 5). Insert the tube into the 3/8” OD female end
of the Tee, pushing the tube into the Tee as far as possible, then pulling
slightly to assure that the seal is secure.
5. Connect the 3/8” tube from the Tee into the inlet side of the pre-filter
while making sure that water will flow in the proper direction as indicated
on the filter. Push the tube into the filter as far as possible and pull
slightly to ensure it is properly sealed. Snap the pre-filter into its wall-
mounted clips.
6. To install the Arrow 5 (item no. 6), mount it to the DIN-rail as seen in the
“Mounting the Unit” figure.
7. Cut a length of 3/8” tubing that will connect the pre-filter to the Arrow 5’s
inlet and push both ends of the tubing into place.
9. Cut a length of 3/8” tubing that will connect the UV device and the smart
faucet using a straight reducer adapter (item no. 10) and connect the
tubing to the desired water faucet (item no. 9) or appliance.

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 8
Installation Guide Cont’d
Mounting the Unit
1. Engage the spring-loaded mechanism of the mounting clips on the device
by hooking the clip onto the bottom edge of the DIN-rail and applying
slight pressure upwards.
2. As bottom portion engages, tilt the upper hook towards the DIN-rail.
3. Release the spring mechanism once the unit is mounted on the rail
Conditioning and Powering the Unit
1. Once the device is connected to the cold-water line, allow water to flow
through the system for 1-2 minutes until any bubbles are released from
the line. During this time, ensure all connections are tight and sealed.
2. Connect the DC power source or AC to DC power adapter to the device.
Hand-tighten the nut to the threaded jack to secure it.
3. If there is no water flow on powering up, the Acuva logo should glow
green for 30 seconds.
4. Turn on the faucet. The indicator LED will glow blue which indicates the
water purification is in progress. If the smart faucet is installed, its base
will glow blue as well.
5. Turn o the faucet and the device will automatically go into standby
mode
WARNING
Do not use a wrench or pliers to tighten the plug or power jack as
this may cause damage to the device.

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 9
No Light: The device is idle or no power is connected.
Blue Light: The device is active and sterilizing water.
Green Light: The device is undergoing its self-cleaning protocol. This 30
second protocol occurs at start up as well as after every 12 hours of idle
time and can be safely interrupted to dispense water.
Note: If there is an issue the indicator light will turn red or yellow and the trouble shooting
table in section 5 should be consulted
Maintenance
The Arrow 5 is designed to give years of trouble-free use. Acuva products
use state-of-the-art UV-LEDs, meaning there are no mercury bulbs to replace.
However, there are some simple tasks that should be performed to ensure
continued operation.
1. Check monthly that none of the connectors are leaking.
2. Replace the in-line filter after winterization or as per the instructions on
the filter label.
Note: The small quartz windows inside the Arrow unit do not reach high temperatures to
encourage mineral build-up (scaling) as with UV lamp systems. As a result, no significant
scaling or loss of performance due to scaling over time is expected.
Regular Maintenance
Winterizing
WARNING
Frozen pipes mean cracked pipes. Failure to properly winterize the
Acuva unit before it is exposed to freezing temperatures can lead to
damage and water leakage.
If the device is installed in a Recreational Vehicle (RV) ensure that the
RV is winterized as per its owner’s manual.
Installation Guide Cont’d
Indicator Light

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 10
Standard Terms and Conditions
The sale and use of all Acuva products is governed by the Acuva
Technologies Inc. Standard Terms and Conditions of Sale and Use (the
“Agreement”), a copy of which is available at www.acuvatech.com.
The Agreement contains important terms that, among other things, aect
Acuva’s liability and your legal remedies against Acuva. Please read
the Agreement carefully as, by purchasing the Acuva product, you have
agreed to be bound by the entire Agreement including the limited warranty,
limitations of liability and methods of resolving disputes. In the event of
any inconsistency between this manual and the Agreement, the Agreement
shall prevail.
Troubleshooting
Indicator LED State Fault Condition Comments to User
Off (No water flow) No Fault -
Off
(Water flow)
The unit is not powered
Verify that the unit is connected to power
and that the input voltage is within
specifications (11-16V).
The flow direction is
reversed
Ensure the inlet and outlet tubes are
connected to the respective fittings
marked “IN” and “OUT” on the device.
The flow rate is too low
The flow sensor inside the unit requires a
minimal water flow to activate the system
(approx. 0.3 Lpm). Ensure there is enough
water pressure in the line to reach this
flow.
Red UV-LED fault
Unplug and plug in the device’s power
jack. If this fault persists, contact Acuva
for support.
Yellow Blinking Low input voltage Verify that the input voltage is above 11
volts.
Blinking Red Over-Temperature Fault
Turn the device o and allow time to
for it to cool down and clear the error. If
the device repeatedly enters this state,
contact Acuva for support.

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 11
Warranty
As set out in the Agreement, Acuva products come with the following
limited warranty.
SCOPE AND PERIOD
Limited Warranty
Acuva warrants to you that the Product will be free from defects in
materials and workmanship under normal use for 1 year from the original
date of purchase by you (the “Warranty Period”). The limited warranty
in this Agreement (the “Limited Warranty”) is not transferable by you. All
subsequent purchasers acquire the Product “as is” without benefit of the
Limited Warranty. Where you purchased the Product from Acuva’s Site
or other online vendors the date of purchase is the date of the purchase
invoice issued to you by Acuva or such online vendors by email. Where you
purchased the Product from an authorized reseller at a physical location,
the date of purchase is the date of the invoice issued to you at the physical
location.
DEFECTS
In the event Acuva determines that the Product is defective, Acuva may
in its discretion: (i) replace the defective Product with a new Product; or
(ii) refund to you the purchase price you paid for the Product. ‘DEFECTS’
SECTION IS NOT APPLICABLE TO RESIDENTS OF QUEBEC.
REPLACEMENT
Where the Product is replaced during the Warranty Period, except as
otherwise prohibited by applicable laws, the warranty for the replaced
Product, as applicable, will expire upon the expiration of the original
Warranty Period. Any warranty service or support under this Limited
Warranty is conditioned upon your return of the Product to Acuva. Where
there has been a replacement of the Product, the Product, as provided
pursuant to this limited warranty, becomes your property and the Product
being replaced becomes Acuva’s property. Where there is a refund, you will
return the Product to Acuva and such Product becomes Acuva’s property.
Acuva may condition a refund or replacement on you returning the product
or require you to provide a credit card number, which will be charged
only if you fail to return the Product. ‘REPLACEMENT’ SECTION IS NOT
APPLICABLE TO RESIDENTS OF QUEBEC.

Acuva’s Arrow 5 UV-LED Water Purifier
OWNER’S PRODUCT MANUAL
Advanced UV-LED Water Purification | acuvatech.com Page 12
Appendix A: Faucet Installation Instructions
1. Drill a 3/4” hole into the counter-top where the Smart Faucet will be
inserted.
2. Thread the faucet cable into the 3/4” hole and insert the faucet stem into
the hole.
3. Thread the faucet power cord through the plastic spacer under the
counter to ensure that the cord is not pinched against the counter when
the faucet is fastened into place, making sure that the spacer’s O-ring
seal is facing up to seal against the counter.
4. Add the plastic threaded fastener to the faucet stem and tighten the
fastener against the spacer to secure the faucet into place. Make sure
that the faucet is positioned properly as required before tightening the
fastener.
5. To connect the ¼” water line to the faucet stem, slip the hex nut onto the
tube, followed by the plastic ferrule and plastic tube support. Press the
tube end and ferrule to the bottom of the faucet stem and tighten the hex
nut by hand, then tighten the nut with a wrench while being careful not to
over-tighten.
Warranty Cont’d
EXCLUSIONS
The limited warranty does not apply:
1. To normal wear and tear;
2. If the Product was not purchased from Acuva or its authorized retailers;
3. To damage caused by misuse, corrosion, moisture or liquids, proximity or
exposure to heat or external environment, accident, abuse, misuse,
neglect, improper installation or misapplication;
4. To physical damage to the Product;
5. To any software, whether or not supplied by Acuva.
