Adam Avant Garde User manual

Avant Garde
Easy Fitting Instructions
Helpful Advice Before Fitting
1. These instructions are provided in an easy to follow style. Simply follow the instructions in sequence
to fit this product.
2. Please retain all packaging until you have checked and counted all the parts and the contents of the
fixing pack against the parts list.
3. The fixing pack contains small items, which should be kept away from young children. We suggest
that you open the fixing pack and place all the contents into a container, therefore reducing the risk
of loosing any small pieces.
4. To clean the surround we advise that you use a damp cloth and buff off with a soft, dry duster. On
going care polish with a good proprietary polish. Do not spray directly on to marble surfaces.
In the unlikely event that this product has missing or damaged parts, please call our help line on
0870 224 2811 or e-mail [e-mail] for assistance or to obtain spare parts.

Tool List:
• 10mm open ended spanner
• Measuring tape
• Pencil
• Cement (If fitting a Gas Fire)
• River Sand (If fitting Gas Fire)
• Silicon adhesive for securing to the wall
• 4 x suitable plastic wall plugs
• 4 x suitable wood screws
Par ts List:
Please ensure you have all the correct parts before beginning to fit this fire suite
a) Surround front
b) Cast chair brick
c) Mantel top
d) Granite hearth
e) Fret, Ash pan cover and grate
f) Fixing Pack containing
5 x m6 nuts and bolts
5 x washers
Ash pan cover knob
2
Avant Garde

Front view
Diagram A
3
(F) Grate
(F) Ash Pan
and Fret
Rear view
Diagram B
(B) Chair Brick
Damper -
Not to be fitted
on gas fires
Bolts
(C) Surround
(A) Mantle Top

4
Assembly instructions for fitting an electric or gas fire
Positioning hearth
Diagram A
Carefully unpack the hearth part (d) and position, Ensure hearth is centralised to your fireplace
opening. If installing an electric fire, ensure you have sufficient room for the power cable of your
electric fire to run to a socket
If fitting a gas fire prepare the bedding mixture, which can be sand and cement with an accelerator
added to speed up hardening, or special hearth bedding mixture available ready mixed .Lay the
bedding mixture on the floor, ensuring sufficient depth of mixture to support the surround off the floor
about 12mm .
The hearth must be sealed directly to the bare floor so that no air can enter the flue from
under the hearth. It must not be bedded on to a carpet (applies to gas)
Assemble the chair brick
Diagram B
• Assemble chair brick part (b) to the surround part (C) using the nuts and bolts provided, Assemble
mantle top part (A) using the nuts and bolts supplied.
• Place the nut and bolt on to the screw shaft and align with pre drilled screw holes in the chair brick,
when screw is tight hand tighten nut.
• See Diagram C
Avant Garde
Screw - Hex Set
Nut and Washer
Inserts through chair
brick into surround
Diagram C

Fitting the surround
With the hearth central to the fireplace opening, place surround onto the hearth (use cardboard to
protect the hearth) mark off position of 4 fixing holes on the wall. Remove surround from the hearth,
drill and fit wall plugs
If being used for an electric fire or no fire.
The surround can now be replaced on the hearth.
When the surround is going to be used with a gas fire, your Corgi installer will require the surround
to be sealed to the wall. To ensure that air only enters the flue from the front face opening of the
surround.
This can be achieved by using a sand cement mixture behind the surround such as used to bed
down the hearth.
The outer edges of the surround sides and mantle top can also be sealed to the wall by using
silicone adhesive.
The surround is attached to the wall using suitable wood screws.
Attaching the grate and ash pan cover
Diagram D
Diagram (D)
Attach the grate by sliding into position, aligning with slot holes at the back of the hair brick. Slide the
fret cover into the side slots on the surround. Finally slide the ash pan cover into position
5
Slide the fret cover into the slots
on the surround
Place ash pan cover into place

6
Note: A CORGI registered gas fitter must be used to fit your gas fire.
Please Note If you need any further advice or any spare parts for this item, please contact our customer
service help line on 0870 224 2811 or e-mail [e-mail] for assistance.
Avant Garde
Helpline telephone number: 0870 224 2811
Helpline email address: [e-mail]
