SERIES 7Q RAID DATA SHEET
Adaptec maxCache
™3.0
Read and Write SSD Caching Solution
(Series 7Q SAS/SATA RAID Adapters 71605Q, 7805Q)
Improves Application Performance up to 25x and Reduces Latency by 25x
Product Highlights
6Gb/s throughput at each port
LP MD2 for 16 native SAS/SATA
ports (71605Q) and 8 native
SAS/SATA ports (7805Q)
Adaptec maxCache 3.0 SSD
caching support for read and fully
redundant write caching
— Allows conguration of SSD caching
pool in RAID0, RAID1, RAID1E and RAID 5
— Supports up to 8 SSDs with up to
2TB of SSD cache
Optimized disk utilization
— SSDs can be partitioned and some
of the capacity can be utilized as
separate logical drive to the host
(e.g. to boot the OS from)
Reduced capital & operating costs
— Support more users with less
hardware
— Improve quality of service with reduced
latency (25x) and accelerated IOPS
(up to 25x)
Preinstalled Adaptec Flash Module
700 (AFM-700) for Zero-Maintenance
Cache Protection with 2GB NAND ash
e Adaptec Series 7Q SAS/SATA RAID adapters,
with maxCache 3.0, deliver evolved application
acceleration benets with the industry-rst read
caching solution and support for fully redundant
SSD write caching. Adaptec’s 71605Q and 7805Q
adapters can deliver up to 25x improvement in
IOPS and 25x reduction in latency compared to
HDD-only storage arrays.
Adaptec maxCache 3.0 –
The Evolution of Performance
Adaptec maxCache 1.0 oered signicant
performance gains for read-intensive applications.
By using SSDs to cache copies of frequently
accessed (aka “hot”) data, maxCache exploits the
performance capabilities of SSDs to store/access
read data from them rather than spinning media.
e read caching function is further improved
with maxCache 3.0, with additional optimizations
to the learned-path algorithm.
Advancing the performance capabilities of SSD
caching to a broader set of application workloads,
maxCache 3.0 has evolved to support write
caching. By caching writes to a redundant SSD
cache pool (either RAID1E or RAID5), maxCache
3.0 leverages the performance and latency
capabilities of SSD technology for both read and
write workloads.
Also new to maxCache 3.0 is the inclusion of the
Optimized Disk Utilization (ODU) feature. As
SSD sizes continue to increase, monopolizing their
entire capacity as a cache-pool is becoming less
attractive. ODU allows the SSD to be partitioned
into both a cache pool and logical device. e
logical partition, unlike the cache pool, is exposed
to the operating system, and can be used to install
an OS to it or store other data that requires fast,
low-latency access.
Integration of maxCache 3.0 SSD caching tech-
nology is seamless. Adaptec Series 7Q adapters
do not require changes to storage architectures,
application soware or operating systems.
Reduction of Capital
and Operating Expenses
With the acceleration of IOPS and reduction of
latency, maxCache 3.0 allows data center and
cloud computing environments to host more
users and perform more transactions per second
using less server hardware. e reduction in
servers has a direct benet on capital expenses
for server hardware purchases, and additional
nancial benet of reducing associated operating
costs of power, cooling, and maintenance,
delivering a highly reduced total cost of ownership
(TCO) solution.
Green Solution
Series 7Q adapters include Zero-Maintenance
Cache Protection, a revolutionary advancement
that solves BBU deciencies by providing full
protection to cached data with no monitoring,
maintenance, disposal, or replacement costs.
ZMCP features 2GB of SLC based NAND ash
memory with super capacitor technology. During
a system power loss, the ash memory-based
cache protection can preserve data for years.
Advanced Data Protection
Adaptec RAID Code (ARC) delivers maximum
reliability with RAID levels 0, 1, 1E, 5, 6, 10, 50
and 60 (71605E supports RAID 0, 1, 1E and 10).
ARC also oers RAID Level Migration (the ability
to easily migrate RAID levels), Online Capacity
Expansion (expand capacity without powering
down the server), and Copyback Hot Spare
(when a failed drive has been replaced, data is
automatically copied from the hot spare back to
the restored drive).
Adaptec maxView Storage Manager
Adaptec maxView provides the powerful features
of Adaptec StorageManager™ in an HTML5 web
interface that can be viewed in standard desktop
or mobile browsers without the need for separate
soware installation.
Compatibility, Reliability, and Support
Series 7Q supports all major operating systems,
including Windows, Linux, VMware and FreeBSD.
It has been extensively tested with third-party
components to deliver the utmost in compatibility.
e cards are backed by a three year warranty
and the company’s technical support.
>
SSD2SSD1 SSD3
RAID 5
for Data Storage
Cache pool for
redundant WB
caching

PMC-Sierra, Inc.
1380 Bordeaux Dr.
Sunnyvale, CA 94089 USA
Tel: [phone]
World Wide Web: www.adaptec.com
Pre-Sales Support: US and Canada: 1 [phone] or [phone] or [email protected]
UK: [phone] or [email protected]
Australia: [phone]
Germany: [phone] or [email protected]
Singapore: [phone]
SERIES 7Q RAID DATA SHEET
Adaptec SAS/SATA Series 7Q RAID Adapter Family (71605Q, 7805Q)
© Copyright PMC-Sierra, Inc. 2013. All rights reserved. PMC, PMC-SIERRA and Adaptec are registered trademarks of PMC-Sierra, Inc. “Adaptec by PMC” is a trademark of PMC-Sierra, Inc.
Other product and company names mentioned herein may be trademarks of their respective owners. For a complete list of PMC-Sierra trademarks, see www.pmc-sierra.com/legal.
DS_maxCache3.0_041513_US Information subject to change without notice.
Adaptec RAID 71605Q 7805Q
Order Part Number 2274600-R (single) 2274300-R (single)
RAID Levels 0, 1, 1E, 5, 6, 10, 50, 60 0, 1, 1E, 5, 6, 10, 50, 60
Form Factor MD2 – Low Prole
2.535”H x 6.6”L
MD2 – Low Prole
2.535”H x 6.6”L
Ports 16 internal 8 internal
Connectors 4 SFF 8643 (int.) 2 SFF 8643 (int.)
Bus Interface 8-Lane PCIe Gen 3 8-Lane PCIe Gen 3
Processor PM8015 PM8015
Cache 1024MB 1024MB
AFM-700 ZMCP Kit Included Included
Adaptec maxCache Storage Adapters with SSD Caching and Zero-Maintenance Cache Protection (ZMCP)
Why to buy? Series 7Q RAID adapters support both SAS and SATA devices and offer maxCache 3.0 read and write SSD caching for increased IOPS
and lower latency. Ideal for I/O intensive storage applications, NAS, online transaction processing servers (OLTP), web servers, and cloud
computing applications.
Customer Needs High I/O transaction and high bandwidth processing; solutions that reduce energy consumption and maintenance costs.
maxCache 3.0 Includes 3rd generation write caching and read caching to deliver up to 25x higher IOPS and 25x lower latency than HDD-based arrays.
Zero Maintenance
Cache Protection
— Maximizes performance and extends power savings by protecting data in adapter cache without incurring monitoring, replacement
or disposal costs. ZMCP is included with Series 7Q products.
Key Software Features — Optimized Disk Utilization
— HBA Mode and Simple Volume Mode for automatic deployment
— Supports up to 256 SATA or SAS devices using SAS expanders
— Hybrid RAID 1 & 10
— Quick initialization
— Online Capacity Expansion
— Copyback Hot Spare
— Dynamic caching algorithm
— Native Command Queuing (NCQ)
— Background initialization
— Hot-plug drive support
— RAID Level Migration
— Hot spares - global, dedicated, and pooled
— Automatic/manual rebuild of hot spares
— SES and SAF-TE enclosure management
— Congurable stripe size
— S.M.A.R.T. support
— Multiple arrays per disk drive
— Dynamic sector repair
— Staggered drive spin-up
— Bootable array support
— Support for Tape Devices, Autoloaders
Management Utilities Adaptec maxView Storage Manager
— Web based GUI Management Utility
— OS Support: Windows, Linux, Solaris VMware
— Remote conguration, monitoring & notication
— Remote rmware updates
— SMI-S Support
— SMTP
ARCCONF
— Command Line Interface
— SMI-S support for VMware
Adaptec BIOS Conguration Utility (CTRL+A)
— Legacy conguration utility
— Flashable BIOS support
Adaptec uEFI BIOS Conguration Utility
— HII based conguration utility
— Flashable BIOS support
Operating Systems Microsoft Windows, Red Hat Linux, SUSE Linux, Fedora, Debian Linux, Ubuntu Linux, Sun Solaris, FreeBSD, VMware ESX.
The latest drivers are available at www.adaptec.com/support.
Physical Dimensions 2.535”H x 6.6”L (64mm x 167mm)
Operating Temperature 0°C to 50°C* (with 200 LFM airow; with ash)
Note: This Adaptec card contains a powerful RAID processor which requires adequate airow to operate reliably. Please install this card only into server
or PC chassis with recommended airow (200 LFM). * Ambient temperature measured 1” away from the RAID processor
Operating Current 7805Q: [email protected] and 1.5A@12V, 71605Q: [email protected] and 1.6A@12V measured on PCIe Gen3 systems with 6G drives
Regulatory Certication CE, FCC, UL, C-tick, VCCI, KCC, CNS
Environmental
Compliance
RoHS
MTBF 700,000 hours at 40°C (ongoing testing)
Warranty 3 years
