Adaptec P2280A User manual

USER’SGUIDE
ULTRA160 FAMILY MANAGER SET

R
Adaptec, Inc.
691 South Milpitas Boulevard
Milpitas, CA 95035
© 1999 Adaptec, Inc.
All rights reserved. Adaptec, and the Adaptec logo
are trademarks of Adaptec, Inc. which may be
registered in some jurisdictions.
Printed in Singapore
STOCK NO.: 512377-00, Rev. B RQ 11/99

R
▼ ▼ ▼ ▼ Ultra160 Family
Manager Set
for Windows NT, Windows 95/98,
Novell NetWare, and SCO UnixWare
User’s Guide

ii
Copyright
© 1999 Adaptec, Inc. All rights reserved. No part of this publication may be
reproduced, stored in a retrieval system, or transmitted in any form or by any means,
electronic, mechanical, photocopying, recording or otherwise, without the prior
written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.
Trademarks
Adaptec, the Adaptec logo, AHA, AIC, EZ-SCSI, and SCSISelect are trademarks of
Adaptec, Inc. which may be registered in some jurisdictions. Windows, Windows
95/98, and Windows NT are registered trademarks of Microsoft Corporation in the
U.S. and other countries used under license.
All other trademarks are owned by their respective owners.
Changes
The material in this document is for information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, Adaptec, Inc. assumes no liability resulting from
errors or omissions in this document, or from the use of the information contained
herein.
Adaptec reserves the right to make changes in the product design without reservation
and without notification to its users.

iii
▼ ▼ ▼ ▼ Contents
1 Introduction
Device Drivers 1-2
Adaptec Ultra160 Family Host Adapters 1-2
Requirements 1-3
2 Microsoft Windows NT Installation
Installing the Driver When Installing Windows NT 2-2
Completing a Fresh Windows NT 4.0 Installation From
Floppy Disk 2-2
Completing a Fresh Windows NT 4.0 Installation
From CD-ROM 2-3
Installing the Driver When Windows NT is Already
Installed 2-4
Updating Windows NT 4.0 2-4
Using Advanced Configuration Parameters 2-5
Using Windows NT SCSI Parameters 2-5
Using Driver-specific Parameters 2-7
Using Windows NT and the Host Adapter 2-10
Removing a Host Adapter 2-10
Swapping a Host Adapter 2-11
Troubleshooting 2-12
Problems and Solutions 2-12
Error Messages 2-13

iv
Ultra160 Family Manager Set User’s Guide
3 Microsoft Windows 95/98 Installation
DOS Drivers for CD-ROM Access 3-2
Install CD-ROM Drivers on a DOS Bootable Hard
Disk 3-2
Update Windows 95 or 98 Installation Disks 3-3
Installing the Driver When Installing
Windows 95/98 3-4
Installing the Driver When Installing Windows 95 3-4
Installing the Driver When Installing Windows 98 3-5
Installing the Driver When Windows 95/98 is
Already Installed 3-6
Updating the Driver for Windows 95 3-7
Troubleshooting 3-8
Problems and Solutions 3-8
4 Novell NetWare Installation
Installing the Driver When Installing NetWare 4-2
NetWare 3.12/3.2 4-2
NetWare 4.12/4.2 4-5
NetWare 5.0 4-6
Installing the Driver When NetWare is Already Installed 4-7
Loading the Driver at Server Bootup 4-8
Using the Load Command Line Options 4-9
adpt160m.ham Command Line Options 4-9
Bit Mask Options 4-11
Sample Load Commands 4-11
Using NetWare and the Host Adapter 4-12
Using Removable Media 4-12
Using the NetWare Tape Backup 4-13
Using a CD-ROM with NetWare 4-14
Optimizing Performance 4-15
Troubleshooting 4-16
Error Messages 4-16

v
Contents
5 UnixWare Installation
Installing the Driver When Installing UnixWare 5-2
Installing the Driver When UnixWare
is Already Installed 5-3
Back Up the Computer 5-4
Load the Package 5-4
Modify the New System File 5-5
Rebuild the UnixWare Kernel 5-6
Boot the New Kernel 5-6
Using UnixWare and the Host Adapter 5-7
Using Tunable Parameters 5-7
Using Multiple Host Adapters 5-7
Removing the Driver 5-8
Troubleshooting 5-9
Problems and Solutions 5-9
Error Messages 5-10
Index
❒

1-1
1
▼ ▼ ▼ ▼
Introduction
The Adaptec®Ultra160 Family Manager Set is a set of software
drivers and other files that enable your Adaptec Ultra160 Family
host adapter to communicate with your computer. The Adaptec
Ultra160 Family Manager Set contains drivers for the following
operating systems:
■Microsoft Windows NT®
■Microsoft Windows® 95/98
■Novell NetWare
■SCO UnixWare
The remainder of this chapter includes a table that lists all Adaptec
host adapters and device drivers that make up the Adaptec Ultra160
Family, as well as the minimum requirements needed to install the
software.
The remaining chapters are organized by operating system. Each
chapter provides instructions on how to install the driver at the
same time you install your operating system. If your operating
system is already installed, instructions on updating or installing the
driver are also included. If you have problems installing and using
the driver, refer to the Troubleshooting sections, included at the end of
each chapter.

1-2
Ultra160 Family Manager Set User’s Guide
Device Drivers
The Ultra160 Family Manager Set has one driver file for each
operating system. Use the the table below to determine the correct
driver for your operating system.
For information on how to install the driver for your SCSI adapter,
refer to the section of this User’s Guide that describes your specific
operating system.
Adaptec Ultra160 Family Host Adapters
The following Adaptec PCI-to-SCSI host adapters are collectively
referred to as the Adaptec Ultra160 Family host adapters:
Operating System Ultra160 Driver
Windows NT
adpu160m.sys
Windows 95/98
adpu160m.mpd
NetWare
adpt160m.ham
SCO UnixWare
adst21
(UnixWare 2.1x)
adst70
(UnixWare 7.01/7.1)
Host Adapter Description
AHA-3960D Dual-channel PCI-to-Ultra160
SCSI Card 39160 Dual-channel PCI-to-Ultra160
SCSI Card 29160 Single-channel PCI-to-Ultra160
SCSI Card 29160N Single-channel PCI-to-Ultra160
(Microsoft operating systems only)
AIC-7892 PCI-to-Ultra160 ASIC
AIC-7899 PCI-to-Ultra160 ASIC

1-3
Introduction
Requirements
The following are the minimum and recommended requirements
needed to install the Adaptec Ultra160 Family Manager Set:
■A PCI computer, with an installed and configured Adaptec
Ultra160 Family host adapter(s).
■An installed primary (boot) floppy disk drive. The drive must
be able to read your operating system disks. A 3.5-inch (1.44
MByte) floppy disk drive is required.
■The driver disks included with your Adaptec Ultra160 Family
Manager Set.
■An installed and configured CD-ROM drive for installing your
operating system from CD-ROM.
■The distribution software and documentation included with
your operating system.
■The User’s Guide for your host adapter.
❒

2-1
2
▼ ▼ ▼ ▼
Microsoft Windows NT
Installation
This chapter explains how to install the Adaptec Ultra160 Family
Manager Set driver
adpu160m.sys
for Windows NT. The
adpu160m.sys
driver supports all Adaptec Ultra160 Family host
adapters. Refer to the list on page 1-2.
If you are performing a first time Windows NT installation, see
Installing the Driver When Installing Windows NT on page 2-2. If
Windows NT is already installed in your system, see Installing the
Driver When Windows NT is Already Installed on page 2-4.

2-2
Ultra160 Family Manager Set User’s Guide
Installing the Driver When Installing Windows NT
The adpu160m.sys driver is not embedded on the Windows NT 4.0
installation disks (or CD-ROM) and must be added during Windows
NT installation.
Completing a Fresh Windows NT 4.0 Installation From
Floppy Disk
1
Start your system with the Windows NT Boot Disk in the
floppy disk drive.
2
When prompted, insert disk #2 in your floppy disk drive. After
a few moments you will see a blue screen. To setup Windows
NT now, press Enter.
3
Press Sto skip auto-detection of your SCSI host adapter.
4
Press Sagain to specify an additional device.
5
Press Enter to select Others; insert the Ultra160 Family
Manager Set disk for Windows in your floppy disk drive.
6
Using the arrow keys, select the following driver and press
Enter:
Adaptec Ultra160 Family PCI SCSI Controller (NT4.0)
7
To add other host adapters that are not part of the Ultra160
Family, press Sand repeat from Step 5 for each additional
adapter and insert the appropriate driver disk. The Adaptec
Ultra160 Family host adapters use the same driver; it is not
necessary to install the driver again.
8
Press Enter to continue with the Windows NT operating
system setup. Follow the instructions on-screen and in the
Windows NT documentation to complete the installation.

2-3
Microsoft Windows NT Installation
Completing a Fresh Windows NT 4.0 Installation
From CD-ROM
1
Insert the Windows NT 4.0 CD into the CD-ROM drive.
2
Start your system. Press the F6 key when you see the following
message: “Setup is inspecting your computer’s hardware
configuration...”
If you do not see this message, your system may not be setup
to boot from a CD-ROM. You will need to install from floppy
disks. See Completing a Fresh Windows NT 4.0 Installation From
Floppy Disk on page 2-2.
3
When prompted, press Sto specify an additional device.
4
Press Enter to select Others; insert the Ultra160 Family
Manager Set disk for Windows in your floppy disk drive.
5
Using the arrow keys, select the following driver and press
Enter:
Adaptec Ultra160 Family PCI SCSI Controller (NT4.0)
6
To add other host adapters that are not part of the Ultra160
Family, press Sand repeat from Step 4 for each additional
adapter and insert the appropriate driver disk. The Adaptec
Ultra160 Family host adapters use the same driver; it is not
necessary to install the driver again.
7
Press Enter to continue with the Windows NT operating
system setup. Follow the instructions on-screen and in the
Windows NT documentation to complete the installation.

2-4
Ultra160 Family Manager Set User’s Guide
Installing the Driver When Windows NT is
Already Installed
To update or install the adpu160m.sys driver if Windows NT is
already installed, follow the instructions below for the version of
Windows NT you are installing.
Updating Windows NT 4.0
1
Start Windows NT.
2
Click the Start button on the Windows NT task bar, and then
point to Settings.
3
Click the Control Panel.
4
Double-click the SCSI Adapters icon.
5
Click the Drivers tab, and then click the Add button.
6
In the Install Driver window, click the Have Disk button.
7
Insert the Ultra160 Family Manager Set disk for Windows into
drive A.
8
From the Copy Manufacturer’s File From text box, type a:\nt4,
and click OK.
9
In the Install Driver window, Click OK.
10
Click the New button when asked if you want to use the
currently installed driver(s) or install new one(s).
11
Type a:\nt4 again, and click Continue. The driver is now
installed.
12
You must restart your computer for the changes to take effect.
Click Yes to restart your computer. Click No to return to the
SCSI Adapters window.

2-5
Microsoft Windows NT Installation
Using Advanced Configuration Parameters
Advanced users may use software parameters to alter the
configuration of the Windows NT device drivers supplied by
Adaptec. All Windows NT configuration information is stored in a
data structure called the Registry. You can edit this information
through a tool called the Registry Editor.
Caution:
Do not edit your registry unless it is absolutely
necessary. If there is an error in your registry, your computer
may become nonfunctional.
Using Windows NT SCSI Parameters
Follow the instructions below to enter the registry values that affect
how the Windows NT SCSI manager interprets the generic
configuration information of SCSI device drivers. All SCSI host
adapters installed in your system are affected by the values you enter
here. A list of valid values follows:
Note:
The following value keys are case-sensitive and must
be entered exactly as shown.
■DisableTaggedQueuing — A nonzero value indicates that the
SCSI host adapter disables tagged queueing for SCSI devices.
The data type for this value is REG_SZ.
■DisableSynchronousTransfers — A nonzero value indicates
that the SCSI host adapter is not to initiate synchronous
negotiations (but it may still accept negotiations initiated by a
SCSI target). The data type for this value is REG_SZ.
■DisableDisconnects — A nonzero value indicates that targets
are not permitted to disconnect during the execution of a SCSI
command. The data type for this value is REG_DWORD.
■MaximumLogicalUnit — This can limit the scan for connected
devices on the SCSI bus. Valid values are 1 to 8. If 1 is specified,
the Windows NT SCSI manager assumes that no SCSI targets
support LUNs other than 0. Otherwise, LUNs from 0 to 8 are
scanned during system initialization. The data type for this
value is REG_DWORD.
!

2-6
Ultra160 Family Manager Set User’s Guide
■Maximum SGList — Specifies the maximum number of
Scatter/Gather elements. Valid values are 17-255. The data
type for this value is REG_DWORD.
To enter Windows NT parameters, follow these steps:
1 Select Run from the Start button.
2 Type regedt32 and press Enter.
3 Open the registry list to the following location:
\HKEY_LOCAL_MACHINE\System\CurrentControlSet\
Services\adpu160m\Parameters\Device
If the Parameters Device keys already exist, skip to Step 8
below to begin entering values. If the keys do not yet exist, you
will need to create them by continuing with Step 4.
4 Click on the adpu160m key.
5 Select Add Key from the Edit menu; Type Parameters in the
Key Name edit box. Leave the Class edit box blank.
6 Click on the Parameters key.
7 Select Add Key from the Edit menu; Type Device in the Key
Name edit box. Leave the Class edit box blank.
To specify a certain host adapter, append Device with the
number of the host adapter. For example, type Device0 for the
first host adapter, Device1 for the second, etc. If you omit the
host adapter number, the configuration information applies to
all Ultra160 Family host adapters.
8 Click on the Device key.
9 Select Add Value from the Edit menu. In the Value Name edit
box, enter one of the valid parameter values. Make sure to
enter the appropriate data type for the value. To enter
additional values, repeat Steps 8 and 9.
Note:
Changes made with the Registry Editor do not take
effect until you shut down and then restart your system.

2-7
Microsoft Windows NT Installation
Using Driver-specific Parameters
To use the Registry Editor to enter adpu160m.sys driver-specific
parameters that affect the configuration information for Adaptec
SCSI PCI device drivers, follow the instructions below. A list of valid
parameters follows:
Note:
The following parameters are case-sensitive and must
be entered exactly as shown. When entering multiple
parameters, each parameter must be separated by a space.
■/INSTRUMENTATION—enables recording of I/O statistics
and errors. If this option is not specified, instrumentation
defaults to disabled. The data type for this value is REG_SZ.
■/INSTR_ERRLOG_Z=nnn—sets the maximum number of
error log entries, if /INSTRUMENTATION is enabled.If a
number is not specified, the maximum number or error log
entries defaults to 32. Valid values are 0-128. The data type for
this value is REG_SZ.
■/MAXTAGS=nnn—specifies the tagged command queue
depth. If a number is not specified, the tagged queue depth
defaults to 128. Valid values are 1-255. The data type for this
value is REG_SZ.
■/HOTPLUG —enables Hot-Plug PCI feature. If this option is
not specified, Hot-Plug PCI feature defaults to disabled.
To enter driver-specific parameters, follow these steps:
1
Select Run from the Start button.
2
Type regedt32 and press Enter.
3
Open the registry list to the following location:
\HKEY_LOCAL_MACHINE\System\CurrentControlSet\
Services\adpu160m\Parameters\Device\DriverParameters
If the Parameters, Device, and Driver Parameters keys already
exist, skip to Step 10 below to begin entering parameters. If the
keys do not yet exist, you will need to create them by
continuing with Step 4.

2-8
Ultra160 Family Manager Set User’s Guide
4 Click on the adpu160m key.
5 Select Add Key from the Edit menu; Type Parameters in the
Key Name edit box. Leave the Class edit box blank.
6 Click on the Parameters key.
7 Select Add Key from the Edit menu; Type Device in the Key
Name edit box. Leave the Class edit box blank.
To specify a certain host adapter, append Device with the
number of the host adapter. For example, type Device0 for the
first host adapter, Device1 for the second, etc. If you omit the
host adapter number, the configuration information applies to
all Ultra160 Family host adapters.
8 Click on the Device key.
9 Select Add Value from the Edit menu; type Driver Parameters
in the Key Name edit box. Enter REG_SZ as the data type and
press Enter.
10 A String Editor text box appears. Enter valid parameters in the
text box. When entering multiple parameters, each parameter
must be separated by a space.
Note:
Changes made with the Registry Editor do not take
effect until you shut down and then restart your system.
Hot-Plug PCI is supported by the Windows NT 4.0 driver
adpu160m.sys . You will need a system that supports Hot-Plug PCI
as well as associated Hot-Plug PCI application software in order for
Hot-Plug PCI to work. Do not enable the Hot-Plug PCI feature unless
your system is Hot-Plug PCI capable and you wish to use the Hot-
Plug PCI feature.
