Adaptec VideOh! CD AVC-1100 User manual

R
VideOh! CD AVC-1100
User’s Guide
VideOh CD AVC-1100 UG Book.book Page i Friday, July 19, 2002 10:25 AM

ii
Copyright
© 2002 Adaptec, Inc. All rights reserved. No part of this publication may be
reproduced, stored in a retrieval system, or transmitted in any form or by any
means, electronic, mechanical, photocopying, recording or otherwise, without the
prior written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.
Trademarks
Adaptec, the Adaptec logo, and VideOh! are trademarks of Adaptec, Inc., which
may be registered in some jurisdictions.
Microsoft, Windows 98SE, Windows Me, Windows 2000, and Windows XP are
registered trademarks of Microsoft Corporation in the U.S. and other countries,
used under license.
Sonic and MyDVD are registered trademarks of Sonic Solutions in the U.S. and
other countries, used under license.
All other trademarks are the property of their respective owners.
Changes
The material in this document is for information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, Adaptec, Inc. assumes no liability resulting from
errors or omissions in this document, or from the use of the information contained
herein.
Adaptec reserves the right to make changes in the product design without
reservation and without notification to its users.
Disclaimer
IF THIS PRODUCT DIRECTS YOU TO COPY MATERIALS, YOU MUST HAVE
PERMISSION FROM THE COPYRIGHT OWNER OF THE MATERIALS TO AVOID
VIOLATING THE LAW WHICH COULD RESULT IN DAMAGES OR OTHER
REMEDIES.
VideOh CD AVC-1100 UG Book.book Page ii Friday, July 19, 2002 10:25 AM

iii
Adaptec Technical Support
If you have questions about installing or using your Adaptec product, check this
document first—you will find answers to most of your questions here. If you need
further assistance, use the support options listed below.
Technical Support Identification (TSID) Number
■Before contacting Technical Support, you need your unique 12-digit TSID
number. The TSID number identifies your product and support status.
■The TSID number is included on two white, bar-coded labels, like the example
below. Affix your TSID label to the printed Installation Guide.
Support Options
■Search the Adaptec Support Knowledgebase (ASK) at ask.adaptec.com for
articles, troubleshooting tips, and frequently asked questions for your product.
■For support via Email, submit your question to Adaptec's Technical Support
Specialists at ask.adaptec.com.
■ To order Adaptec products, including accessories and cables, call
[phone]. Or, you can order cables online at
www.adaptec.com/buy-cables .
Europe
■Visit our Web site at www.adaptec-europe.com.
■German and English: Search the Adaptec Support Knowledgebase (ASK) at
ask-de.adaptec.com for articles, troubleshooting tips, and frequently asked
questions for your product.
For support via e-mail, submit your question to Adaptec's Technical Support
Specialists at ask-de.adaptec.com.
■French: Search the Adaptec Support Knowledgebase (ASK) at ask-fr.adaptec.com
for articles, troubleshooting tips, and frequently asked questions for your
product.
For support via e-mail, submit your question to Adaptec's Technical Support
Specialists at ask-fr.adaptec.com.
■ To order Adaptec products, including accessories and cables, call [phone] .
Or, you can order cables online at www.adaptec.com/buy-cables.
Australia and New Zealand
■Visit our Web site at www.adaptec.com.au.
■For support via e-mail, submit your question to Adaptec's Technical Support
Specialists at ask.adaptec.com.
VideOh CD AVC-1100 UG Book.book Page iii Friday, July 19, 2002 10:25 AM

iv
Hong Kong and China
■Visit our Web site at www.adaptec.com.
■Fax Technical Support at [phone].
Singapore
■Visit our Web site at www.adaptec.com.
Japan
■Search the Adaptec Support Knowledgebase (ASK) at ask.adaptec.co.jp
■Visit our Web site at www.adaptec.co.jp.
VideOh CD AVC-1100 UG Book.book Page iv Friday, July 19, 2002 10:25 AM

v
Limited 2-Year Hardware Warranty
1. Adaptec, Inc. (“Adaptec”) warrants to the purchaser of this product that it will be free from
defects in material and workmanship for a period of two (2) years from the date of purchase.
If the product should become defective within the warranty period, Adaptec, at its option,
will repair or replace the product, or refund the purchaser’s purchase price for the product,
provided it is delivered at the purchaser’s expense to an authorized Adaptec service facility
or to Adaptec.
2. Repair or replacement parts or products will be furnished on an exchange basis and will
either be new or reconditioned. All replaced parts or products shall become the property of
Adaptec. This warranty shall not apply if the product has been damaged by accident,
misuse, abuse or as a result of unauthorized service or parts.
3. Warranty service is available to the purchaser by delivering the product during the warranty
period to an authorized Adaptec service facility or to Adaptec and providing proof of
purchase price and date. The purchaser shall bear all shipping, packing and insurance costs
and all other costs, excluding labor and parts, necessary to effectuate repair, replacement or
refund under this warranty.
4. For more information on how to obtain warranty service, write or telephone Adaptec at 691
South Milpitas Boulevard, Milpitas, CA 95035, [phone].
5. THIS LIMITED WARRANTY DOES NOT EXTEND TO ANY PRODUCT WHICH HAS
BEEN DAMAGED AS A RESULT OF ACCIDENT, MISUSE, ABUSE, OR AS A RESULT OF
UNAUTHORIZED SERVICE OR PARTS.
6. THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES WHICH NOW
OR HEREAFTER MIGHT OTHERWISE ARISE RESPECT TO THIS PRODUCT. IMPLIED
WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE AND NON-INFRINGEMENT SHALL (A) HAVE NO GREATER
DURATION THAN 2 YEARS FROM THE DATE OF PURCHASE, (B) TERMINATE
AUTOMATICALLY AT THE EXPIRATION OF SUCH PERIOD AND (C) TO THE EXTENT
PERMITTED BY LAW BE EXCLUDED. IN THE EVENT THIS PRODUCT BECOMES
DEFECTIVE DURING THE WARRANTY PERIOD, THE PURCHASER’S EXCLUSIVE
REMEDY SHALL BE REPAIR, REPLACEMENT OR REFUND AS PROVIDED ABOVE.
INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING WITHOUT LIMITATION
LOSS OF DATA, ARISING FROM BREACH OF ANY EXPRESS OR IMPLIED WARRANTY
ARE NOT THE RESPONSIBILITY OF ADAPTEC AND, TO THE EXTENT PERMITTED BY
LAW, ARE HEREBY EXCLUDED BOTH FOR PROPERTY DAMAGE, AND TO THE
EXTENT NOT UNCONSCIONABLE, FOR PERSONAL INJURY DAMAGE.
7. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES FOR CONSUMER PRODUCTS, AND SOME STATES
DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO
THE ABOVE LIMITATION OR EXCLUSIONS MAY NOT APPLY TO YOU.
8. This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
VideOh CD AVC-1100 UG Book.book Page v Friday, July 19, 2002 10:25 AM

vi
Adaptec Software License Agreement
PLEASE READ CAREFULLY: THE USE OF THIS SOFTWARE IS SUBJECT TO THE SOFTWARE
LICENSE TERMS OF ADAPTEC, INC. AND OTHER LICENSORS WHOSE SOFTWARE MAY
BE BUNDLED WITH THIS PRODUCT.
BY YOUR USE OF THE SOFTWARE INCLUDED WITH THIS PRODUCT YOU AGREE TO THE
LICENSE TERMS REQUIRED BY THE LICENSOR OF THAT SOFTWARE, AS SET FORTH
DURING THE INSTALLATION PROCESS. IF YOU DO NOT AGREE TO THE LICENSE
TERMS APPLICABLE TO THE SOFTWARE, YOU MAY RETURN THE ENTIRE UNUSED
PRODUCT FOR A FULL REFUND.
(1) In return for acquiring a license to use the Adaptec software, which may include software
from third party licensors and patches made available by Adaptec (“Software”), and the related
documentation, you agree to the following terms and conditions:
1. License. This Agreement grants you, the Licensee, a license to:
a. Use the Software on a single computer system, which is not intended for use by more
than one (1) user; and:
b. Make one copy of the Software in machine readable form solely for back-up purposes,
provided you reproduce Adaptec’s copyright proprietary legends as well as the
copyright and proprietary notices of any third party licensors whose software may be
incorporated. You shall not remove any copyright notices in the Software.
Notwithstanding the foregoing, the Software may be used on the home, laptop or other
secondary computer of the principal user of the Software, and an additional copy of the
Software may be made to support such use. As used in this license, the Software is “in
use” when it is either loaded into RAM or installed on a hard disk or other permanent
memory device. The Software may be “in use” on only one computer at any given time.
You agree to use the Software in compliance with all applicable laws, including
copyright laws, and that you will not copy, transmit, perform, or distribute any audio or
other content using the Software without obtaining all necessary licenses or permissions
from the owner of the content.
2. Restrictions. You may not distribute copies of the Software to others. You may not post or
otherwise make available the Software, or any portion thereof, in any form, on the Internet.
You may not use the Software in a computer service business, including in time sharing
applications. You may not create additional classes, interfaces or subpackages of any portion
of the Software. The Software contains trade secrets and, in order to protect them, you may
not decompile, reverse engineer, disassemble, or otherwise reduce the Software to a human-
perceivable form. YOU MAY NOT MODIFY, ADAPT, TRANSLATE, RENT, LEASE, LOAN,
RESELL FOR PROFIT, DISTRIBUTE, NETWORK OR CREATE DERIVATIVE WORKS
BASED UPON THE SOFTWARE OR ANY PART THEREOF.
3. Ownership of Software. As Licensee, you own the media upon which the software is
recorded or fixed, but Adaptec and its licensors retain title and ownership of the Software
recorded on the original media and all subsequent copies of the Software, regardless of the
form or media in which or on which the original and other copies may exist. This license is
not a sale of the Software or any copy.
4. Confidentiality. You agree to maintain the Software in confidence and that you will not
disclose the Software to any third party without the express written consent of Adaptec. You
further agree to take all reasonable precautions to preclude access of unauthorized persons
to the Software.
5. Term. This license is effective until January 1, 2045, unless terminated earlier. You may
terminate the license at any time by destroying the Software (including the related
documentation) together with all copies or modifications in any form. Adaptec will have the
right to terminate our license immediately if you fail to comply with any term or condition
of this Agreement. Upon any termination, including termination by you, you must destroy
the Software (including the related documentation), together with all copies or
modifications in any form.
6. Special Terms Applicable to Databases. Where a database is included with the Software, you
acknowledge that it is licensed only in connection with the use of the Software to perform
disc creation, and that the database and all data derived therefrom must be maintained in
confidence in accordance with the provisions of Section 4. This license does not grant you
any rights to distribute or disclose such database or data.
VideOh CD AVC-1100 UG Book.book Page vi Friday, July 19, 2002 10:25 AM

vii
7. Limited Warranty. Adaptec and its Licensors warrant only that the media upon which the
Software is furnished will be free from defects in material or workmanship under normal
use and service for a period of thirty (30) days from the date of delivery to you. ADAPTEC
AND ITS LICENSORS DO NOT AND CANNOT WARRANT THE PERFORMANCE OR
RESULTS YOU MAY OBTAIN BY USING THE SOFTWARE OR DOCUMENTATION.
EXCEPT FOR THE FOREGOING LIMITED WARRANTY, ADAPTEC AND ITS LICENSORS
MAKE NO WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED,
AS TO NON-INFRINGEMENT OF THIRD PARTY RIGHTS, MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow the exclusion of
implied warranties or limitations on how long an implied warranty may last, so the above
limitations may not apply to you. This warranty gives you specific legal rights and you may
also have other rights which vary from state to state.
8. The entire liability of Adaptec and its Licensors, and your exclusive remedy for a breach of
this warranty, shall be:
a. The replacement of any media not meeting the above limited warranty which is
returned to Adaptec; or:
b. if Adaptec or its distributor is unable to deliver replacement media which is free from
defects in materials or workmanship, you may terminate this Agreement by returning
the Software and your money will be refunded.
THE FOREGOING STATES THE SOLE AND EXCLUSIVE REMEDIES ADAPTEC AND
ITS LICENSORS WILL PROVIDE FOR BREACH OF WARRANTY.
9. Limitation of Liability. IN NO EVENT WILL ADAPTEC OR ITS LICENSORS BE LIABLE TO
YOU FOR ANY INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES,
INCLUDING ANY LOST PROFITS, LOST SAVINGS, OR LOSS OF DATA, EVEN IF
ADAPTEC OR A LICENSOR HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES, OR FOR ANY CLAIM BY ANY OTHER PARTY. Some states do not allow the
exclusion or limitation of special, incidental, or consequential damages, so the above
limitation or exclusion may not apply to you.
10. Export. You acknowledge that the laws and regulations of the United States and other
countries may restrict the export and re-export of the Software. You agree that you will not
export or re-export the Software or documentation in any form in violation of applicable
United States and foreign law.
11. Government Restricted Rights. The Software is subject to restricted rights as follows. If the
Software is acquired under the terms of a GSA contract: use, reproduction or disclosure is
subject to the restrictions set forth in the applicable ADP Schedule contract. If the Software is
acquired under the terms of a DoD or civilian agency contract, use, duplication or disclosure
by the Government is subject to the restrictions of this Agreement in accordance with 48
C.F.R. 12.212 of the Federal Acquisition Regulations and its successors and 48 C.F.R.
227.7202-1 of the DoD FAR Supplement and its successors.
12. General. You acknowledge that you have read this Agreement, understand it, and that by
using the Software you agree to be bound by its terms and conditions. You further agree that
it is the complete and exclusive statement of the agreement between Adaptec and you, and
supersedes any proposal or prior agreement, oral or written, and any other communication
between Adaptec and you relating to the subject matter of this Agreement. No additional or
any different terms will be enforceable against Adaptec unless Adaptec gives its express
consent, including an express waiver of the terms of this Agreement, in writing signed by an
officer of Adaptec. You assume full responsibility for the use of the Software and agree to
use the Software legally and responsibly. This Agreement shall be governed by the internal
laws of the state of California, without regard to or application of its conflicts of laws
principles, except as to copyright matters, which are covered by Federal law. This
Agreement is deemed entered into at Milpitas, California by both parties. Should any
provision of this Agreement be declared unenforceable in any jurisdiction, then such
provision shall be deemed severable from this Agreement and shall not affect the remainder
hereof. All rights in the Software not specifically granted in this Agreement are reserved by
Adaptec.
Should you have any questions concerning this Agreement, you may contact Adaptec by
writing to:
Adaptec, Inc.
Legal Department
691 South Milpitas Boulevard
Milpitas, California 95035.
VideOh CD AVC-1100 UG Book.book Page vii Friday, July 19, 2002 10:25 AM

viii
Regulatory Compliance Statements
Federal Communications Commission Radio Frequency Interference Statement
WARNING: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy, and if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. However, if this
equipment does cause interference to radio or television equipment reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
■Reorient or relocate the receiving antenna.
■Increase the separation between equipment and receiver.
■Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
■Consult the dealer or an experienced radio/television technician for help.
■Use a shielded and properly grounded I/O cable and power cable to ensure compliance of
this unit to the specified limits of the rules.
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference and (2) this device must accept
any interference received, including interference that may cause undesired operation.
European Union Compliance Statement
This Information Technology Equipment has been tested and found to comply with
EMC Directive 89/336/EEC, as amended by 92/31/EEC and 93/68/EEC, in
accordance with:
■EN55022 (1998) Emissions
■EN55024 (1998) Immunity:
– EN61000-4-2 (1998) Electrostatic discharge: ±4 kV contact, ±8 kV air
– EN61000-4-3 (1998) Radiated immunity
– EN61000-4-4 (1995) Electrical fast transients/burst: ±1 kV AC, ±0.5 kV I/O
– EN61000-4-5 (1995) Surges ±1 kV differential mode, ±2 kV common mode
– EN61000-4-6 (1996) Conducted immunity: 3 V
– EN61000-4-11 (1994) Supply dips and variation: 30% and 100%
In addition, all equipment requiring U.L. listing has been found to comply with EMC
Directive 73/23/EEC as amended by 93/68/EEC in accordance with EN60950 with
amendments A1, A2, A3, A4, A11.
Australian/New Zealand Compliance Statement
This device has been tested and found to comply with the limits for a Class B digital
device, pursuant to the Australian/New Zealand standard AS/NZS 3548 set out by
the Spectrum Management Agency.
Adaptec, Inc.
Tested to Comply
With FCC Standards
FOR HOME OR OFFICE USE
AVC-110 0
VideOh CD AVC-1100 UG Book.book Page viii Friday, July 19, 2002 10:25 AM

ix
Canadian Compliance Statement
This Class B digital apparatus meets all requirements of the Canadian Interference-
Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur
le matériel brouilleur du Canada.
Japanese Compliance (Voluntary Control Council Initiative)
This equipment complies to class B Information Technology equipment based on
VCCI (Voluntary Control Council for Interface). This equipment is designed for home
use but it may causes radio frequency interference problem if used too near to a
television or radio. Please handle it correctly per this documentation.
VideOh CD AVC-1100 UG Book.book Page ix Friday, July 19, 2002 10:25 AM

1
In this Guide
Introduction 2
What’s in the Package 3
System Requirements 3
Plugging In 4
Installing the Drivers 5
Installing the VideOh! CD Software 22
Using Your VideOh! CD 23
Using Adaptec AV Capture 24
Registering Your AVC-1100 31
Troubleshooting Your AVC-1100 31
Technical Specifications 31
VideOh CD AVC-1100 UG Book.book Page 1 Friday, July 19, 2002 10:25 AM

2
Adaptec AVC-1100 User’s Guide
Introduction
Congratulations on the purchase of your Adaptec VideOh! CD
AVC-1100. With your VideOh! CD kit, you can convert your
analog videos into digital format and create your own Video CDs
(VCDs):
■Capture your favorite video footage with your AVC-1100 and
the Adaptec AV Capture software.
■Organize and burn VCDs with Sonic®MyDVD®software,
which also helps you add backgrounds to your videos and
menus for easy navigation.
■Edit your videos with the digital video editing tool integrated
with MyDVD, if you want to add music, transitions, and titles
to your movies.
This User’s Guide tells you how to set up your VideOh! CD
hardware, and provides detailed instructions for installing and
using the VideOh! CD software.
DISCLAIMER: This product or software may be designed to assist you in reproducing materials in
which you own the copyright or have obtained permission to copy from the copyright owner.
Unless you own the copyright or have permission to copy from the copyright owner, you may
be violating copyright law and be subject to payment of damages and other remedies. If you are
uncertain about your rights you should contact your legal advisor.
VideOh CD AVC-1100 UG Book.book Page 2 Friday, July 19, 2002 10:25 AM

3
What’s in the Package
What’s in the Package
Your Adaptec VideOh! CD kit includes:
■Adaptec AVC-1100 USB video capture device
■6-foot USB cable
■6-inch L-R RCA audio Y cable
■CD, including drivers, Sonic MyDVD, and Adaptec AV Capture
software
■VideOh! CD AVC-1100 Installation Guide
System Requirements
To use your VideOh! CD kit, you need a PC-compatible computer
with:
■Intel Pentium II 400 MHz (or faster) processor (800 MHz
recommended)
■Windows®98SE, Windows Me®, Windows 2000®, or
Windows XP®
■64 MB RAM minimum (128 MB recommended)
■250 MB free disk space for applications
■450 MB free disk space per 10 minutes of captured video
■Sound card
■Available USB port
■CD-ROM drive
■CD-Recorder or DVD-Recorder for output
■Video card and monitor that support 16-bit color at 1024 x 768
resolution (24/32-bit color and higher resolution
recommended)
VideOh CD AVC-1100 UG Book.book Page 3 Friday, July 19, 2002 10:25 AM

4
Adaptec AVC-1100 User’s Guide
Plugging In
To set up your AVC-1100:
1Connect your AVC-1100 to your computer, using the 6-foot USB
cable.
Note: Adaptec highly recommends that you connect
directly to your computer, and not through a USB hub.
2If required, insert the L-R RCA audio Y cable into the Audio In
port.
Cable connects to USB
port on computer
USB port
Video In port
Audio In port
VideOh CD AVC-1100 UG Book.book Page 4 Friday, July 19, 2002 10:25 AM

5
Installing the Drivers
3Plug one end of your camcorder cable into the Audio In and
Video In ports of your AVC-1100, using the Y cable if required.
Plug the other end into your analog video device.
Note: To ensure that your videos are captured successfully,
unplug any extraneous USB devices you may have connected
to your computer.
Installing the Drivers
Before you can begin capturing video, you must install the VideOh!
CD device drivers.
Because three drivers must be installed, these instructions lead you
through the installation procedure more than once. Follow the
complete set of installation instructions provided for your
operating system to ensure that all drivers are properly installed:
■For Windows XP, see page 6.
■For Windows 2000, see page 9.
■For Windows Me, see page 14.
■For Windows 98SE, see page 18.
VideOh CD AVC-1100 UG Book.book Page 5 Friday, July 19, 2002 10:25 AM

6
Adaptec AVC-1100 User’s Guide
Windows XP
When you plug in your AVC-1100, Windows XP automatically
detects it and opens the Found New Hardware Wizard. To perform
the installation, follow the instructions provided in this section.
During the installation process, the Video Capture driver is
installed first and the Audio Capture driver is installed next. You
won’t see the Composite Device driver being installed. To ensure
that all three drivers are installed properly, follow the instructions
provided in Double-Checking Driver Installation on page 8.
To install the drivers:
1Insert the CD from your VideOh! CD kit into your CD-ROM
drive.
Note: If the VideOh! software installation screen appears,
exit this screen until driver installation is complete.
2In the Found New Hardware Wizard, select Install the software
automatically..., then click Next.
VideOh CD AVC-1100 UG Book.book Page 6 Friday, July 19, 2002 10:25 AM

7
Installing the Drivers
3Click Continue Anyway.
Windows installs the driver.
4Click Finish.
The Found New Hardware Wizard appears.
5Repeat Step 2 through Step 4 to complete the installation.
VideOh CD AVC-1100 UG Book.book Page 7 Friday, July 19, 2002 10:25 AM

8
Adaptec AVC-1100 User’s Guide
Double-Checking Driver Installation
To ensure that the driver has installed properly on your
Windows XP system:
1On your desktop, double-click My Computer, double-click
Control Panel, then double-click System. The System
Properties window opens.
2Open Device Manager, and check in three places:
■Click Imaging devices. Adaptec AVC-1100 Video Capture
should be listed.
■Click Sound, video, and game controllers. Adaptec AVC-1100
Audio Capture should be listed.
■Click Universal Serial Bus controllers. USB Composite
Device should be listed.
If any or all of these drivers don’t appear, refer to Troubleshooting
Your AVC-1100 on page 31.
Drivers
VideOh CD AVC-1100 UG Book.book Page 8 Friday, July 19, 2002 10:25 AM

9
Installing the Drivers
Windows 2000
When you plug in your AVC-1100, Windows 2000 automatically
detects it and opens the Found New Hardware Wizard. To perform
the installation, follow the instructions provided in this section.
During the installation process, the Audio Capture driver is
installed first and the Video Capture driver is installed next. You
won’t see the Composite Device driver being installed. To ensure
that all three drivers are installed properly, follow the instructions
provided in Double-Checking Driver Installation on page 13.
To install the drivers:
1Insert the CD from your VideOh! CD kit into your CD-ROM
drive.
Note: If the VideOh! software installation screen appears,
exit this screen until driver installation is complete.
2In the Found New Hardware Wizard, click Next.
VideOh CD AVC-1100 UG Book.book Page 9 Friday, July 19, 2002 10:25 AM

10
Adaptec AVC-1100 User’s Guide
3Select Search for a suitable driver..., then click Next.
4Select only CD-ROM drives, then click Next.
Windows locates a driver file.
VideOh CD AVC-1100 UG Book.book Page 10 Friday, July 19, 2002 10:25 AM

11
Installing the Drivers
5Click Next.
Note: T he drive letter for your CD-ROM may be different
than the one shown in the example above.
The Audio Capture driver file name is
avc1100a.inf . The
Video Capture driver file name is avc1100v.inf .
6Click Yes.
VideOh CD AVC-1100 UG Book.book Page 11 Friday, July 19, 2002 10:25 AM
