ADC TrueNet 1U User manual

1455459 Rev A Page 1
© 2008, ADC Telecommunications, Inc.
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1 DESCRIPTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 Selecting a Mounting Bracket Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Installing the Panel on the Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.3 Installing Vertical Cable Guides (VCGs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.4 Sliding the Drawer In and Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.5 Grounding the Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
(continued)
Content Page
1U PANEL
2U PANEL
22049-A
TrueNet®1U and 2U Fiber Panel
Installation and Cable Routing Instructions
ADCP-92-082 •Issue 2 •10/2008

ADCP-92-082 • Issue 2 • 10/2008
Page 2
© 2008, ADC Telecommunications, Inc.
2.6 Installing Adapter Packs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.7 Installing MPO Cassettes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3 CABLE CLAMP INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1 Installing a Cable Clamp for OSP Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2 Installing a Cable Clamp for MPO Trunk Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4 CABLE ROUTING PROCEDURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1 Termination and Splice Panel Procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1.1 Routing Pigtails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1.2 Routing OSP Cable, Right Side Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1.3 Routing OSP Cable, Left Side Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.1.4 Routing Pigtails and OSP Fibers in Splice Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.2 Termination Only Panel Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.2.1 Routing OSP Cable, Right Side Entry (Adapter Packs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.2.2 Routing OSP Cable, Left Side Entry (Adapter Cassettes) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.2.3 Routing OSP Cable, Left Side Entry (MPO Cassettes) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.2.4 Routing OSP Cable, Right Side Entry (MPO cassettes) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.3 MPO Termination Only Panel Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.3.1 Routing MPO Trunk Cable, Right Side Entry (MPO Adapter Packs) . . . . . . . . . . . . . . . . . . . . . . . . 24
4.3.2 Routing MPO Trunk Cable, Left Side Entry (MPO Adapter Packs) . . . . . . . . . . . . . . . . . . . . . . . . . 25
5 CUSTOMER INFORMATION AND ASSISTANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
INTRODUCTION
This manual contains descriptions and installation and cable routing instructions for the ADC
TrueNet 1U and 2U Fiber Panels.
Revision History
Related Publications
TrueNet MPO Trunk Cable Clamp Kit Instructions 92-080
Trademark Information
ADC and ADC Telecommunications are registered trademarks of ADC Telecommunications, Inc.
Content (continued) Page
ISSUE DATE REASON FOR CHANGE
1 10/2007 Original.
Title/Description ADCP Number

ADCP-92-082 • Issue 2 • 10/2008
Page 3
© 2008, ADC Telecommunications, Inc.
Admonishments
Important safety admonishments are used throughout this manual to warn of possible hazards to
persons or equipment. An admonishment identifies a possible hazard and then explains what
may happen if the hazard is not avoided. These warnings are flagged by use of the triangular
alert icon (seen below) and are listed in descending order of severity of injury or damage and
likelihood of occurrence.
1 DESCRIPTION
The TrueNet 1U and 2U Panels can accommodate up to 48 and 96 terminations, respectively.
The TrueNet 1U and 2U Panels can be configured for termination and splice or termination only
(without splice trays). Figure 1 shows the external features of a typical 1U panel.
Figure 1. TrueNet 1U Panel External Features
Danger: Danger is used to indicate the presence of a hazard that will cause severe personal
injury, death, or substantial property damage if the hazard is not avoided.
Warning: Warning is used to indicate the presence of a hazard that can cause severe personal
injury, death, or substantial property damage if the hazard is not avoided.
Caution: Caution is used to indicate the presence of a hazard that will or can cause minor
personal injury or property damage if the hazard is not avoided.
REMOVABLE REAR
COVER PROVIDES
EASY ACCESS FOR
CABLE ROUTING
AND MANAGEMENT
RADIUS LIMITERS FOR
CABLE MANAGEMENT (8)
CABLE CLIP
(1 PER SIDE)
HINGED
FRONT
COVER
DESIGNATION
LABEL (2)
COVER
LATCH
BULKHEAD
ACCOMMODATES
ADAPTER PACKS OR
MPO CASSETTES
OSP CABLE ENTRY
(EITHER SIDE)
SLIDING
TRAY
MOUNTING
BRACKET (2)
22074-A
SPLICE
TRAY LOCATION
TRAY RETAINING
CLIPS (2 PER SIDE)

ADCP-92-082 • Issue 2 • 10/2008
Page 4
© 2008, ADC Telecommunications, Inc.
Typically, these panels ship empty (without adapter packs, MPO cassettes, splice trays, or
pigtails), but they may also be ordered with any of these components already installed.The panel
accommodates adapter packs and MPO cassettes. The 1U termination and splice panel has one
splice tray. The 2U termination and splice panel has two splice trays. Figure 2 shows the
external features of a 2U panel.
Figure 2. TrueNet 2U Panel External Features
2 INSTALLATION
Installation of a TrueNet panel involves the following tasks:
1. Selecting the mounting brackets (covered in Section 2.1 on next page);
2. Installing the panel on the rack (covered in Section 2.2 on Page 6);
3. (Optional) Installing vertical cable guides (covered in Section 2.3 on Page 7);
4. (Optional) Installing adapter packs (covered in Section 2.6 on Page 11);
5. (Optional) Installing MPO cassettes (covered in Section 2.7 on Page 12);
6. Installing a cable clamp (covered in Section 3);
7. Routing cables and pigtails (covered in Section 4).
REMOVABLE REAR
COVER PROVIDES
EASY ACCESS FOR
CABLE ROUTING
AND MANAGEMENT
RADIUS LIMITERS FOR
CABLE MANAGEMENT (8)
HINGED
FRONT
COVER DESIGNATION
LABEL (2)
COVER
LATCH
BULKHEAD
ACCOMMODATES
ADAPTER PACKS OR
MPO CASSETTES
OSP CABLE ENTRY
(EITHER SIDE)
MOUNTING
BRACKET (2)
22053-A
SPLICE
TRAY LOCATION
CABLE CLIP
(2 PER SIDE)
SLIDING
TRAY
TRAY RETAINING
CLIPS (2 PER SIDE)

ADCP-92-082 • Issue 2 • 10/2008
Page 5
© 2008, ADC Telecommunications, Inc.
2.1 Selecting a Mounting Bracket Option
The 1U and 2U panels are shipped with mounting brackets configured for a 19-inch EIA/
WECO rack with a 5-inch recess. The mounting brackets can also be reconfigured for a 4-inch
rack recess. Figure 3 shows the available mounting options for both panels.
Figure 3. Selecting a Mounting Bracket Option
Warning: Never install equipment in a wet location or during a lightning storm. When
installing or modifying communication lines, disconnect lines at the network interface before
working with uninsulated lines or terminals.
22052-A
1U FIBER PANEL
2U FIBER PANEL
5 INCH RACK RECESS
POSITION (AS SHIPPED)
5 INCH RACK RECESS
POSITION (AS SHIPPED)
ROTATE BRACKET
FOR 23-INCH
RACK MOUNTING
ROTATE BRACKET
FOR 23-INCH
RACK MOUNTING

ADCP-92-082 • Issue 2 • 10/2008
Page 6
© 2008, ADC Telecommunications, Inc.
2.2 Installing the Panel on the Rack
Using 12-24 screws, secure the panel on the rack as shown in Figure 4.
Figure 4. Installing the Panel on the Rack
Note: Figure 4 shows the 1U and 2U fiber panels installed in a 19-inch rack with a 5-inch
recess.
12-24 SCREWS
(4 PLACES)
12-24 SCREWS
(4 PLACES)
22050 -A

ADCP-92-082 • Issue 2 • 10/2008
Page 7
© 2008, ADC Telecommunications, Inc.
2.3 Installing Vertical Cable Guides (VCGs)
Install the VCGs (one per side) as shown in Figure 5.
Figure 5. Installing Vertical Cable Guides
INSTALLATION
HOLES FOR VCG
6-32 SCREWS
(2 PER VCG)
(PROVIDED)
6-32 SCREWS
(2 PER VCG)
(PROVIDED)
1U FIBER PANEL
2U FIBER PANEL
VCG (2)
VCG (2)
INSTALLATION
HOLES FOR VCG
22051-A

ADCP-92-082 • Issue 2 • 10/2008
Page 8
© 2008, ADC Telecommunications, Inc.
2.4 Sliding the Drawer In and Out
The panel has a tray release button and tray retainer clips designed to ensure that the drawer is
opened carefully and remains open until work in the drawer is competed. These items look the
same and operate the same on the 1U and 2U panels.
Use the following procedure to slide the drawer in and out (2U shown):
1. To release a closed drawer, press the release button down, as shown in Figure 6, and slide
the drawer out to the first detent.
2. To free the drawer to open it fully, press in the retainer clips (one on each side) located as
shown in Figure 7. Slide the drawer out until it locks into place.
3. To release an open drawer to close it, release the retainer clips (one on each side) located
as shown in Figure 8. Slide the drawer in until it locks into the closed position.
Figure 6. Releasing Closed Drawer to Open It
PRESS BUTTON DOWN
TO PULL TRAY OUT
TO FIRST DETENT
22100-A

ADCP-92-082 • Issue 2 • 10/2008
Page 9
© 2008, ADC Telecommunications, Inc.
Figure 7. Freeing Drawer to Slide It Out Fully
Figure 8. Releasing Open Drawer to Close It
PRESS IN TRAY RETAINER
CLIPS (ONE ON EACH SIDE)
TO FULLY EXTEND TRAY
22101-A
PRESS IN TRAY RETAINER
CLIPS (ONE ON EACH SIDE)
TO SLIDE TRAY BACK
INTO PLACE
22102-A

ADCP-92-082 • Issue 2 • 10/2008
Page 10
© 2008, ADC Telecommunications, Inc.
2.5 Grounding the Panel
Each panel has two grounding locations marked with the standard grounding symbol. These
locations are on the rear cover and right side of the panel (see Figure 9). Use M4 hardware
(customer supplied) to attach at the grounding location a 2-hole lug terminal such as shown in
Figure 10.
Figure 9. Grounding Locations
(Rear View of Panel)
Figure 10. Ground Stud
GROUNDING
LOCATIONS
23126-A
23127-A
2-HOLE LUG
TERMINAL
COPPER WIRE
STRIP BACK INSULATION
PER LUG MANUFACTURER'S
RECOMMENDATION
HOLE CENTER
SPACING: 0.75 INCHES

ADCP-92-082 • Issue 2 • 10/2008
Page 11
© 2008, ADC Telecommunications, Inc.
2.6 Installing Adapter Packs
The 1U panel accommodates two adapter packs. The 2U accommodates four adapter packs.
Adapter packs are installed in the same manner for both 1U and 2U panels. Adapter packs
installed on left side of panel are angled left while adapter packs installed on right side are
angled right. Install the adapter packs as shown in Figure 11 (2U shown).
Figure 11. Installing Adapter Packs
MAKE SURE NYLATCH
PLUNGER FASTENERS
ARE PULLED OUT
INSTALL ADAPTER PACKS
IN ORIENTATION SHOWN
NYLATCH PLUNGER FASTENERSMUST BE
PULLED OUT BEFORE INSERTING THE
ADAPTER PACK INTO MOUNTING HOLES
IN PANEL
AFTER INSTALLING
ADAPTER PACK,
PUSH NYLATCH
PLUNGER FASTENERS
"IN" TO LOCK ADAPTER
PACK INTO PANEL
"OUT"
POSITION
"IN"
POSITION
21568-B
INSTALL RIGHT SIDE ADAPTER PACKS
WITH ADAPTERSANGLED TOWARD THE RIGHT
INSTALL LEFT SIDE ADAPTER
PAC KSWITH ADAPTERSANGLED
TOWARD THE LEFT

ADCP-92-082 • Issue 2 • 10/2008
Page 12
© 2008, ADC Telecommunications, Inc.
2.7 Installing MPO Cassettes
The 1U panel accommodates two MPO cassettes, the 2U accommodates four. The procedure for
the 1U and 2U is the same. To install or remove an MPO cassette, pull the Nylatch plunger
fastener out, orienting the MPO as shown in Figure 12.
Figure 12. Installing MPO Cassettes
MAKE SURE NYLATCH
PLUNGER FASTENERS
ARE PULLED OUT
INSTALL MPO CASSETTES
IN ORIENTATION SHOWN
NYLATCH PLUNGER FASTENERS MUST BE
PULLED OUT BEFORE INSERTING THE
MPO CASSETTES INTO MOUNTING HOLES
IN PANEL.
AFTER INSTALLING MPO
CASSETTE, PUSH NYLATCH
PLUNGER FASTENERS "IN" TO
LOCK CASSETTE INTO PANEL
INSTALL LEFT SIDE MPO
CASSETTES WITH ADAPTERS
ANGLED TOWARD THE LEFT
INSTALL RIGHT SIDE MPO
CASSETTES WITH ADAPTERS
ANGLED TOWARD THE RIGHT
"OUT"
POSITION
"IN"
POSITION
22059-A

ADCP-92-082 • Issue 2 • 10/2008
Page 13
© 2008, ADC Telecommunications, Inc.
3 CABLE CLAMP INSTALLATION
3.1 Installing a Cable Clamp for OSP Cable
For both termination and splice panels and termination only panels, an OSP cable must be
installed and routed. The procedure is the same regardless of the type of panel being installed.
The OSP cable can enter the panel from the left or right side of the panel (as viewed from the
rear of the panel).
Determine the direction of cable entrance and install the cable clamp as shown in the example in
Figure 13.
Figure 13. Cable Clamp Assembly for OSP Cable
PLATE
SCREW (2)
YOKE (2)
GROMMET
(SIZE DETERMINED
BY DIAMETER OF
OSP CABLE)
LEFT SIDE
OSP CABLE
ENTRANCE
RIGHT SIDE
OSP CABLE
ENTRANCE
REAR COVER
CAN BE REMOVED
TO AID IN OSP
CABLE ROUTING
SWELL
LATCH (2)
22055-A

ADCP-92-082 • Issue 2 • 10/2008
Page 14
© 2008, ADC Telecommunications, Inc.
3.2 Installing a Cable Clamp for MPO Trunk Cable
For panels with MPO adapter packs, an MPO trunk cable must be installed and routed. The
procedure is the same regardless of the type of panel being installed.
The MPO trunk cable can enter the panel from the left or right side of the panel (as viewed from
the rear of the panel).
Determine the direction of cable entrance and install the cable clamp. Some orientation
examples are shown in Figure 14.
Figure 14. Cable Clamp Assembly for MPO Trunk Cable
Note: This procedure requires use of the MPO trunk cable clamp kit, which can be
ordered from ADC using catalog # TFP-ACC002. This kit is required for routing MPO
trunk cable in panels with MPO adapter packs. This kit may also be used for routing MPO
trunk cable in panels with MPO cassettes, but the kit is not required for MPO cassette
applications.
Note: When the MPO trunk cable clamp kit is used, there are limitations on the number of
panels that can be stacked up on the rack in certain configurations. For more information,
refer to the instructions (ADCP-92-080) provided with the kit.
REAR COVER CAN BE
REMOVED TO AID IN
MPO TRUNK ROUTING
SWELL
LATCH (2)
LEFT SIDE
VERTICAL MPO
TRUNK CABLE
ENTRANCE
RIGHT SIDE
HORIZONTAL MPO
TRUNK CABLE
ENTRANCE
22179-A

ADCP-92-082 • Issue 2 • 10/2008
Page 15
© 2008, ADC Telecommunications, Inc.
4 CABLE ROUTING PROCEDURES
4.1 Termination and Splice Panel Procedures
4.1.1 Routing Pigtails
Typically, the termination and splice panel is shipped without adapter packs or pigtails and will
therefore need to be configured as required. Alternatively, the panel may have been ordered with
adapter packs pre-cabled with pigtails or with MPO cassettes already installed. If pigtails need
to be routed in the panel being installed, route the pigtails corresponding to the example shown
in Figure 15 for a right side adapter pack or Figure 16 for a left side adapter pack.
Figure 15. Routing Pigtails from Right Side (Top View)
22072-A
IF NECESSARY, PULL EACH 900 MICRON FIBER FROM
STUB END OF SUBUNIT, TO CORRECT LENGTH TO
ELIMINATE SLACK AT ADAPTER PACK.
CORRECT LENGTH AT ADAPTER PACK
FOR SPLICE TRAY ROUTING,
SEE SECTION 3.3,
“SPLICE TRAY ROUTING”
RECOMMENDED CABLE
LENGTH FROM STUB END
TO CONNECTOR IS 108 INCHES
STUB
END
SLACK LOOP AROUND OUTSIDE OF
SPLICE TRAY IS NOT REQUIRED
NOTE:

ADCP-92-082 • Issue 2 • 10/2008
Page 16
© 2008, ADC Telecommunications, Inc.
Figure 16 shows routing from the left side.
Figure 16. Routing Pigtails from Left Side (Top View)
4.1.2 Routing OSP Cable, Right Side Entry
For right side cable entry, route the OSP cable from the cable clamp position to the splice tray as
shown in Figure 17. Note that “right” is defined here from the perspective of the front of the
panel.
22061-A
CORRECT LENGTH AT ADAPTER PACK
SLACK LOOP AROUND OUTSIDE OF
SPLICE TRAY IS NOT REQUIRED
NOTE:
FOR SPLICE TRAY ROUTING,
SEE SECTION 3.3,
“SPLICE TRAY ROUTING”
STUB
END
IF NECESSARY, PULL EACH 900 MICRON FIBER FROM
STUB END OF SUBUNIT, TO CORRECT LENGTH TO
ELIMINATE SLACK AT ADAPTER PACK.
RECOMMENDED CABLE
LENGTH FROM STUB END
TO CONNECTOR IS 108 INCHES

ADCP-92-082 • Issue 2 • 10/2008
Page 17
© 2008, ADC Telecommunications, Inc.
Figure 17. Routing OSP Cable, Right Side Entry
NOTE: SLACK LOOP AROUND
OUTSIDE OF SPLICE
TRAY IS NOT REQUIRED
CONVOLUTED
TUBING (1 FT)
(PROVIDED)
CABLE CLAMP
(RIGHT SIDE ENTRY)
RECOMMENDED
BREAKOUT
LENGTH - 120 INCHES
22064-A
USE VELCRO STRAP
(PROVIDED) TO SECURE
SPLICE TRAY TO PANEL
FOR SPLICE TRAY
ROUTING, SEE
SECTION 3.2.4,
"SPLICE TRAY
ROUTING"

ADCP-92-082 • Issue 2 • 10/2008
Page 18
© 2008, ADC Telecommunications, Inc.
4.1.3 Routing OSP Cable, Left Side Entry
For left side cable entry, route the OSP cable from the cable clamp position to the splice tray as
shown in Figure 18. “Left” is defined from the front of the panel.
Figure 18. Routing OSP Cable, Left Side Entry
NOTE: SLACK LOOP AROUND
OUTSIDE OF SPLICE
TRAY IS NOT REQUIRED
CONVOLUTED
TUBING (1 FT)
(PROVIDED)
CABLE CLAMP
(RIGHT SIDE ENTRY)
22065-A
USE VELCRO STRAP
(PROVIDED) TO SECURE
SPLICE TRAY TO PANEL
FOR SPLICE TRAY
ROUTING, SEE
SECTION 3.2.4,
"SPLICE TRAY
ROUTING"
RECOMMENDED
BREAKOUT
LENGTH - 120 INCHES

ADCP-92-082 • Issue 2 • 10/2008
Page 19
© 2008, ADC Telecommunications, Inc.
4.1.4 Routing Pigtails and OSP Fibers in Splice Tray
Route the pigtail and OSP fibers in the splice tray as shown in the Figure 19.
Use Velcro to secure the splice tray to the panel.
Figure 19. Routing Pigtails and OSP Fibers in Splice Tray
Note: For location of the velcro, refer to Figure 18 on the previous page.
WWW.ADC.COM WWW.ADC.COM
OSP
BREAKOUT
SIDE
PIGTAIL
BREAKOUT
SIDE
PIGTAIL FIBERS
FROM ADAPTERS
USE LACING TO
SECURE SUBUNIT
OSP
FIBERS
PIGTAIL FIBER ROUTING
OSP FIBER ROUTING 22066-A
USE LACING TO
SECURE SUBUNIT

ADCP-92-082 • Issue 2 • 10/2008
Page 20
© 2008, ADC Telecommunications, Inc.
4.2 Termination Only Panel Procedures
4.2.1 Routing OSP Cable, Right Side Entry (Adapter Packs)
For right side cable entry in a panel with adapter packs, route the OSP cable from the cable
clamp position to the splice tray as shown in Figure 20. Note that “right” is defined here from
the perspective of the front of the panel.
Figure 20. Routing OSP Cable, Right Side Entry (Adapter Packs)
CONVOLUTED
TUBING
(PROVIDED)
OSP CABLE
TIE-DOWN
POINT
- DRAWER IN CLOSED POSITION
- TOP COVER NOT SHOWN, FOR CLARITY
- REAR COVER REMOVED
NOTE:
22068-A
RECOMMENDED
BREAKOUT
LENGTH - 60 INCHES
TIE-DOWN
POINT
APPROX. 9 INCHES
OF 900 um FIBER
EXPOSED
