Spec Sheet
Basic Structured Cabling Systems
Category 5e 110 Type Blocks
ADC’s Basic Category 5e and Category 6 Structured Cabling Systems are complete channel
solutions offering 20-year product performance warranties along with a multitude of product
choices and design options. In addition, the components of these economical systems are also
guaranteed to meet the minimum requirements of TIA 568B for Category 5e and Category 6
for dependable data transmission in any network configuration, from the switch to the network
interface.
Features:
Fits standard 110 type footprint•
Wires can be terminated with a 110 tool•
Offered in 4 or 5 pair increments•
Includes label and label holders for circuit identification•
Compliances:
Meets TIA/EIA/IEEE Category 5e performance standards•

Spec Sheet
Website: www.adc.com
FromNorthAmerica,CallTollFree:1-800-366-3891•OutsideofNorthAmerica:[phone]
Fax:[phone]•ForalistingofADC’sglobalsalesofficelocations,pleaserefertoourwebsite.
ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101
Specifications published here are current as of the date of publication of this document. Because we are continuously
improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may
verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.
views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products or features
contained herein may be covered by one or more U.S. or foreign patents. An Equal Opportunity Employer
101844AE 8/08 Revision © 2008, 2006, 2005 ADC Telecommunications, Inc. All Rights Reserved
Specifications
Environment for use: Indoors, in dry, closed room
Operating Temperature Range: -10° to 60 °C (14º to 43 ºF)
Transmission performance: ≥TIA/EIA 568-B.2 Category 5e
Number of plug insertion cycles: ≥750
Insulation Displacement Contact
Wire diameter for solid copper conductors: 22-26 AWG (0.40 to 0.65 mm)
110 Interface Resistance: ≤20mΩ
Contact Resistance: ≤1mΩ
Number of Wire Re-terminations: ≥100
Electrical Rating of Complete Assembly at 25 °C (77 ºF) and 50%RH
Ringing Voltage Rating: ≤150V AC
Current Rating: <2A
Insulation Resistance: ≥100 MΩat 500V DC
Safety Rating: UL 1863
Ordering Information
Description Catalog Number
110 Type Blocks
100 pair block – 4 pair increments ECO BLOCK 100-4L
100 pair block – 5 pair increments ECO BLOCK 100-5L
300 pair block – 4 pair increments ECO BLOCK 300-4L
300 pair block – 5 pair increments ECO BLOCK 300-5L
110 Type Block 19" Rack Mount Kits
100 pair rack mountable block with 5-Pair C-Clips with 19" Mounting Bracket with
labels and label holders
ECO-BLOCKRM-100
300 pair rack mountable block with 5-Pair C-Clips with 19" Mounting Bracket with
labels and label holders
ECO-BLOCKRM-300
Accessories
4-pair C-Clip (pack of 24pcs) ECO BLOCK-4
5-pair C-Clip (pack of 20pcs) ECO BLOCK-5
Cable Trough ECO TROUGH-L
Jumper Trough for 19" equipment rack ECO-BLOCKRMT
