ADC H2TU-C-202 Original operating instructions

HiGain
HiGain
FCC Class A Compliance
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Limited Warranty
Product warranty is determined by your service agreement. Contact your sales representative or
Customer Service for details.
Modifications
Any changes or modifications made to this device that are not expressly approved by ADC DSL
Systems, Inc. voids the user's warranty.
All wiring external to the products should follow the provisions of the current edition of the National
Electrical Code.
Standards Compliance
This equipment has been tested and verified to comply with the applicable sections of the following
safety standards:
 GR 63-CORE - Network Equipment-Building System (NEBS) Requirements
 GR 1089-CORE - Electromagnetic Compatibility and Electrical Safety
 Binational standard, UL-1950/CSA-C22.2 No. 950-95: Safety of Information Technology
Equipment
Trademark Information
ADC is a registered trademark of ADC Telecommunications, Inc. HiGain is a registered trademark of
ADC DSL Systems, Inc. Other product names mentioned in this installation guide are used for
identification purposes only and may be trademarks or registered trademarks of their respective
companies.
Copyright Information
© 2000 ADC DSL Systems, Inc. All rights reserved. Information contained in this document is company
private to ADC DSL Systems, Inc., and shall not be modified, used, copied, reproduced or disclosed in
whole or in part without the written consent of ADC.
ADC DSL Systems, Inc.
14402 Franklin Avenue
Tustin, CA 92780-7013
Tel: [phone]
Fax: [phone]
Technical Assistance
Tel: [phone]
Tel: [phone]
Fax: [phone]
DNV C ertificatio n, Inc.
REGISTERED FIRM
ISO 9001/TL 9000
H2TU-C-202 LIST 1F
TheHiGain®HDSL2 product family is the industry’s first practical implementation of
High-bit-rate Digital Subscriber Line 2 (HDSL2). When an H2TU-C line unit is used
in conjunction with a HiGain ™HDSL2 remote unit (H2TU-R), the system provides
1.552 Mbps transmission on one unconditioned copper pair over the full Carrier
Service Area (CSA) range. The CSA includes loops up to 12,000 feet of 24 AWG wire
or 9,000 feet of 26 AWG wire, including bridged taps.
FEATURES
SPECIFICATIONS
•Front-panel status LED, craft port, and
four-character status display •Payload (PL) or HiGain (HG) loopback source identification
•Ultra-low wander •Bipolar Violation Transparency (BPVT) option
•Loss of Signal (LOS)/Alarm Indication Signal
(AIS) payload alarm option •Performance Report Messaging (SPRM and NPRM)
•Grounded loop detection •Bit Error Rate (BER) alarm option
•Dual loopback commands •Power Back Off (PBON and PBOC) for
configuring power output levels
•Maintenance screens for inventory,
provisioning, troubleshooting, and
performance monitoring
•Remote provisioning through TL1, FSL, or
11-bit payload commands
Operating Temperature -40 °F to +149 °F (-40 °C to +65 °C)
Operating Humidity 5% to 95% non-condensing
HDSL2 Span Voltage 0, -185 Vdc
Mounting 220 mechanics high-density shelf
HDSL2 Line Rate 1.552 Mbps Overlapped Pulse Amplitude Modulation Transmission
with Interlocking Spectra (OPTIS)
HDSL2 Output +16.8 dBm ±0.5 dB, 135 Ωat CO side
+16.5 dBm ±0.5 dB, 135 Ωat remote side
Maximum Loop Attenuation 35 dB at 196 KHz, 135 Ω
DSX-1 Line Rate 1.544 Mbps ±200 bps
DSX-1 Line Format Alternate Mark Inversion (AMI) or Bipolar with 8-Zero Substitution (B8ZS)
DSX-1 Frame Format Extended SuperFrame (ESF), SuperFrame (SF), or Unframed (UNFR)
DSX-1 Pulse Output 6 V pk-pk, pre-equalized for 0 to 655 feet of ABAM cable
DSX-1 Input Level +1.5 to -7.5 dB DSX
INSTALLATION
To ensure proper installation of the H2TU-C, align the H2TU-C with the enclosure
slot guides and slide the unit in. When the unit is properly seated, the retaining latch
snaps closed.
POWER-UP SEQUENCE
When the H2TU-C powers up, the four-character display illuminates and reports
status messages.
If the H2TU-C is unable to communicate with the next span device, it displays various
alarm and status messages.
If the unit is able to communicate with the next span device, the following occurs:
1The Status LED flashes red, while acquiring each device in the system, and turns
steady green when the entire system is operating with no alarms. The DS1 signal
must be present.
2Thefour-characterdisplayreportsmargin(SNR)readings(shouldbe≥6dB)and
loop attenuation (should be <35 dB @196 KHz).
3Any alarm conditions that exist after the system powers up are reported on the
display. The HLU reports alarms if no DS1 signal is applied.
PROVISIONING
After installing the H2TU-C, perform these basic provisioning tasks by accessing the
HiGain HDSL2 logon screen. Refer to the onscreen Help menu for navigational aids.
1Connect a maintenance terminal to the craft port (see front-panel illustration
inside), then press + to refresh the logon screen, if necessary.
2Select the Config menu, Date and Time, then type the date and time.
3Select the Inventory menu, then type in the unit ID numbers.
4Change the settings of any system parameters, if necessary, by selecting the
Config menu, Standard Options or ADC Options.
5Once the H2TU-C is successfully installed and provisioned, access the Monitor,
Performance, or Event Log menu to clear the Performance, Alarm History, or
Event Log screens, or use Master Clear in the Config menu.
Continued
CTRL R
Þ
L
HiGain
HDSL2
H
D
S
L
2
M
O
D
E
STATUS
RS-232
DCE
L
B
K
H
2
T
U
•
C
2
0
2
XMT
BRG
D
S
X
1RCV
1F
H2TU-C-202 LIST 1F
LINE UNIT
QUICK INSTALLATION
´,-)¶0@¨
1213090
October 2, 2000
Product Catalog: 150-2402-16
CLEI: VACHVW8C
Document: 352-202-116-02
