PG-FlexPlus™FSU-571 System Controller Card – Quick Installation Guide
Page 1 of 2
The ADC® PG-FlexPlus System Controller Card manages DS0
cross-connections between T1 interface cards in the Universal
Access Platform (UAP) system.
REQUIRED EQUIPMENT
• anti-static wrist strap
• flat-head screwdriver
INSTALLING THE SYSTEM CONTROLLER
CARD
The System Controller Cards can only be installed in slots 11 and
12 of the Universal Access Platform (UAP) system.
1. Put on an anti-static wrist strap and plug it into an ESD
grounding jack on the UAP chassis. See Operating Company
practices for ESD grounding locations.
2. Remove the System Controller Card’s slot cover(s) from the
slot in which you want to install the card.
a. Loosen the thumbscrews at the top and bottom of the slot
covers.
b. Remove the slot covers.
3. Open the retaining latch on the front of the card.
4. Align the card with the card guide and carefully slide it into
the slot.
5. Simultaneously close the top and bottom ejector levers to
install the card in the slot.
6. Secure the card in the chassis by tightening the thumbscrews
with a flat-head screwdriver.
SYSTEM CONTROLLER CARD LEDS
The System Controller Card LEDs on the front of the active sys-
tem controller card indicate the overall status of the UAP. The
following table describes the system controller card LEDs. See
the figure left for location of the system controller card LEDs.
If not installing a redundant sytem controller card, the sin-
gle system controller card must be installed in slot 11.
Fail
Active
Critical
Major
Minor
Misc
ACO
ACO
Button
Craft port
(DB-9 connector)
Status
LEDs
LED Color State Description
FAIL Red
Off No failures exist on the system
controller card.
On At least one card failure exists on
the system controller card.
ACT Green
Off The system controller card is not
active.
On The system controller card is
active.
CRIT Red
Off No outstanding critical alarms exist
in the UAP.
On At least one outstanding critical
alarm exists in the UAP.
MAJ Red
Off No outstanding major alarms exist
in the UAP.
On At least one outstanding major
alarm exists in the UAP.
MIN Yel low
Off No outstanding minor alarms exist
in the UAP.
On At least one outstanding minor
alarm exists in the UAP.
MISC Yellow
Off
No outstanding miscellaneous
alarms exist in the UAP.
Miscellaneous alarms pertain to
power and fan problems and user-
configured external alarms.
On
At least one outstanding
miscellaneous alarm exists in the
UAP.
ACO Green
Off
No alarm condition exists or the
Alarm Cut-OFF (ACO) button has
not been pressed during a current
alarm condition.
On
The ACO cutoff button has been
pressed during an alarm condition;
LED remains green until there is a
status change in the critical, major,
or minor alarm.

Page 2 of 2
©Copyright 2003 ADC DSL Systems, Inc. All Rights Reserved.
ADC is a registered trademark of ADC Telecommunications, Inc. PG-FlexPlus is a
trademark of ADC DSL Systems, Inc. No right, license, or interest to such trade-
marks is granted hereunder, and you agree that you shall assert no such right,
license, or interest with respect to such trademarks. Other product names mentioned
in this document are used for identification purposes only and may be trademarks or
registered trademarks of their respective companies.
Information contained in this document is company private to ADC DSL Systems,
Inc., and shall not be modified, used, copied, reproduced or disclosed in whole or in
part without the written consent of ADC.
Contents herein are current as of the date of publication. ADC reserves the right to
change specifications at any time without notice. Information furnished by ADC is
believed to be accurate and reliable. In no event shall ADC be liable for any dam-
ages resulting from the loss of data, loss of use, or loss of profits and ADC further
disclaims any and all liability for indirect, incidental, special, consequential or other
similar damages. This disclaimer of liability applies to all products, publications
and services during and after the warranty period.
CRAFT PORT INTERFACE
Connect the UAP directly to a local Operation Support System
(OSS) terminal, using a straight-through cable from the DB-9
connector. The DB-9 connector is on the front of the active sys-
tem controller card. This connection is at 9600 baud with eight
data bits, no parity, and one stop bit.
LOGGING ON
To log on to the Craft Interface, follow these steps:
Connect a local terminal to the UAP through the DB-9 connector
on the front panel of the system controller card.
1. To enter the default user name from the LOGIN prompt, type
admin, then press .
2. To enter the default password from the Main menu, type pass-
word#1, then press .
LIMITED WARRANTY
Product warranty is determined by your service agreement.
Refer to the ADC Warranty/Software Handbook for additional
information, or contact your sales representative or Customer
Service for details.
FCC CLASS A COMPLIANCE
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protec-
tion against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harm-
ful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interfer-
ence in which case the user will be required to correct the inter-
ference at his own expense.
MODIFICATIONS
The FCC requires the user to be notified that any changes or
modifications made to this device that are not expressly approved
by ADC voids the user’s warranty.
All wiring external to the product(s) should follow the provisions
of the current edition of the National Electrical Code.
TECHNICAL SUPPORT
Technical assistance is available 24 hours a day, 7 days a week by
contacting the ADC Technical Assistance Center (TAC) at:
REVISION HISTORY
If the login is not successful, the Craft Interface displays
the Login screen again.
Password#1 is the factory-default password. If you estab-
lish a different password, you must type the new password
at a subsequent log on.
Passwords are case sensitive. The password must use at
least 6 and no more than 12 characters, and the new pass-
word MUST start with a letter.
ENTER
ENTER
Telephone: [phone]
(toll-free in the U.S. and Canada)
E-mail: [email protected]
Knowledge
Base:
http://adc.com/Knowledge_Base/
index.jsp
Web: www.adc.com
Rev Date Revisions
01 2/4/2002 Initial release
02 1/6/2003 Updated Product Support Information
PG-FlexPlus™FSU-571
System Controller Card
Quick Installation Guide
Section SCP-FSU571-020-02Q
Issued January 6, 2003
´,Sq¶8W¨
1251818
This document applies to the following products:
Model CLEI Description
FSU-571, List 2 SBPQAA9E~~ FSU-571 System
Controller Card
