ADC Adcuff+ Manual

Intended Use:
ADC®blood pressure cuffs are noninvasive blood pressure cuffs that are intended for use with manual and automated
noninvasive blood pressure measurement devices.
Contraindications:
Aneroid sphygmomanometers are contraindicated for neonate use. Do not use with neonatal cuffs or neonate patients.
Symbol Definitions:
The following symbols are associated with your ADC Adcuff+reusable cuff:
Size Chart:
Review the size chart for proper age and limb range usage.
Adcuff+Size GuideTM Marking System:
ADC’s Size Guide™Marking System assures use of correct cuff size
and proper cuff alignment (Figure 1). Printed Index and Range
markings and applicable limb range (in cm) allow easy identification
of the correct cuff size. A printed artery mark indicates the bladder
midpoint for correct cuff positioning. A convenient nylon coated TPU
hang tag (on most sizes) permits flexible use with pocket aneroid
gauges. The cuffs can also be used with palm and clock aneroids,
as well as NIBP monitors. Hook-and-loop adhesive surface provides
a snug, infinitely variable fit and is designed to withstand a minimum
of 30,000 open/close cycles.
Applying the Cuff:
Place the cuff over the bare upper arm with the artery mark positioned directly over the
brachial artery. The bottom edge of the cuff should be positioned approximately one inch
(2-3cm) above the antecubital fold. Wrap the end of the cuff NOT containing the inflation
pocket around arm snugly and smoothly and engage adhesive strips. To verify a correct fit,
check that the INDEX line falls between the two RANGE lines. (Figure 2)
ADC®AdcuffTM+
One-piece Reusable BP Cuff
Directions
for Use, Care, &
Maintenance
AMERICAN DIAGNOSTIC CORPORATION
Symbol Definition
Important Warning/Caution
Not Made With Natural Rubber Latex
Phthalate Free
Circumference Size
LATEX
Symbol Definition
Conforms to EU Standards
Authorized European Representative’s Information
Manufacturer’s Information
Temperature Limit
Humidity Limitation
°F
Cuff Size Color Limb Range (cm)
Infant Orange 9-14.8
Child Green 13-19.5
Sm Adult Royal Blue 19-27
Cuff Size Color Limb Range (cm)
Adult Navy 23-40
Lg Adult Burgundy 34-50
Thigh Brown 40-66
Left Arm
Tube
(Figure 2)
Range Lines
Index Line
Index Line
13
T
12
X
10
SA
9
C
7
I
11
A
23-40 cm
Adult - 11
TM
23-40 cm
Reusable BP Cuff
11
+
MODEL REF GTIN
1 Tube 8451-11AN-1 00634782095963
2 Tube 8451-11AN-2 00634782095970
use larger cuff
use smaller cuff
Gauge Hang Tab
Artery Mark
Tube Ports
Size Icons Hook & Loop
Closure Adhesive
(Figure 1)

Maintenance:
Cleaning and disinfection procedures must be conducted by persons trained in medical device cleaning and disinfection. If
using a germicidal or other cleaning agent, consult the manufacturer’s instructions for proper use and efficacy.
CAUTION: Use only the cleaning or germicidal cleaner agent types listed below or damage to cuff may occur.
CAUTION: Repeated reprocessing may cause degradation of device; follow inspection procedures to assure integrity of device.
CAUTION: Do not aggressively scrub cuff as damage to cuff markings and/or cuff closure integrity may occur.
Materials:
When cleaning or disinfecting, use sterile cloths, soft brush, soaking tray, and potable rinse water (softened preferred).
For low-level disinfection, use one of the following:
• Bleach-based germicidal cleaner suitable for use on healthcare equipment and capable of low-level disinfection; for
example, a 1:10 dilution of bleach (6500 ppm sodium hypochlorite) and detergent.
• Commercial wipes with 0.5% bleach and water solution or 70% isopropyl alcohol.
Reference EPA-registered disinfectants at: https://www.epa.gov/pesticide-registration/list-antimicrobial-products-registered-
epa-sterilizers.
Basic Cleaning:
Note: Do not allow liquid to enter tubing while cleaning.
1. Use a soft brush to remove visible contamination.
2. Thoroughly rinse with water.
3. Damp dry with a clean cloth and allow to air dry further if needed.
Low-Level Disinfecting:
Note: Do not allow liquid to enter tubing while disinfecting.
1. Use a soft brush to remove visible contamination.
2. Rinse with water.
3. Thoroughly saturate (spray or immerse) all surfaces of the cuff and accessories with selected cleaning agent.
4. Soft brush all surfaces. Allow a 5-minute wet contact time, or longer, if directed by the germicidal cleaner manufacturer.
Do not exceed 10 minutes of wet contact time.
5. Thoroughly rinse with water.
6. Damp dry with a clean cloth and allow to air dry further if needed.
After cleaning or disinfecting, inspect cuff for deterioration and adequate closure integrity, and inflate to assess for leaks. Do
not use the cuff if any abnormalities are found.
Environmental Conditions:
Storage temperature: -4°F to 149°F (-20°C to 65°C) Operating temperature: 32°F to 122°F (0°C to 50°C)
Storage relative humidity: 15% to 95% non-condensing Operating relative humidity: 15% to 90% non-condensing
ADC
55 Commerce Drive
Hauppauge, NY 11788
U.S.A.
Inspected & Packaged in the U.S.A.
tel: [phone]
toll free: 1-800-232-2670
fax: [phone]
www.adctoday.com
[email protected]
ADC (UK) Ltd.
Unit 6, PO14 1TH
United Kingdom
IB p/n 93-adcuffplus-00 rev 0 (2/17/2021) Printed in the U.S.A.
Implied Warranty: Any implied warranty shall be limited in dura-
tionto the terms of this warranty and in no case beyond the original
selling price (except where prohibited by law). This warranty gives
you specific legal rights and you may have other rights which vary
from state to state.
For Australian Consumers: Our goods come with guarantees that
cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and compen-
sation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does not amount to a
major failure.
Warranty:
ADC warranty service extends to the original retail purchaser only
and commences from the date of delivery. ADC warrants its prod-
ucts against defects in materials and workmanship under normal use
and service. Adcuff inflation system components (cuff, tubing, bulb,
valves, and connectors) are warranted for three years.
What Is Covered: Replacement of parts, and labor.
What Is Not Covered: Transportation charges to ADC®. Damages
caused by abuse, misuse, accident, or negligence. Incidental,
special, or consequential damages. Some states do not allow the
exclusion or limitation of incidental, special, or consequential
damages, so this limitation may not apply to you. To Obtain
Warranty Service: Send item(s) postage paid to ADC, Attn: Repair
Dept., 55 Commerce Dr., Hauppauge, NY 11788.
Please include your name and address, phone no., proof of
purchase, and a brief note explaining the problem.
