Introduction
Congratulations on your decision to
purchase the GF -815 stereo preamp-
lifier. Two channel audio is better
than ever! The new DVD Audio and
SACD formats can support a wider fre-
quency spectrum (100kHz) and great-
er dynamic range (144dB) than con-
ventional CD. The G F-
815 is designed
to capture all the fidelity that high
resolution audio has to offer, with
precision broadband components and
an ultra low noise floor. Equipped
with a phono stage, this new ADCOM
preamp hasn’t forgotten about your
legacy components. Audition the GF -
815 paired with an ADCOM power amp
and CD / DVD player and rediscover
the magic of two channel. To realize
the full potential of your new stereo
preamplifier, and before making any
connections to it, please read these
operating and installation instructions
thoroughly.
Placin the GFP-815
Unpackin the GFP-815
In the unlikely event damage has oc-
curred, notify your dealer immediate-
ly and request the name of the carrier
so a written claim to cover shipping
damages can be initiated. The right to
a claim against a public carrier can be
forfeited if the carrier is not notified
promptly in writing and if the shipping
carton and packing materials are not
available for inspection by the carrier.
Save all packing materials until the
claim has been settled.
Although the GF -815 does not gen-
erate much heat, it is good practice to
ensure the amplifier’s long-term,
trouble-free operation to provide ad-
equate ventilation for the unit. There-
fore, the GF -815 should be kept
away from external sources of heat
such as radiators and hot-air ducts.
We recommend that you exercise care
when placing components on top of
the GF -815. If you are placing a heat
producing component (such as an am-
plifier) on top of or below the GF -
815, it is recommended that you allow
at least 3 inches vertical spacing for
proper airflow.
If your system includes the use of the
phono input, you may find that pla-
cing components above or under the
GF -815 may induce hum, caused by
the proximity of their power trans-
former to the phono cables or input
jacks. If this should occur, moving the
components will usually help reduce
the hum.
The optimal performance of your new
GF -
815 will ultimately depend on the
care with which you make the connec-
tions between the amplifier, pream-
plifier and loudspeakers. All in
put and
output signal connections should be
made only with high quality, low-loss,
low capacitance cables. For recom-
mendations of the type and quality of
interconnections that are best for
your applications, consult with your
ADCOM retailer.
There are no user serviceable parts
inside. Refer all servicing to qualified
service personnel.
Safety Information
The unit must be connected to a pow-
er supply only of the type and voltage
specified on the rear panel. Connect
the component to the power outlet
only with the supplied power supply
cable or an exact equivalent. Do not
modify the supplied cable. Do not de-
feat grounding and/or polarization
provisions. The cable should be con-
nected to a 3-pin polarized wall out-
let, matching the wide blade of the
plug to the wide slot of the recepta-
cle. Do not use extension cords. Do
n
ot route the power cord where it will
be crushed, pinched, bent, exposed to
heat, or damaged in any way. ay
particular attention to the power cord
at the plug and where it exits the
back of the unit. The power cord
should be unplugged from the wall
outlet if the unit is to be left unused
for a long period of time. Immediately
stop using the component and have it
inspected and/or serviced by a quali-
fied service agency if:
If you observe these recommendations
the GF -815 will perform reliably in
any reasonable environment.
You should also pay attention to such
normal considerations as protection
from excessive dust and moisture.
Dust on the surface of the cabinet can
be easily and safely removed with a
duster such as made by Swiffer™. Fin-
ger prints can be removed with a soft
cloth dampened with a mild non-
ammonia cleaner.
• Class A line level preamp
• High resolution audio bandwidth
• 7 source audio inputs
• 2 mp3 input front and rear panel
• hono input stage (MM & MC)
• Main & Record outputs
• External remote in and loop
• Bass, treble, and balance adjust
• Front panel headphone input
• Remote control and rs-232 control
. The power suppl
y cord or plug has been
damaged;
. Objects have fallen on or liquid has
been spilled into the unit;
. The unit has been exposed to rain;
. The unit shows signs of improper
operation; or
. The unit has been dropped or damaged
Key Features
Before your new ADCO preamplifier
left our factory, it was carefully in-
spected for physical imperfections
and tested for all electrical parame-
ters as a routine part of ADCOM’s sys-
tematic quality control. This, along
with full operational and mechanical
testing, should ensure a product flaw-
less in both appearance and perfor-
mance. After you have unpacked the
GT -815, inspect it for physical dam-
age. Save the shipping carton and all
packing material as they are intended
to reduce the possibility of transpor-
tation damage should the preamplifier
ever need to be shipped again.

Description
of Unit: Front Panel
[1] Standby button
Toggles the GF -815 in and out of
Standby mode. When in standby
mode, the GF -815 is activated by
pressing either the remote control
power button or toggling the front
panel power switch. When the GFR-
815 is active, the LED indicator
in the
Standby button will illuminate.
[2] IR Sensor
This lens protects the infrared receiv-
er which receives commands from the
remote control. Note: the pathway
between the lens and remote control
must be free of obstruction for the re-
mote control to operate the GF -815.
[3] Headphones Jack
Headphones may be used through the
use of the phones output jack on the
front panel. This jack will accept a
standard 1
⁄4” stereo headphone plug.
[4-7] Source Selections
These seven buttons select the source
you desire for listening. When you se-
lect phono(1), 2, 3, 4, 5, 6 or mp3(7),
the selected source is also routed to
the record outputs. The seven source
select buttons are also available on
the remote control.
[8] Tone Button
This button is used to engage the bass
and treble controls. In the out posi-
tion, the tone controls will have no
effect.
[9] MP3 IN Jacks
Mp3 devices can be connected to the
mp3 input jack on the front pan-
el(3.5mm) or the mp3 RCA jacks on
the back panel.
[10] Bass &
Treble Knobs
The bass and treble knobs control the
bass and treble frequencies by in-
creasing or decreasing levels.
[11] Balance Knob
Balance control provides adjustment
for greater accuracy of stereo imag-
ing.
[12] Mute Button
ressing this button mutes the main
outputs. To turn the mute feature off,
press the mute button again. Note:
turning the volume knob on the front
panel will not deactivate the mute
feature.

[13] Volume Knob
The front panel volume control knob
is motorized. It may be adjusted ei-
ther by hand or with the volume but-
tons on the remote control. The point
dot on the volume knob indicates the
volume level.
Description of Unit:
Rear Panel
[14] GND Ground Post
To reduce the chance for hum con
nect
the turntable ground lead to this at-
tachment point.
[15] Source Inputs
Source 1~7 inputs (R/L) Connects to
the line outputs of a CD player or
other analog audio source compo-
nent. Up to seven analog audio
source devices can be connected.
[16] Stereo Outputs
Rec Output: Connect rec output to
the Record or Input jacks of a record-
ing device.
M in Output: A line level stereo out-
put that connects to your amplifier’s
inputs.
[17] RS232 Control
The Adcom GF -815 can be con-
trolled via the serial RS-232 port.
The serial port can be connected to
a system controller, C or ‘dumb
terminal’ via a straight through
standard 9-pin(DB9) serial port cable
(MALE on one end and FEMALE on the
other end).
[18] Ext Remote
Aremote infrared sensor can be con-
nected here.
[19] Auto turn on
A trigger, if properly hooked-up,
can
prove to be very convenient.
-in input jack use the 12V DC or AC
trigger in conjunction with another
device to turn the GFR-815 on and
off. The trigger output from the oth-
er device should go to the trigger
input on the rear panel of the GF -
815.
-loop output jack is provided to
allow trigger control of additional
components in your system.
[20] AC Input
Connects the GF -815 to a standard
electrical outlet using the supplied
power cord. Use the provided stand-
ard IEC AC cord to provide power to
the unit. The plug is a polarized type.
for electrical safety, observe proper
polarization at main out
let and do not
modify plug in any way. If it is ever
necessary, replace the fuse with a
fuse of identical type and rating for
continued protection. See “Trouble-
shooting” for more information.
Input 1 select
Sets the input level for input
source 1 to mm or mc for phono
cartridge input or line for other
analog devices.
Volta e switch (Bottom)
Sets the GF -815 voltage to 120V
(U.S. standard) or 230V (interna-
tional standard).
Main power switch
Switches the GF -815’s main pow-
er on and off.
Remote Control
The supplied remote con
trol, pictured
here, duplicates the frequently used
front panel controls. Two AAA bat-
teries are included. The model num-
ber of the remote control is RC815.

Troubleshootin
Servicin
Cable-TV incoming signal line (round, 75Ω) at the wall,
or the first component the cable is connected to (i.e. the
cable box, or VCR). If the hum is no longer present, you
must insert a “75Ω ground loop isolator” before recon-
necting the line. You should check with your ADCOM deal-
er to obtain one. If the “75Ω ground loop isolator” works
only partially or not at all, then please read note 2 to
complete the troubleshooting procedure.
Note 2: Make sure that the power amplifier is at least 6”
from processor or other equipment using microprocessors.
Usually putting another component between them is suf-
ficient to minimize the hum. If this does not reduce the
hum, turn the system off and disconnect all Inputs from
the amplifier. If the hum still persists, then your dealer or
service center must examine the unit/system. If the hum
disappears, try another set of RCA cables. Connect one
RCA cable at a time to see if one specific cable is respon-
sible. If any or all cables cause the hum to appear, then
the unit should be evaluated for proper operation by your
dealer or authorized service center.
lease see our website
for a list of authorized service centers in your area.
Hum can be caused by adding new components to your
system, but that does not imply there is anything electri-
cally wrong with any new component. With the advent of
audio/video and home theater systems, the problem has
become commonplace. Generally, the cause is the Cable-
TV incoming signal line. This new incoming line may add
an additional ground at a different potential to the AC
line ground of your other equipment (refer to note I and
2, to troubleshoot a hum problem).
ADCOM has a technical service department to answer
questions pertinent to the installation and operation of
your unit. In the event of difficulty, please contact us for
advice. If your problem cannot be resolved through our
combined efforts, we may refer you to an authorized re-
pair agency, or authorize return of the unit to our facto
ry.
Note 1: Cable TV systems can sometimes contribute to
ground loop problems which cause “hum.” To determine if
your
cable system is the contributing factor, disconnect the
Use the troubleshooting notes above to solve common sit-
uations that don’t require professional attention. If the
steps stated in possible solution do not resolve your prob-
lem, then please contact your ADCOM dealer or call the
ADCOM customer service department. Any problems not
covered here should be brought to the attention of your
ADCOM dealer or ADCOM customer service department.
A speci l note on “hum:” When there is a low-volume
“hum” audible throughout your speakers, even with the
main volume turned all the way down, you have a com
mon
phenomenon known as a “ground loop.” A ground loop is
basically a difference in ground voltages between two or
more components which are connected electrically and
which creates multiple current paths where there must
only be one. This difference in potentials creates a 60Hz
low-level sound (approximately a low A), that seems to be
a “hum.”
SYMPTOM POSSIBLE REASON POSSIBLE SOLUTION
ower LED does not
glow. No sound
AC ower Cord(s) not plugged in. AC
Fuse(s) failed. Transformer thermal protec-
tion engaged. I2V DC triggering malfunc-
tioning.
lug in AC ower Cord(s). Replace AC
Fuse(s). Wait until unit cools down. It will
reset. Reset power switch manually.
Check connection of 12V DC trigger at
source.
ower LED glows, but no
sound
reamp or source unit is not on. Connec-
tions in rear of amp are loose.
Make sure whole system is on. Verify all
connections on rear of amp.
One channel not produc-
ing sound
IN UT(s) or OUT UT(s) connector discon-
nected or loose. Speaker disconnected.
Internal protection engaged.
Verify both connections on that channel.
Verify connection at speaker. Bring to
Dealer or Service Center.
Hum from all speakers
at any volume
Ground loop (difference in ground voltages
between components).
If Cable TV is present (see Note 1). If Ca-
ble TV is not present (see Note 2).
Hum from all speakers
(hum goes up or down
with volume)
roblem with source unit (CD, tape, etc.),
or RCA cable connecting that source unit to
the preamp.
Try different source (tuner, tape, etc.)
and/or different RCA cable.
Hum from the amplifier
itself
Some major appliance, dimmer, halogen or
fluorescent light is creating interference.
Make sure all appliances, dimmers and
suspect lights are off.

ADCOM LLC
PO Box 54087
Phoenix, AZ 85032
hone, Fax or Email inquiries to:
Voice: [phone]
Fax: [phone]
Monday through Friday, 9:00 AM to 5:00 M MST
Email: [email protected]
For fax inquiries, please include a return fax number for
the reply. When calling or writing about your ADCOM
product, be sure to note and refer to its serial number as
well as the date of purchase and the dealer from whom it
was purchased. In any communications to us, please in-
clude a daytime phone number where we may reach you.
In the event the unit needs to be sent to a service center,
you will be instructed on the proper procedure when you
call or write for a return authorization. Under no circum-
st nces should your unit be shipped to our f ctory with-
out prior uthoriz tion, or p cked in other th n its orig-
in l c rton nd fillers.
Always ship prepaid via FEDEX or U S. Do not ship via ar-
cel ost, since the packing was not designed to withstand
rough arcel ost handling. Improper packaging and ship-
ment of the product will void your warranty coverage.
Warranty – USA & Canada
This warranty is only valid if this product was purchased
and used in the United States or Canada. Warranty cover-
age for products purchased and/or used outside of the
United States and/or Canada is provided by local ADCOM
authorized dealers and distributors in the country where
the product was sold. Consult your local dealer or distribu-
tor about the terms of your warranty.
ADCOM LLC, makes the following limited warranties. The-
se limited warranties extend to the original purchaser or
any person receiving this product as a gift from the origi-
nal purchaser and to no other purchaser or transferee.
There is no w rr nty provided by ADCOM for products
purch sed from un uthorized sellers, de lers or from
previous owners.
Limited Two Ye r W rr nty
(Home, Non-Commerci l Use Only)
Briefly, ADCOM warrants this product against defects in
materials or workmanship for a period of two (2) years
after the date of original retail purchase from an ADCOM
authorized dealer. During this period, ADCOM will repair
or replace a defective product or part, at our option, with
a new or refurbished product or part without charge to
you. Consult the warranty document enclosed with the
product or our website for the complete terms and condi-
tions of the warranty.
Limited Ninety (90) D y W rr nty
(Commerci l Use Only)
Briefly, ADCOM warrants this product against defects in
materials or workmanship for a period of ninety (90) days
after the date of original retail purchase from an ADCOM
authorized dealer. Consult the warranty document en-
closed with the product or our website for the complete
terms and conditions of the warranty.
No person, agent, distributor, dealer, or company is au-
thorized to change, modify or extend the terms of ADCOM
warranties in any manner whatsoever.
Your Responsibilities
The above warranties are subject to the following conditions:
(1) You must retain and present your dated invoice or bill
of sale to provide proof of original purchase from an
ADCOM Authorized Dealer and coverage during the warran-
ty p
e
riod.
(2) All warranty servicing of this product must be done by
an authorized ADCOM Service Center.
(3) Charges by third parties for set-up, installation, de-
installation, adjustments, shipment, insurance, and other
charges are not covered by this warranty.
(4) This warranty extends only to defects in material or
workmanship as limited above and does not extend to any
product or part which has been lost or discarded by you,
or to damage to products or parts caused by misuse, acci-
dent, pets, Acts of God such as lightning or fluctuations in
electrical power, improper installation, improper mainte-
nance or use in violation of instructions provided in this
Owner’s Manual, or to products which have been altered
or modified. This warranty does not extend to products
which have had the serial number removed, altered, de-
faced, or rendered illegible.
(5) hysical damage to the product
from any cause
is
not
covered by this warranty and the product will be returned
as received without repair.

GFP
-
815 Specifications
Output Level
MainOutputs...............................................................
1.2 Vrms
RecOutputs...............................................................
282mVrms
L/R Output Difference
MainOutputs......................................................... ... ....
0.1dB
Output Level (M ximum)
THDat0.1%MainOutputs.................................................... ... 9.0Vrms
Frequency Response (-3dB Line volume t m x)
HighLevel............................................................. .. 10Hz-100kHz
hono.............................................................. .... 20Hz-80KHz
THD + Noise (@ r ted output 20Hz - 20kHz)
HighLevel................................................................... 0.005%
MM..........................................................................0.03%
MC...................................................................... ...
0.15%
Sign l to Noise (80K Filter JIS-A
HighLevel.................................................................... ≥98dB
MM......................................................................... ≥64dB
MC........................................................................ ≥55dB
Input Imped nce
Line................................................................................ 130KΩ
Line2-6.............................................................................
31KΩ
M 3................................................................................. 31KΩ
MM.................................................................................. 30KΩ
Input Sensitivity (@ r ted output)
Line1-6........................................................................... .. 300mV
M 3............................................................................ .... 75mV
MM.............................................................................. ... 3.2mV
MC........
...............................................................
....
. .
. . .
.
0.5mV
RIAA ccur cy (20Hz - 20kHz)
hono ............................................................................. ± 0.5dB
Tone Controls
Bass(100Hz)........................................................................... ±8dB
Treble(10kHz).......................................................................... ±9dB
General
Power ..........................................120VAC-230VAC—50/6OHz
Ch ssis Dimensions . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . 3” (76.2mm) x 17” (432mm) x 11.5” (292.1mm)
M ximum Dimensions . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . 3.5” (88.9mm) x 17” (432mm) x 12.5” (317.5mm)
Weight ...... ...................................12lbs.(5.5kg)
Weight, P cked ................................... 15lbs.(6.8kg)

GFP-815 Serial Port
Command Set
INTRODUCTION
The Adcom GFP-815 can be controlled via the serial RS-232 port. The serial port can be connected to a sys-
tem controller, PC or ‘dumb terminal’ via a straight-through standard 9-p
in serial port cable ( ALE on one end
and FE ALE on the other end). When using a PC, a terminal emulator program (e.g. HyperTerminal or Pro-
Comm), can be used to control the GFP-815.
The communications parameters should be set as follows:
9600 baud, 8 data bits, no parity, 1 stop bit and Flow Control: Hardware
GFP-815 COMMAND SET
COMMAND Strin Hexadecimal Strin ASCII
POWER ON 57,20,31,20,31,20,32<CR> W 1 1 2<CR>
POWER OFF 57,20,31,20,31,20,31<CR> W 1 1 1<CR>
POWER TOGGLE 57,20,31,20,31,20,33<CR> W 1 1 3<CR>
VOLU E UP 57,20,31,20,39,20,31<CR> W 1 9 1<CR>
VOLU E DOWN 57,20,31,20,39,20,32<CR> W 1 9 2<CR>
UTE ON 57,20,31,20,31,30,20,32<CR> W 1 10 2<CR>
UTE OFF 57,20,31,20,31,30,20,31<CR> W 1 10 1<CR>
UTE TOGGLE 57,20,31,20,31,30,20,33<CR> W 1 10 3<CR>
POLARITY NOR AL (0) 57,20,31,20,32,20,31,33<CR> W 1 2 13<CR>
POLARITY INVERT (180) 57,20,31,20,32,20,31,34<CR> W 1 2 14<CR>
POLARITY TOGGLE 57,20,31,20,32,20,31,35<CR> W 1 2 15<CR>
TRIGER ON 57,20,31,20,33,20,31<CR> W 1 3 1<CR>
TRIGER OFF 57,20,31,20,33,20,32<CR> W 1 3 2<CR>
PHONO (INPUT 1) 57,20,31,20,32,20,36<CR> W 1 2 6<CR>
INPUT 2 57,20,31,20,32,20,37<CR> W 1 2 7<CR>
INPUT 3 57,20,31,20,32,20,38<CR> W 1 2 8<CR>
INPUT 4 57,20,31,20,32,20,38<CR> W 1 2 9<CR>
INPUT 5 57,20,31,20,32,20,31,30<CR> W 1 2 10<CR>
INPUT 6 57,20,31,20,32,20,31,31<CR> W 1 2 11<CR>
P3 (INPUT 7) 57,20,31,20,32,20,31,32<CR> W 1 2 12<CR>
NEXT INPUT 57,20,31,20,32,20,34<CR> W 1 2 4<CR>
PREVIOUS INPUT 57,20,31,20,32,20,35<CR> W 1 2 5<CR>
TONE ON 57,20,31,20,34,20,31<CR> W 1 4 1<CR>
TONE OFF 57,20,31,20,34,20,32<CR> W 1 4 2<CR>
Please Note: ‘’<CR>’’ stands for Carriage Return, the Hex Code is ‘’0D’’. A
space in Hex is ’’20’’, a space in ASCII is just a blank space (as shown above).

ADCOM llc
O Box 54087
hoenix, AZ 85078
H: [phone]
Email: [email protected]om
Web: www.adcom-usa.com
Web: www.adcom.com
