Adcom HD2SDIS User manual

HD2SDIS
GENLOCK
BOX
User Manual
Ver. 1.1

Content
Feature ...................................................................................3
Front Panel...............................................................................4
Rear Panel................................................................................4
Side Panel ................................................................................5
Button/LED Indicate ....................................................................6
Genlock mode ...........................................................................9
Installation ............................................................................. 10
Package Contents ..................................................................... 10
Specifications.......................................................................... 11
Firmware Upload ...................................................................... 13

Feature
SDI Supports HD formats :
720p50 & 60
1080i50 & 60
1080p24, 25, 30, 50 & 60
SDI Support 525i & 625i SD D1 format
Auto 3G/HD/SD-SDI detection
One HDMI input source can split to two 3G-SDI displays simultaneously.
Frame rate conversion(1.000/1.001)
External Button Configuration
Firmware is upgradable in the field using the integrated USB port
The converter is Plug-and-Play
Support VESA Mode
Support Gen-lock input

Front Panel
NO
Component
Function
1
SDI Output Port
From your SDI Display Device plug into
these ports ( Pass Through)
2
LEDs indicate
The LEDs is indicate Output Format
(SD/HD/3G/Power)
3
Mode Buttons
Select Format/TV Wall/TV Ratio
Rear Panel
NO
Component
Function
1
Power Jack
The Power adapter plug into here.
2
HDMI Input Port
From your HDMI Source plug into these
ports
3
Reference input
Port
From your reference Sync Source plug
into these ports
1
2
3
1
2
3

Side Panel
NO
Component
Function
1
USB Connector
Upgrade Firmware/Control Box by PC
1

Button/LED Indicate
1. Switch Format:
Chick the button 1, the box will be setting to Output Format Mode and change
Frame Rate by button 2 and 3.
RES
FRAME RATE
FRACTION
By Pass
720x480
B -59.94i (BT.656)
C- 59.94i (CEA-861)
720x576
50i
1280x720
60p
59.94p
50p
30p
25p
1920x1080i
60i
59.94i
50i
1920x1080p
60p
59.94p
50p
30p
29.97p
25p
24p
23.98p
: is default format at change button 1 after.
SD LED
HD LED
3G LED
BY PASS
●
●
●
720 x 480
○
○
●
720 x 576
○
●
○
1280 x 720
○
●
●
1920 x 1080i
●
○
○
1920 x 1080p
●
○
●
●: LED ON
○: LED OFF

2. Aspect Ratio Mode:
Check the button 3 , the box will be seting to Aspect Ratio Mode
Mode
Display
16:9
(Default)
4:3
1:1
(dot by dot)
3. Function Button Mode:
Hold on the button 3 until show the Func button Mode
Unlock
Lock
FUNC BUTTON
UN-LOCK
FUNC BUTTON
LOCK
LED indicate:
Function
SD LED
HD LED
3G LED
HDCP LED
UN-LOCK (defalt)
●
○
○
●
LOCK
○
○
●
●

4. LED Mode:
Resolution
SD LED
HD LED
3G LED
HDCP LED
NTSC / PAL
●
○
○
○
720p / 1080i /
1080 [24p, 25p, 30p]
○
●
○
○
1080 [50p,60p]
○
○
●
○
HDCP Content
○
○
○
●
SIGNAL UN-LOCKED
○
○
●
(Blinking)
○
5. FIRMWARE Mode:
Hold on the 3 and 2 button, the display is showed firmware version on display of
left upper.
6. GENLOCK Mode:
Hold on the button 2 until show the Func button Mode, have two kinds of mode.
Free –Run Mode
External Mode
GENLOCK MODE
FREE-RUN
GENLOCK MODE
EXTERNAL
7. DEFAULT Mode:
Pull all button (1, 2 and 3) at the same time, the box auto reset to default.
FIRMWARE VERSION
0.1.0.1

Genlock mode
Out
IN
480i
59
576i
50
720
p60
720
p59
720
p50
1080
i60
1080
i59
1080
i50
1080
p60
1080
p59
1080
p50
480i
59
●
●
●
●
●
576i
50
●
●
●
●
●
720p
60
●
●
720p
59
●
●
720p
50
●
●
1080i
60
●
●
●
●
1080i
59
●
●
●
●
●
1080i
50
●
●
●
●
1080
p60
●
●
●
●
1080
p59
●
●
●
●
●
1080
p50
●
●
●
●
●：GENLOCK LOCK
●：FRAME LOCK

Installation
HD2SDIS-GENLOCK installation consists of the following:
1. Disconnect +12DC adaptor to converter.
2. Connect Video Source (HDMI) to the HDMI Connector.
3. Connect SDI Equipment to the BNCs connector
4. Connect the +12DC adaptor to the converter.
Package Contents
The HD2SDIS-GENLCOK package contains the following items:
User Manual x 1
+12 DC Adapter x 1
HD2SDIS-GENLOCK Converter x 1
