Universal MaxRax™ Roof Rack
Assembly Instructions
Addictive Desert Designs® | Page 1
ADDICTIVE DESERT DESIGNS®
®
Preparation:
• Disconnect the negative battery terminal. Park the vehicle on level ground and set the emergency brake.
• We recommend reading through the installation instructions in whole before performing the work.
• Estimated Installation Time: 1 Hours
**is installation requires 2 people for best results**
You will need the following tools:
- Ratchet - 7/32" Allen Wrench/Socket - 9/16" Wrench or Socket
Included in Kit:
48 - Button Head Bolts (3/8”-16 x 1”) 64- Flat Washers (1/2”-13 x 1 1/2”)
48 - Nylon Locking Nut (3/8”-16) 2- Side Panels
2- End Panels 3- Cross Rails
4- Corner Gussets
Assembly:
1. Line up one of the Side Panels with one of the End Panels to form a right angle. Line the bolt holes up, then
install the supplied 3/8" Bolts (x5), 3/8" Washers (x5), and 3/8" Lock Nuts (x5). ere are 3 along the sides and 2
on the bottom portion of each corner. Leave these bolts loose for now. (Fig A)
Fig A

Universal MaxRax™ Roof Rack
Assembly Instructions
Addictive Desert Designs® | Page 2
ADDICTIVE DESERT DESIGNS®
®
2. Take the other Side Panel and line it up the same way. Install the supplied 3/8" Bolts (x5), 3/8" Washers (x5),
and 3/8" Lock Nuts (x5). Leave these bolts loose for now. (Fig B)
Fig B
3. Lay the second End Panel in place and connect it to the Side Panels in the same way you connected the rst
End Panel. Use the supplied 3/8" Bolts (x10), 3/8" Washers (x10), and 3/8" Lock Nuts (x10). (Fig C)
Fig C

Universal MaxRax™ Roof Rack
Assembly Instructions
Addictive Desert Designs® | Page 3
ADDICTIVE DESERT DESIGNS®
®
4. Lay the rst Cross Rail in place so that the bolt holes line up with the holes on the Side Panels. en, install
the supplied 3/8" Bolts (x4), 3/8" Washers (x4), and 3/8" Lock Nuts (x4). Leave these bolts loose for now. (Fig D)
Fig D
5. Repeat Step 4 with the second and third Cross Rails, until your Roof Rack looks like the one in (Fig E). Leave
all of the bolts loose for now.
Fig E

Universal MaxRax™ Roof Rack
Assembly Instructions
Addictive Desert Designs® | Page 4
ADDICTIVE DESERT DESIGNS®
®
6. Set one of the Corner Gussets in place. ey bolt to the top rails of the End Panels and Side Panels. Use the
supplied 3/8" Bolts (x4), 3/8" Washers (x8), and 3/8" Lock Nuts (x4) to it in place. en, repeat this step on the
other 3 Gussets. (Fig F)
Fig F
7. Go back and tighten all 3/8" bolts to 30 foot pounds.
8. Stand back and enjoy your new ADD MaxRax™ Roof Rack.
9. Check and re-tighten, if necessary, all mounting bolts aer 100 miles and periodically thereaer.

Universal MaxRax™ Roof Rack
Assembly Instructions
Addictive Desert Designs® | Page 5
ADDICTIVE DESERT DESIGNS®
®
For Additional Support or Technical Questions,
Please Call 480-671-0820 or
Email I[email protected]
is product is protected by one or more U.S. patents
