Addi-Data ADDIALOG APCI-3504 Parts list manual

DIN EN ISO 9001:2000
certified
A
DDI-DATA GmbH
Dieselstraße 3
D-77833 OTTERSWEIER
Technical support:
+49 (0)7223 / 9493 – 0
Technical description
ADDIALOG APCI-3504
Analog output board for the PCI bus
5th edition 06/2005

2
Product information
This manual contains the technical installation and important instructions for correct commissioning
and usage, as well as production information according to the current status before printing.
The content of this manual and the technical product data may be changed without prior notice.
ADDI-DATA GmbH reserves the right to make changes to the technical data and the materials
included herein.
Warranty and liability
The user is not permitted to make changes to the product beyond the intended use, or to interfere with
the product in any other way.
ADDI-DATA shall not be liable for obvious printing and phrasing errors. In addition, ADDI DATA, if
legally permissible, shall not be liable for personal injury or damage to materials caused by improper
installation and/or commissioning of the board by the user or improper use, for example, if the board is
operated despite faulty safety and protection devices, or if notes in the operating instructions regarding
transport, storage, installation, commissioning, operation, thresholds, etc. are not taken into
consideration. Liability is further excluded if the operator changes the board or the source code files
without authorisation and/or if the operator is guilty of not monitoring the permanent operational
capability of working parts and this has led to damage.
Copyright
This manual, which is intended for the operator and its staff only, is protected by copyright.
Duplication of the information contained in the operating instructions and of any other product
information, or disclosure of this information for use by third parties, is not permitted, unless this right
has been granted by the product licence issued. Non-compliance with this could lead to civil and
criminal proceedings.
ADDI-DATA software product licence
Please read this licence carefully before using the standard software. The customer is only granted the
right to use this software if he/she agrees with the conditions of this licence.
The software must only be used to set up the ADDI-DATA boards.
Reproduction of the software is forbidden (except for back-up and for exchange of faulty data
carriers). Disassembly, decompilation, decryption and reverse engineering of the software are
forbidden. This licence and the software may be transferred to a third party if this party has acquired a
board by purchase, has agreed to all the conditions in this licence contract and the original owner does
not keep any copies of the software.
Trademarks
-ADDI-DATA is a registered trademark of ADDI-DATA GmbH.
-Turbo Pascal, Delphi, Borland C, Borland C++ are registered trademarks of Borland Insight
Company.
-Microsoft C, Visual C++, Windows XP, 98, Windows 2000, Windows 95, Windows NT,
EmbeddedNT and MS DOS are registered trademarks of Microsoft Corporation.
-LabVIEW, LabWindows/CVI, DasyLab, Diadem are registered trademarks of National Instruments
Corp.
-CompactPCI is a registered trademark of PCI Industrial Computer Manufacturers Group.
-VxWorks is a registered trademark of Wind River Systems Inc.

WARNUNG
In case of wrong uses and if the board is not used for
the purpose it is intended:
♦people may be injured,
♦the board, PC and peripheral may be destroyed,
♦the environment may be polluted
♦Protect yourself, the others and the environment!
♦Read carefully the safety precautions (yellow leaflet).
If this leaflet is not with the documentation, please contact us
and ask for it.
♦Observe the instructions of the manual.
Make sure that you do not forget or skip any step. We are not
liable for damages resulting from a wrong use of the board.
♦Used symbols:
i IMPORTANT!
designates hints and other useful information.
WARNING!
It designates a possibly dangerous situation.
If the instructions are ignored the board, PC and/or
peripheral may be destroyed.
3

Contents APCI-3504
1INTENDED PURPOSE OF THE BOARD...................... 7
1.1 Limits of use......................................................................8
2USER ....................................................................9
2.1 Qualification ....................................................................9
2.2 Personal protection..........................................................9
3HANDLING OF THE BOARD ..................................10
4TECHNICAL DATA................................................11
4.1 Elektromagnetic compatibility (EMC).............................11
4.2 Physical set-up of the board..........................................11
4.3 Versions ..........................................................................12
4.4 Limit values.....................................................................12
4.4.1 Voltage outputs ................................................................... 12
4.4.2 Current outputs (APCI-3504-C)............................................. 13
4.4.3 Timer.................................................................................... 13
4.4.4 Safety (Voltage and current outputs) ................................... 13
4.5 Component scheme.......................................................14
5INSTALLATION OF THE BOARD .............................16
5.1 Opening the PC..............................................................16
5.2 Selecting a free slot .......................................................16
5.3 Plugging the board into the slot ....................................17
5.4 Closing the PC ...............................................................17
6SOFTWARE .........................................................18
6.1 Board registration ..........................................................19
6.1.1 Installation of a new board..................................................19
ADDevice Manager.............................................................20
6.1.2 Changing the registration of a board.................................. 21
Description of the ADDIREG program ..................................21
Registration test ...................................................................24
6.2 Questions and software downloads on the web............24
7CONNECTING THE PERIPHERAL........................... 25
7.1 Connector pin assignment.............................................25
7.2 Connection to the screw terminal board PX 9200.........25
7.2.1 Connection of the APCI-3504 to the PX 9200 ..................... 25
7.2.2 Layout of the screw terminal board.....................................26
4

Contents APCI-3504
7.2.3 Screw terminal and connector assignment ........................ 26
Connector assignment (Board and srew terminal board) ...26
Screw terminal assigment....................................................27
8FUNCTIONS OF THE BOARD ................................28
8.1 Block diagram................................................................28
8.2 Analog outputs ...............................................................28
8.2.1 Voltage outputs ................................................................... 29
8.2.2 Current outputs....................................................................30
8.3 Watchdog.......................................................................30
8.4 Timer...............................................................................30
9STANDARD SOFTWARE ........................................31
9.1 Software functions..........................................................31
9.2 Software samples...........................................................33
5

Contents APCI-3504
Figures
Fig. 3-1: Correct handling ................................................................ 10
Fig. 4-1: Component scheme ......................................................... 14
Fig. 4-2: Component scheme (solder side) .....................................15
Fig. 5-1: PCI-5V slot (32-bit)............................................................... 16
Fig. 5-2: Opening the blister pack.................................................... 16
Fig. 5-3: Inserting the board .............................................................17
Fig. 5-4: Fastening the board at the back cover .............................17
Fig. 6-1: New inserted board (Example) ........................................... 19
Fig. 6-2: ADDevice Manager (Example)........................................... 20
Fig. 6-3: ADDIREG registration program (example)........................... 21
Fig. 7-1: 15-pin. SUB-D female connector (BU1) ...............................25
Fig. 7-2: Connection to the screw terminal board PX 9200 ............. 25
Fig. 7-3: Layout of the screw terminal board PX 9200......................26
Fig. 7-4: Terminal assignment of the PX 9200 .................................. 27
Fig. 8-1: Block diagram of the APCI-3504 ........................................ 28
Fig. 8-2: Reaction time of the analog outputs ................................. 29
Fig. 8-3: Switching principle of the analog ground lines
(Voltage version) ................................................................ 29
Fig. 8-4: Switching principle of the analog ground lines
(current version)..................................................................30
Tables
Table 9-1: Supported software functions..........................................31
Table 9-2: Supported software samples for the APCI-3504 .............. 33
6

APCI-3504 Intended purpose of the board
1INTENDED PURPOSE OF THE BOARD
The board APCI-3504 is the interface between an industrial process and a
personal computer (PC).
The board APCI-3504 must be inserted in a PC with PCI 5V/32-bit slots,
which is used as electrical equipment for measurement, control and
laboratory use as definedn in the norm IEC 61010-1.
The PC is to comply with the norm IEC61326 for measurement, control and
laboratory use and with the specifications for EMC protection.
Products complying with these specifications bear the CE mark.
Data exchange between the APCI-3504 board and the peripheral is to occur
through a shielded cable. This cable must be connected to the 15-pin SUB-D
female connector of the APCI-3504 board.
The board has up to 4 input channels in voltage or current version for
processing analog signals.
An external 24 V supply voltage is necessary to run the output channels.
The PX 9200 screw terminal board allows to connect the external voltage
supply signals through the ST3122-A cable.
The use of the APCI-3504 board in combination with external screw
terminal or relay boards is to occur in a closed switch cabinet; the
installation is to be effected competently.
The connection with our standard cable ST3122-A complies with the
minimum specifications as follows:
-metallized plastic hoods
-shielded cable
-cable shield folded back and firmly screwed to the connector housing.
Uses beyond these specifications are not allowed. The manufacturer is not liable
for any damages which would result from the non-observance of this clause.
The use of the board according to its intended purpose includes observing
all advises given in the Technical description and in the Safety leaflet.
7

Intended purpose of the board APCI-3504
1.1 Limits of use
The use of the board in a PC could change the PC features regarding noise
emission and immunity. Increased noise emission or decreased noise
immunity could result in the system not being conform anymore.
The APCI-3504 board is not to be used as safety related part for
securing emergency stop functions.
The emergency stop functions are to be secured separately.
This securing must not be influenced by the board or the PC.
The installation of the board APCI-3504 in sites lying under risk of
explosion is excluded.
Make sure that the board remains in its protective packing until it is used.
Do not remove or alter the identification numbers of the board.
If you do, the guarantee expires.
8

APCI-3504 User
2USER
2.1 Qualification
Only persons trained in electronics are entitled to perform the following works:
-installation
-use,
-maintenance.
2.2 Personal protection
Consider the country-specific regulations about:
-the prevention of accidents
-electrical and mechanical installations
-radio interference suppression.
9

Handling of the board APCI-3504
3HANDLING OF THE BOARD
Fig. 3-1: Correct handling
10

APCI-3504 Technical data
4TECHNICAL DATA
4.1 Elektromagnetic compatibility (EMC)
The board has been subjected to EMC tests in an accredited laboratory. The
board complies with the limit values set by the norm EN55011 and
EN61000-6-2 as follows:
True value Set value
ESD (Discharge by contact/air) ................. 4/8 kV 4/8 kV
Fields.......................................................... 10 V/m 10 V/m
Burst........................................................... 4 kV 2 kV
Conducted radio interferences ................... 10 V 10 V
4.2 Physical set-up of the board
The board is assembled on a 4-layer printed circuit card.
Dimensions:
168 mm
99 mm
Weight: ...................................................... approx. 160 g
Installation in: ........................................... 32/64-bit PCI slot 5 V
Connection to the peripheral:
2 SUB-D HD female connectors ............... 1 x 15-pin connector
for the analog outputs
Accessories1:
Standard cable: .......................................... ST3122-A
Screw terminal board................................. PX 9200
1Not included in the standard delivery.
11

Technical data APCI-3504
4.3 Versions
2 versions of the board APCI-3504 are availabe.
APCI-3504 APCI-3504-C
4 voltage outputs 4 current outputsAnalog outputs
4.4 Limit values
Max. altitude: ............................................ 2000 m
Operating temperature: .............................. 0 to 60°C
Storage temperature: ................................. -25 to 70°C
Relative humidity: ..................................... 30% to 99% non condensing
Minimum PC requirements:
PCI BIOS from Version 1.0
Bus speed: ................................................. < 33 MHz
Operating system: ..................................... Windows NT, 98, 2000, XP
Energy requirements:
External operation voltage:........................ 24 V ±5%
Maximum current consumption
(+ 5 V from the PC): ................................. 560 mA ±15 mA
1
4.4.1 Voltage outputs
Number of channels: ................................. 4 analog outputs
Output type: ............................................... single-ended
Resolution: ................................................ 12-bit
Output voltage range: ................................ - 10 V to (+10 V - 1 LSB)
LSB: .......................................................... 4.8828 mV
Accuracy: .................................................. 11-bits
Time to ready (tr): ..................................... typ. 4.5 µs
Settling time
(= tr + settling time of the DAC): .............typ. 15 µs (by 10 V step)
Temperature drift: ..................................... max. 10 ppm/°C
Maximum output current: ......................... ±5 mA
Short-circuit current: ................................. ±20 mA
1All digital outputs are connected and all digital inputs are set to high
12

APCI-3504 Technical data
4.4.2 Current outputs (APCI-3504-C)
Number of channels: ................................. 4 analog outputs
Resolution: ................................................ 12-bit
Max output current: ................................... 0 to 20 mA
LSB: .......................................................... 4.883 µA
Typical error: ............................................. ≤25 µA
Max. error: ................................................ ≤100 µA
Time to ready (tr): ..................................... typ. 4.5 µs
Settling time
(= tr + settling time of the DAC): .............typ. 70 µs (by 20 mA step)
Temperature drift: ..................................... max. 10 ppm/°C
Maximum load: ....................................... 500 Ω
4.4.3 Timer
Timer depth: ..............................................12-bit
Time bases: ............................................... µs, ms, s
Control period: .......................................... 1 to 4095 µs, ms, s
Tolerance: .................................................. ≤1 µs, ms, s
4.4.4 Safety (Voltage and current outputs)
Optical isolation to the PC: ....................... 500 VDC min.
Voltage/current after reset: ........................ 0 V / 0 mA
Watchdog
Watchdog depth: .......................................12-bit
Time bases: ............................................... µs, ms, s
Control period: .......................................... 1 to 4095 µs, ms, s
Tolerance: .................................................. ≤1 µs, ms, s
13

Technical data APCI-3504
4.5 Component scheme
Fig. 4-1: Component scheme
14

APCI-3504 Technical data
Fig. 4-2: Component scheme (solder side)
15

Installation of the board APCI-3504
5INSTALLATION OF THE BOARD
i IMPORTANT!
Do observe the safety precautions (yellow leaflet)!
5.1 Opening the PC
♦Switch off your PC and all the units connected to the PC
♦Pull the PC mains plug from the socket.
♦Open your PC as described in the manual of the PC manufacturer.
5.2 Selecting a free slot
Insert the board in a free PCI-5V slot (32-bit).
Fig. 5-1: PCI-5V slot (32-bit)
Remove the back cover of the selected slot according to the instructions of
the PC manufacturer. Keep the back cover. You will need it if you remove
the board
Discharge yourself from electrostatic charges.
Take the board out of its protective blister pack.
Fig. 5-2: Opening the blister pack
16

APCI-3504 Installation of the board
5.3 Plugging the board into the slot
♦Insert the board vertically into the chosen slot.
Fig. 5-3: Inserting the board
♦Fasten the board to the rear of the PC housing with the screw which
was fixed on the back cover.
Fig. 5-4: Fastening the board at the back cover
♦Tighten all the loosen screws.
5.4 Closing the PC
♦Close your PC as described in the manual of the PC manufacturer.
17

Software APCI-3504
6SOFTWARE
In this chapter you will find a description of the delivered software and its
possible applications.
i IMPORTANT!
Further information for installing and uninstalling the different
drivers is to be found in the delivered description
"Installation instructions for the PCI bus".
A link to the corresponding PDF file is available in the navigation pane
(Bookmarks) of Acrobat Reader.
i IMPORTANT!
The supported software functions for the APCI-3504 are listed
in chapter 9.
The board is supplied with a driver CD-ROM (CD 1) containing the
ADDIPACK software package for Windows NT 4.0 and Windows
XP/2000/98.
ADDIPACK is composed of following programs:
-ADDIREG: The ADDIREG registration program is a 32-bit program for
Windows NT 4.0 and Windows XP/2000/98. The user can register all
hardware information necessary to operate the ADDI-DATA PC boards.
-ADDIDRIVER contains API functions to operate the ADDI-DATA
boards in 32 bits.
-ADDevice Manager configures the resources of the ADDI-DATA
virtual board (See below).
-ADDI-DATA virtual board:
ADDI-DATA software is based on the principle of a virtual board: it
transposes the different functions (e.g. digital inputs, analog outputs,
timer, ...) of all inserted ADDI-DATA boards as the functions of a single
(virtual) board. The virtual board features a pool of functions, the
functionality of which can be called up without calling a specific board.
-ADDEVICE MAPPER was specifically developed for the ADDIPACK
boards to facilitate the management of the virtual board. With this
program you can optimally adapt the virtual board to your application
requirements.
IMPORTANT!
For some functions of the ADDEVICE MAPPER program the browser
Internet Explorer 6 or higher has to be installed on your PC.
18

APCI-3504 Software
6.1 Board registration
When starting the set-up of ADDIREG, the APCI-3504 is automatically
recognised and registered.
6.1.1 Installation of a new board
If a new board is recognised, the following windows is displayed:
Fig. 6-1: New inserted board (Example)
The boards which have been removed from the PC since the last ADDIREG
start are listed in the upper table
The new inserted boards are listed in the lower table.
In case further information is required for the operation of the board, click
on "More Information". ADDevice Manager is started.
19

Software APCI-3504
ADDevice Manager
Fig. 6-2: ADDevice Manager (Example)
The following parameters are displayed for every inserted board:
First column:
-Board name
-Board index: Number allocated to the board when it is registered in
ADDIREG.
-Slot number
-IRQ line
-Different addresses which are automatically allocated to the board by the
BIOS.
Other columns:
The program distinguishes between the resources (Analog/digital
input/output, watchdog, ...) of the virtual board (V, software) and the real
board (R, board).
The following parameters are listed
-Module number,
-Number of resources
-Index: The first index line represents the number of the first resource
(left: virtual resource - right: real board) The second index line represents
the number of the last resource (left: virtual resource - right: real board).
-Type (24 V/5 V, voltage/current, HS/OC - High-Side/Open collector).
-IRQ: if the input/output channels are interruptible, the program displays
the number of the first and of the last input/output channel
20
