User Guide
CF or CFast Drive
(AE6CF / AE6CAS)

www.addonics.com
Phone: [phone]
Fax: [phone]
Email: http://www.addonics.com/sales/query/
CONTACT US
Removing Cover of CF / CFAST Drive
To remove the top cover of the CF / CFast Drive, loosen the 4 screws located at the
side of the device using a Philips screwdriver by turning counter-clockwise.
Separate the metal casing of the drive from the housing by lifting up the casing.
Cable Connections
Data Cable
Each of the 6 SATA data cables will need to be connected to a SATA port.
Power Cable
Two 4-pin molex power connectors from the power supply will connect to the 4-pin
molex power cable on the CF/CFast drive. This will power all six slots on the
CF/CFast drive.
Installing CF / CFAST cards into the CF Drive
Slide the CF card into each of the slot on the CF / CFAST Drive.
Note: It is recommended to fill up the CF / CFAST Drive with CF / CFAST cards
from top to bottom, left to right. This is to help in identifying which cards connect to
which ports for easier troubleshooting.
Top Cover Screws
