Addonics Technologies AE25SNSP User manual

Technical Support
If you need any assistance to get your unit functioning properly, please have your
product information ready and contact Addonics Technical Support at:
Hours: 8:30 am - 6:00 pm PST
Phone: [phone]
Email: http://www.addonics.com/support/query/
v3.1.11
www.addonics.com
T E C H N O L O G I E S
User Guide
2.5" Snap-In SP
(AE25SNSP)

Installing the 2.5” Snap-In SP
Screw the device into the 3.5” drive bay of your computer. After unit is screwed
in, attach the SATA power cable that comes with the unit and the SATA data cable
into the device’s connectors as shown above. Connect the LED cable to the 4 pin
LED port on the back of the device. Attach the other end of the cables to your
computer or host controller.
SATA Power Connector
SATA Data Connector
4 Pin LED Port
Screws
Back View
SATA Power Cable
LED Cable
SATA Data Cable
To power supply
in your system
To SATA port
in your system
Opening device and inserting HD
By default the lock should be set to the open (up) position. Pull the lever to open
up the device and slide in the 2.5” HD right side up.
After inserting your HD to the device, close the cover. Lock the cover with the
included key by turning it clockwise all the way.
Removing the HD
Make sure that there is no HD activity before unlocking the cover. Pull the lever
and carefully pull out the HD.
Note: The HD can reach temperatures exceeding 50°C. Handle with care to
prevent accidental burning.
Lever
Lock
Front View
