IMPORTANT SAFEGUARDS
WHEN USING ANY ELECTRICAL APPLIANCE, BASIC SAFETY
PRECAUTIONS SHOULD ALWAYS BE FOLLOWED.
PLEASE READ ALL INSTRUCTIONS CAREFULLY
AND RETAIN FOR FUTURE REFERENCE
AVAC12000
Portable Air Conditioner
Installation Instructions
User Guide

2
BEFORE USE
These symbols on your device mean:
This appliance is filled with Propane gas R290. Follow strictly the
manufacturer’s instruction concerning use and repairs!
Before using the machine, read carefully the entire instruction manual.
Do not install, operate or store the device in a room smaller than 13m
2
.
GENERAL CAUTIONS
FOR INDOOR USE ONLY.
Do not use in cabinet, closet, boats, caravans or similar locations.
Do not use the unit in swimming pools, washrooms or similar wet areas.
Leave the unit to stand for 12hours before connecting to the mains supply
after transport or when it has been tilted (ex. during cleaning).
Only use the unit in the upright position on a flat level surface (even during
transport!) and at least 50cm from any objects.
Do not use the unit in a potentially explosive environment containing
combustible liquids, gases or dusts.
Do not use the appliance in the vicinity of flammable or explosive
substances or fuels. Never use any paint, cleaning sprays, anti-insect sprays or
similar near the unit; this could deform the plastic or cause electrical damage.
Ensure that there is at least 50cm between the sides of the appliance and
any flammable, heating materials.
Do not place objects on the unit or restrict air inlet/outlet.
The unit should not be used in an area where it could be splashed with

3
water.
Closely supervise any children and pets when the unit is in use.
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
CHILDREN SHALL NOT PLAY WITH THE APPLIANCE.
Cleaning and user maintenance should not be carried out by children.
Switch off and unplug the unit when not in use.
Never leave a functioning device unsupervised.
Do not pull the unit along by the cord.
Avoid over-twisting, -coiling, -pulling the power cord, never use nylon or iron
wire to tie/tidy the power cord.
Make sure that the plug and socket remain visible and accessible at all the
time.
Do not use extension cords.
Never reach to retrieve the unit if it has fallen in water. In such case,
immediately pull the plug. Have the unit checked before using it again.
IF THE SUPPLY CORD IS DAMAGED, IT MUST BE REPLACED BY AN
ELECTRICIAN OR SIMILARLY QUALIFIED PERSON,TO AVOID HAZARD.
THE MAINS SUPPLY MUST CONFORM TO THE SPECIFICATION
SHOWN ON THE RATING PLATE AT THE BACK OF THE UNIT.
The appliance shall be installed in accordance with national wiring regulations.
Do not exceed the recommended room size for max. efficiency. (26m² floor
area, 2.4m ceiling)
Close the doors and windows.
Keep curtains or blinds closed during the sunniest hours of the day.
Keep filters clean.
Once room has reached the desired conditions, reduce the setting for
temperature and ventilation.
Do not turn on the appliance if you have discovered damage to the
appliance, cord or plug, if the appliance is malfunctioning or if there are signs
of any other defect.

4
THE MACHINE IS TO BE USED ONLY FOR ITS PRESCRIBED PURPOSE.
ANY OTHER USE IS DEEMED TO BE A CASE OF MISUSE.
THE USER/
OPERATOR, NOT THE MANUFACTURER WILL BE LIABLE FOR ANY
DAMAGE OR INJURIES OF ANY KIND CAUSED AS A RESULT OF THIS.
SAFETY RELATING TO REFRIGERANT R290:
Read these warnings carefully.
This appliance contains the refrigerant R290. R290 is a refrigerant that
complies with the relevant European Directives. Never perforate the
refrigerant circuit. R290 is flammable (GWP3)!
Do not use means to accelerate the defrosting process or to clean, other
than those recommended by the manufacturer.
The appliance shall be stored in a room without continuously operating
ignition sources (for example: open flames, an operating gas appliance or an
operating electric heater).
Do not pierce or burn any of the components of the cooling circuit of the
unit. Do not set light to the unit.
The appliance shall be stored so as to prevent mechanical damage from
occurring.
Appliance should be installed, operated and stored in a room with a floor
area larger than 13m2 .
Be aware that the refrigerants may not contain an odour, which means you
cannot smell leaks..
Compliance with national gas regulations shall be observed.
Keep ventilation openings clear of obstruction.
The appliance shall be stored in a well-ventilated area where the room size
corresponds to the room area as specified for operation.
Under no circumstances should any person open, remove the cover, or try
to modify or repair this unit in any way.

5
Components
1. Control Panel
2. Remote control receiver
3. Air vent
4. Carrying handle
5. Water gate (for energy saving)
6. See-through window for water level
inside the unit
7. Air filter (air inlet)
8. Cord compartment
9. Exhaust air outlet
10. Drainage knob / drainage point
11. Air filter (air inlet)
12. Air filter (air inlet)
Front
Fig 1. Fig 2
Fig 3
Back
Accessories
13. Exhaust hose
14. Flat Type adaptor - Inserting over hose and into window spacer
15. Inward Adaptor (connecting unit & exhaust hose)
16. PVC strip - for filling the open
window space
17. PVC strip - for filling the open
window space
18. PVC strip (with hole) - for filling the
open window space and with hole
for connection to flat type adapter
19. Drain tube for continuous drainage
20. Active carbon filter
21. Remote control
2
7
1
3
10
11
12
9
8
4
5
6
13
14
15
19
20 21
18
17
16

6
Installation
Offer window spacer to the window gap and adjust the length as you need.
Feed exhaust hose through the window spacer and slide window across so that
spacer is held securely.This technique may also be used for sash windows. Note:
Take care to maintain protection against intruders
The unit is a portable air conditioner that may be moved from room to room.
Using the extendable slide
Fig 4.
Extendable slide
Window kit

7
Mounting of the exhaust hose
Use only the hose provided
and clip exhaust hose and unit
adaptor to the back of the air
conditioner.
FIG. 5
FIG. 8WARNING!
The length of the exhaust pipe
is specially designed according
to the specification of this
product. Do not replace or
prolong it with your own private
hose as this could cause the unit
to malfunction.
FIG. 7
The hose may be extended
from 300mm to 1500mm but
for maximum efficiency use the
shortest length possible.
FIG. 6
Avoid kinks and bends in the
exhaust hose as this will cause
expelled moist air to build up
causing the unit to overheat
and shut down.

8
1. Remove the filter frame from the unit.
2. Separate the filter fixer from the filter frame.
3. Remove the active carbon filter from its plastic bag.
4. Insert the active carbon filter into the filter frame.
5. Fix the filter by reassembling the fixer onto the
filter frame.
6. Re-fit the filter frame inside the unit.
Installation of the carbon filter
This machine is equipped with the active carbon filter. The activated carbon is
charcoal that has been treated with oxygen to open up millions of tiny pores
between the carbon atoms. It is used to get rid of unwanted odours (smoke,
fumes, and animal odour). Please note, the carbon filter is not washable, its life
span is variable and depends on the ambient conditions where the unit is used.
The filter should be checked periodically and replaced if necessary (normally, it’s
6 months), below is the installation of the active carbon filter along with this unit:
FIG. 10
FIG. 9

9
Operation
Control panel
A. TIMER button
B. SPEED (ventilation) button
C. MODE button
D. ON/OFF (POWER) button
E. IONIZER / TIO2 button (only
for the model with ionizer/TiO2
function)
F. SLEEP button
G. DISPLAY window
H. TEMPERATURE UP button
I. TEMPERATURE DOWN button
1. Timer indicator
2. High fan speed indicator
3. Medium fan speed indicator
4. Low fan speed indicator
5. AUTO mode indicator
6. COOL mode indicator
7. FAN mode indicator
8. DEHUMIDIFY (DRY) mode
indicator
9. Water full indicator
10. Compressor operation indicator
11. Ionizer/TiO2 mode indicator
(only for the model with ionizer/
TiO2 function)
12. Sleep mode indicator
FIG. 11

10
Adjust the air vent
Before using the unit, please do
open the horizontal louver!
Adjust the louvers to your
desired direction
Turning ON/OFF
Press ON/OFF button, the unit will start in AUTO (automatic) mode.
Automatic mode
In automatic mode, the unit can cool , ventilate or heat depending on ambient
temperature and setpoint adjustment.The unit is preset as follows:
1. If ambient temperature is > 23°C, the unit will be in automatic cooling
mode. Default setting 24°C. During this operation, the indicator for AUTO and
COOL mode light up in green:
2. If the ambient temperature is < 24°C, but > 20°C, the unit will work
in ventilation mode. During this operation, the indicator for AUTO and FAN
mode light up in green:
FIG. 12
FIG. 12

11
Setpoint setting in automatic cooling mode 18-32°C
If you set the setpoint at 24°C the unit starts to cool at 27°C (Setpoint + 3°C).
It cools down to 25°C (Setpoint +1°C) and then switches back to the ventilation.
Setting mode/function
Press MODE button to select required working mode: cooling, fan or dehumidify
(dry) Sign of your selected mode comes on.
Setting temperature
1. Press ‘Temperature up’ or ‘Temperature down’ button to regulate the
temperature you desired.
2. The display window will show the temperature you set as you press
‘Temperature up’ or ‘Temperature down’ button. Otherwise, it will always show
the ambient temperature.
3. The pre-setting temperature of this machine is: 24°C for cooling.
°C
FIG 14
Time

12
Setting ventilation speed
Press SPEED button to choose the ventilation speed you need, high, medium or
low.The sign of high or low ventilation will light on at the same time.
Setting timer
1. Press TIMER button to set the operating hours you desired (1 to 24 hours, the
sign of timer will light on).When the set time has been reached, the machine
will turn off automatically.The display window will show the hour(s) you set as
you press TIMER button. If the timer button is not pressed, the unit will work
continuously.
2. By pressing the timer but without turning on the other functions, you can PRE-
SET the time for the machine to work. For example, if you press the timer to
‘2’, the unit will work automatically after 2 hours.
Sleep function
1. In cooling mode, by pressing the SLEEP button, the set temperature will
increase 1oC at the 1st hour, another 1ºC at the second hour, then keeps at
that temperature.
2. In sleep mode, the ventilation will keep at low speed. Re-press the SLEEP button,
the setting temperature and ventilation speed will return to the pre-selected one.
3. The unit will shut down automatically after the SLEEP function running for
12 hours.
4. Please note, the sleep function is not available while the machine is working
in ventilation, dehumidication or auto mode. Only available in Cooling or
Heating mode.
5. When the machine is in Sleep function, the Fan Speed would turn to be
LOW speed.
Dehumidify (DRY) mode
In dehumidify (DRY) mode, the temperature cannot be adjusted, the ventilation
will fix at low speed. When the unit is operating in Dehumidify ( DRY) mode,
humidity extracted from the air is collected in an internal tank. If the tank reaches
full, the compressor and motor cut out automatically. At the same time, the
“Water Full” indicator comes on. An alarm will also sound.When the tank is full,
drain the water as shown in the page about “DRAINAGE”. You may also use the
unit without having to empty the tank so often by using “continuous drainage”,
please also refer to the page about “DRAINAGE”.

13
Self-diagnosis
This machine is equipped with self-diagnosis function. If something is wrong in the
machine, the LED will show the word “E1” or “E2”.
At this time, please contact Addvent (0117 938 6402). Please DO NOT dismantle
the machine by yourselves in any case.
All the above functions can also be performed
with the supplied remote control.
This remote control requires 2 pcs AAA batteries
to operate (battery is not supplied along with
the unit).
Efficiency Boosting
This unit is equipped with “energy efficiency boosting” function, by adding water
(2.5L max.) to the water gate at the side of the unit, the energy efficiency can
be elevated.The principle is: while the machine is working, the condenser will be
getting hot, if you add the water into the unit after the unit has been worked for
more than one hour, the water will cool down the condenser, thus it consumes
less power, i.e. saving energy.
FIG 15
1. Open the water gate 2. Fill the water (max.
2.5L) please pay
attention on the
water level of the
see-through window
beneath the water
gate.
3. Refit the water gate
into place
FIG 16

14
NOTE
1. This efciency feature by adding water is proposed to do after one
hour operation and the water should NOT be over 2.5L, otherwise,
the “water full” indicator will light in red and the unit will stop
working. ✩ This action should only be performed while the power
is on, in order the “water full” alarm could work, also please pay
attention on the water level of the see-through window beneath the
water gate.
2. In case the “water full” indicator is in red, please drain the water
from the drain point at the back side of the unit until the red light
goes out. The unit should work again now.
IMPORTANT!
1. To prolong the compressor’s life, after switch-off of the unit, please wait for
3 minutes (at least) before re-switch.
2. The cooling system will switch off if the ambient temperature is lower than
the set one.The ventilation, however, keeps working on the set level. If the
ambient temperature rises above the selected level, the cooling will return
to work.
3. This machine is equipped with ANTI-FROST function.While using the
heating function during low temperature, sometimes the heating will stop
for a while in order to melt the frost. As this occurs, just wait for the heating
returns to work.

15
Drainage
1.Turn off the air conditioner and avoid moving
it when full.
2. Position a container (a water tray for
example) underneath the drain hole.
3. Remove the drain knob & rubber plug from
the drain hole and allow the water to drain
out.
4.When the container is almost full, replace the
rubber plug in the drain hole and empty the
water tray.
5. Repeat until the unit is emptied.
6. Replace the rubber plug and tighten the drain
knob firmly.
7. Switch on the unit - the full water or
compressor operating indicator should not be
flashing.
Should you prefer to use the appliance without
having to empty the tank every so often,
proceed as follows :
Remove the drain knob and rubber plug and
retain for future use.
Connect the drain tube supplied to the
water outlet as shown and locate the other
end into a drain.
The drain tube may be extended by adding
an extension tube and using a suitable
connector.
FIG 17
FIG 18
FIG 19
FIG 20
When the unit is operating in Cooling or Dehumidify ( DRY) mode, humidity
extracted from the air is collected in an internal tank. If the tank reaches full, the
compressor and motor cut out automatically. At the same time, the “Water Full”
indicator comes on. An alarm will also sound.When the tank is full, carry out the
following instructions:

16
Please note
1. The drain must be at a lower level than the drain hole on the unit.
2. Flashing ‘Water Full’ indicator will not function in this mode of drainage.
3. If you want to extend the water tube, you can connect it with another tube
(OD: 18mm). *The extended tube is NOT supplied along with the unit.

17
Maintenance
Always unplug the air conditioner from the mains before cleaning.
To maximize the efficiency of the air conditioner, clean the unit
regularly.
Cleaning the housing
Use a soft, damp cloth to wipe the body clean.
Never use aggressive chemicals, gasoline, detergents, chemically treated cloths, or
other cleansing solutions.These all could possibly hurt the cabinet.
Cleaning the filter
Use a vacuum cleaner or tap the filter lightly to remove loose dust and dirt from
the filters and then rinse thoroughly under running water (no hotter than 40°C).
Dry thoroughly before replacing.
Notice! Never operate the unit without the filters.
End of season storage
Drain any water in the unit before completely operating the unit on ventilation
only mode for a few hours, to thoroughly dry the inside.
Clean or change the filter
Unplug and store the power cord as shown
Replace in the original carton or cover
for storage.
FIG. 21
Power
Cord
Inside

18
Fault Check List
The air conditioner does not run Is the air conditioner plugged in?
Is there a power failure?
Is the ‘full water’ indicator flashing?
Is the room temperature below the
set temperature?
The machine seems to do little Is there direct sunshine? (Please put
down the curtain.)
Are too many windows or doors
open?
Are there too many people in the
room?
Is there something in the room
producing lots of heat?
Is the room too large?
Maximum recommended Room Size
= 26m²
Standard 2.4m ceiling.
The machine seems to do nothing. Is the filter dusty, contaminated?
Is the air intake or output blocked up?
Is the room temperature below your
selected temperature?
Too noisy Is the machine positioned unevenly so
as to create vibration ?
Is the floor underneath the machine
uneven?
The compressor doesn’t run. If so, it is possible the overheat
protection of the compressor is on.
Just wait for the temperature to drop.

Telephone: [phone]
Unit 12, Access 18, Bristol BS11 8HT
www.addvent.co.uk
ISSUE 1/1122
Waste electrical products should not be disposed of
with household waste. Please recycle where facilities
exist. Check with your local authority or retailer for
recycling advice.
Specification
Model no. AVAC12000
Power supply 230V/50Hz
Cooling capacity 12000BTU/3.4kW
Power/Ampere consumption 1300W/5.8A
Dehumidify capacity 31L/day
Air Volume (max. speed) 510m³/hr
Refrigerant R290/270g
Fan speed 3
Timer 1~24 hours
Working temperature 18°C- 32°C
Exhaust hose Ø 150 x 1500mm
N.W. 30kg
Product size (W x D x H) 415mm x 418mm x 790mm
REMARK:
Measuring condition for above is as per EN 14511: Cooling – DB= 35ºC, WB= 24ºC
DB = temperature of dry bulb = room temperature
WB = temperature of wet bulb = relative humidity.
Test condition for data in our rating label is as per safety regulation: EN60335-2-40
Current & Fuse : F10AL250V or T10AL250V
WARRANTY
ONE YEAR
EXCHANGE
1
