Friedrich CP15F10A User manual

/
CP15F10A

Ta
bl
e o
f
C
ontents
A
ir Conditioner Safet
y
......................................................................................................................................................
1
Insta
ll
at
i
on Requ
i
rement
s
...............................................................................................................................................
3
T
oo
l
s an
d
Part
s
....................................................................................................................................................................
3
L
ocation Re
q
uirements
.......................................................................................................................................................
3
El
ectr
i
ca
l
Requ
i
rement
s
......................................................................................................................................................
4
In
stallat
i
o
n In
st
r
uct
i
o
n
s
..................................................................................................................................................
6
Unpackin
g
...........................................................................................................................................................................
6
W
i
n
d
ow Insta
ll
at
i
on (on some mo
d
e
l
s
)
...............................................................................................................................
7
Th
roug
h
-t
h
e-Wa
ll
Ca
bi
net Insta
ll
at
i
o
n
...............................................................................................................................
9
Com
p
lete Installatio
n
........................................................................................................................................................
10
Ai
r
Co
n
ditio
n
e
r
Use
.........................................................................................................................................................
11
Start
i
ng Your A
i
r Con
di
t
i
oner—D
i
g
i
ta
l
Contro
l
..............................................................................................................
12
R
emote Control O
p
eratio
n
................................................................................................................................................
13
N
orma
l
Soun
ds
..................................................................................................................................................................
1
3
A
ir
Co
n
d
i
t
i
o
n
e
r
Ca
r
e
........................................................................................................................................................
14
Cleaning the Air Filter
......................................................................................................................................................
r
14
C
l
ean
i
n
g
t
h
e Front Pane
l
...................................................................................................................................................
14
R
epa
i
r
i
ng Pa
i
nt Damage ...................................................................................................................................................
14
Ann
ua
l M
a
in
te
n
a
n
ce
.........................................................................................................................................................
14
Trou
bl
es
h
oot
i
n
g
...............................................................................................................................................................
14
Ass
i
sta
n
ce
o
r
Se
rvi
ce
......................................................................................................................................................1
5
W
arrant
y
...........................................................................................................................................................................
1
6
1

This Installation and Operation Manual has been designed to insure maximum satisfaction in the performance of your unit. For
years of trouble-free service, please follow the installation instructions closely. We cannot overemphasize the importance of
proper installation. We have added new information to the basic instructions to help you achieve success.
General Instructions
WARNING
Please read this manual thoroughly prior to equipment
installation or operation.
It is the installer’s responsibility to properly apply and
install the equipment. Installation must be in
conformance with the NFPA 70-2008 National Electric
Code or current edition, International Mechanic Code
2009 or current edition and any other applicable local
or national codes.
Failure to do so can result in property damage,
personal injury and / or death.
WARNING
Refrigeration system under high pressure.
Do not puncture, heat, expose to flame or incinerate.
Only certified refrigeration technicians should service
this equipment.
R410A systems operate at higher pressures than R22
equipment. Appropriate safe service and handling
practices must be used.
Only use gauge sets designed for use with R410A. Do
not use standard R22 gauge sets.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual
and on your appliance. Always read and obey all safety messages.
This is a safety Alert symbol. This symbol alerts you
to potential hazards that can kill or hurt you and
others.
All safety messages will follow the safety alert
symbol with the word “WARNING” or “CAUTION”.
These words mean:
WARNING
Indicates a hazard which, if not
avoided, can result in severe
personal injury or death and damage
to product or other property.
CAUTION
Indicates a hazard which, if not
avoided, can result in personal injury
All safety messages will tell you what the potential hazard is, tell you
how to reduce the chance of injury, and tell you what will happen if
the instructions are not followed.
and damage to product or other property.
NOTICE
Indicates property damage can
occur if instructions are not
followed.
2

K. pan-head Phillips screws(2)
K

B
C
C
A
D
Power supply
cord Wiring requirements
■115-volt (103.5 min. - 126.5 max.)
■0-12 amps
■15-amp time-delay fuse or circuit breaker
■Use on single outlet circuit only.
■230-volt (207 min. - 253 max.)
■0-12 amps
■15-amp time-delay fuse or circuit breaker
■Use on single outlet circuit only.
¹⁄₄"
(0.6 cm)
The wall opening measurements should be:
Height (A): 17 ¼" plus twice thickness of wood used to build
frame
Width (B): 26 ¼"
Depth (D): 4" minimum to 8" maximum.
Electrical Requirements
Ground wire must be connected to ground screw located in lower
right corner of air conditioner when air conditioner is in cabinet.
The electrical ratings for your air conditioner are listed on the
model and serial number (nameplate) label. The model and serial
number label is located behind the front panel on the flange below
the control panel area.
Specific electrical requirements are listed in the chart below.
Follow the requirements for the type of plug on the power supply
cord.
Window installation
Window opening measurements:
27"min. to 42" max. (76.2 cm to 101.6 cm) opening width (A).
20" min. (50.8 cm) opening height (B).
Through-the-wall installation
A.27" min.(76.2cm)
B . 20" min. (50.8 cm)
A
B
A. 17 ¼"
B. 26 ¼"
C. Wood thickness
D. 4" minimum to
8" maximum.
CP15
CP18 / CP24
4

Recommended grounding method
This air conditioner must be grounded. This air conditioner is
equipped with a power supply cord having a grounded 3 prong
plug. To minimize possible shock hazard, the cord must be
plugged into a mating, grounded 3 prong outlet, grounded in
accordance with all local cod es and ordinances. If a mating outlet
is not available, it is the customer' s responsibility to have a
properly grounded 3 prong outlet installed by a qualified electrical
component installer.
It is the customer' s responsibility:
To contact a qualified electrical installer, and
To assure that the electrical installation is adequate and in
conformance with National Electrical Code, ANSI/NFPA 70 -
latest edition, and all local codes and ordinances.
Copies of the standards listed may be obtained from:
National Fire Protection Association
One Batterymarch Park
Quincy, MA 02269
Power Supply Cord
NOTE: Your unit’s device may differ from the ones shown.
This room air conditioner is equipped with a power supply cord
required by UL. This power supply cord contains state-of-the-art
electronics that sense leakage current. If the cord is crushed, the
electronics detect leakage current and pow er will be
disconnected in a fraction of a second.
To test your power supply cord:
1. Plug power supply cord into a grounded 3 prong outlet.
2. Press RESET.
3. Press TEST (listen for click; Reset button will trip and pop
out).
4. Press and release RESET (listen for click; Reset button will
latch and remain in). The power supply cord is ready for
operation.
NOTES:
The Reset button must be pushed in for proper operation.
The power supply cord must be replaced if it fails to trip when
the test button is pressed or if it fails to reset.
Do not use the power supply cord as an off/on switch. The
power supply cord is designed as a protective device.
A damaged power supply cord must be replaced with a new
power supply cord obtained from the product manufacturer
and must not be repaired.
The power supply cord contains no user serviceable parts.
Opening the tamper-resistant case voids all warranty and
performance claims.
A. Reset button
B. Test button
TEST
TEST
RESET
RESET
A
A
B
B
5

7
Window Installation (on some models)
NOTES:
■Handle air conditioner carefully and gently.
■Be sure your air conditioner cabinet does not fall out of the
opening during installation or removal.
■The place where the power cord exits the air conditioner
should be no more than 4 ft (122 cm) from a grounded
3prongpower outlet.
■Do not block the louvers on the front panel.
■Do not block the louvers on the outside of the air conditioner.
Attach Top Channel
NOTE: Attach top channel and side curtains to air conditioner
cabinet before placing cabinet in window.
1. Locate provided bag of screws.
2. Place top channel on top of air conditioner cabinet, lining up
the 4 holes in top channel with the 4 holes on top of air
conditioner cabinet.
3. Using 4 - #10 x ³⁄₈" washer-head Phillips thread-cutting
screws, attach top channel to air conditioner cabinet.
Attach Side Curtains
1. Locate provided bag of screws.
2. Insert top and then bottom of right-hand curtain housing in
top and bottom curtain channels on air conditioner.
Top view
Bottom view
3. Extend right-hand curtain outward so you may insert the
first screw through the middle hole of the curtain. Using #10 x
¹⁄₄" pan-head Phillips screw, screw curtain to middle hole in
air conditioner cabinet.
NOTE: This screw is required to correctly attach curtain (top
to bottom) to the air conditioner cabinet.
4. While the right-hand curtain is still extended, insert #10 x ¹⁄₄"
pan-head Phillips screws into the top and bottom slots of
curtain. Screw curtain to the top and bottom holes in the air
conditioner cabinet side.
5. Slide the curtain housing into the curtain channels as far as it
will go.
6. Repeat above steps for the left-hand curtain.
Attach foam adhesive seal
Attach foam adhesive seal along the bottom of the curtain
bottom channel.
A. Top channel
B. #10 x
³⁄₈ " washer-head Phillips thread-cutting screws
A. Curtain housing
B. Curtain top channel on air conditioner
A
B
AB
A. Curtain housing
B. Curtain bottom channel on air conditioner
A. Curtain housing
B. Foam adhesive seal
A
B
A
B
7

7
