Adesso NuScan 4000 User manual

Light Source 650 nm Laser Diode
Depth of Field 400 mm
Scan Speed 100 scans / sec
Read Angle 38°
Radio Range (open area) 30 m
Communication Bluetooth 2.0 Compliant
Best Resolution 0.1 mm (4 mils) - Code 39
Memory size 1MB (Saves 75,000 sets EAN-13 Barcodes)
Print Contrast 45% or more
Indicators Green/Red LED & Beeper
Interface USB (RS232 Data Format), USB (HID)
Operational Specications:
Electrical Specications:
Environment Specications:
Physical Specications:
Supported Symbologies
Includes:
NuScan 4000
Scanner Cradle Holder
(2) AA NiMH rechargeable 1.2V battery
Quick Start Guide
Shipping Information:
Class II Bluetooth®
Wireless Technology
Each read scan instantly transfers your scanned data over
a range of 30m to your computer without the hassle
of cords.
Advanced Built-in Laser Engine
Direct Input
The 650 nm laser diode lets you scan with precision and
accuracy at an operating distance of 216 mm from the
barcode and will read up to 100 scans per second.
Your scans will automatically input data into common
applications such as MS Excel/Word when you have them
open, all without installing any software.
Superior Mobility
A lightweight and compact design perfect for on-the-go
scanning situations.
Wide Symbology Compatibility
Supports over 20 dierent kinds of barcode symbologies,
letting you scan multiple types of barcodes with one pass.
Cradle,Charger
& Receiver
Wide Symbology
Compatibility
Class II Bluetooth
®
Wireless Technology
NuScan 4000 783750004473 10
Item UPC Code Box Dimensions Box Wt. Qty/Ctn
NuScan TM 4000
Bluetooth Wireless Barcode Scanner
Cradle, Charger & Receiver
www.adesso.com
The3 inone cradle, charger and receiver helps extend battery
life and function as a stand for hands-free scanning.
Windows 8
Compatible
Whether it is hard-to-reach barcodes or a need for mobility,the
NuScan 4000 is a barcode scanner designed to simplify your job
and allow you to be more productive. Equipped with a Class
II Bluetooth receiver that provides a reliable 30m wireless data
transfer range, the lightweight scanner is perfect for warehouses
repair shops,factories, libraries and many other facilities.The
scanner’s laser diode scans at a rate of 100 scans per second
with precision and ease. The NuScan 4000 comes with a
patented cradle that helps extend battery life, giving you
enough power to do 25, 000 scans before another recharge is
necessary.
Battery Type AA NiMH rechargeable battery 1.2V x 2
(2.4 V 2500mAH)
Input Voltage 5 V DC ± 0.5 V
Charge Time 4 ~ 5 hours
Scans per Charge 15, 000 scans when fully charged
Regulation FCC Class B, CE, IEC60825 Class I
Operating Temperature 0° C to 50°C
Operating Humidity 10% to 85% relative humidity, non-condensing
Shock Resistance Withstand1.2 m drop on Concrete
Dimension (scanner only) 3.5 x 2.4 x 6.3” (90 x 60 x 160 mm)
Weight 0.34 lbs/155 g (for scanner), 0.5 lbs/225 g (for cradle)
Portable
Code 128, coda bar, interleave 25, Industrial 25, matrix 25, China postage,
UPC-A,UPC-E, EAN-13, EAN-8, code11, code 39, code 32, code 93, …
