Adesso NuScan 5000 User manual

Barcode Scanner
Model no. NuScan 5000
User’s Manual

FCC Compliance
This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user‘s authority to operate the
equipment.
Limited Warranty
No warranty of any kind is made in regard to this material, including,
but not limited to, implied warranties of merchantability or fitness for
any particular purpose. We are not liable for any errors contained herein
or for incidental or consequential damages in connection with furnishing,
performance or use of this material. We shall be under no liability in
respect of any defect arising from fair wear and tear, willful damage,
negligence, abnormal working conditions, failure to follow the
instructions and warnings, or misuse or alteration or repair of the
products without written approval.

1
Table of Contents
1. INTRODUCTION………………………………………………………2~3
2. INSTALLATION…………………………………………………………4~6
3. SET UP FROM BAR CODE LABEL…………………………………….7
Operating Settings……………………………………………………….8
Sensor Mode……………………………………………………………8~9
USB Country Keyboard Types………………………………..10~11
1D Symbologies On/Off…………………………………………12~14
2D Symbologies On/Off…………………………………………15~16
Symbologies Set Up……………………………………………..17~23
Termination String Setup Bar Codes…………………………….24

2
Introduction

3
NUSCAN 5000 barcode scanner, using 2D engine, combines the best
scanning performance and value. The device provides an accurate, easy,
and fast method of data entry and data storage for computerized
information systems. It is easy to install drivers to operate.
All the operating parameters are programmed by bar code programming
menu and stored in non-volatile RAM which can retain the settings after
power is turned off.
When a barcode is successful decoded, the blue LED light of the scanner
will turn on and off. The scanner will beep once.

4
Installation
Insert the plug on the free end of the Communications Cable into the
appropriate connector on the PC as below described:
USB cable Connection(USB HID):
Reset Configuration to Defaults
If you are unsure of the scanner configuration or have scanned the
incorrect codes, please scan the “Reset Configuration to Defaults”
barcode below. This will reset the scanner to its factory defaults settings
in USB interface.
1. Be sure that PC is turned OFF
2. Connect scanner cable to the USB port on the PC.
3. Ensure that all connections are secure. Turn on your PC.
4. And please operate the scanner under the right software application.
5. Aim the scanner at a barcode, ensure that the scanner is in trigger
mode (default), and press the trigger.
6. On successful decode, the blue LED light will turn on and off. The
scanner will beep once. And will show the barcode data on the
screen.

5
Reset Configuration to Defaults
If you are unsure of the scanner configuration or have scanned the
incorrect codes, please scan the “Reset Configuration to Defaults”
barcode. This will reset the scanner to its factory defaults settings.
** Code Programming ON
(Pro CMD : 0006010)
Load Factory Default
(Pro CMD : 0001160)
** Code Programming OFF
(Pro CMD : 0006000)

6
Operation
Tip
Do not hold the scanner directly over a barcode at 90˚. Scanning
light bounces directly back into the scanner from the barcode label
is known as specular reflection which will create a "dead zone"
where decoding is difficult. Practice a few times to find what range
of angles works best.
Maintenance
Cleaning the scan window is the only maintenance required. A
dirty window may affect scanning accuracy.
Wipe the scanner window gently with a lens tissue or other
material suitable for cleaning optical material.
Do not spray water or other cleaning liquids directly onto the
window.

7
Setup from Bar Code Label

8
** Code Programming ON
(Pro CMD : 0006010)
** Code Programming OFF
(Pro CMD : 0006000)
Operating settings
Trigger Mode
Auto-Sensing
Pro CMD : 0302000
Pro CMD : 0302010
Sensor Mode Timeout
Sensor
Mode
High Sensitivity (= 8)
Pro CMD : 0313000
Pro CMD : 0312020
Normal Sensitivity (= 11)
Low Sensitivity (= 14)
Pro CMD : 0312010
Pro CMD : 0312000
Enhanced Sensitivity (= 5)
Pro CMD : 0312030

9
** Code Programming ON
(Pro CMD : 0006010)
** Code Programming OFF
(Pro CMD : 0006000)
Allow Reading All = enable to
read all symbologies and
programming codes
Prohibit Reading All = allow reading
programming codes only.
Pro CMD : 0001020
Pro CMD : 0001010
Allow Reading All 1D
Prohibit ReadingAll 1D
Pro CMD : 0001040
Pro CMD : 0001030
Allow Reading All 2D
Prohibit ReadingAll 2D
Pro CMD : 0001060
Pro CMD : 0001050

10
USB Country Keyboard Types
The keyboard arrangements and country codes vary in different
countries. Refer country codes to the table “USB Country Keyboard
Types”. Follow the steps mentioned below to program.
1. “Code Programming ON”
2. “Select Country Code”
3. Read digit codes (according to country code)
4. “Save ”
5. “Code Programming OFF”
** Code Programming ON
(Pro CMD : 0006010)
** Code Programming OFF
(Pro CMD : 0006000)
Select Country Code
( Pro CMD : 1103000 )
Save
(Pro CMD：0000160)
Country/Language
Number
Country/Language
Number
U.S.
0
Netherlands(Dutch)
14
Belgium
1
Norway
15
Brazil
2
Poland
16
Canada(French)
3
Portugal
17
Czech
4
Romania
18
Denmark
5
Russia
19
Finland(Swedish)
6
Slovakia
21
France
7
Spain
22
Germany/Austria
8
Sweden
23
Greece
9
Switzerland(German)
24
Hungary
10
Turkey F
25
Israel(Hebrew)
11
Turkey Q
26
Italy
12
U.K
27
Latin-American
13
Japan
28

11
Digit Code
It is must to be read save after read digit code.
0
(Pro CMD : 0000000 )
5
(Pro CMD : 0000050 )
1
(Pro CMD : 0000010 )
6
(Pro CMD : 0000060 )
2
(Pro CMD : 0000020 )
7
(Pro CMD : 0000070 )
3
(Pro CMD : 0000030 )
8
(Pro CMD : 0000080 )
4
(Pro CMD : 0000040 )
9
(Pro CMD : 0000090 )

12
** Code Programming ON
(Pro CMD : 0006010)
** Code Programming OFF
(Pro CMD : 0006000)
1D Symbologies On/Off –1
CODE 39 ENABLE
CODE 39
CODE 39 DISABLE
Pro CMD : 0408020
Pro CMD : 0408010
ENABLE * Sign
DISABLE * Sign
CODE 93
Pro CMD: 0408090
Pro CMD: 0408080
CODE 93 - ENABLE
CODE 93 - DISABLE
Pro CMD : 0410020
Pro CMD : 0410010
CODE 128 - ENABLE
CODE 128
CODE 128 - DISABLE
Pro CMD : 0400020
Pro CMD : 0400010
CODABAR - ENABLE
CODABAR
CODABAR - DISABLE
Pro CMD : 0409020
Pro CMD : 0409010
INTERLEAVED 25 -
ENABLE
INTERLEAVED
25
INTERLEAVED 25 -
DISABLE
Pro CMD : 0405020
Pro CMD : 0405010

13
** Code Programming ON
(Pro CMD : 0006010)
** Code Programming OFF
(Pro CMD : 0006000)
1D Symbologies On/Off –2
UPC-A ENABLE
UPC/EAN
UPC-A DISABLE
Pro CMD : 0404020
Pro CMD : 0404010
UPC-E ENABLE
UPC-E DISABLE
Pro CMD : 0403020
Pro CMD : 0403010
EAN-8 ENABLE
EAN-8 DISABLE
Pro CMD : 0401020
Pro CMD : 0401010
EAN-13 ENABLE
EAN-13 DISABLE
Pro CMD : 0402020
Pro CMD : 0402010
EAN-128 ENABLE
UCC/EAN
EAN-128 DISABLE
Pro CMD : 0412020
Pro CMD : 0412010
ENABLE
Industrial 25
DISABLE
Pro CMD: 0417020
Pro CMD: 0417010
ENABLE
Matrix 25
DISABLE
Pro CMD: 0406020
Pro CMD: 0406010

14
** Code Programming ON
(Pro CMD : 0006010)
** Code Programming OFF
(Pro CMD: 0006000)
1D Symbologies On/Off –3
MSI Plessy ENABLE
MSI Plessy
MSI Plessy DISABLE
Pro CMD : 0420020
Pro CMD : 0420010
Code 11 ENABLE
Code 11
Code 11 DISABLE
Pro CMD : 0415020
Pro CMD : 0415010
ISBN ENABLE
ISBN
ISBN DISABLE
Pro CMD : 0416020
Pro CMD : 0416010
ENABLE
UCC/EAN
Composite
DISABLE
Pro CMD : 0414020
Pro CMD : 0414010

15
** Code Programming ON
(Pro CMD : 0006010)
** Code Programming OFF
(Pro CMD : 0006000)
2D Symbologies On/Off - 1
Data Matrix -ENABLE
Data Matrix
Data Matrix -DISABLE
Pro CMD : 0504020
Pro CMD : 0504010
**Forward Direction
Barcode Only
Both
Pro CMD: 0504320
Pro CMD:0504322
Backward Direction
Barcode Only
Pro CMD : 0504321
QR Code -ENABLE
QR Code
QR Code -DISABLE
Aztec -ENABLE
Aztec
Aztec -DISABLE
Pro CMD : 0503020
Pro CMD : 0503010

16
** Code Programming ON
(Pro CMD : 0006010)
** Code Programming OFF
(Pro CMD : 0006000)
PDF 417ENABLE
PDF 417
PDF 417 DISABLE
Pro CMD : 0501020
Pro CMD : 0501010
**Forward Direction Barcode
Only
Both
Pro CMD:0501320
Pro CMD:0501322
Backward Direction Barcode
Only
Pro CMD:0501321

17
** Code Programming ON
(Pro CMD : 0006010)
** Code Programming
OFF
(Pro CMD : 0006000)
Symbologies Set Up - 1
TRANSMIT UCC/EAN-8
CHECK –ENABLE
UPC/EAN -8
CHECK Digit
TRANSMIT
UCC/EAN-8
CHECK –DISABLE
Pro CMD : 0401040
Pro CMD : 0401030
TRANSMIT UCC/EAN-13
CHECK –ENABLE
UPC/EAN -13
CHECK Digit
TRANSMIT
UCC/EAN-13
CHECK –DISABLE
Pro CMD : 0402040
Pro CMD : 0402030
ISBN
Transmit 13 digits
Transmit
Transmit 10 digits
Pro CMD : 0416030
Pro CMD : 0416040
TRANSMIT UPC-E
CHECK –ENABLE
UPC-E
CHECK Digit
TRANSMIT UPC-E
CHECK –DISABLE
Pro CMD : 0403040
Pro CMD : 0403030
TRANSMIT UPC-A
CHECK –ENABLE
UPC-A
CHECK Digit
TRANSMIT UPC-A
CHECK –DISABLE
Pro CMD : 0404040
Pro CMD : 0404030

18
** Code Programming ON
(Pro CMD : 0006010)
** Code Programming OFF
(Pro CMD : 0006000)
Symbologies Set Up - 2
NO Check, Transmit All
Interleaved 25
CHECK Digit
Check, Transmit No
Check
Pro CMD : 0405050
Pro CMD : 0405060
Check, Transmit All
Pro CMD : 0405070
NO Check, Transmit All
Matrix 25
CHECK Digit
Check, Transmit No
Check
Pro CMD : 0406050
Pro CMD : 0406060
Check, Transmit All
Pro CMD : 0406070
Code 39 FULL ASCII
-ENABLE
CODE 39
FULL ASCII
Code 39 FULL ASCII
-DISABLE
Pro CMD : 0408110
Pro CMD : 0408100
NO Check, Transmit All
CODE 39
CHECK Digit
Check, Transmit No
Check
Pro CMD : 0408050
Pro CMD : 0408060
Check, Transmit All
Pro CMD : 0408070
