ADF Web HD67032M User manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 102 Page 1 of 26
User Manual
Revision 1 102
English
M-Bus - Repeater - Isolator
(Order Code: HD67032M, HD67032-B2-40, HD67032-B2-80,
HD67032-B2-160, HD67032-B2-250)
for Website information:
www adfweb com?Product=HD67032-B2-20
www adfweb com?Product=HD67032-B2-40
www adfweb com?Product=HD67032-B2-80
www adfweb com?Product=HD67032-B2-160
www adfweb com?Product=HD67032-B2-250
for Price information:
www adfweb com?Price=HD67032-B2-20
www adfweb com?Price=HD67032-B2-40
www adfweb com?Price=HD67032-B2-80
www adfweb com?Price=HD67032-B2-160
www adfweb com?Price=HD67032-B2-250
Benefits and Main Features:
Very easy to configure
Electrical isolation of M-Bus branches
Industrial temperature range: -40°C / 70°C (-40°F / 158°F)
For other M-Bus products see also the following link:
Converter M-Bus /
www adfweb com?Product=HD67021 (RS232)
www adfweb com?Product=HD67022 (RS4 5)
www adfweb com?Product=HD67030 (Ethernet)
M-Bus Analyzer - Scanner -Sniffer
www adfweb com?Product=HD67031
M-Bus / Modbus - Converter
www adfweb com?Product=HD67029M-232 (Modbus on RS232)
www adfweb com?Product=HD67029M-485 (Modbus on RS4 5)
M-Bus / Modbus TCP - Converter
www adfweb com?Product=HD67044
M-Bus / CANopen - Converter
www adfweb com?Product=HD67051-B2
M-Bus Master / PROFIBUS DP Slave - Converter
www adfweb com?Product=HD67053M
M-Bus - Concentrator - Datalogger
www adfweb com?Product=HD67054M
M-Bus Slave / Modbus Master - Converter
www adfweb com?Product=HD67059M-232
Do you have an your customer protocol? Then go to:
www adfweb com?Product=HD67003
Do you need to choose a device? Do you want help?
www adfweb com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 102 Page 2 of 26
INDEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLES OF CONNECTION 4
CONNECTION SCHEME 7
CHARACTERISTICS 8
CONFIGURATION 8
POWER SUPPLY 9
FUNCTION MODES 10
LEDS 11
M-BUS 12
ETHERNET 13
USE OF COMPOSITOR SW67032 14
NEW / OPEN CONFIGURATION 15
SOFTWARE OPTIONS 16
SET COMMUNICATION 17
UPDATE DEVICE (FOR HD67032M) 18
UPDATE DEVICE (FOR HD67032-B2-XXX) 19
DOWNLOAD CONF 21
MECHANICAL DIMENSIONS 22
ORDERING INFORMATIONS 23
ACCESSORIES 24
DISCLAIMER 25
OTHER REGULATIONS AND STANDARDS 25
WARRANTIES AND TECHNICAL SUPPORT 26
RETURN POLICY 26
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document
With this “Document Code” go to web page www adfweb com/download/
and search for the corresponding code on the page Click on the proper
“Document Code” and download the updates
REVISION LIST:
WARNING:
ADFweb com reserves the right to change information in this manual about
our product without warning
ADFweb com is not responsible for any error this manual may contain
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners
Revision Date Author Chapter Description
1 005 23/12/2013 Fl All Revision
1 100 15/12/2015 Ff All Added new hardware version
1 101 29/01/2016 Ff All Revision
1 102 03/07/2018 Ff All Revision

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 3 of 26
SECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual When using the device, legal and
safety regulation are required for each individual application The same applies also when using accessories
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i e
independent limit switches, mechanical interlocks, etc )
Q UALIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job
R ESIDUAL R ISKS
The device is state-of-the-art and is safe The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage
CE CONFORMITY
The declaration is made by our company You can send an email to support@adfweb com or give us a call if you need it

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 4 of 26
EXAMPLES OF CONNECTION:

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 5 of 26

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 6 of 26

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 7 of 26
CONNECTION SCHEME:
Figure
1
: Connection scheme for
HD67032
-
B2
-
x
x
x

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 8 of 26
CHARACTERISTICS:
The HD67032 series are M-Bus - Repeater- Isolator with the following features:
Electrical isolation of M-Bus branches;
Baud Rate and Parity changeable with software;
Mountable on 35mm DIN Rail;
Power Supply 15…21V AC or 18…35V DC;
Temperature range -40°C to 70°C
At the Gateway can be connected up to 250 standard M-Bus devices This number depends of the code expressed by the xxx number:
HD67032-B2-20 support up to 20 M-Bus devices;
HD67032-B2-40 support up to 40 M-Bus devices;
HD67032-B2-80 support up to 80 M-Bus devices;
HD67032-B2-160 support up to 160 M-Bus devices;
HD67032-B2-250 support up to 250 M-Bus devices
In the case of HD67032-B2-160 the device must be mounted on 35mm DIN rail which is horizontally mounted on a wall or cabinet
back-plate To avoid obstructions to the airflow around the unit it is recommended to not cover the paths of air It is recommended to put
the device into a ventilated cabinet
In the case of HD67032-B2-250 the device must be mounted on 35mm DIN rail which is horizontally mounted on a wall or cabinet
back-plate This unit have a fan in the top of the enclosure To avoid obstructions to the airflow around the unit it is recommended to not
cover the paths of air Take care to not cover the fan It is recommended to put the device into a ventilated cabinet
CONFIGURATION:
You need Compositor SW67032 software on your PC in order to perform the following:
Define the communication parameters of the M-Bus;
Update Firmware

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 9 of 26
Caution:
Do n
ot reverse the polarity power
POWER SUPPLY:
The devices can be powered at 15…21V AC and 18…35V DC The consumption depends to the code of the device For more details see the
two tables below
VAC
VDC
Vmin Vmax Vmin Vmax
15V 21V 1 V 35V
Consumption at 24V DC:
Device No Load [W/VA] Full Load [W/VA]*
HD67032-B2-20
3 5
4
HD67032-B2-40 5
HD67032-B2-80 8
HD67032-B2-160 14
HD67032-B2-250 30
* This value is with all the Slave M-Bus devices of the code (20, 40, 80, 160, 250) connected to the line
HD67032-B2-xxx

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 10 of 26
FUNCTION MODES:
The device has got two functions mode depending on the position of the ‘Dip1 of Dip-Switch A’:
The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device
The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for upload the Project
For the operations to follow for the updating, see ‘UPDATE DEVICE’ section
According to the functioning mode, the LEDs will have specifics functions, see ‘LEDS’ section

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 11 of 26
LEDS:
The HD67032-B2-xxx device has got five LEDs that are used to give information of the functioning status
The various meanings of the LEDs are described in the table below
LED Normal Mode Boot Mode
1: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
2: M-Bus Slave
communication (yellow) Blinks when correct M-Bus request is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: M-Bus Master
communication (yellow) Blinks when correct M-Bus response is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: Not used (yellow) OFF Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
5: Ethernet Link (green) ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 12 of 26
M-BUS:
The M-Bus is a unpolarized bus
A two wire standard telephone cable (JYStY N*2*0 8 mm) is used as the transmission medium for the M-Bus The maximum distance
between a slave and the repeater is 350m; this length corresponds to a cable resistance of up 29Ω This distance applies for the standard
configuration having Baud rates between 300 and 9600 Baud, and a maximum of 250 slaves The maximum distance can be increased by
limiting the Baud rate and using fewer slaves, but the bus voltage in the space state must at no point in a segment fall below 12V, because
of the remote powering of the slaves In the standard configuration the total cable length should not exceed 1000m, in order to meet the
requirement of a maximum cable capacitance of 180nF (Taken from M-Bus specifics)

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 13 of 26
ETHERNET:
The Ethernet port is used for programming the device
The Ethernet connection must be made using Connector2 of HD67032-B2-xxx with at least a Category 5E cable The maximum length of the
cable should not exceed 100m The cable has to conform to the T568 norms relative to connections in cat 5 up to 100 Mbps To connect the
device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a
cross cable

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 14 of 26
USE OF COMPOSITOR SW67032:
To configure the Converter, use the available software that runs with Windows called SW67032 It is downloadable from the site
www adfweb com and its operation is described in this document (this manual is referenced to the last version of the software present on our
web site) The software works with MSWindows (XP, Vista, Seven, 8; 10; 32/64bit)
When launching the SW67032, the window below appears (Fig 2)
Note:
It is necessary to have installed Net Framework 4
Figure 2: Main window for SW67032

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 15 of 26
NEW CONFIGURATION / OPEN CONFIGURATION:
The “New Configuration” button creates the folder which contains the entire device’s configuration
A device’s configuration can also be imported or exported:
To clone the configurations of a Programmable “M-Bus – Repeater - Isolator” in order
to configure another device in the same manner, it is necessary to maintain the folder
and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 16 of 26
SOFTWARE OPTIONS:
By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor
In the section “Language” it is possible to change the language of the
software
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb com website
Checking the option “Check Software Update at Start of Program”, the
SW67032 check automatically if there are updatings when it is launched

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 17 of 26
SET COMMUNICATION:
This section define the fundamental communication parameters of the M-Bus buses
By Pressing the “Set Communication” button from the main window for SW67032 (Fig 2) the
window “Set Communication” appears (Fig 3) The window is divided in two sections
In the section “Hardware Type” it is possible to define the hardware used:
HD67032M;
HD67032M-40/80/160/250;
HD67032-B2
The means of the fields for “M-Bus” are:
In the field “Baudrate” it is possible to select the baud rate of the M-Bus lines;
In the field “Parity” it is possible to select the parity of the lines
The means of the fields for the “Ethernet” section are (only for HD67032-B2):
In the fields “IP ADDRESS” insert the IP address that you want to give to the Converter;
In the fields “SUBNET Mask” insert the SubNet Mask;
In the fields “GATEWAY” insert the default gateway that you want to use This feature can be
enabled or disabled pressing the Check Box field This feature is used for going out of the net
These informations are used for programming the Converter
Figure 3: “Set Communication” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 18 of 26
UPDATE DEVICE (for HD67032M-20):
By pressing the “Update Device” button it is possible to load the created Configuration into the
device, and also the Firmware if is necessary, using the RS232 port
In order to load the parameters or update the firmware in the device, follow these instructions:
Turn OFF the Device;
Connect the RS232 cable from your PC to the Converter;
Insert Jumper1;
Select the “COM port” and press the “Connect” button;
Turn on the device;
Check the “Device state” Led It must blink quickly (see “LEDS” section);
Press the “Next” button;
Select which operations you want to do
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK” turn off the device;
Remove Jumper1;
Disconnect the RS232 cable;
Turn ON the device
Figure 4: “Update via Serial” windows

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 19 of 26
UPDATE DEVICE (for HD67032-B2-xxx):
By pressing the “Update Device” button, it is possible to load the created Configuration into the
device; and also the Firmware, if necessary
If you don’t know the actual IP address of the device you have to use this procedure:
Turn off the Device;
Put Dip1 of ‘Dip-Switch A’ in ON position;
Turn on the device
Connect the Ethernet cable;
Insert the IP “192.16 .2.205”;
Press the “Ping” button, “Device Found! must appear”;
Press the “Next” button;
Select which operations you want to do;
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK” turn off the Device;
Put Dip1 of ‘Dip-Switch A’ in OFF position;
Turn on the device
At this point the configuration/firmware on the device is correctly updated
If you know the actual IP address of the device, you have to use this procedure:
Turn on the Device with the Ethernet cable inserted;
Insert the actual IP of the Converter;
Press the “Ping” button, must appear “Device Found!”;
Press the “Next” button;
Select which operations you want to do;
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK” the device automatically goes at Normal Mode
Figure 5: “Update via UD ” windows

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
M
-
Bus
–
Repeater
–
Isolator
Document code: MN67032_ENG Revision 1 100 Page 20 of 26
Figure 6: “ rotection” window
Note:
When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67032
device
Note:
When you receive the device, for the first time, you also have to update the Firmware in
the HD67032 device
Warning:
If Fig 6 appears when you try to do the Update try these points before seeking
assistance:
Check if the serial COM port selected is the correct one;
Check if the serial cable is connected between the PC and the device;
Try to repeat the operations for the updating;
If you are using a USBRS232 converter try with a native COM port or change the
converter;
Try to repeat the operations for the updating;
Try with another PC;
Try to restart the PC;
Check the LAN settings;
If you are using the program inside a Virtual Machine, try to use in the main
Operating System;
If you are using Windows Seven, Vista, 8 and 10 make sure that you have the administrator privileges;
In case you have to program more than one device, using the "UDP Update", you have to cancel the ARP table every time you
connect a new device on Ethernet For do this you have to launch the "Command Prompt" and write the command "arp -d" Pay
attention that with Windows Vista, Seven, 8 you have to launch the "Command Prompt" with Administrator Rights;
Pay attention at Firewall lock
In the case of HD67032 you have to use the software “SW67032”: www adfweb com\download\filefold\SW67032 zip
