LT -3060 LED Power Repeater 第1
LT-3060
LED Power Repeater
Manual
Pls kindly read through this manual before use

LT -3060 LED Power Repeater 第2
，Foreword，
Thanks for choosing our LT-3060 LED Power Repeater. Before installation
and usage, we strongly recommend you to read through this manual
carefully.
，After-sales service，
From the day you purchase our products within a year, if being used
properly in accordance with the instruction, and quality problems occur, we
provide free repair or replacement services except the following cases:
1. Any defects caused by wrong operations.
2. Any damages caused by unauthorized removal, maintenance,
modifying circuit, incorrect connections and replacing chips.
3. Any damages due to transportation, vibration etc after the purchase.
4. Any damages caused by earthquake, fire, lightning strike, pollution
and abnormal voltage.
5. Any damages caused by negligence, inappropriate storing at high
temperature and humidity environment or near harmful chemicals.
6. Product has been updated.
，Safe warnings，
1. Please don’t install this controller in lightening, intense
magnetic and high-voltage fields.
2. To reduce the risk of component damage and fire
caused by short circuit, make sure correct connection
3. Always be sure to mount this unit in an area that
will allow proper ventilation to ensure a fitting temperature.
4. Check if the voltage and power adapter suit the controller & if anode or
cathode definition is the same as the controller’s.
5. Don’t connect cables with power on, make sure a correct connection
and no short circuit checked with instrument before power on.
6. Please don’t open controller cover and operate if problems occur.
For update information, kindly please consult with your supplie

LT -3060 LED Power Repeater 第3
Product Introduction
LED Power Repeater is suitable for all of our company's
power-output style controllers’ power expansion, it accepts PWM
control, the control quantity will be twice as much by every
adding one more power repeater, unlimited quantity of
power repeater to be connected theoretically.
Ⅰ. Specification
Part No ：LT -3060
Power Input
DC5V-DC24V
Working Temp：
-35℃－55℃
OutputCurrent：:
5A/CH×3
Dimension：
L121×W39×
H39(mm)
Consumption：
＜2W
Package size：
L123×W42×
H42(mm)
Output Power：
1～75W(5V)
Weight(G.W.)
100g
1～180W(12V) 1～360W(24V)
Ⅱ. Features
1、3 Channels RGB output, 5A/CH, total 15A.
2、Accept PWM control.
3、Unlimited connection quantity theoretically, unlimited
power output expansion.
4、Unlimited distance between controller to repeater, repeater
to repeater theoretically.
Ⅲ. Product label

LT -3060 LED Power Repeater 第4
Ⅳ. Dimension

LT -3060 LED Power Repeater 第5
Ⅴ.Conjunction diagram,the quantity of repeater connected is
unlimited theoretically.
1.Take LED module for example,repeaters are all parallel
connected to controller.
2.DMX decoder connected to constant voltage power repeater as
follows:

LT -3060 LED Power Repeater 第6
3.Power repeater connected to LED wall dimmer as follows:

LT -3060 LED Power Repeater 第7
Ⅵ. Exception handles
Fault Case
Reasons
Solutions
No light
1. No power from plug
2. At black mode
3. Overload Recovery
4. Incorrect connection
1 Change the socket
2. Change the running mote
3 Lighten load, react
4 Check the connection
Incorrect Color
No Synchronous
5. Wrong RGB connection
6 Wrong Sync Cable
Connection
5 Check RGB connection
6 Check Sync cable
connection
