Black Box CityLAN 100 Series User manual

CityLAN 100 SERIES
LONG DISTANCE FDDI REPEATER
FEBRUARY 1999
LCL163A
LCL163A-48
LCL163A-R
LCL164A
LCL164A-2MIC
LCL164A-48
Order toll-free in the U.S. 24 hours, 7 A.M. Monday to midnight Friday: 877-877-BBOX
FREE technical support, 24 hours a day, 7 days a week: Call 724-746-5500 or fax [phone]
Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com · E-mail: [email protected]
CUSTOMER
SUPPORT
INFORMATION
Multimode A Singlemode B
Alarm Line State Alarm Line State
Multimode B Singlemode A
Alarm Line State Alarm Line State Class 1
Laser
Port B
Port A
Tx Rx Tx RxMultimode
Repeater 1 Repeater 2

LONG DISTANCE FDDI REPEATER
2
FEDERAL COMMUNICATIONS COMMISSION
AND
CANADIAN DEPARTMENT OF COMMUNICATIONS
RADIO FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio frequency energy and if
not installed and used properly, that is, in strict accordance with the
manufacturer’s instructions, may cause interference to radio communication. It
has been tested and found to comply with the limits for a Class A computing
device in accordance with the specifications in Subpart J of Part 15 of FCC
rules, which are designed to provide reasonable protection against such
interference when the equipment is operated in a commercial environment.
Operation of this equipment in a residential area is likely to cause interference,
in which case the user at his own expense will be required to take whatever
measures may be necessary to correct the interference.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise
emission from digital apparatus set out in the Radio Interference Regulation of
the Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant
les limites applicables aux appareils numériques de la classe A prescrites dans
le Règlement sur le brouillage radioélectrique publié par le ministère des
Communications du Canada.

LONG DISTANCE FDDI REPEATER
3
NORMAS OFICIALES MEXICANAS (NOM)
ELECTRICAL SAFETY STATEMENT
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas
antes de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para
referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de
operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo,
cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca,
etc.
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales
que sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más
allá a lo descrito en las instrucciones de operación. Todo otro servicio
deberá ser referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama,
sofá, alfombra o superficie similar puede bloquea la ventilación, no se
debe colocar en libreros o gabinetes que impidan el flujo de aire por los
orificios de ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor
como radiadores, registros de calor, estufas u otros aparatos (incluyendo
amplificadores) que producen calor.

LONG DISTANCE FDDI REPEATER
4
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del
tipo descrito en el instructivo de operación, o como se indique en el
aparato.
12. Precaución debe ser tomada de tal manera que la tierra fisica y la
polarización del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no
sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen
del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las
lineas de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no
sea usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su
desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

LONG DISTANCE FDDI REPEATER
5
CERTIFICATION NOTICE FOR
EQUIPMENT USED IN CANADA
The Canadian Department of Communications label identifies certified
equipment. This certification means that the equipment meets certain
telecommunications-network protective, operation, and safety requirements. The
Department does not guarantee the equipment will operate to the user’s
satisfaction.
Before installing this equipment, users should ensure that it is permissible to be
connected to the facilities of the local telecommunications company. The
equipment must also be installed using an acceptable method of connection. In
some cases, the company’s inside wiring associated with a single-line individual
service may be extended by means of a certified connector assembly (extension
cord). The customer should be aware that compliance with the above conditions
may not prevent degradation of service in some situations.
Repairs to certified equipment should be made by an authorized Canadian
maintenance facility—in this case, your supplier. Any repairs or alterations made
by the user to this equipment, or equipment malfunctions, may give the
telecommunications company cause to request the user to disconnect the
equipment.
Users should ensure for their own protection that the electrical ground
connections of the power utility, telephone lines, and internal metallic water pipe
system, if present, are connected together. This precaution may be particularly
important in rural areas.
CAUTION:
Users should not attempt to make such connections
themselves, but should contact the appropriate electric
inspection authority, or electrician, as appropriate.
The LOAD NUMBER (LN) assigned to each terminal device denotes the
percentage of the total load to be connected to a telephone loop which is used
by the device, to prevent overloading. The termination on a loop may consist of
any combination of devices, subject only to the requirement that the total of the
load numbers of all the devices does not exceed 100.

LONG DISTANCE FDDI REPEATER
6
Contents
Chapter Page
1. Technical Specifications.............................................................8
2. Product Overview.....................................................................10
2.1 Drive Distance.......................................................................................10
2.2 Station Count.........................................................................................10
2.3 Power Supply ........................................................................................10
2.4 Ergonomics ...........................................................................................10
2.5 Contact Alarms......................................................................................11
2.6 Management Interface...........................................................................11
3. Typical Applications .................................................................13
4. Installation................................................................................16
4.1 Operating Modes...................................................................................16
4.1.1 Mode 1 - Direct Terminal Connection...............................................................................16
4.1.2 Mode 2 - Remote Terminal Connection (dial in)...............................................................17
4.1.3 Mode 3 - Remote Terminal Connection (dial out).............................................................17
4.1.4 Mode 4 - Remote Controller Device.................................................................................18
4.2 Step by Step Installation........................................................................19
4.3 Installation Testing.................................................................................21
4.3.1 Transmitter Power Tests ..................................................................................................21
4.3.2 Single-mode Media Test (inter LCL163A/LCL164A units only)........................................23
5. Diagnostic LEDs.......................................................................26
5.1 Dual Repeater .......................................................................................26
5.2 Single Repeater.....................................................................................27
6. Management Serial Interface...................................................28
6.1 Hardware Configuration.........................................................................30
6.2 Software Configuration ..........................................................................30
6.2.1 Whole Screen Mode.........................................................................................................31
6.2.2 Command Mode ...............................................................................................................33
6.3 Field Definitions and Use.......................................................................34
6.3.1 Password (editable)..........................................................................................................34
6.3.2 Serial Number (editable)...................................................................................................34

LONG DISTANCE FDDI REPEATER
7
6.3.3 Location (editable) ............................................................................................................34
6.3.4 Self Test............................................................................................................................35
6.3.5 Display Modes (editable)..................................................................................................35
6.3.6 Redundant PSU................................................................................................................35
6.3.7 Port Status........................................................................................................................35
6.3.8 Line State..........................................................................................................................36
6.3.9 Power Alarm State............................................................................................................37
6.3.10 Single-mode Media Test...................................................................................................38
6.3.11 Connected to: (editable) ...................................................................................................38
6.3.12 Operating Mode................................................................................................................39
6.3.13 Hayes Modem Init. String (editable) .................................................................................39
6.4 Serial Port..............................................................................................40
6.5 Alarm Reporting.....................................................................................40
6.6 Contact Alarms......................................................................................42
7. Power and Fuses.....................................................................43
8. Troubleshooting .......................................................................45
9. Appendix I: Management Cable Pinouts..................................47
10.Appendix II: Example Test Result Sheet –Dual Repeater......48
11.Appendix III: Example Test Result Sheet – Single Repeater.49
12.Glossary of Terms...................................................................50
Figures
Figure 1: LCL163A/LCL164A Front and Rear Panels.......................................12
Figure 2: Linking Three Buildings around a City Using LCL163A/LCL164A
Extended Distance Repeaters...........................................................13
Figure 3: Linking a Central Office to a Remote Site..........................................14
Figure 4: M-Port Link from Concentrator to Single LCL163A............................15
Figure 5: Management Hardware Configurations .............................................29
Figure 6: Contact Closure Pins........................................................................42
Figure 7: DC Power Input ................................................................................44
Figure 8: Management Cable Pinouts..............................................................47

LONG DISTANCE FDDI REPEATER
8
1. Technical Specifications
BIT ERROR RATE 2.5 x 10-10 (max)
CONNECTORS Multimode Duplex SC Connector (fitted as standard)
FDDI MIC (optional)
Single-mode FC or SC
LINK LENGTHS Multimode 2km
Single-mode 60km SC (High Power Option)
40km FC and SC (Standard Power Options)
OPTICAL POWER BUDGET
Multimode 62.5/125µm fiber 12.5dB
Single-mode 9/125µm fiber 19dB (FC Standard Power
Option)
19dB (SC Standard Power
Option)
30dB (SC High Power
Option)
OPTICAL OUTPUT POWER Min. Max.
Multimode FDDI MIC (2km) -19dBm -14dBm
Duplex SC (2km) -18.5dBm -14dBm
Single-mode FC (Standard
Power) -12dBm -7dBm
SC (Standard
Power) -15dBm -8dBm
SC (High Power) -4dBm 0dBm
OPTICAL INPUT POWER Min. Max.
Multimode FDDI MIC (2km) -31dBm -14dBm
Duplex SC (2km) -31dBm -14dBm
Single-mode FC (Standard
Power) -31dBm -14dBm
SC (Standard
Power) -34dBm -8dBm
SC (High Power) -34dBm -3dBm

LONG DISTANCE FDDI REPEATER
9
Wavelength 1300nm
ENVIRONMENT Temperature Operating 0οC to 40οC
Storage -10οC to 70οC
Humidity Max 95% (non-condensing)
COMPLIANCE EMC CE DIRECTIVE 89/336/EEC
FCC Part 15 Subpart J
Safety CE DIRECTIVE 73/23/EEC
UL1950, cUL1950
CASE DIMENSIONS 1U high, 19” rackmountable
483mm x 165mm x 43mm (W x L x H)
POWER SUPPLY 90 to 264V @ 47 to 63Hz or 35-60V DC
POWER CONSUMPTION Less than 15W (51 BTU/hr)
CONTACT CLOSURES 30V, 1A DC (Max.); 120V, 0.5A AC (Max.)

LONG DISTANCE FDDI REPEATER
10
2. Product Overview
The BLACK BOXCityLANFDDI Extended Distance Repeater
(LCL163A/LCL164A) supports 100Mbps ANSI X3T9.5/X3T12 data over greatly
extended distances on single-mode fiber.
2.1 Drive Distance
On the multimode side the LCL163A/LCL164A repeaters support a distance of
2km. The single-mode interface supports a 40km drive distance as standard.
With high power SC optics on the single-mode interface, a distance of 60km is
obtainable.
2.2 Station Count
Any number of repeaters can be used within a network. The only constraint
being that each device is included in the total station count for the overall ring.
Each repeater has 4 physical layer entities. There is a re-timing function on each
port, therefore each repeater is considered as 2 stations. The default value for
the number of physical layer entities on a ring is 1,000, i.e. 500 Dual Attach
Stations (DAS).
2.3 Power Supply
The unit is powered using a nominal 100V-240V-AC supply (+/- 10%). The
power supply is universal across all acceptable input voltage ranges.
A 48V-DC power supply is available as an order time option.
2.4 Ergonomics
The dual repeater is housed in a standard 19”, 1U high rackmount case (165mm
deep) for optimum use of rack space.
Variants of the CityLANFDDI repeaters are available as single and dual
repeaters. Dual repeaters (LCL164A) support the connection of a DAS via two
fiber pairs. The single repeater (LCL163A) supports an SAS connection. The
units are all functionally the same and two single repeaters are functionally the
same as a single dual repeater.

LONG DISTANCE FDDI REPEATER
11
2.5 Contact Alarms
The unit has dry contact alarms to report failure conditions. These operate as
normally open and normally closed contacts. See Section 6.5, Alarm Reporting,
for details.
2.6 Management Interface
A serial management interface provides out-of-band control and management
of the LCL163A/LCL164A, either via modem or via a direct VT100 terminal
attachment. See Chapter 6, Management Serial Interface.

LONG DISTANCE FDDI REPEATER
12
Figure 1: LCL163A/LCL164A Front and Rear Panels
LCL163A/LCL164A REAR PANEL
LCL163A/LCL164A FRONT PANEL
Multimode A Singlemode B
Alarm Line State Alarm Line State
Multimode B Singlemode A
Alarm Line State Alarm Line State Class 1
Laser
Port B
Port A
Tx Rx Tx RxSinglemode
Repeater 1 Repeater 2
STATUS LEDS MULTIMODE OPTICS
Monitor Port
Tx Rx Tx Rx
Port A Port B
FAN
CONTACT
CLOSURES
RS232
MANAGEMENT INTERFACE
POWER INPUT
SOCKET
Singlemode

LONG DISTANCE FDDI REPEATER
13
3. Typical Applications
Figure 2: Linking Three Buildings around a City using LCL163A/LCL164A
Extended Distance Repeaters
In the above application, several local sites are interconnected using
LCL163A/LCL164As. Two of the A and B ports of the multimode local rings are
connected to the multimode A and B ports of the LCL163A/LCL164A. This
extends the ring via the single-mode fiber to each of the other sites, where they
are returned to multimode A and B interfaces for connection to that backbone.
MultimodeA Singlemode B
Alarm LineState Alarm LineState
MultimodeB SinglemodeA
Alarm LineState Alarm LineState Class 1
Laser
Port BPort A
Tx Rx Tx RxMultimode
Repeater1 Repeater2
MultimodeA Singlemode B
Alarm LineState Alarm LineState
MultimodeB Singlemode A
Alarm LineState Alarm LineState Class 1
Laser
Port B
Port A
Tx Rx Tx RxMultimode
Repeater1 Repeater 2
MultimodeA Singlemode B
Alarm LineState Alarm LineState
MultimodeB Singlemode A
Alarm LineState Alarm LineState Class 1
Laser
Port B
Port A
Tx Rx Tx RxMultimode
Repeater1 Repeater 2
Private Redundant FDDI Backbone.
Each Link can be up to 40km
Private FDDI Backbone
Private FDDI Backbone
Private FDDI Backbone
LCL164A
LCL163A/LCL164A
LCL163A/
LCL164A
Dual Attach Router

LONG DISTANCE FDDI REPEATER
14
Figure 3: Linking a Central Office to a Remote Site
MultimodeA Singlemode B
Alarm LineState Alarm Line State
MultimodeB Singlemode A
Alarm LineState Alarm Line State Class 1
Laser
Port B
Port A
Tx Rx Tx RxMultimode
Repeater 1 Repeater 2
Router
USER SITE
MultimodeA Singlemode B
Alarm LineState Alarm Line State
MultimodeB Singlemode A
Alarm LineState Alarm Line State Class 1
Laser
Port B
Port A
Tx Rx Tx RxMultimode
Repeater 1 Repeater 2
Dual Attach Router
LCL164A
Multimode to
Singlemode Repeater
CENTRAL OFFICE
LCL163A
Multimode to
Singlemode Repeater
Citywide FDDI Backbone
Local FDDI Backbone
Up to 40km
Singlemode
Link
Out Of Band
Serial Management
to Remote Site
VT100
In this application, the single attach ports of the routers are inter-connected
using two LCL163A repeaters. The router port is simply connected to either
multimode port (i.e. A or B). The corresponding single-mode fiber is taken to
either port of the far end LCL163A which in turn is connected to the router via
the corresponding multimode ports. For dual homing connections, dual
LCL164A repeaters may be used by simply connecting each port of the router to
the A and B ports via the single-mode fibers to the far end A and B ports and
subsequently to the multimode M-ports of a concentrator.

LONG DISTANCE FDDI REPEATER
15
Figure 4: M-Port Link from Concentrator to a Single LCL163A
Multimode A Singlemode B
Alarm Line State Alarm Line State
Multimode B Singlemode A
Alarm Line State Alarm Line State Class 1
Laser
Port B
Port A
Tx Rx Tx RxMultimode
Repeater 1 Repeater 2
Router
USER SITE
CONCENTRATOR
CENTRAL OFFICE
LCL163A
Multimode to
Singlemode Repeater
Citywide FDDI Backbone
Local FDDI Backbone
Up to 40km
Singlemode Link
Out Of Band
Serial Management
to Remote Site
VT100
Multimode Ports
Connected Locally
to FDDI Backbone
Singlemode Ports
Connected Remotely to
LCL163A
In this application the Single Attach Station port of the router is connected to the
single-mode M-Port of the concentrator via one LCL163A (single version). The
multimode Single Attach Station Port of the router connects to the multimode
port on the LCL163A. The single-mode port of the LCL163A connects directly to
the single-mode M-Port of the concentrator.

LONG DISTANCE FDDI REPEATER
16
4. Installation
4.1 Operating Modes
For the LCL163A/LCL164A to operate correctly in a ring the Test Switch fitted
on the back panel must be set to the Normal position. The LCL163A/LCL164A
needs no further configuration to operate simply in a ring. However, for
maximum efficiency of alarm reporting over extended distances, four
management operating modes are available.
1) Direct Terminal Connection.
2) Remote Terminal Connection (dial in).
3) Remote Terminal Connection (dial out).
4) Remote Controller Device using simple asynchronous commands to
gather information from the LCL163A/LCL164A.
In all operating modes, dry contact alarms can be configured to indicate error
conditions.
4.1.1 Mode 1 - Direct Terminal Connection
This is the factory default configuration.
The RS232 cable supplied with the LCL163A/LCL164A allows connection of a 9
way serial port of a PC or laptop to the LCL163A/LCL164A. The PC should
have a VT100 style terminal emulator loaded which requires the following
configuration:
9600 baud
8 bits
1 stop bit
No parity
XON/XOFF flow control.
After power on, the terminal displays the self-test sequence followed by the main
screen showing status information for the LCL163A/LCL164A.
To connect an unattended Auto Answer Modem to the LCL163A/LCL164A in
terminal mode, please NOTE: At start up LCL163A/LCL164A sends the
initialization string “ATQ1&D2&S1&C1”.

LONG DISTANCE FDDI REPEATER
17
This sets the modem to Quiet Mode, uses DTR, DSR and DCD. If you require
that the modem be capable of being dialed into after a power down of the
modem, it is vital that you configure the modem to 9600 Baud, Auto Answer held
permanently in its own memory. Check your modem user manual for details of
setting the modem into unattended auto answer mode.
When configured to “Terminal” the LCL163A/LCL164A makes no use of DCD or
DSR. DTR is always asserted.
To return to this mode from any mode, connect the terminal and press “CTRL_
Z”, followed by “CTRL_L”.
4.1.2 Mode 2 - Remote Terminal Connection (dial in)
Dial in access to the LCL163A/LCL164A is made using modems and a remote
VT100 or PC emulating a VT100 terminal. Figure 5 shows a typical link.
To connect the modem to the LCL163A/LCL164A, use a standard 25 way
straight through serial cable.
Configure the modem to 9600 Baud, Auto Answer, Enabled DTR. Other control
lines are not required. NOTE: The LCL163A/LCL164A sends an initializer string
to the modem on power up, as described in Mode 1.
At the remote site the VT100/PC emulator is connected to the remote modem.
See the VT100/PC manual for the cable required to connect to that modem.
For dial in access it is suggested that you use a Hayes compatible modem. The
“Connected To” management field should be set to “modem” which will send the
initializer string to the modem each time a critical event is to be reported as well
as on power up. See Section 6.3.11 for details of the “Connected To” field.
Dial in access is commonly used with the dry contact alarms that indicate a
condition to a control center which subsequently dials into the unit to ascertain
the nature of the alarm. See “Alarm Reporting” in Section 6.5 for details of
contact devices.
4.1.3 Mode 3 - Remote Terminal Connection (dial out)
For those systems where direct dial out access is required, the unit may be
configured to dial a remote location via a Hayes compatible modem whenever a
fault condition occurs.

LONG DISTANCE FDDI REPEATER
18
Configure the modem to 9600 Baud, Monitor DTR.
The LCL163A/LCL164A will automatically request use of Data Set Ready and
Carrier Detect of the Hayes modem, whenever a critical event is to be reported,
by using the “&D2&S1&C1” control string.
Using a directly attached terminal (see Mode 1 above) and referring to Section
6.3, configure the LCL163A/LCL164A “Connected To” field to “Modem” and
include the telephone number of the remote site in the “Modem Init String”, in
the form “D <number to dial>” e.g.: Modem Init String ATD 123 456 789.
Set the events that you require the modem to dial out on. See “Alarm
Reporting” in Section 6.5. Save the changes as you leave edit mode.
NOTE: Once saved these choices, including phone numbers etc., are held in
non-volatile memory within the LCL163A/LCL164A. Consequently problems
with borrowed or swapped modems are avoided.
Attach the modem using a 25 way straight through cable.
The LCL163A/LCL164A will dial out whenever one of the “Alarm” conditions
occurs. If the far end is busy or unavailable, the LCL163A/LCL164A will retry at
minute intervals until the call is answered.
4.1.4 Mode 4 - Remote Controller Device
To permit a remote device to interrogate the LCL163A/LCL164A, a simple
control interface is included that permits a remote station to be programmed to
poll the LCL163A/LCL164A for specific information on a Command/Response
basis sent line by line.
To use the command mode, attach a terminal as described in Mode 1 above and
edit the Display Mode to be line by line.
In this mode, the LCL163A/LCL164A can be directly attached to the device or a
terminal or connected to via a modem for dial in or out access as described in
Modes 1, 2 and 3.

LONG DISTANCE FDDI REPEATER
19
4.2 Step by Step Installation
1. Decide on the operating mode that best suits the system (see Operating
Modes).
2. Attach a PC running a VT100 emulator using the cable supplied. Set the
VT100 to 9600 baud, 8 bits, 1 stop bit, no parity, XON/ XOFF flow control.
3. Using the terminal emulator, edit the LCL163A/LCL164A configuration to
support:
a) Chosen operating mode.
b) Alarm conditions.
See Section 6, Management Serial Interface for details of how to edit the
LCL163A/LCL164A fields.
4. Check the loss budgets for the single-mode and multimode interfaces. Use
the table below to check the required maximum and minimum losses for
each link versus connector/product type.
Connector Type Receiver
Saturation
Minimum Loss between
LCL163A/LCL164 as (to
avoid saturation)
Maximum Loss
(Link Budget)
Multimode MIC -14dBm 012dB
Multimode SC -14dBm 012.5dB
Single-mode FC
(Standard Power) -14dBm 7db 19dB
Single-mode SC
(Standard Power) -8dBm 0dB to like device or 8dB
to High Power remote
device
19dB
Single-mode SC
(High Power) -3dBm 3dB 30dB
If the link loss is less than the minimum required or if the received power
from the remote equipment is greater than the receiver saturation figures,
then optical attenuators must be used.

LONG DISTANCE FDDI REPEATER
20
5. Fasten the LCL163A/LCL164A into a rack or place on a suitable shelf.
Check that the ventilation holes in the sides of the unit and the fan vent on
the back of the box are not covered.
Do NOT power up the units at this stage.
6. Connect the single-mode interface ensuring that clean single-mode jumpers
are used. Refer to the connection guide below.
7. Connect the multimode interface ensuring that clean multimode jumpers are
used. Refer to the connection guide below.
Connect the fiber between adjacent dual repeaters as follows:
Single-mode Fiber Link Connections (Dual Repeater)
This LCL164A Far End LCL164A
Single-mode Port A Rx Single-mode Port B Tx
Single-mode Port A Tx Single-mode Port B Rx
Single-mode Port B Rx Single-mode Port A Tx
Single-mode Port B Tx Single-mode Port A Rx
Connect the fiber between adjacent single repeaters as follows:
Single-mode Fiber Link Connections (Single Repeater)
This LCL163A Far End LCL163A
Single-mode Port Rx Single-mode Port Tx
Single-mode Port Tx Single-mode Port Rx
Connect the fiber on the multimode side between the LCL163A/LCL164A and
the DAS as follows:
