ADInstruments CODA MONITOR User manual

Quick Start
Get set up and start recording
ADINSTRUMENTS
CODA® MONITOR

Copyright © ADInstruments Pty Ltd, 2000 - 2022. All rights reserved. LabChart is a registered trademark
of ADInstruments Pty Ltd. CODA is a registered trademark of Kent Scientic. All other trademarks are
the property of their respective owners.
Overview
www.adinstruments.com
Document Number: 6781-B
This guide will help you to quickly set up the ADInstruments CODA®
Monitor with LabChart soware and its corresponding Device Enabler
that allows the CODA®Monitor to stream data into LabChart.
This document was, as far as possible, accurate at the time of release.
However, changes may have been made to the soware and hardware it
describes since then. ADInstruments Pty Ltd reserves the right to alter
specications as required. Late-breaking information may be supplied
separately.

Installation
Install Soware
1 Ensure that LabChart for Windows 8.1.18 or later is installed, prior to
installing ADInstruments CODA® Monitor Device Enabler. LabChart
soware can be downloaded through the ADInstruments website:
https://www.adinstruments.com/support/labchart#soware-downloads
2 Install the ADInstruments CODA® Monitor Device Enabler via
• USB pen drive (supplied with any Rodent NIBP CODA Monitor Set)
connected to your computer’s USB drive.
• Using the Feature Manager in LabChart soware and ensuring
that it is enabled.
• Or by downloading the latest CODA® Monitor Device Enabler from
Soware Downloads on the ADInstruments website:
https://www.adinstruments.com/support/labchart#soware-downloads
3 Exit LabChart soware.

Conscious Animal Preparation
1 Place the corresponding CODA NIBP Rodent Holder on the infrared
warming pad. You can use the disposable warming pad covers to
prevent soiling the warming pad.
2 Place both RightTemp sensors (pad and body temperature probes)
beneath the rodent holder. Secure the sensors if necessary.
3 Allow the rodent to freely enter the CODA NIBP Rodent Holder with
its tail extending beyond the hatch of the holder.
4 Slide the corresponding Occlusion Cu and then Volume Pressure
Recording (VPR) Cu onto the tail of the animal. They should t
closely, but still be able to slide freely along the tail.
5 Place a blanket over the setup if required, ensuring that the animal
still has access to breathable air.
6 Allow the animal to acclimatize. Ensure that the animal has
acclimated to the holder and that the tail temperature has reached
35-37 degrees Celsius before taking any measurements.
Anesthetized Animal Preparation
1 Prepare the infrared warming pad. You can use the disposable
warming pad covers to prevent soiling the warming pad.
2 Place the anesthetized animal on the warming pad.
3 Place and secure the RightTemp pad sensor beneath the animal.
4 Insert the RightTemp body sensor into the rectum of the animal.
Secure the sensor if necessary.
5 Slide the corresponding Occlusion Cu and then VPR Cu onto the
tail of the animal. They should t closely, but still be able to slide
freely along the tail.
Usage

Hardware Setup
ADInstruments
CODA®Monitor
Rodent NIBP CODA
RightTemp Sensor
Far Infrared Warming Pad
(203 x 254 mm)
USB
from VPR Cu Sensor
from Occlusion Cu
Power Supply
from Animal
from Pad
Rodent NIBP CODA
RightTemp Sensor

Recording Setup
1 Connect the ADInstruments CODA®Monitor to the computer via
supplied USB cable.
2 Connect the leads of the Occlusion Cu, VPR Cu Sensor, RightTemp
sensors and warming pad to the ADInstruments CODA®Monitor.
3 Connect the ADInstruments CODA®Monitor to mains power via
supplied power cable.
4 The ADInstruments CODA®Monitor will turn on with its touchscreen
displaying a start display that is on standby until successful
recognition by LabChart soware.
5 Double click on LabChart icon to open LabChart soware.
6 Wait for LabChart’s device scan to successfully recognised the
CODA® Monitor, which is represented by a green tick next to CODA®
Monitor.
7 Select the CODA®Monitor device and click the OK button.
8 Open a New document in LabChart soware, which will
automatically setup ten recording channels in Chart View.
Usage

9 You should also see that the touchscreen automatically changes to
its default recording display with START button in its center.
10 Further setup details can be made via the Menu and Warm buttons
on the touch screen display, which includes:
• Animal type • Deation time
• Interval • Set parameter ranges
• Temperature setup • CODA®Monitor Tests
11 Return back to the default recording display once all the desired
changes are conrmed.
12 You can start recording by rst clicking the Chart View Start button
in LabChart soware and then pressing Start on the ADInstruments
CODA®Monitor touch screen.
13 The button will automatically change to a STOP button allowing you
to stop measurements at any time.
