ADIR ADIKI200 Series User manual

Multi-Tiered
USER GUIDE
ADIKI200-SERIES
Book
Display

AdirKids commits to delivering
safe and quality children’s products.
We pride ourselves on creating uniquely exquisite products for your children that they
will enjoy for many years to come. Furnishing your child’s room or classroom can be
expensive and stressful, but we’ll help make the process affordable and stress-free.
Every product is designed to the highest standards, with safety being the top priority,
and we offer a broad range of aesthetics, ensuring to t your classroom or child’s style.
Plus, our expert team makes sure everything you need works as efciently as possible.
Thank you
for your
purchase.

1 Parts and Hardware
3 Assembly Instructions
11 Limited Warranty
12 Disclaimer
Table of Contents

1
Parts and Hardware
Top Support Panel (x1)
Left/Right Side Panel (x2)
Front and Back Bottom Support
Cross-Panel (x2)
Shelf Support Track (x6) Bottom Shelf Back Panel (x4)
Top Shelf Back Panel (x1) Back Panel (x2)
A B
C
D E
F G
Parts:

2
H1: Cam Lock Bolt (x24)
H2 : Cam Lock (x24) Screw (x20)
Side Panel Screw Cap (x20)
Tack Glide (x4)
Nail (x22)
Parts and Hardware
H I
J
L
K
Hardware:
Tools Required (But Not Included)
• Screwdriver
• Hammer
H1 H2

3
Assembly Instructions
STEP 1
A. Take a Bottom Shelf Back Panel (E) and insert 4 Cam Lock Bolts (H1) into the pre-drilled holes.
B. Take a Shelf Support Track (D) and insert 4 Cam Locks (H2) into the pre-drilled holes.
C. Connect the Bottom Shelf Back Panel (E) to the Shelf Support Track (D) and tighten all the
Cam Locks (H2).
D. Repeat this for the remaining 3 Bottom Shelf Back Panels (E) and the Shelf Support Tracks (D).
E
D
H1
H2

Assembly Instructions
4
STEP 2
A. Locate the Front and Back Bottom Support Cross-Panel (C) and insert 4 Cam Lock Bolts (H1)
into the pre-drilled holes.
B. Take a Shelf Support Track (D) and insert 4 Cam Locks (H2) into the pre-drilled holes.
C. Connect the Back Bottom Support Cross-Panel (C) to the Shelf Support Track (D) and tighten
all the Cam Locks (H2).
D. Repeat this for the second Back Bottom Support Cross-Panel (C) and the Shelf Support
Tracks (D).
C
D
H1
H2

5
Assembly Instructions
STEP 3
A. Take the two assembled structures from Step 2 and connect them with the Right-Side
Panel (A) using the included Screws (I).
B. Tighten the Screws (I) with a screwdriver and then place 4 Side Panel Screw Cap’s (J) into
the pre-drilled holes.
I
J
A
C
C

6
Assembly Instructions
STEP 4
A. Slide the Bottom Shelf Back Panel (E), and Shelf
Support Track (D) assembled structure, with the
Shelf Support Track (D) facing inward, as pictured.
B. Insert a Screw (I), tighten with a screwdriver, and then
place a Side Panel Screw Cap (J) into the pre-drilled
hole, as pictured.
I
J
E
D
D

7
STEP 5
A. Repeat Step 4 for the remaining assembled structures of Bottom Shelf Back Panel
(E) and Shelf Support Track (D).
B. Insert a Screw (I) into each hole, tighten with a screwdriver, and then place a Side
Panel Screw Cap (J) into the pre-drilled holes, as pictured.
C. Slide the Top Shelf Back Panel (F) into the Shelf Support Track (D).
Assembly Instructions
I
J
F
E

8
STEP 6
A. Slide the Top Support Panel (B) over the Top Shelf
Back Panel (F).
B. Insert two Screws (I) into each hole to secure the
Top Support Panel (B), tighten with a screwdriver,
and then place two Side Panel Screw Cap’s (J)
into the pre-drilled holes, as pictured.
Assembly Instructions
I
B
J
F

9
Assembly Instructions
STEP 7
A. Attach the Left-Side Panel (A) to the assembled structure and fasten 10 Screws (I)
into the pre-drilled holes. Insert 10 Side Panel Screw Cap’s (J) into the pre-drilled
holes, as pictured.
I
J
F

10
Assembly Instructions
STEP 8
A. Attach both Back Panels (G) to the assembled structure using the 22 included
Nails (K) with a hammer.
B. Turn the structure upside down and attach the included 4 Tack Glides (L) to each
corner of the literature display structure.
K
L
G
G

11
Limited Warranty
1. AdirCorp (the company) warrants to the purchaser that the product will be free from
defects in workmanship and materials for a period of one (1) year from the date of
purchase.
2. These warranties are not assignable or transferable to any other person.
3. Any damage to the product as a result of misuse, tampering, abuse, neglect, accident,
improper installation, modification, unauthorized service, destruction, or the alteration of
the serial number, or use violate of the instructions furnished by the Company will void this
warranty.
4. The sole responsibility of the Company shall be limited to the repair or replacement (in its
sole discretion) of any component of the product which fails to conform to this warranty at
no cost to the purchaser for the period of the warranty.
5. Contact the Company directly to obtain service under this warranty. If it becomes
applicable to send a defective product to the Company, a Return Authorization Number
must first be obtained from the company. In order to obtain service under this warranty,
purchaser must provide the Company with the following items (a) proof of purchase, (b)
police or fire department report, (c) photographs of damaged sad, and (d) written
testimonial.
6. Products shipped without prior Return Authorization and Return Authorization Number may
not be accepted, and the Company will not be responsible for their disposition and/or cost
of return to the owner.
7. The Company will not assume any responsibility for any loss or damage incurred in ship-
ping. All return authorized products should include a copy of the original invoice in order
that this warranty may be Honored.
8. This warranty is not an insurance policy. The Company is not responsible for any manner of
damage to or theft of the Purchaser’s product or its contents.
9. We recommend that the product being returned is accompanied by the sales receipt with
all relevant information regarding the purchase of the item and is returned to the Company
within ten (10) days of the claim date of purchase to validate this warranty.
10. Any implied warranties that the purchaser may have are limited to the duration of the
warranties described above. There are no further warranties that extend or apply beyond
the face hereof, and the company expressly disclaims and excludes any and all warranties
of merchantability or fitness for a particular purpose. Some states do not allow limitations
on how long an implied warranty lasts, so the above limitation may not apply to you.
11. Repair or replacement shall be the sole remedy for the purchaser under this warranty. The
company shall not be liable for any direct, indirect, incidental or consequential damages,
losses or expense arising from the use or misuse of the product. Some states do not allow
the exclusion or limitations of incidental or consequential damages, so the limitation may
not apply to you.
12. This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.

12
Disclaimer
By purchasing products from AdirCorp, the user agrees as follows:
TO THE MAXIMUM EXTENT PERMITTED BY LAW, THE PRODUCTS AND INFORMATION
ON THIS SITE IS PROVIDED “AS IS” AND WITH ALL FAULTS AND ADIRCORP. MAKES NO
PROMISES, REPRESENTATIONS, OR WARRANTIES, EITHER EXPRESS, IMPLIED, STATUTORY,
OR OTHERWISE, WITH RESPECT TO THE PRODUCTS AND INFORMATION, INCLUDING
ITS CONDITION, ITS CONFORMITY TO ANY REPRESENTATION OR DESCRIPTION, OR
THE EXISTENCE OF ANY LATENT OR PATENT DEFECTS, AND ADIRCORP. SPECIFICALLY
DISCLAIMS ALL IMPLIED (IF ANY) WARRANTIES OF TITLE, MERCHANTABILITY, NON
INFRINGEMENT, FITNESS FOR A PARTICULAR PURPOSE, ACCURACY OR COMPLETENESS,
QUIET ENJOYMENT, AND QUIET POSSESSION. THE ENTIRE RISK ARISING OUT OF USE OR
PERFORMANCE OF THE PRODUCTS AND INFORMATION LIES WITH USER.
TO THE MAXIMUM EXTENT PERMITTED BY LAW, IN NO EVENT SHALL ADIRCORP PRODUCTS
OR ITS SUPPLIERS BE LIABLE FOR CONSEQUENTIAL, INCIDENTAL, SPECIAL, INDIRECT, OR
EXEMPLARY DAMAGES WHATSOEVER ARISING OUT OF OR IN ANY WAY RELATING TO THIS
AGREEMENT OR USER’S USE OF OR INABILITY TO USE THE PRODUCTS AND INFORMATION,
OR THE PROVISION OR FAILURE TO PROVIDE SUPPORT SERVICES, INCLUDING, BUT
NOT LIMITED TO, LOST PROFITS, LOSS OF CONFIDENTIAL OR OTHER INFORMATION,
BUSINESS INTERRUPTION, PERSONAL INJURY, LOSS OF PRIVACY, FAILURE TO MEET
ANY DUTY (INCLUDING OF GOOD FAITH OR REASONABLE CARE), NEGLIGENCE, COSTS
OF PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES, OR ANY OTHER CLAIM FOR
PECUNIARY OR OTHER LOSS WHATSOEVER, OR FOR ANY CLAIM OR DEMAND AGAINST
USER BY ANY OTHER PARTY, EVEN IF ADIRCORP HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. THESE LIMITATIONS SHALL APPLY NOTWITHSTANDING ANY FAILURE OF
ESSENTIAL PURPOSE OF ANY LIMITED REMEDY.
NOTWITHSTANDING ANY DAMAGES USER MAY INCUR FOR ANY REASON WHATSOEVER
(INCLUDING, WITHOUT LIMITATION, ALL DAMAGES REFERENCED ABOVE AND ALL DIRECT
OR GENERAL DAMAGES), THE ENTIRE LIABILITY OF ADIRCORP AND ANY OF ITS SUPPLIERS
UNDER ANY PROVISION OF THIS AGREEMENT AND YOUR EXCLUSIVE REMEDY FOR ALL
OF THE FOREGOING SHALL BE LIMITED TO THE GREATER OF THE AMOUNT ACTUALLY
PAID FOR THE PRODUCTS AND INFORMATION OR U.S. $1. THE FOREGOING LIMITATIONS,
EXCLUSIONS, AND DISCLAIMERS SHALL APPLY TO THE MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW, EVEN IF ANY REMEDY FAILS ITS ESSENTIAL PURPOSE.
If any provision of this Agreement is declared invalid or unenforceable, the remaining provisions
of this Agreement will remain in effect. AdirCorp has the right to modify these terms and
conditions at any time.

13
