ADJUSTME TDH3 User manual

[email protected] | www.adjustme.eu | © 3/2019 by ADJUSTME | All rights reserved | A part of Group 1
Data sheet for TDH3
Normal operation
• TDH3 is connecting to control box. Press any button. 3-digits display shows current desk height in centimeters.
• Press or button to adjust the desk height.
• When no button has been pressed for 10 seconds, display goes off. Press any button to light up the display again.
• When no button has been pressed for 30 seconds, the system goes to <0.1 W standby mode. Long press any button
to wake the system up. Display shows desk height again.
Reset
• Press both and buttons at the same time for 3 seconds. Continue pressing the buttons until both columns
are in lowest position. When finish reset, the control box makes a beep and the buttons can be released.
• When conducting reset, the display shows ”000” in last 100mm stroke. When finish reset, the display shows
starting height again.
• If releasing and buttons before the display shows ”000”, the desk goes back to normal operation.
If releasing and buttons after the display shows ”000”, the user has to finish the reset to go back to
normal operation.
• Reset is necessary at first operation of the desk.
Memory position
• TDH3 supports 3 memory positions.
1. Operate the desk to preferred height and then press S for 2 sec and the digital display will start to flashing for 3 sec.
2. Press any of and the display will show P1, P2 or P3 when position has been stored.
3. Now, hold any of the buttons until the desk reaches the stored height.
• Stored postion can only be overwritten, not to be cleared.

[email protected] | www.adjustme.eu | © 3/2019 by ADJUSTME | All rights reserved | A part of Group 2
Data sheet for TDH3
Drawing
Standard dimension (mm)

[email protected] | www.adjustme.eu | © 3/2019 by ADJUSTME | All rights reserved | A part of Group 3
Data sheet for TDH3
Programming of your highest / lowest position
NB: The setting of your highest / lowest position will be overruled during reset:
During reset the desk will go to lowest position configured by factory.
After reset the desk will remember your settings of highest/lowest position.
Setting new highest position:
1. Press and buttons together for a sec.
2. Release button – meaning you still press button
3. Press 3 times
4. You will hear a “beep” - Done
Setting new lowest position:
1. Press and buttons together for a sec.
2. Release button – meaning you still press button
3. Press 3 times
4. You will hear a “beep” - Done
Cancel new highest position:
1. Go to the position you have set as your highest position.
2. Press both and buttons at the same time for 1-2 seconds (less than 3 seconds) and release
3. After app. 5 seconds the control box makes 1 beep to confirm that programmed highest position has been
cancelled and button can be released.
Cancel new lowest position:
1. Go to the position you have set as your lowest position.
2. Press both and buttons at the same time for 1-2 seconds (less than 3 seconds) and release
3. After app. 5 seconds the control box makes 1 beep to confirm that programmed lowest position has been
cancelled and button can be released.
