ADOR AD-Allure User manual

SAVE THESE INSTRUCTIONS
OPERATION INSTRUCTIONS
AD-Allure MASSAGE CHAIR

01
TABLE OF CONTENTS
Thanks for purchasing this product. Please read this manual instruction carefully in
order to know how to use this product correctly before operation. Please pay more
attention to some important safety warning and keep this manual book properly for
future use.
Note: Our Company reserves the right to revise the design and description of this
product without any further notice. Please refer to the actual color of this product.
02-03
04-06
07
08-09
10-11
12-39
12
12-31
32-33
34
35
35
35-36
37
38
38
39
40
Safety and Maintenance
Safety Warning
Name of Components
Function
Introduction to the Remote Controller
Method of Usage
I.Turn on the power supply of this product
II.Massage Function Control Operation
III.Introduction to Armrest Shortcut Keys
IV.Voice Control Mode
V.Operation Instructions for Bluetooth Speaker Play
VI.Turn off the power and stop massage
VII.Installation Instructions for Armrests
VIII.nstallation Instructions for Legrest
IX.Instructions for Removal and Use of Head Cushion and Backrest
X.Floor Protection
XI.Instruction for Movement
Product Specification

0302
Safety and Maintenance Safety and Maintenance
1.Important Safety Warnings
·Do not allow children to touch any movable part of this product.
·Use the well-grounded power supply unit suitable for this product.
·Pull out the plug after use or before cleaning to avoid any physical injury or damage to
the product.
·Operate this product as instructed in this manual.
·Do not use any parts or accessories which are not recommended.
·Do not use this product outdoors.
·Please read the Operation Instructions carefully before operation.
·Never use this product for any other purpose not listed herein.
·20 minutes of usage each time is recommended.
·Do not use this product if the leather is broken or damaged.
·Do not use this product if the cover or leather is broken or damaged.
·Do not use this product if the radiator hole is covered or blocked.
·Do not drop anything into this product.
·Never fall asleep while using this product.
·Do not use this product if you are drunk or feel unwell.
·Do not use this product within one hour after a meal.
·Do not use this product with excessive force to avoid any injury.
·Do not carry any fragile, explosive, or combustible material in your pocket, such as a
mobile phone and lighter when using the massage chair.
2. Operating Environment
·Do not use this product in a very moist environment such as the bathroom.
·Stop using this product immediately when the ambient temperature changes sharply.
·Do not use this product in any heavily-dusty or caustic environment.
·Do not use this product in a small space or a place without good ventilation.
·The normal room temperature ranges from 0 °C to 35 °C.
·Do not use this product in an excessively humid room such as a bathroom. Use it at a
relative humidity between 20% and 80%.
·Do not use this product outdoors.
·Avoid direct sunlight.
·Keep this product away from any heat source such as a stove and air outlet of an air
conditioner.
·Do not use this product during thunder or lightning weather.
·Do not use this product in dusty places.
3. The following populations should not use this product:
·Patients with osteoporosis.
·Patients with heart disease or wearing electronic medical devices such as a
pacemaker.
·People who have a fever.
·Pregnant women or women on their menstrual period.
·Patients who are injured or have a skin disease.
·When unsupervised, any children are under the age of 14 and those unconscious are
not allowed to use this product.
·People who are told by their physicians to have rest or who feel unwell.
·People whose bodies are wet are forbidden to use this product.
·This product has a hot surface. Persons insensitive to heat must pay attention when
using this product.
4. Safety Precautions
·Check whether voltage is consistent with the specification of this product.
·Never insert or pull out the plug with a wet hand.
·Do not let water flow into this product to avoid electric shock or cause damage to this
product.
·Do not pull the power cord when plugging or unplugging it. Rough handling is
forbidden.
·Do not damage the wire or modify the circuit of this product.
·Do not clean live parts of this product with a wet cloth such as a power switch and plug.
·Be away from this product in case of power failure to avoid any injury if power is
restored suddenly.
·Stop using this product at once while it works abnormal, and consult your local supplier.
·Stop using this product if you feel unwell, and consult your health care practitioner.
·This product is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning the use of this product by
the personnel responsible for their safety. Children should be supervised to ensure that
they do not play with this product.
·If the power cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified staff in order to avoid hazards.
5. Product Service and Maintenance
·This product should be maintained by the service center designated by the
manufacturer only. No user should disassemble or maintain it without permission.
·Do not forget to turn off the main power switch after usage.
·Do not use this product if the power socket becomes loose.
·If this product will be left unused for a long period of time, it is necessary to roll up the
power cord of this product and store this product in a dry and dust-free environment.
·Do not store this product at a high temperature or near open flame. Avoid prolonged
exposure to direct sunshine.
·Please clean this product with dry cloth. Never use thinner, benzene or alcohol.
·The mechanical components of this product are specially designed and manufactured,
so no special maintenance is needed.
·Do not use a sharp object to stab at this product.
·Do not roll or pull this product on any uneven ground. Instead, it should be lifted before
moving.
·Please use this product intermittently. Do not keep it working continuously for a long
period of time.
6. Solutions to Ordinary Malfunctions
·If the motor sounds during operation of this product, this is the normal operation sound.
·If the controller cannot work normally, check whether the plug and the power socket are
connected reliably, and whether the power switch is turned on.
·If the rated working time is over, this product will automatically activate the power-off
button; If this product keeps operating for a long period of time, the temperature
protector will stop this product automatically. The product can be used again after half
an hour.
7. Storage Conditions
·Storage room temperature: -5 °C to 35 °C.
·Relative humidity (RH) between 20% and 80%; free of corrosive gases, and a well-
ventilated room.

0504
Safety Warning Safety Warning
Warning Warning
When the legrest of the massage chair is lifted, nobody should apply pressure on
the legrest to prevent the massage chair from falling forward which will damage this
product or result in personal injuries.
Do not remove or pull out the remote controller cable or the power cord in the
standby or power-on state to avoid any damage to this product or accidental electric
shock of a body part. You are advised to unplug the remote controller cable and the
power cord and put them away after you use the massage chair.
Warning
Before sitting on the massage chair, make sure that the massage chair manipulator
does not stay in the seat cushion position to avoid discomfort to the buttocks during
the body pressing down and any damage to the massage chair manipulator.
Warning
When the zero-gravity lying function is enabled, be sure to check whether there is
any child or pet staying or playing under the bottom of the legrest and backrest, in
order to avoid any damage to this product or physical injury.
No downward pressure

06 07
1
2
3
5
8
16
21
12
22
9
18
20
14
15
17
6
7
19
10
13
11
4
Safety Warning
Warning
Before using the massage chair, remove any hard objects in your pocket(s) or any
jewelry carried with you (e.g. key, watch, other similar portable hard objects) to
avoid any damage to this product or physical injury during massage.
Warning
Do not unplug the power cord, or directly turn off the power switch on the back of
the massage chair during massage, in order to avoid any damage to this product or
physical injury.
Name of Components
1. Head cushion
2. 3D digital audio
3. Upper arm airbag
component
4. Back airbag component
5. Arm airbag component
6. Remote controller
placement slot
7. Salient massage hand
with magnetic therapy
8. Seat cushion
9. Legrest
10. Backrest
11. Armrest shortcut key
12. Wireless phone charger
13. Armrest
14. LED atmosphere lamp
15. Side cover
16. Backrest cover
17. Remote controller
18. PSU back cover
19. Lockable wheel
20. Power cord and plug
21. Switch
22. Mains input
POWE R INPU T
ON/ OFF

0908
and right upper arms. The Bluetooth function of the smart device can be used to
play music wirelessly.
·The wireless charging function of the mobile phone is available at the left armrest
shortcut key. The mobile phone can be placed on the fixed wireless charging.
·The left armrest is equipped with an AUTO key, a voice control button for wakeup
(it is only effective when the voice control switch in the remote controller is turned
on), a back heat treatment switch, a leg UP key, a leg DOWN key, a linkage lying
key, a linkage sitting key, a 3D massage intensity knob, ON/OFF (pause) key and
other shortcut keys.
·In the air bags for the left and right palms, there are salient massage with magnetic
therapy function.
·Leg stretching massage function: the lower legs and backrest can be lifted and
lowered for automatic lying, as well as automatic cyclic lying. Meanwhile, the leg
air bags and the back manipulator simultaneously cooperate with each other for
massage, and the legs can be stretched for massage.
·This product is equipped with the leg kneading massage function: the kneading
and airbag squeezing massage functions are provided on the leg rest to relieve the
stiffness or tension of the leg muscles caused by standing for a long period of time.
·This product is equipped with the salient scraping massage for the calf: It can
relieve fatigue, tightness, and pain of the calf muscles, effectively promote the
blood circulation, massage meridians, effectively improve the stiffness or tension of
the leg muscles, and relieve local swelling and restore vitality.
·The massage chair is equipped with the independent up/down adjustment function
of the leg rest and the backrest, the linkage up/down adjustment function of the
backrest, and the zero-gravity automatic lying angle adjustment function.
·The foot roller massage function is available for the feet bottoms. Three sets of
rollers roll to massage the roots of the toes; rolling and scraping massage is
available for the foot arch; there are three speed levels for adjustment.
·The leg rest is equipped with the adjustment function, so linkage extension and
retraction are possible for the feet and legs; when the legs are pulled out with the
pedals, the legs will rise (the opposite direction to the feet) together with the
stretching of the feet. The stretching length of the feet relies on the length of the
user's legs. The extension length of the legs is half of the stretching length of the
feet, and the retraction of the feet and legs depends on the spring force.
·The left and right armrests are equipped with LED atmosphere lamps.
·Such functions as shutdown, automatic sitting up, and automatic manipulator
resetting are available.
·The product has a remote controller with TFT color screen.
·The head cushion uses the two section foldable design, and you can decide the
number of layers upon your own request to reduce the massage intensity of the
neck and shoulder. The head cushion can extend to the back to reduce the
massage intensity of the back. This is suitable for different users and can be
selected freely.
·This product is designed with a set of intelligent 3D massage manipulators with
silent design that can move up and down and extend from front to back.
·It is designed with automatic detection and micro-adjustment functions of the
shoulder position, as well as automatic detection function of the human body curve
and shiatsu massage points. Therefore, according to the detected human body
curve and shiatsu massage points, it can automatically adjust the manipulators to
extend from front to back, making the massage more user-friendly and scientific.
·21 special automatic massage functions are available: fast massage, comfortable
massage, relaxing massage, stretching massage, full body massage, neck &
shoulder massage, back & waist massage, and full airbag massage, Stress
relieving, Energy, Good-night sleep, Joint care, Spine massage, Office regimen,
Sport recovery, Neck & shoulder care, Brain refresh, Spine care, Waist care, Legs
care and Rejuvenation.
·There are five intelligent memory functions (M1, M2, M3, M4, M5): Remarks on
saved massage functions and techniques are available (e.g. father, mother,
daughter, son, or none).
·Manual massage range selection is available for the manipulators: including five
massage ranges for your option (i.e. full range, local, fixed point, upper back and
lower back).
·Manual massage function selection is available for the manipulators: 11 massage
techniques are available, including kneading(Seven modes of kneading can be
switched cyclically), tapping (Tapping I, Tapping II), simultaneous kneading and
tapping, shiatsu (Shiatsu I, Shiatsu II), shoulder lifting, 3D (3D I, 3D II, 3D III, 3D
IV), etc.
·Massage adjustment function: 7 massage adjustment functions are available,
including 5 speed levels for back massage adjustment, 5 intensity levels for back
massage adjustment, 5 range levels for massage adjustment, 5 width levels for
massage adjustment, 5 intensity levels for airbag adjustment, 3 speed levels for
roller adjustment, 4 time levels for massage adjustment.
·Airbag massage function for the upper body: airbag massage function for the arms
(8 built-in air bags), airbag massage function for the upper arms (4 built-in air
bags), airbag massage function for the waist (4 built-in air bags), and 5 intensity
levels for airbag adjustment.
·Airbag massage function for the lower body: airbag massage function for the legs
(6 built-in air bags), airbag massage function for the feet (22 built-in air bags), and
5 intensity levels for airbag adjustment.
·This product is equipped with the back heat treatment function: carbon fiber is
used as a far infrared heat source.
·The slide rail technology for the backrest ensures zero space between the
backrest and wall, so as to save the space to the greatest extent.
·The backrest guide adopts the curve guide technology, so it completely fits the
curve of the human back. The full body can enjoy full massage from the head to
the thighs.
·This product is equipped with the intelligent voice control and recognition function
(i.e. built-in voice-activated microphone for the left armrest shortcut key).
·The music player system is available. 3D digital audio systems are built into left
FunctionFunction

1110
1.Display:
·TFT color LCD showing the massage functions in the running state.
2.Switch:
·Turn on or off the massage.
3.AUTO key:
·Enter the automatic function mode selection interface. For more information about the
functions, refer to Page 16 of the Operation Instructions.
4.Zero-gravity key:
·Adjust the angle of the massage chair for zero gravity. There are a total of four modes
to choose from (i.e. 1st pressing is Level 1; 2nd pressing is Level 2; 3rd pressing is
Level 3; and 4th pressing makes the massage chair restore to the original state).
5.Up key:
·Up navigation key: select an object upward in the menu, or adjust the massage position
upward.
6.OK:
·Confirm the selected massage function for massage.
7.Left button:
·Left navigation key: return to the previous menu, or select an object leftwards.
8.Down key:
·Down navigation key: select an object downward in the menu, or adjust the massage
position downward.
9.Backrest up button:
·Adjust the backrest upward according to your own massage needs for the most
comfortable massage posture.
10.Legrest Up key:
·Adjust the legrest upward according to your own massage needs for the most
comfortable massage posture.
11.Legrest down key:
·Adjust the leg rest downward according to your own massage needs for the most
comfortable massage posture.
12.Backrest down button:
·Adjust the backrest downward according to your own massage needs for the most
comfortable massage posture.
13.Pause button:
·Pause all the massage functions currently in service. Press this button again to
continue to run all the massage functions before such pause.
14. Menu button:
·Enter the main menu selection interface. For more information about the functions, refer
to Page 15 of the Operation Instructions.
15.Right button:
·Right navigation key: enter the submenu, or select an object rightwards.
16.Linkage sitting key:
·According to the required massage angle, simultaneously adjust the linkage sitting
function of the backrest and the leg rest for the most comfortable linkage sitting
massage posture.
17.Linkage lying key:
·According to the required massage angle, simultaneously adjust the linkage lying
function of the backrest and the leg rest for the most comfortable linkage lying massage
posture.
Introduction to the Remote Controller Introduction to the Remote Controller
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1

II. Massage Function Control Operation:
1312
1.Standby
30:00
Fast massage
Auto program 30:00
00:00
Method of UsageMethod of Usage
I. Turn on the power supply of this product:
·After the massage chair is powered on and turned off,
the remote controller is blank in the standby state (i.e.
the LED lamp is off) and cannot perform any operation
(except the key switch). You can use the armrest shortcut
keys to adjust the angle of the backrest and leg rest. You
can also use the voice control button for wakeup.
2.Start massage (power switch)
·Press the switch to start massage. Enter the start-up screen. The backrest will
maintain the default position, and the leg rest will be slightly raised. Just wait for
any one of automatic function programs in the automatic function selection
interface to start massage. If no "AUTO" function is selected within 5 minutes, the
massage chair will automatically shut down.
1) Lying angle adjustment
·After selecting any automatic function, the positions of the backrest and the leg
rest will be adjusted to the preset angles.
· After the angle is adjusted, the massage chair will automatically perform the
shoulder position and body shape detection. Wait for completion of such detection
(alternatively, press "OK" to skip the step).
2) Shoulder position adjustment
·After detecting the shoulder position, the buzzer will beep. If there is any difference
from the actual shoulder position, adjust it to the appropriate position by pressing
the "UP" or "DOWN" key. The shoulder position has 11 adjustable levels. If there is
no shoulder position adjustment within 10 seconds, the massage function will start
automatically. Press "OK" directly to start massage immediately. If no shoulder
position can be detected, massage will be started according to the shoulder height
by default. Note: During massage, under the information interface, you can press
"Right Button" to select the "Shoulder Adjustment" menu, and press "OK" to enter
the shoulder adjustment interface. You can also use "Up Key" or "Down Key" to
adjust the shoulder position.
Comfort massage
Select the object with ▲▼ and press OK
Relax massage
Stretch massage
Full body massage
Meck&shoulder massage
Auto lying down
Attention! Ensure that there
are no objects around the
massage chair
Press OK to skip
Body sensing
Just a moment......
Press OK to skip
Auto Mode
Fast massage>
Knead
Back speed Back intensity
Upper air Roll speed
Adjustment Shoulder
Select the object with ◀▶ and press OK
30:00
Shoulder position
Please use ▲▼ to adjust the shoulder position and press OK
·High shoulder position
·Suitable shoulder position
·Low shoulder position
Plugging-in diagram Product connection
diagram
Power switch diagram
of the product
POWER INPUT
POWER INPUT
ON/OFF
ON/OFF

1514
Note: you can't adjust the massage position when it is in auto program.
MainMenu
Auto program
30:00
·If you need to adjust the shoulder position after the massage program is started,
you can directly select "Shoulder Position Adjustment" to enter the shoulder
position adjustment interface; you can press "Up Key" or "Down Key" to adjust the
shoulder position height; you can press "Left Button" to return to the previous
menu, or wait for 10 seconds to automatically return to the information interface
·After entering the massage program, if you need to adjust the massage position,
you can press the "Menu" button on the remote controller to select "Manual
Function" to enter; you can select any one of the manual functions, and then press
"Left Button" to return to the information interface (i.e. The information interface will
switch to the manual function interface)
·In the manual function interface, if the massage range shows a fixed point or local
area, you can directly press "Up Key" or "Down Key" to adjust the manipulator
upward and downward
·In the manual function interface, if the massage range displays neither fixed point
nor local area, you need to select "Massage Adjustment" to enter, and then select
"Massage Range", and a fixed point or local area, and press "Left Button" to return
to the information interface. Next, you need to press "Up Key" or "Down Key" to
adjust the manipulator upward and downward
3.Pause button
·While the massage function is in service, press "Pause" button to temporarily stop
all the massage functions; press "Pause" button again to continue the massage
function before pause. If the pause time exceeds 20 minutes, all the massage
functions will be automatically turned off.
3) Massage position adjustment
Button Description
Move the massage balls upward to a suitable shoulder position
Move the massage balls downward to a suitable shoulder position
4.Menu button
·Press "Menu Button" to enter the massage function selection interface of the main
menu, including automatic, manual, and other functions, intelligent storage, angle
adjustment, settings and other function interfaces.
·Enter the menu interface. Press "Up Key" or "Down Key" to select the function.
Confirm via "OK" to enter the next level of selection; press "Left Button" to return to
the previous menu interface.
Method of UsageMethod of Usage
30:00
00:00
Auto Mode
Fast massage>
Knead
Back speed Back intensity
Upper air Roll speed
Adjustment Shoulder
Select the object with ◀▶ and press OK
30:00
Shoulder position
Please use ▲▼ to adjust the shoulder position and press OK
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
30:00
00:00
ManualMode
Knead>
Range:Spot
Width:2
Back speed Back intensity
Upper air Roll speed
Adjustment Shoulder
use ▲▼ to adjust the massage position at the Spot and Partial
Pause
Pressthepausebuttonagain
toresumeusing

1716
Function
·Press "Menu Button" to enter the main menu interface. Press "Up Key" or "Down
Key" to select the automatic functions. Press "OK" (or press "AUTO Key" directly in
the information interface) to enter the selection of automatic functions.
· 21 special automatic massage functions are available: fast massage, comfortable
massage, relaxing massage, stretching massage, full body massage, neck &
shoulder massage, back & waist massage, and full airbag massage, Stress
relieving, Energy, Good-night sleep, Joint care, Spine massage, Office regimen,
Sport recovery, Neck & shoulder care, Brain refresh, Spine care, Waist care, Legs
care and Rejuvenation.
· Enter the automatic function interface. Press "Up Key" or "Down Key" to select any
automatic function massage program. It will automatically return to the information
interface, which will be displayed as the automatic function information interface.
1) Automatic function (main menu - automatic function)
Fast
massage Experience all the massage effects quickly.
The most comfortable massage experience.
Gentle and comfortable deep massage to relieve your body
fatigue and relax the body.
Stretch your legs and waist through the leg rest and the backrest to
effectively remove fatigue,relieve joint pain and restore vitality.
Deep massage to rejuvenate your body.
With the unique massage technique for the neck and shoulder, the
effective massage for the cervical spine and scapula can be
performed to relieve the neck and shoulder pain and reduce fatigue
on the neck and shoulder.
Focus on the back and waist massage to relieve the pain on the
back and waist.
Focus on the full-body airbag massage to achieve full relaxation
and deep massage of the body and fully relieve the fatigue and
pain from your body.
Comfortable
massage
Relaxing
massage
Stretching
massage
Full body
massage
Neck&
shoulder
massage
Back&waist
massage
Full airbag
massage
Method of UsageMethod of Usage
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
30:00
Fast massage
Auto program
Comfort massage
Select the object with ▲▼ and press OK
Relax massage
Stretch massage
Full body massage
Meck&shoulder massage
Description
Neck &
shoulder
care
With the unique massage technique for the neck and shoulder, the
effective massage for the cervical spine and scapula can be
performed to relieve the neck and shoulder pain and improve the
blood supply to the brain.
Restore the full body from fatigue and pain; achieve relaxation,
improve micro-circulation, and quickly relieve fatigue for the back
and limbs.
Stress
Relieving
Energy
Good-night
Sleep
Joint Care
After a night of rest, the body can have a rest; the whole body
muscles are massaged to quickly wake up the body functions and
start a new day of vitality.
Through the massage for the twelve major acupoints for healthcare,
it helps the body to adjust balance, quickly improve your sleep and
your sleep quality.
Care for the health of all your limbs and joints by pushing, pulling,
stretching, and other massage modes.

Note: The automatic functions in service already selected will be displayed in the
massage function status bar.
2) Manual function (main menu - manual function)
·Press "Menu Button" to enter the main menu interface. Press "Up Key" or "Down
Key" to select the manual function, and press "OK" to enter the manual function
interface.
·11 manual massage techniques/functions: OFF, kneading, Tapping I, Tapping II,
simultaneous kneading and tapping, Shiatsu I, Shiatsu II, shoulder lifting, 3D I, 3D
II, 3D III, 3D IV, etc.
·After entering the manual function interface, press “Up Key” or “Down Key” to
select the required manual massage technique. Press “OK” to confirm(There are
seven modes of kneading, press the "confirm key" to switch cyclically). After
selecting the technique, you will not automatically return to the information
interface. Press "Left Button" to return to the previous interface. After returning to
the information interface, you will find that you have entered the information
interface of the manual function.
Legs Care
Office
Regimen
Sport
Recovery
Brain
Refresh
Spine Care
Waist Care
For sitting in the office for a long period of time, this function can
increase physical exercise by massage and improve the body
functions.
Make you quickly recover from physical fatigue after exercise.
Relieve the neck and shoulder pain; promote the blood supply to the
brain by massaging the YUZHEN and DAZHU points.
Care for the health of spine and perform improvements for the lack
of exercise.
Focus on improving the health of the lumbar spine and alleviating
the stiffness of the waist muscles.
Quickly relieve the pain of the lower extremities and the muscle
fatigue.
Improve the quality of nap and work efficiency.
Rejuvenation
Spine
Massage
Improve humpback and chest down; massage for each vertebra;
care for the spine health; and improve the protrusion of
intervertebral disc.
Method of UsageMethod of Usage
Manual mode 30:00
TapⅠ
TapⅡ
Knead & Tap
ShiatsuⅠ
Kneading
Tapping
Function
Description
Shiatsu
Simultaneous
kneading and
tapping
Shoulder
lifting
3D
Speed
Speed, width
Speed
Speed, width
Speed
Speed, width
·5 speed levels
adjustable
·5 width levels
adjustable
Note: In 3D massage technique mode, the width of 3DⅠ and 3DⅡ cannot be
adjusted; the width of 3DⅢ and 3DⅣ can be adjusted.
2) Other functions (main menu key - other functions)
·Press "Menu Button" to enter the main menu interface. Press "Up Key" or "Down
Key" to select other function icons. Press "OK" to enter another function interfaces.
·Other functions include: airbag massage for the upper body, airbag massage for
the lower body, back heating, leg kneading and other massage functions.
·After entering another function interface, press "Up Key" or "Down Key" to select
the massage function. After selecting any one of the functions, use "Right Button"
to enable or disable the function. Then press "OK" to confirm. Press "Left Button"
to return to the previous menu interface.
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Stop
Knead
Select the object with ▲▼ and press OK
1918

Method of UsageMethod of Usage
Otherfunctions 30:00
Upper air
Lower air
Back heat
Calf knead
ON
OFF
01) Other functions - airbag massage for the upper body
·Airbag massage for the upper body: including airbag massage for the upper arms
pressure, airbag massage for the arms, airbag massage for the waist, and other
airbag massage functions.
·Enter another function interface. Press “Up Key” or “Down Key" to select the airbag
massage function for the upper body. Use “Right Button” to enable or disable the
airbag massage function for the upper body. Then press “OK” to confirm. Press
"Left Button" to return to the previous menu interface.
Otherfunctions 30:00
Upper air
Lower air
Back heat
Calf knead
ON
OFF
Auto Mode 30:00
Back speed Back intensity
Upper air Roll speed
00:00
Fast massage＞
Knead
Shoulder
Adjustment
02) Other functions - airbag massage for the lower body
·Airbag massage for the lower body: including airbag massage functions for the
legs, feet, etc.
·Enter another function interface. Press “Up Key” or “Down Key" to select the airbag
massage function for the lower body. Use “Right Button” to enable or disable the
airbag massage function for the lower body. Then press “OK” to confirm. Press
"Left Button" to return to the previous menu interface.
2120
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK Select the object with ▲▼ and press OK
Select the object with ▲▼ and press OK Select the object with ◀▶ and press OK
30:00
00:00
03) Other functions - back heating
·Back heating: enable or disable the back heating function; the back will become
warmer after such heating for 3min.
·Enter another function interface. Press “Up Key” or “Down Key" to select the back
heating function. Use “Right Button” to enable or disable such function. Then press
“OK” to confirm. Press "Left Button" to return to the previous menu interface.
04) Other functions - leg kneading
·Leg kneading: enable or disable the leg kneading function.
·Enter another function interface. Press “Up Key” or “Down Key" to select the leg
kneading function. Use “Right Button” to enable or disable such function. Then
press “OK” to confirm. Press "Left Button" to return to the previous menu interface.
Otherfunctions 30:00
Upper air
Lower air
Back heat
Calf knead
ON
OFF
Select the object with ▲▼ and press OK
Auto Mode 30:00
00:00
Fast massage＞
Knead
Back speed Back intensity
Upper air Roll speed
Shoulder
Adjustment
Select the object with ◀▶ and press OK
Otherfunctions 30:00
Upper air
Lower air
Back heat
Calf knead
ON
OFF
Select the object with ▲▼ and press OK
Auto Mode
Fast massage＞
Knead
Back speed Back intensity
Upper air Roll speed
Shoulder
Adjustment
Select the object with ◀▶ and press OK

2322
Method of UsageMethod of Usage
30:00
00:00
30:00
4) Intelligent storage (main menu - intelligent storage)
·Press the "Menu Button" to enter the menu interface. Press "Up Key" or "Down
Key" to select the intelligent storage icon. Press "OK" to enter the intelligent
storage interface, including: intelligent storage call, intelligent storage saving,
cancellation and other storage functions.
·Intelligent storage call includes: M1, M2, M3, M4, and M5.
·Intelligent storage saving include: M1, M2, M3, M4, and M5.
·Call: Call the stored massage mode, massage technique, airbag mode and
intensity under the current running status, the positions and angles of the leg rest
and the backrest, and other massage functions.
·Storage: Store the massage mode, massage technique, airbag mode and intensity
under the current running status, the positions and angles of the leg rest and the
backrest, and other massage functions.
·Cancellation is the exit option.
Note: When saving the massage method, you can comment on the saved
massage function and method (e.g. father, mother, son, daughter, or none).
MemoryUse
MemorySave
Cancel
Otherfunctions
Upper air
Lower air
Back heat
Calf knead
ON
OFF
Select the object with ▲▼ and press OK
Fast massage＞
Knead
Back speed Back intensity
Upper air Roll speed
Shoulder
Adjustment
Select the object with ◀▶ and press OK
Auto Mode
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Note: Note: You can comment on the saved massage functions and techniques
(e.g. father, mother, daughter, son, or none).
Memory Save 30:00
M1
M2
M3
M4
M5
Adderuser
Dad
Mom
Son
Daughter
None
Memory Use30:00
M1
M2
M3
M4
M5
01) Intelligent storage - save or cancel
·After entering the intelligent storage (saving) interface, press "Up Key" or "Down
Key" to select the massage function to be stored. Press "OK" to save or cancel.
·Enter the intelligent storage (saving) interface. Press "Up Key" or "Down Key" to
select any one of the M1-M5 saving procedures. Select "OK" to confirm, and
comment on the saved massage function; press "Left Button" to return to the
previous menu interface.
02) Intelligent storage - call or cancel
·After entering the intelligent storage (call) interface, press "Up Key" or "Down Key"
to select the massage function to be called. Press "OK" to enter the call or
cancellation interface.
·Enter the intelligent storage (call) interface. Press "Up Key" or "Down Key" to
select any one of the M1-M5 call procedures required to call the saved massage
program; press "Left Button" to return to the previous menu interface.
MemoryUse
MemorySave
Cancel
Select the object with ▲▼ and press OK
MemoryUse
MemorySave
Cancel
Select the object with ▲▼ and press OK

2524
Method of UsageMethod of Usage
Angleadjustment 30:00
Wholebodyangle
Calfangle
Backangle
Zero-g
5) Angle adjustment (main menu-angle adjustment)
·Press "Menu Button" to enter the main menu interface. Press "Up Key" or "Down
Key" to select the angle adjustment icon. Press "OK" to enter the angle adjustment
interface.
·Angle adjustment includes: full body angle, backrest angle, leg rest angle, zero
gravity and other adjustment functions.
·After entering the angle adjustment interface, press "Up Key" or "Down Key" to
select the desired angle adjustment function. After selecting any angle, press “OK”
to confirm the selected angle adjustment. Press "Left Button" to return to the
previous menu interface.
Wholebodyangle
30:00
Use the ▲▼ to adjust the whole body angle
01) Angle adjustment - angle for the whole body
·Angle adjustment for the whole body: adjust the angles of the backrest and the leg
rest at the same time.
·Enter the angle adjustment interface. Press "Up Key" or "Down Key" to select the
angle function for the whole body. Then press "Up Key" or "Down Key" to adjust
the angle for the whole body to the desired angle; press "Left Button" to return to
the previous menu interface.
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK Select the object with ▲▼ and press OK
Angleadjustment 30:00
Wholebodyangle
Calfangle
Backangle
Zero-g
Select the object with ▲▼ and press OK
Calfangle 30:00
Backangle 30:00
02) Angle adjustment - leg angle
03) Angle adjustment - backrest angle
·Backrest angle adjustment: lying adjustment of the backrest.
·Enter the angle adjustment interface. Press "Up Key" or "Down Key" to select the
backrest angle function. Then press "Up Key" or "Down Key" to adjust the backrest
lying angle to the desired massage angle; press "Left Button" to return to the
previous menu interface
Angleadjustment 30:00
Wholebodyangle
Calfangle
Backangle
Zero-g
Select the object with ▲▼ and press OK Use the ▲▼ to adjust the calf angle
30:00
Angleadjustment
Wholebodyangle
Calfangle
Backangle
Zero-g
Select the object with ▲▼ and press OK
Use the ▲▼ to adjust the Back angle
·Legrest angle adjustment: adjust the legrest upward and downward.
·Enter the angle adjustment interface. Press "Up Key" or "Down Key" to select the
leg rest angle function. Then press "Up Key" or "Down Key" to adjust the legrest
angle to the desired massage angle; press "Left Button" to return to the previous
menu interface.

2726
Method of UsageMethod of Usage
04) Angle adjustment - zero-gravity
·Angle adjustment for zero gravity: There are three levels of angle adjustment for
zero gravity and zero gravity OFF function. A total of four modes can be selected.
·Enter the angle adjustment interface. Press "Up Key" or "Down Key" to select the
zero gravity function; press "OK" to enter the zero gravity interface, and then press
"Up Key" or "Down Key" to select OFF, any of Level 1, Level 2 or Level 3 for the
zero gravity angle. Then press "OK" to confirm; press "Left Button" to return to the
previous menu interface.
Zero-g30:00
OFF
1
2
3
6) Settings (Main Menu-Settings)
·Press "Menu Button" to enter the main menu interface. Press "Up Key" or "Down
Key" to select the settings icon. Press "OK" to enter the settings interface.
·Settings include: language settings, Bluetooth settings, intelligent voice control,
Equipment ID and other settings functions.
·After entering the settings interface, press the “Up Key” or “Down Key” to select
the desired settings function. Select any one of the settings functions, and then
press “Right Button” to set the selected settings function. Press the “OK” to
confirm; press "Left Button" to return to the previous menu interface.
30:00
Angleadjustment
Wholebodyangle
Calfangle
Backangle
Zero-g
Select the object with ▲▼ and press OK Select the object with ▲▼ and press OK
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Setting 30:00
Language
Bluetooth
Voice control
ID CODE
ON
OFF
Select the object with ▲▼ and press OK
01) Settings - language settings
·Voice settings: including Chinese and English (the function has memory, that is,
after such selection, power-off and restart, it will be the last selected state).
·Enter the settings interface. Press "Up Key" or "Down Key" to select the language
settings. Press "Right Button" to enter the language settings. Press "OK" to select
the required Simplified Chinese or English; press "Left Button" to return to the
previous menu interface.
02) Settings - Bluetooth settings
·Bluetooth settings (OFF by default): After the Bluetooth function of the massage
chair is enabled, the Bluetooth-enabled audio source device (e.g. mobile phone,
MID tablet) can be connected with the Bluetooth module of the massage chair, and
the music played by the audio source device can be wirelessly transmitted to the
audio system of the massage chair via Bluetooth for music playback.
·Enter the settings interface. Press "Up Key" or "Down Key" to select the Bluetooth
settings. Press "Right Button" to enter the Bluetooth ON/OFF interface. Press "OK"
to select the required ON or OFF; press "Left Button" to return to the previous
menu interface.
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Setting 30:00
Language
Bluetooth
Voice control
ID CODE
Select the object with ▲▼ and press OK
Chinese
English
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Setting 30:00
Language
Bluetooth
Voice control
ID CODE
ON
OFF
Select the object with ▲▼ and press OK

2928
Method of UsageMethod of Usage
03) Intelligent Voice Control
·Intelligent voice control: enable or disable the intelligent voice control function (the
function has a memory, that is, after such selection, power-off and restart, it will be
the last selected state); Note: When the intelligent voice control is disabled, voice
wakeup cannot be performed.
·Enter the settings interface. Press "Up Key" or "Down Key" to select the intelligent
voice control function. Press "Right Button" to enter the intelligent voice control
function settings. Press "OK" to select the required ON or OFF; press "Left Button"
to return to the previous menu interface.
04) Equipment ID
·Equipment ID: Display the current device ID number.
·Enter the settings interface. Press "Up Key" or "Down Key" to select the equipment
ID and check the equipment number of the current device.
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Setting 30:00
Language
Bluetooth
Voice control
ID CODE
ON
OFF
Select the object with ▲▼ and press OK
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Setting 30:00
Language
Bluetooth
Voice control
ID CODE
Select the object with ▲▼ and press OK
2003140001
30:00
00:00
Adjustment 30:00
BackSpeed
Backintensity
Massagearea
Massagewidth
Airintensity
RollSpeed
1
2
3
4
5
7) Massage adjustment
·In the state of the information interface, press "Left Button" or "Right Button" to
select the massage adjustment button, and press "OK" to enter the massage
adjustment interface.
·Massage adjustment includes: 7 massage adjustment functions can be selected,
including back massage speed, back massage intensity, massage range, massage
width, airbag intensity, roller speed, and massage time.
·After entering the massage adjustment interface, press "Up Key" or "Down Key" to
select the desired massage adjustment function. After selecting any one of the
desired massage adjustment functions, use "Right Button" to enter the massage
level selection interface. Then press "OK" to confirm the selected level. Press "Left
Button" to return to the previous menu interface.
Function
Description
Back massage
speed 5 speed levels adjustable
Back massage
intensity 5 intensity levels adjustable
Massage range There are 5 modes for your choice: fixed point, local area,
full back, upper back, and lower back
Massage width 5 width levels adjustable
Airbag intensity 5 intensity levels adjustable
Roller speed Choose from 4 modes including OFF and Level 1-3
Massage time Choose from 4 modes: +10min, +5min, -5min, -10min
Auto Mode
Fast massage>
Knead
Back speed Back intensity
Upper air Roll speed
Adjustment Shoulder
Select the object with ◀▶ and press OK Select the object with ▲▼ and press OK

3130
Method of UsageMethod of Usage
Note:
·According to the remaining massage time, when the displayed time is not enough
for the addition and subtraction of a certain time, the operation will not be
displayed (the upper limit of the time display is 40 minutes). For example: If the
display time of the remote controller is 39 minutes, the massage time adjustment
range will be: -5min, -10min (+10min or +5min cannot be displayed).
·The adjustment of airbag intensity can only be used when the airbag function or
the automatic function is enabled (for more information about how to enable the
airbag function, refer to Page 18 of the Operation Instructions).
5.Zero-gravity key
·Press "Zero-gravity Key" to adjust the position of zero gravity. You can choose
different angle positions for zero gravity according to your own needs (i.e. 1st
pressing is Level 1; 2nd pressing is Level 2; 3rd pressing is Level 3; and 4th
pressing makes the massage chair restore to the original state).
Button
Description
Zero-gravity Key: Once it is pressed, the positions of the leg rest and
the backrest can be automatically adjusted to the positions for zero
gravity.There are three zero-gravity modes and the lying OFF mode,
which can be switched.
6.Lying angle adjustment button
Button
Description
Leg rest up button: Hold down the button to make the leg rest rise
slowly. Release it to stop such action.
Leg rest down button: Hold down the button to make the leg rest
move downward slowly. Release it to stop such action.
Backrest up button: Hold down the button to make the backrest rise
slowly. Release it to stop such action.
Backrest down button: Hold down the button to make the backrest
move downward slowly. Release it to stop such action.
Linkage sitting key: By holding down this key, the backrest will rise
slowly and the leg rest will move downward slowly; by releasing it,
such UP/DOWN action of the backrest and the leg rest will be
stopped.
Linkage lying key: By holding down this key, the backrest will move
downward slowly and the leg rest will rise slowly; by releasing it, such
DOWN/UP action of the backrest and the Leg rest will be stopped.

3332
III.Introduction to Armrest Shortcut Keys
1. Voice control microphone: Built-in voice control microphone.
2. AUTO key: Press it to enable the automatic massage function.
3. Voice control and wake-up button: Short press to enable the voice control function,
long press 3 seconds to turn on or off the voice control function.
4. Heat treatment key: Click the key to enable or disable the heat treatment function.
5. Leg rest down button: Adjust the leg rest downward.
6. Leg rest up button: Adjust the leg rest upward.
7. Linkage sitting key: Adjust the linkage sitting angle.
8. Linkage lying key: Adjust the linkage lying angle.
9. Wireless phone charger: wireless charging of mobile phone
10. 3D intensity knob: adjust the massage intensity of 3D manipulator.
11. Switch: Hold it down for 2 seconds to turn on or off the massage chair.
Method of UsageMethod of Usage
3D
1
2
3
4
5
6
7
8
9
10
11
-+
Button
Description
Power button: Short press this button to pause the operation; if it is
hold down for 3 seconds, power will be ON/OFF.
If the pause time during massage exceeds 20 minutes, all the
massage functions will be automatically turned off.
3D intensity knob: adjust the massage intensity of 3D manipulator
(counterclockwise indicates "-", while clockwise indicates "+"). The
intensity range is Level 1-5.
Linkage sitting key: By holding down this key, the backrest will rise
slowly and the leg rest will move downward slowly; by releasing it,
such UP/DOWN action of the backrest and the leg rest will be stopped.
Linkage lying key: By holding down this key, the backrest will move
downward slowly and the leg rest will rise slowly; by releasing it, such
DOWN/UP action of the backrest and the leg rest will be stopped.
Leg rest up button: Hold down the button to make the leg rest rise
slowly. Release it to stop such action.
Leg rest down button: Hold down the button to make the leg rest
move downward slowly. Release it to stop such action.
Heat treatment key: Click the key to enable or disable the heat
treatment function.
Automatic mode key: Press it to switch among those automatic
massage functions.
Voice-control wake-up button: press this button to wake up the voice
control function and press for 3 seconds to turn the function on or off.
if no valid voice entry is recognized within 6 seconds, the voice function
is automatically turned off (this button only works after The voice control
function turned on

3534
Method of UsageMethod of Usage
1.Enter the smart device main menu. Open "Settings" and select the "Bluetooth"
option. Open "Bluetooth", and Bluetooth will automatically "Search for a New
Bluetooth Device".
2.The smart device will search for the corresponding Bluetooth model (e.g. IMCM-
XXXX). Click the "Match" button. If you are asked whether to match with the
device, you just select "Match" to complete matching.
3.Turn on "Music Player" in the smart device and select the song to play.
V. Operation Instructions for Bluetooth Speaker Play
VI. Turn off the power and stop massage
·If the power button is pressed during massage, it will stop all the massage
functions immediately, and the backrest, the legrest and massage chair
manipulators will go back to the default positions. When the preset massage time
is up, all the massage functions will be OFF. The backrest and the legrest will not
go back to the default positions.
·Shut off the power supply of this product, as shown in the attached figure (Power
Shut-off Diagram of the Product).
VII. Installation Instructions for Armrests
1.Unpack the two packages. Lift out the massage chair and armrest components.
Carefully check the accessories and appearance for any damage. Then assemble
them with a Phillips screwdriver. Then find the supplied power cord and remote
controller from the package. Firstly, insert the remote controller into the front
socket on the right side of the massage chair and tighten it (Figure 1); then plug in
the power cord, and turn on the switch to power on. At this moment, the massage
chair will start the automatic recovery action. After it is changed from the lying and
packing state to the standing standby state, unplug its PUS for assembly.
2.Raise the rear end of the armrest,respectively insert the plug and trachea
corresponding with the same mark on the rear end of the armrest with the
connecting plug and trachea at the back of the backrest,and the match should be
in place and firm(Figure 2).
Power Shut-off Diagram of the Product
Disconnection Diagram
Unplugging Diagram
POWER INPUT
POWER INPUT
ON/OF F
ON/OF F
IV Voice Control Mode.
·When the massage chair is turned on or in standby mode, the sound “Hi Alice” or
“Hey Alice” will be produced to enable the voice control function.
·Long press 3 seconds to turn on or off the voice control function.
·After such function is enabled successfully, the massage chair will reply “I am here”
At this moment, once a corresponding voice control entry to be implemented is
given within six seconds, the corresponding voice control function can be performed
after a reply is received from the massage chair; if no correct voice control entry is
given within six seconds, the voice control function automatically will be off
automatically and needs to be enabled again.
·Note: When waking up the voice control function, please use English, the speech
rate is moderate, Voice commands should be follow up the Voice entry.
VOICE CONTROL ENTER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
No.
Voice control entry
Massage on
Massage close
Comfort Massage
Relax massage
Full body massage
Neck massage
Back and waist massage
Stretch massage
Open the air pressure
Close the air pressure
Up the seat position
Down the seat position
Change the other mode
Go little down
Go little up
Answer entry
Answer: Ok, massage on
Answer: Ok, massage close
Answer: Ok, comfort massage
Answer: Ok, relax massage
Answer: Ok, full body massage
Answer: Ok, neck and shoulder massage
Answer: Ok, back and waist massage
Answer: Ok, stretch massage
Answer: Ok, open the air pressure
Answer: Ok, close the air pressure
Answer: Ok, up the seat position
Answer: OK, down the seat position
Answer: OK, change the other mode
Answer: Ok, go little down
Answer: Ok, go little up
Press at least 3 second “ ” button on the armrest (on/off Voice Control mode) .
Make sure the device is on Voice Control mode. Call “Hi Alice” or “Hey Alice”
before the following Commands:
Note: commands 14 and 15 can only be used after command 13.

3736
3.Hold the armrest with both bands and insert the middle hook of the armrest into
the massage chair frame(Figure 3).
4.Align the limit hole of the armrest assembly with the wire inserted with the limit
post of the backrest and insert the armrest(Figure 4).
5.Fix the back end of the armrest with two M6 screws(Figure 5).
6.Fix the front end of the armrest with two M6 screws which has inserted the front
end hook of the armrest into the front end square opening of the massage frame in
the second step(Figure 6).
7. Align the buckle on decorations with the corresponding buckle seat of the armrest
and tighten it(Figure 8).
Method of UsageMethod of Usage
Figure 1 Figure 2
Figure 3 Figure 4
Figure 5 Figure 6
Figure 7
3 4
VIII. Installation Instructions for Legrest
·After connecting the wires and the air hose between the legrest and the massage
chair, remove the cable ties and insert the connecting part into the seat (Figure 1).
·Place the round tubes on the left and right sides of the legrest onto the legrest
support (Figure 2)
·Next, turn the legrest fixing cover over to cover the round tubes on both sides of
the legrest (Figure 3).
·Fasten the legrest to the massage chair with two M5 screws (one on each side).
Check whether there is any abnormality during turning up and down, or any tube,
cable or wire is folded. If everything is OK, the legrest is installed (Figure 4).
1 2
