ADOR AD-Infinix User manual

Please read SAFETY INSTRUCTIONS carefully before using the chair.
User 's Manual
Massage Chair
AD-Infinix

1. The patented backrest is designed to reduce noise as the massage system
delivers a life like soothing kneading, rocking, knocking, tapping, shiatsu and
rolling massage.
2. The computer body scan automatically scans the body, measuring where the top
of the neck is located to ensure a complete and accurate massage.
3. Press the zero gravity button and the chair will recline back, raising the legs and
steepening the pitch of the seat base, ultimately putting the user in an optimal
stress reduced position.
4. Even in the most limited of spaces, the Infinix massage chair is equipped with
space saving technology. When the chair reclines, the base will move forward to
reduce the amounts of space required to house the chair. The total space
needed from the wall to bacrkrest is 5 inches.
5. Located at the bottom of the feat along the bridge are rollers that spin. The
nodes on the rollers will emulate fingers digging into the middle area of the feet,
loosening the ligaments and muscles.
6. Calf spinning massager are placed on the mid-section of the legrest. When
activated the circular discs will rotate kneading the back of the calves.
7. Airbag massager are located all throughout the massage chair where airbags
inflate and decompress on the arms, legs, shoulders and feet. The squeezing
action will massage the muscles promoting better blood circulations.
8. The Legrest can be extended and retracted within a range of 8.6 inches, suitable
for a variety of different heights. This chair will fit comfortably from 4'10" to 6'3".
9. With a quick control panel on the armrest it easy and fast to start a preset
programmed massage.
10. Enjoy the high quality bluetooth speakers by syncing your bluetooth device to
the chair. Listen to your favorite tunes while enhancing your massage
experience.
11. Located in the lower lumbar area are 2 heating pads that give a warm heat to
help loosen the muscle as it gets massaged.
12. This chair is designed for the times were we are so dependent on our
devices. The Infinix massage chair has a USB charging port located on the
armrest.
Function Introduction
Massage Chair
17
27
28
1
5
6
15
23
25
26
7
8
9
The use method of convenient hand controller
21
Note: We reserve the right for design modification.It is subject to change
without notice.The pictures in this manual are only for reference.
Please refer to the actual product.
1.Thank you for choosing ADOR Luxury Massage Chairs
2.Please read this manual carefully before using the massage chair.
3.Please keep this manual in a safe place for future reference.
4.Please pay attention to SAFETY INSTRUCTIONS.
Content
External structure parts
Internal structure parts
Preparation
Safety instructions
Mechanical components diagram
Mechanical components list
Installation
Installation
The adjustment before massage
Operation instruction &function illustration
Manual control
Massage Operation
After massage
Please keep this manual in a safe place for future reference.
Clean and maintenance
Malfunction guide
Maintenance
Others
Technical data
AD-Infinix

1 2
Please read this manual carefully to make sure the installation and operation of the
massage chair is being used correctly.
“Safety Instructions” are provided in both Warning and Caution "icons" for important
safety information.
The "warning" and "caution" should be fully observed and followed as instructed.
This sign indicates forbidden behavior.
This sign indicates must follow
instruction to operate.
This sign indicates disassembly or
tampering is not allowed.
This sign indicates correct operation
of cable.
Warning
This sign indicates warnings of potential death or serious injury.
Caution
This sign indicates caution of potential bodily injury or damage to the chair
▲
Symbol meaning
The following should be kept for any further references.
Safety instructions Safety instructions
Preparation
People with osteoporosis, vertebral fractures, sprains or muscle strains must
consult with your medical doctor before using to avoid serious injury.
Heart disease patients (including those who have pacemakers or any other
medical devices implants must NOT use this product.
Cancer patients must consult with their with their medical doctor before using.
People with perceptual disorders or diabetes must consult their medical doctor
before using.
People with abnormal spine or scoliosis must consult their doctor.
People with bulging discs or any disc issues must consult with their doctor.
Pregnant women and those who have recently had childbirth must consult with
their doctor before using.
If you have any various skin disease or inflammation must consult their doctor
before using.
Any one that may not be able to discern the surrounding temperature must have
supervision.
If you have fever or any illness you must consult with your doctor before using.
If elderly in poor health or above 80 years of age must consult with their doctor.
Anyone with any handicap or mental disability must consult with their doctor before
using. A capable adult that can supervise must attend at all times.
If you are impaired by alcohol or any other substance do not use this device.
If this chair is wet in any way or you are wet do not use this chair.
Do not children under the age of 16 use this chair.
Do not fall asleep in this unit and no external articles such as blankets or pillows
are permitted to avoid injury.
Not suitable
users.
People with above symptoms should not use massage chair, or use it under doctor's
advice. User's discretion is advised when use the chair.
Risk of causing
accident or body
discomfort.
Warning
Before sitting, please confirm that there are no foreign objects
obstructing the function of the chair.
Before operating the chair be sure to check that there are no people,
pets or objects in or around the area (behind, under, sides or in front of
the chair).
In the event if physical pain or irritation is experienced, immediately stop
using and consult your doctor.
If the massage rollers are massaging the head adjust the starting
position of the massage to start on the neck area avoiding the head
which may lead to injury.
Avoid excessive neck massage which may cause bruising or soreness.
Do not massage the abdomen or knees with this machine.
If you want to leave your seat during the massage, you must stop the
massage chair wait for the chair to be in the full upright position before
getting out.
Do not use it with other instruments.
Do not allow children or pets to play on or around the unit (especially
when in use); nor can they sit or stand on backrests ,armrests or legrest.
Periodically inspect the backrest to ensure the lining is in good condition
without any tears.
Before moving the unit, the backrest and legrest must be in the default
fully upright position.
Daily
inspection
and
maintenance
If the power cord is damaged in any way do not use the chair and
proceed to unplug from the power outlet.
Don't use other electric power except rated voltage to avoid fire, electric
shock or any breakdown.
Any broken, re-processed, knotted, twisted power cord or pressed
under heavy cargo is not permitted to be used.
Never operate this chair if it has a damaged cord or plug, if it is not
working.
Keep the power line away from stove or other heat sources.
If the chair is not working properly or has been in contact with any liquids do
not use the chair and contact the manufacturer for technical support
Self-modification, disassembly or maintenance is forbidden.
If power cord or plug is damaged, please don't replace it yourself, please
contact us or appointed dealer for replacement.
To avoid electric shock or bodily harm, please don't open or disassemble any
part of the chair. If the chair is found to be opened or tampered by the
customer it will void all warranties.
Check upholstery periodically on the backrest and other areas to make sure
there are no tears or worn out areas before using. if any damage is found
unplug the chair and contact your local dealer.
Fire and electric
shock
Upholstery &
Overheating
Fire and electric
shock
Accident/injury
Warning
When assembling, make sure there is No power running in chair.
Insert the plug of the chair into correct power rated power outlet.
Make sure the plug is completely inserted into the socket to
reduce short circuit or fire risk.
Unplug the power when not in use,stop all massage functions and
turn off the power switch and unplugging the chair from the outlet.
Do NOT fold the pads & cushions when placing them in storage.
Do not let this chair operate for more than a couple of hours
consecutively to avoid overheating. Not intended for commercial
use.
Preparation

3 4
The remote must be place back in the holder.
Unplug the power when any damage on the power cable.
Caution
Please when unplugging the power cable from the outlet be sure
the power switch on the base of the chair and remote is in turned
off.
Unplug the power immediately when there is a power outage.
Keep Dry-Don't use or store the chair in the wet environment
like nearing the swimming pool, or bathroom.
Keep the chair and remote control dry all the time.
Do not use it when user's body is wet.
Make sure the ground wire and plug is in good working
order.
Don't use plug adapter (If the enclosed plug doesn't match
with socket, please don't change the plug by yourself and
find a professional electrician to install a matched
socket )
Unplug the power before cleaning the chair.
Unplug the power after using the chair.
When pulling out the power cable from the outlet be sure
that the head of the plug is held and not the cable.
Safety instructions Safety instructions
Preparation Preparation
To avoid leakage or
electric shock.
To avoid electric shock.
To avoid electric shock
or fire harzard.
To avoid accidents
To avoid damage or accidents
during power outage
▲
Keep this chair clear from any gas lines, telephone lines,
water lines and electrical cables. If not followed it may lead
to explosions, fires and electrical shock, injury or even
death.
Power cable to kept
away from these areas
Grounding instruction
The chair provides a power cord that has a ground. Do not us any other power
cable unless advised by the manufacturer.
hctiwsehtffonrutesaelp,tuodenrubsiesufehtnehW
and unplug the power. Opening the lid covering the fuse
which is located by the switch box. Using a same size
fuse to replace the old one, then cover with the cap. If
you do not have a fuse please contact the manfacturer.
Please operate tthis chair on a flat and level hard surface.
Caution
Keep the chair away from stove or other heating products.
Don’tput the chair directly under the sun or other high
temperatureplaces.
To avoid structural failure and injury
The maximum suggested operating time is 20mins.
Before sitting on the chair to avoid injury please inspect
everything to confirm that the massage heads are in the
correct position.
When you exceed 20 min per
day you may cause injury or
bruising
To avoid electric shock in any
leakage or breakdown .
To avoid fade, discolor on upholstery
or hardened,deteriorated on PU.
Don't use the chair outdoor.
Make sure the ground plug is in good condition
before plugging into the power outlet.
Don't press with hands or step on the massage heads with feet.
Don't put hands between the working massage heads.
Don't put hands or feet in the gap of mechanical parts.
Don't drop or insert anything into the slot of massage chair.
Don't stand or sit or put anything on the backrest, armrest or legrest.
Don't move the chair while in use.
Don't stand on the chair during operation.
Don't pull out the plug or turn off the power switch during use.
Don't put your hands or head between leg-rest or beneath.
Don't use the massage chair while wearing hair ornaments.
Don't put hard things in pocket when take buttocks and huckle
massage.
Don't sit or press on the backrest when the chair is in reclining
position.
Don't use at bare skin or were thin clothes, thin clothes may can
achieve better massage effect, But it also may cause irritation to the
skin or cryogenic burns.
Do not use massager in close proximity to loose clothing or jewelry.
Keep long hair away from massager while in use.
Keep the chair away from heat, wet, sharp things and
corrosive, inflammable, explosive environment.
To use electric blanket or other heating products on the
chair is forbiden .
Make sure the plug completely insert into the socket.
To reduce short circuits and any
fire hazards.
To avoid the accident when turn on
the power.
Turn off all controls before removing plug from outlet.
Checking whether any damage on wire,make sure
no water or dirt is on the power cable.
Please make sure that the power switch is at the“OFF”
position before inserting the power plug into the socket.
To avoid accidental injury.
To avoid accidents or injury
Don ' t put in the space of dust serious or corrosive gas
environment,
Don ' t put the chair in a small space places or use in the bad
air circulation places.
Replace fuse

5 6
OK
AUTO EMERGENCY
MENU
Heating
Method
Position
Simple remote
control
Mechanical Roller
for the Leg
Preparation
Internal structure partsExternal structure parts
Preparation
External structure
Internal structure
Right shoulder massage device
Loud speaker
Back seat cushion
Right armrest
Seat
Legrest
Footrest
Head pad
Left armrest
Castor
Left shoulder
massage device
Remote control pocket
Back cover
Power switch
Power case
Power cord socket
Fuse holer
Remote control
Massage head
Shoulder airbag
Waist heating cloth
Air bags in the arm area
Side airbag of leg
Foot roller
Footrest airbag

8
1
1
1
1
1
1
1
11
12
13
14
15
16
17
18
1
2
3
4
7
6
1
1
1
1
1
Left Side fender Assembly
Shoulder Assembly
5
9
10
1
1
1
1
13 14
按摩操作
7 8
1
1
19
20
1
1
21 1
22 1
23 1
Mechanical components diagram
Mechanical components list
Explosion Diagram
Preparation
Mechanical components list
Preparation
NO . Q'ty Q'tyNameNO . Name
Power case assembly
Back cover assembly
Back cover
Massage mechanism
Right side fender
Front swing assembly
Back swing assembly
Footrest electric actuator
Front fender assembly
Power case assembly
Solenoid valve assembly
Leg support plate
Right armrest assembly
Remote control
Back electric actuator
Foot and leg assembly
Left amrest assembly
Back frame assembly
Back seat cushion
Pillow
Bottom frame assembly

9 10
决定设置场所
①②
Installation(1)
Installation
Installation
Installation
Installation(2)
Installation
①First take out the accessory box and the legrest.
②Use 2 or more people to remove the main body of the massage chair from the box.
③Confirm all the accessories are accounted for.
When removing the legrest from the box be
sure to firmly grab it with 2 hands and slide it
out of the box and unwrap.
When mounting
the side panels
grab the areas as
shown.
Step 1. Take out the main body and accessories from the carton box.
Massage chair main body
The accessories
Electric power cable Remote control
Legrest device
Check environment
Make sure when placing the chair there is enough space when chair is reclined.
At least 50cm
from wall
Chair should be on a rug or carpet to reduce noise when operating.
Because the chair is heavy, it may ruin your floor in long time setting.
Please put a blanket or other soft things to protect your floor.
Caution
Don’t use the chair near wet or humid places like swimming pool , bathroom,
saunas and heating/cooling vents to avoid electric shock and/or injury.
The chair must be placed flat, leveled surfaces to avoid damage and injury.
Do not place this chair near a window or any place where it will make contact
with sunlight that can cause fading and damage to the upholstery.
At least 5cm
from wall
Step2. Placing the Remote in the holder
located on side panel you will find the remote holder bag stitched by the arm massager.
Remove the packaging, flip to the outer wall and insert the remote.
Remote control
Remote control
pocket
OK
AUTO
EMERGENCY
MENU
Heating
Method
Position
OK
AUTO EMERGENCY
MENU
Heating
Method
Position

11 12
①④
1
2
3
4
⑥
⑤
②
③
Installation
Installation(3)
Installation Installation
Installation(4)
Installation
▲
Note: The shaft must be securely attached, otherwise it will fall off. When inserting the air
pipe and wiring harness, do not wrap the air pipe and wiring harness together.
The wiring
harness plug.
Limit level pin
The wiring
harness plug.
1
2
3
4
Spindle
Air tube
Air tube
Step 4. After assembling.
Plug the cable line in the hole a on the
power box as shown in the right picture.
Insert the plug of cable line into the socket.
Turn on the switch behind the power box.
(Switch on/off "O/I", press I down to turn
it on.)
Press the on button on the remote, select a
preset program massage and enjoy!
Make sure the switch is off before you
insert the plug of cable line into the
power socket.
Plug the power cord
into the power box
socket.
Hand controller
Power box
socket
Velcro of the front of seat.
Velcro within the legrest
Velcro of the front of seat
cushion.
Velcro outside the legrest
connection leather.
Step 3. Mounting the Leg-rest
Place the legrest in front for front of the base of the chair.
Match the air hose from the legrest to the base. Then proceed to connect the electrical plug
into the base.
Raise the legrest with both hands,push the shaft of legrest to the limit level pin
hanger. Then thread the bolt to connect the legrest and use the split pin to lock in.
Connect the top flap of the legrest to the base of the chair using the velcro stiched on both
ends.
OK
AUTO
EMERGENCY
MENU
Heating
Method
Position

1
▲
13 14
Check
The adjustment before massage
Caution
Environment Check environment
Don’t use the chair in or near wet places
like swimming pool, bathroom, etc to
avoid serious injury or electric shock.
Don’t use under sunlight or near stove
or other heat sources to avoid upho-
lstery deteriorated and fire
Please use chair on a level surface that
is hard and flat to avoid damage and
injury.
Check places in front
Check the surrounding areas to make sure
there is nothing around to avoid injury or
damage to the chair.
Check power cable, plug
Space to use the chair
(1) Using a clean cloth be sure the power
cable is clean without damage.
(2) No damage to the cable is a must. If
damage to the cable is seen turn off the
chair, unplug and contact customer
service.
At least 15 inches are needed infront of
the legrest to extend.
Check surroundings
When the backrest or legrest reclines
or extends, please pay attention to:
(1) Check for any person, pets or things
in every direction before using.
(2) Check the there is substantial space
to use the chair.
The adjustment before massage
assaM eg noitarepo
The chair must be at least 3 inches from the
wall to recline.
Press down the head part of the backrest to
tilt back on the castors. Then push the chair
to desired destination steadily and set it
down slowly.
If you feel the
massage isn't
strong enough,
you can
remove the
pillow pad on
the backrest.
Rolling Wheel
No more than 40 degrees
Kind suggestion
How to move massage chair Adjustment before massage
Caution
Don’t move chair when it’s working in case
of accidents or damage
How to move
Bind the cables and put them in the seat to
avoid damage when moving.
If you bump or drop the chair, it may damage
the inner parts of the chair.
Don’t use the castor if the floor is wooden or
any other soft materials. It will damage your
floors. It will need 2 or more persons to lift the
chair when moving.
Make sure the power is off and the plug is
completely removed from the chair to avoid
tripping or damage to the
cable.
Normally
Be sure the the legrest ins in the full
down position before attempting move.
It is even advised to remove the legrest
when moving long distances.
Because the chair is heavy, it may
ruin your floor. Please put a
mat or rug under the
chair. This will also
make the chair quieter
during operations.
Before adjustment
Before starting the
massage the rollers
should be at the top of
the backrest.
When at the top gently sit
in the chair to avoid
injury.
When chair conducts the body scan and is
unable to detect where the shoulder and
neck is, the massage will start at the highest
default position..
Right position: When getting
body scan be sure that your
back and shoulders are firmly
pressed against the backrest
so that computer can scan your back
precisely. Once the scan is complete it will
beep. At that time you have to option to
adjust the starting point by moving up or
down/up button. You have 5 sec to make the
adjustment as it beeps to make the
adjustment.
arepoegass
aM it no

OK
15 16
Press this button to power on or off the chair
The menu key needs to be used in conjunction with the navigation key, and then
press this key to enter the massage status interface.
When pressing this key you can choose from 3 different preset programs.
massage programs: " Recover”, “Relief”,“Stretch”. The default working time is 20
minutes.
then press this button again to reset the chair to the initial working state. The zero
gravity icon on the main interface will show the current zero gravity status after the
massage starts.
as menu navigation keys in the menu mode. You can use the up and down direction keys
to quickly select the menu items, as well as the left and right direction keys to quickly
enter the previous and next menus. The up and down direction keys play the role of
manually adjusting the position of the massage machine during the shoulder height
detection and the fixed-point adjustment function in the manual massage mode.
turned on, the corresponding heating symbol turns red, and when turned off, the
corresponding heating symbol disappears.
Pressing this button will activate the air massage intensity from 3 levels.
This button stop the chair immediately.
This will take you to the main menu screen.massage functions of the massage chair.
In the main interface, press this key to switch the massage method. Select from
kneading, tapping, knocking, kneading&tap , and shiatsu.
In the power-on state, press this key to turn on and off the waist heating function. When
In the state of manual massage, you can press this button to select Whole, Partial and
Point .
The navigation direction keys have four buttons: up, down, left, and right. They are used
In the menu mode in the power-on state, press this key to confirm the selection of menu
items and pop up the next menu.
During the operation of manual tapping, knocking and shiatsu, press this button on the
main interface to adjust the massage width. Narrow , Middle and Wide can be selected.
Under the state of air pressure massage, press this key to adjust the air pressure
intensity, 5 levels can be adjusted.
Under the manual massage state, press this key to adjust the massage speed, 5 levels
can be adjusted.
Under the state of power on, press this key, the sole roller can select three speed of
Quick, Soft and Stop in sequence.
Press and hold this button, the leg will rise, release this button, the leg will stop
running.
Press and hold this button, the leg will descend, release this button, the leg will stop
running.
Press and hold this button, the backrest goes up and the legrest goes down.
Release this button and the backrest and legrest stop running.
Press and hold this button, the backrest goes down and the legrest goes up.
Release this button and the backrest and legrest stop running.
In the power-on state, press this button to adjust the chair posture to zero gravity ,
Manual control
Manual control Manual control
saM as eg repo oita n
saM as eg epo r ta oi n
Auto Manual Airbag
Roller Heating Timing
Setting Stop
Menu
Select by the navigation keys
OK
AUTO EMERGENCY
MENU
Heating
Method
Position
Foot roller
Back up &Leg down
Back down & leg up
On/Off
Menu
Confirm button
Left
Up
Right
Down
Auto
Heating
Air pressure
Zero-Gravity
Legrest up
Legrest down
Speed
Width
Intensity
Emergency
Method
Position
AUTO
EMERGENCY
MENU
Method
Heating
Position

17 18
Menu Interface
After power on ,if you press the “on/off ”button,the buzzer will ring with a
short and crisp sound.The LCD displays the main menu interface and
enters the standby state.The Main screen displays information such as
auto,manual ,airbag,roller, heating, timing,setting ,stop current working
state,etc.Those information will be updated in real time after the operation.
Menu Main Interface
Manual Massage: On the main interface of
the menu, select manual massage through
the navigation key. After pressing the "OK"
key, there are four functional options: mode,
position, width and speed; After selecting the
corresponding function, press "OK" to enter
the next menu, and select the desired massage
mode: kneading, tapping, knocking, kneading
and tapping, shiatsu; Massage position include
whole, partial and point; Massage width
and speed.
Stop: In the main interface of the
menu, use the navigation keys to
select Stop. After pressing the
[OK] key, the massage chair stop
massaging, and heating turn off.
Press Menu key again, to go back
to main interface.
Heating: In the main interface of the menu,
use the navigation keys to select Heating.
After pressing the [OK] key, you can
choose to turn on or turn off waist heating.
Auto Massage: After pressing the “on/off”key, the cursor will stop in
the automatic massage program by default. After pressing the “OK”
key, you will enter the menu interface. There are the following
massage modes:“Recover ”,“Relief”,“Stretch”,“Music Sync”,“Renew”,
Calming”and “Special ”.Under Special , there are two automatic
massage modes to choose after pressing “OK”.
After pressing the “OK”Key in the main menu interface,it will
switch to the menu interface and all massage functions can be
set by pressing the button.Pressing the “Menu”key in the menu
interface will exit the menu and return to the main interface.
Airbag: In the main menu interface, use the navigation keys to
select "Airbag", after pressing the [OK] key, there are two air
pressure function options: position and intensity. After selecting
the corresponding function, press the [OK] key to enter the next
menu and select the desired massage parts: full body, upper
body, legs and feet; massage intensity: 5 levels of display.
Foot Roller: In the main interface of the
menu, use the navigation keys to select
Roller. After pressing the [OK] key, you
can choose quick, soft and stop.
When power on, the first time you use
the auto program, massage chair will
start the body scan and “body
scanning ...'' will be shown on screen.
After the body scan is finished, the
Timer: In the main interface of the
menu, use the navigation keys to
select Timer. After pressing the [OK]
key, you can choose massage time to
10 mins, 20mins or 30 mins. The
default time is 20 mins, the massage
chair will turn off automatically when
the time is up.
Settings:In the main interface of
the menu, use the navigation keys
to select Settings. After pressing
the [OK] key, you can choose the
desired language.
中文
English
한글
Massage State Interface
Under the main interface of the menu
displayed on the LCD screen,press the
“Menu”button to enter the massage state
interface,and then press the “Menu”button
to return to the main interface of the menu.
Auto Manual
Roller Heating Timing
Setting Stop
Menu
Select by the navigation keys
Airbag
Kneading
Tapping
Shiatsu
Knocking
Massage
time left
Zero gravity
09:35
Massage width(narrow, mid, wide)
Air Massage Strength( 5 levels)
Massage speed（5 levels）
Auto
Manual
Roller
Heating
Timer
Settings
Stop
Menu
Select by the navigation keys
Airbag
Recover
Relief
Stretch
Music Sync
Renew
Calming
Special Refresh
Energy
Auto
Manual
Roller
Heating
Timer
Settings
Stop
Airbag
Select by the navigation keys
Mode
Position
Width
Speed
Level 1
Level 2
Level 3
Level 4
Level 5
Kneading
Tapping
Knocking
Knead&Tap
Shiatsu
Narrow
Middle
Wide
Whole
Partial
Point
Menu
Select by the navigation keys
Menu
Position
Intensity
Full Body
Upper Body
Legs & Feet
Level 1
Level 2
Level 3
Level 4
Level 5
Auto
Manual
Roller
Heating
Timer
Settings
Stop
Airbag
Auto
Manual
Roller
Heating
Timer
Settings
Stop
Airbag
Auto
Manual
Roller
Heating
Timer
Settings
Stop
Airbag
Auto
Manual
Roller
Heating
Timer
Settings
Stop
Airbag
Select by the navigation keys
Menu
Quick
Soft
Stop
Select by the navigation keys
Menu
ON
OFF
Select by the navigation keys
Menu
10 min
20 min
30 min
Select by the navigation keys
Menu
Language
Auto
Manual
Roller
Heating
Timer
Settings
Stop
Airbag
Massage operation
Manual control
LCD display graphic description
Massage operation
Manual control
LCD display graphic description
Massage function
Massage position
Auto
Manual
Massage State
Airbag
Roller
Heating
Timer
Settings
Stop
buzzer will tick (once every second). At this point, the massage rollers
are in the shoulder position, you can press Up and Down to adjust.
When adjusting, “shoulder height adjusting...” will be displayed on the
screen. The default working time is 20 minutes. The massage chair will
turn off and reset to its upright position once the massage is over.
Body Scanning
Body Scanning
Body Scanning…
Set function by pressing Menu key

How to Use the Simple Control
How to Use the Simple Control How to Use the Simple Control
19 20
1. Press on/off key to turn on or turn off the chair.
5. Keep pressing this button for seconds , backrest goes down and legrest goes up.
Release this button, backrest and legrest stops moving, the angle is locked in this
position.
4. Keep pressing this button for seconds, backrest goes up and legrest goes down.
Release this button, backrest and legrest stops moving, the angle is locked in this
position.
2. In on status, press the Auto to enter three auto programs: Recover, Relief , Stretch .
3. In on status , press this button , massage chair will go to Zero-gravity position, press it
again to return to the original position.
AUTO
AUTO
Massage operation Massage operation
On/Off
Auto
Zero-Gravity
Back up &Leg down
Back down & leg up

21 22
Backrest Down/Legrest Up
2
32
1
1
Backrest up/Legrest down
a
3
4
Foot massage function :
The foot has an all-around
rolling and airbag massage
function. By stimulating the
foot reflection area, it can
dredge the meridians of
human body, regulate and
restore the body's viscera
function, effectively improve
human body resistance and immunity.
Press this button on controller,
backrest goes down and
legrest goes up. Release
this button, backrest and
legrest stops moving,the
angle is locked in this
position.
Press this button on controller,
backrest goes up and legrest
goes down. Release this
button, backrest and
legrest stops moving,
the angle is locked in
this position.
Operation instruction and function illustration
Massage operation
ON/OFF
Massage operation
Operation instruction and function illustration
Function Illustration
Remote control
① Operate according to controller operation
instructions. As for the massage method's
details, please refer to remote control's
Usage page.
② When the massage ends, massage machine
will return to the default position, meanwhile
"Shutting down" will be displayed on the
controller.
④ Press "ON/OFF" button on the remote which
will beep once. It will then enter the display
interface .
① Put one end plug of power line to “a” hole.
② Put power plug to socket.
③ Turn on the power switch on the power
box, massage chair powers on.
Step1. Power on
Power switch
Step2. Massage
Step3. Turn off the power
①When the chair is On, press On/Off button
to turn off the massage chair and it will
restore automatically.
Turn off the power switch on the bottom of ②
the back of chair after the rollers reach
storage position.
Unplug the power plug from the socket.③
1. Before using, pull up the pillow,
back cushion etc. to check if the
PU material is broken, if there is
damage, please stop using,
unplug the chair, and ask for
repairment.
2. Only plug to proper socket.
Warning
Attention
1.Before sitting down, make sure there is no
things pinched between armrest, legrest ,
backrest and seat of the chair.
the chair is in reset state before 2.Make sure
using.
3.Do not stand on it when using the massage
chair.
Legrest can extend or retract within a
range of 22 CM.
Legrest Up
Press this button on controller,
legrest goes up.Release the
button,legrest stops moving,
the angle is locked in this
position.
Legrest Down
Press this button on controller,
legrest goes down.Release
the button,legrest stops
moving, the angle is
locked in this position.
Zero gravity
Press the button "Zero” ,backrest
go down and legrest raise up,
the chair go into Zero gravity status
automatically.Press the Button again,
the backrest and legrest stop
moving, and it will lock at
this position.However to
change the angles,we
can keep comfortable
massage status all the time.
Legrest extend and retract
The armrest has built-in pulse
pressure massage function,
put your arm in the air bag
when it is not inflating.
After the airbag is inflated,
the arm and palm can be
massaged,no matter how
the seat changes, can
always maintain a
comfortable massage
state on the arm.
Arm massage
Multilayer extrusion airbags
is deployed on both sides
of the shoulder. Achieve
pressure shoulder
stretch massage,
relieve shoulder
fatigue.
Shoulder massage
Foot massage function
1. Please make sure there is no people, no pets or any stuff around the backrest to avoid unexpected hurt or
property loss.
2. When adjusting the backrest, be careful of the gap between the backrest and armrest.
3. When the legrest is moving, please do not stand on or leave from the seat, do not stop the legrest from moving
in case of causing damage to the chair.
4. Please refer to control instruction for more details.
OK
AUT O EMERGENCY
MENU
Heating
Method
Position

23 24
4
1
2
5
6
3
Massage operation
After massage
Restoration of massage chair
Clean and Maintenance
Maintenance
Put the controller back into the controller
bag of the right armrest after the chair
back to the initial position.
Make sure there is no people or pet or anything
within the range of backrest and legrest.
Make backrest and legrest restore to the
normal position by controller.(or press
ON/Off key to make backrest and legrest
restore to the normal position)
Switch off the power.
Unplug the electricity from the socket.
(Attention: hold the right plug position)
Clean the chair if necessary.
Attention!
After using, press ON/OFF to end all the
massage method and wait for restoration.
Make sure to cut the electricity to avoid any
unexpected hurt to children or pets.
After using, turn off the power, unplug the
electricity. Avoid moisture, dirt and aging
of insulation in case of causing damage.
Or
●
1
●
2
●
3
●
1
●
2
●
3
●
4
●
4
●
1
●
2
●
3
●
1
●
2
●
1
●
3
●
2
●
2
●
1
●
1
●
1
●●
3
2
Synthetic leather
Plastic parts
Do not use the thinner,
gasoline, alcohol or
other chemical
materials.
Clean with tidy, soft and dry cloth slightly.
Dip soft cloth into 3-5% neutral detergent
solution, squeeze it then clean the stain on
the surface gently.
Wash cloth, squeeze it and wipe with
detergent.
General cleaning
Clean it softly with dry cloth.
Allow to dry (air blower is prohibited)
If leather is dirty
Brush the dirty parts
with weak neutral detergent.
(avoid excessivebrushing)
Dip cloth into weak neutral
detergent, squeeze it and clean
the material surface.
Wipe with water-dipped but
squeezed cloth.
Excessive cleaning may cause
damage to cloth material.
Allow to dry.
Do not use the thinner, gasoline,
alcohol or other chemical
materials.
Cloth material
Dip cloth into neutral detergent,
squeeze it and clean.
Wipe with water-dipped but
squeezed cloth.
Allow to dry.
Clean the controller
Wipe with soft cloth after squeezing.
Allow to dry.
Do not use the thinner, gasoline, alcohol or
other chemical materials.
Remote control
About cleaning
Before cleaning, unplug the electricity,
don't touch plug with wet hands.
Make sure hands are dry when plugging
to the socket.
If failed to follow the mentioned instruction,
user may get electric shock or burned.
Water
Water
Neutral Detergent
Neutral Detergent
Water
Neutral Detergent
Water
OK
AUTO EMERGENCY
MENU
Heating
Method
Position
OK
AUTO EMERGENCY
MENU
Heating
Method
Position

25 26
180W
1160×770×1265mm
（ )L×W×H
84/100.5kg
Malfunction guide
FAQ and Troubleshooting
Note: If the troubles are not caused by above reasons, please turn off the power switch and
cut off the power, then contact the manufacturer or service agent to repair your chair.
Trouble Possible reason Troubleshooting
The massage chair can't
work after power is on.
Massage function suddenly
stops while working.
Check if the control is on or not.
Setting time is up.
Open control switch
Not choose massage function Choose massage function
Normal sound, no need to pay
attention to it.
Normal, no need to pay attention to it.
Turn off the power to have the
massager rest for over half an
hour before next turn working.
Connect the electricity power again
Check whether the plug and socket
in poor contact.
It is sound of air pump, motor and
mechanical parts.
Inner parts fretted away due to long
time work. It’s normal
Sound suddenly becomes
much louder while working.
Remove the obstacles; turn off
the power to have the massager
rest for over half an hour before
next turn working.
Check if there are any obstacles; the
chair overloads; for the sake of safety,
sometimes the massage machine may
automatically stop working.
Neither the backrest nor the
legrest can be lay down.
Please ask manufacturer or appointed
or authorized maintenance man for
checking and replacement.
Excessive operation; setting time is up.
The chair can't return to its
original position.
Massage rollers work on shifts.
Different height of the left
roller and right roller.
Make sure plug and socket are connected.
There is beep sound inside
the massager while working.
Check if it is due to long time working.
Please ask appointed or authorized
maintenance man for checking and
repairing.
Electric wire or plug
give out heat
Turn off the power to have the
massager rest for over half an
hour before next round working.
Wire or plug has damaged.
Please ask manufacturer or appointed
or authorized maintenance man for
checking and replacement.
The fuse burned out.
Replace fuse of same specification.
Something wrong with inner circuit
Please ask appointed or authorized
maintenance man for checking and
repairing.
Suddenly power-down
Turn off the power to have the
massager rest for over half an
hour before next turn working.
Stop using，and ask appointed
maintenance man for help.
It may work overload
Other abnormal case
Others
Technical data
Technical data
Others
Name
Model
Input voltage
Safety design
NW/GW
Packing size
Power
Class
Massage Chair
Ⅰ
120V~ 60Hz
AD-Infinix
