ADT A1-ETHERNET User manual

January 3, 2017
Part #11010 © 2017 ADT
A1-ETHERNET
Multiprotocol Ethernet Interface
Thank you for purchasing the A1-ETHERNET Multiprotocol Ethernet Interfac e.
•This product is designed to connect the iMASTER Standard A1 series of inverters to Ethernet
communication networks. Please read this instruction manual thoroughly in order to become
familiar with the proper interface handling, installation and usage procedures.
•Improper handling may inhibit correct operation or caus e premature interface failure.
•Please deliver this instruction manual to the end user of the interface, and retain it in an
accessible location.
•For inverter usage instructions, please refer to the applicable inverter instruction manual.
Instruction
Manual

1
A1-ETHERNET Multiprotocol Ethernet Interface Instruction Manual
Part Number 11010
Printed in U.S.A.
©2017 ADT
All rights reserved
ADT reserves the right to make changes and improvements to its products without providing notice.
Notice to Users
PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE-SUPPORT
DEVICES OR SYSTEMS. Life-support devices or systems are devices or systems intended to sustain
life, and whose failure to perform, when properly used in accordance with instructions for use provided in
the labeling and user's manual, can be reasonably expected to result in significant injury.
No complex software or hardware system is perfect. Bugs may always be present in a system of any
size. In order to prevent danger to life or property, it is the responsibility of the system designer to
incorporate redundant protective mechanisms appropriate to the risk involved.

2
Preface
This instruction manual has been prepared to help you connect your iMASTER Standard A1 inverter to
Industrial Ethernet networks using the A1-ETHERNET Multiprotocol Ethernet interface card. This
instruction manual does not contain inverter usage instructions. Please refer to this instruction manual in
conjunction with the applicable inverter instruction manual in order to become familiar with the proper
handling, installation and operation of this product. Improper handling or installation procedures may
result in incorrect operation or premature product failure.
Related Publications
Listed below are public ations that are necessary for reference in conjunction with this instruction manual.
•A1 Instruction Manual
These documents are subject to change without notice. Please be sure to refer to the most recent
available versions.
Safety precautions
Please read this instruction manual thoroughly prior to proceeding with installation, connections,
operation, or maintenance and inspection. Additionally, ensure that all aspects of the system are fully
understood, and familiarize yourself with all safety information and precautions before operating the
inverter.
Safety precautions in this instruction manual are classified into the following two categories:
Failure to heed the information indicated by this symbol may lead
to dangerous conditions, possibly resulting in death or serious
bodily injuries.
Failure to heed the information indicated by this symbol may lead
to dangerous conditions, possibly resulting in minor or light bodily
injuries and/or substantial property damage.
Failure to heed the information contained under the CAUTION title can also result in serious
consequences. These safety precautions are of utmost importance and must be observed at all times.

3
Installation and Wiring
•To avoid electrical shock, remove all power from the inverter and wait at least five minutes prior to
starting installation. Additionally, confirm that the DC link bus voltage as measured between the P
(+) and N (-) terminals is less than 25 VDC.
•Installation should be performed only by qualified personnel.
•To avoid electrical shock, do not operate the inverter with the front cover or wiring cover removed,
as accidental contact with exposed high-voltage terminals and internal components may occur.
•To prevent explosions or similar damage, ensure that all cables are properly connected to the
correct terminals, and observe all wiring polarity indic ators.
•Do not install or operate the interface if it is damaged or has parts missing.
•Prevent conductive items such as screws and metal fragments, or flammable substances such as
oil, lint, paper fibers and sawdust from entering the inverter and interface card enclosure.
•Incorrect handling during installation or removal may cause equipment failure.
•Do not subject the cables to scratches, excessive stress, heavy loads or pinching.
•To prevent damage due to electrostatic discharge, always touch a grounded piece of metal prior
to touching any equipment.
•Do not stand on or rest heavy objects on the equipment.
•To prevent burns from hot components, do not touch the inverter while power is on, or for some
time after power is removed.
•Electrical noise may be emitted from the inverter, motor and wires. Always implement appropriate
countermeasures to prevent nearby sensors and devices from malfunctioning due to such noise.
Operation
•To avoid electrical shock, do not open the front cover of the inverter while power is on or while the
inverter is running.
•To avoid electrical shock, do not operate switches with wet hands.
•If the inverter’s parameters are incorrectly configured, or configured without adequate
understanding of the appropriate inverter Instruction Manual and User's Manual, the motor may
rotate with a torque or at a speed not permitted for the machine. Confirm the settings of all
parameters prior to running the inverter.

4
Maintenance, inspection, and parts replacement
•To avoid electrical shock, remove all power from the inverter and wait at least five minutes prior to
starting inspection. Additionally, confirm that the DC link bus voltage as measured between the P
(+) and N (-) terminals is less than 25 VDC.
•Maintenance, inspection, and parts replacement should be performed only by qualified personnel.
•Remove all watches, rings and other metallic objects prior to starting work.
•To avoid electrical shock or other injuries, always use insulated tools.
Disposal
•Contact the local or state environmental agency in your area for details on the disposal of
electrical components and packaging.
Other
•Do not attempt to modify the equipment: doing so may cause electrical shock or injuries.
•For clarity purposes, illustrations in this manual may be drawn with covers or safety guards
removed. Ensure all covers and safety guards are properly installed prior to starting operation.
•Do not perform hi-pot tests on the equipment.
•Performing a parameter initialization (parameter 97.01) may res et all inverter parameters to their
factory default settings. After performing this operation, remember to reenter any custom
parameter values prior to starting operation.
Icons
The following icons are used throughout this manual:
Indicates information which, if not heeded, can result in the product not operating to full
efficiency, as well as information concerning incorrect operations and settings which may
result in accidents.
Indicates information that can prove handy when performing certain settings or operations.

Indicates a referenc e to more detailed information.

5
−TABLE OF CONTENTS −
1PRE-OPERATION INSTRUCTIONS ........................................................... 8
1.1 Product Overview .................................................................................................... 8
1.2 Features and Specifications................................................................................... 8
1.3 Component Overview............................................................................................ 14
1.4 LED Indicators ....................................................................................................... 15
1.4.1 Ethernet Link/Activity LEDs..............................................................................................15
1.4.2 Standard LED Description ...............................................................................................15
1.4.2.1 Module Status LED...................................................................................................15
1.4.2.2 Network Status LED .................................................................................................15
1.4.3 EtherCAT LED Description ..............................................................................................16
1.4.3.1 Module Status LED (Run) .........................................................................................16
1.4.3.2 Network Status LED (Error) ......................................................................................16
2INSTALLATION ....................................................................................... 17
2.1 Pre-Installation Instructions ................................................................................. 17
2.2 Installation Procedure ........................................................................................... 17
3INVERTER PARAMETER SETTINGS ...................................................... 18
4PARAMETER NUMBERING AND BEHAVIOR......................................... 19
4.1 Register Numbers.................................................................................................. 19
4.2 Scanned Parameters ............................................................................................. 21
4.3 Commonly Used Parameters................................................................................ 21
4.3.1 Run command (00.02) .....................................................................................................21
4.3.2 Frequency command (00.04) ...........................................................................................21
4.3.3 Output frequency monitor (01.01) ....................................................................................22
4.3.4 Rotation direction monitor (01.04) ....................................................................................22
4.3.5 Trip monitor .....................................................................................................................22
5ADT FIELDBUS OPTION CONFIGURATION STUDIO ............................. 23
5.1 Overview ................................................................................................................. 23
5.2 General Object Editing Activities......................................................................... 25
5.3 Ethernet Settings ................................................................................................... 26
5.3.1 Authentication ..................................................................................................................26
5.3.2 Network Configuration .....................................................................................................26
5.4 Internal Logic Settings .......................................................................................... 27
5.4.1 Fail-safe Values ...............................................................................................................27
5.4.1.1 Overview ..................................................................................................................27
5.4.1.2 Timeout Time ...........................................................................................................27
5.4.1.3 Timeout Object Configuration ...................................................................................27
5.4.2 Fail-safe Example ............................................................................................................27
5.5 Discovery over Ethernet ....................................................................................... 28
5.6 Manage Device Parameters .................................................................................. 28
5.7 Backup and Restore Parameters ......................................................................... 29
5.8 Restore Factory Settings ...................................................................................... 30
5.9 Help ......................................................................................................................... 30
6EMBEDDED WEB SERVER..................................................................... 31

6
6.1 Overview ................................................................................................................. 31
6.2 Monitor Tab ............................................................................................................ 31
6.2.1 Information Window .........................................................................................................31
6.2.2 Parameter Group Selection List .......................................................................................32
6.2.3 Parameter List .................................................................................................................32
6.2.4 Parameter List Filter ........................................................................................................33
6.2.5 Radix Selection................................................................................................................33
6.3 Dashboard Tab....................................................................................................... 34
6.3.1 Information Window .........................................................................................................34
6.3.2 Gauge Window Navigation...............................................................................................34
6.3.3 Gauge Window Configuration ..........................................................................................34
6.3.4 Submitting Changes ........................................................................................................37
6.4 Customizing the Embedded Web Server ............................................................ 38
6.4.1 Customization Overview ..................................................................................................38
6.4.2 XTPro Overview ..............................................................................................................38
6.4.3 XTPro Web Browser-Based Implementation ....................................................................39
6.4.4 XTPro HMI-Based Implementation...................................................................................40
6.4.5 XTPro Supported Commands ..........................................................................................40
7FILE SYSTEM .......................................................................................... 41
7.1 Overview ................................................................................................................. 41
7.2 USB with Windows Explorer ................................................................................ 41
7.3 FTP with Windows Explorer ................................................................................. 42
7.4 Loading New Web Server Content....................................................................... 42
8Firmware ................................................................................................. 44
8.1 Overview ................................................................................................................. 44
8.2 Update Procedure.................................................................................................. 44
9PROTOCOL-SPECIFIC INFORMATION................................................... 45
9.1 Modbus/TCP ........................................................................................................... 45
9.1.1 Overview .........................................................................................................................45
9.1.2 Holding & Input Registers ................................................................................................45
9.1.3 Coil & Discrete Input Mappings ........................................................................................45
9.1.4 Connection Timeout Options............................................................................................46
9.1.5 Node Settings ..................................................................................................................47
9.1.6 Holding/Input Register Remap Settings ...........................................................................47
9.2 EtherNet/IP ............................................................................................................. 48
9.2.1 Overview .........................................................................................................................48
9.2.2 Server Settings ................................................................................................................48
9.2.3 Connection Timeout Options............................................................................................49
9.2.4 Generic Class 1 I/O Produced and Consumed Data Settings...........................................49
9.2.5 Generic Class 1 (I/O) Connection Access ........................................................................50
9.2.6 AC/DC Drive Profile Class 1 (I/O) Connection Access .....................................................50
9.2.7 Explicit Messaging Via Get/Set Attribute Single Services .................................................52
9.2.8 Explicit Messaging Via Data Table Read/Write Services..................................................52
9.2.9 Inverter Parameter Access Tag Format ...........................................................................53
9.2.10 ControlLogix Examples: Setup .........................................................................................53
9.2.11 ControlLogix Example: EDS Add-On Profile (AOP) ..........................................................54
9.2.11.1 ControlLogix Example: EDS Add-On Profile (AOP) Generic I/O Messaging ..............57
9.2.11.2 ControlLogix Example: EDS Add-On Profile (AOP) AC/DC Drive Profile ...................58
9.2.12 ControlLogix Example: I/O Messaging .............................................................................58

7
9.2.12.1 ControlLogix Example: Generic Default I/O Add-On Instruction ................................61
9.2.12.2 ControlLogix Example: AC/DC Drive Profile Add-On Instruction ...............................62
9.2.13 ControlLogix Example: Read Parameters ........................................................................64
9.2.14 ControlLogix Example: Reading and Writing MSG Instructions ........................................68
9.3 Allen Bradley CSP (PCCC).................................................................................... 69
9.3.1 Overview .........................................................................................................................69
9.3.2 Explicit Messaging Via Typed Read/Write Services .........................................................69
9.3.3 Inverter Parameter File Number Offset Format ................................................................69
9.3.4 SLC-5/05 Example: Read Parameters .............................................................................71
9.3.6 SLC-5/05 Example: Reading and Writing Multiple MSG Instructions ................................76
9.4 BACnet/IP ............................................................................................................... 77
9.4.1 Protocol Implementation Conformance Statement ...........................................................77
9.4.2 Default Supported Objects ...............................................................................................81
9.4.3 Default Supported Object Details .....................................................................................82
9.4.4 Server Settings ................................................................................................................82
9.4.5 Node Settings ..................................................................................................................82
9.4.6 Device Object Settings.....................................................................................................82
9.4.7 BACnet Object Settings ...................................................................................................82
9.4.8 Analog Input Object Settings............................................................................................83
9.4.9 Analog Output Object Settings .........................................................................................83
9.4.10 Analog Value Object Settings ..........................................................................................83
9.4.11 Binary Input Object Settings.............................................................................................84
9.4.12 Binary Output Object Settings..........................................................................................85
9.4.13 Binary Value Object Settings ...........................................................................................85
9.4.14 Multi-state Input Object Settings ......................................................................................86
9.4.15 Multi-state Output Object Settings....................................................................................86
9.4.16 Multi-state Value Object Settings .....................................................................................87
9.5 PROFINET IO .......................................................................................................... 88
9.5.1 Overview .........................................................................................................................88
9.5.2 Device Settings................................................................................................................88
9.5.3 Connection Timeout Options............................................................................................88
9.5.4 Cyclic I/O Produced and Consumed Data Access Settings ..............................................88
9.5.5 PROFIdrive Profile...........................................................................................................89
9.5.5.1 PROFIdrive standard telegram 1 ..............................................................................90
9.5.5.2 PROFIdrive control and status words........................................................................90
9.5.5.3 PROFIdrive reference speed setpoint and actual speed ...........................................91
9.5.5.4 PROFIdrive state diagram ........................................................................................92
9.5.5.5 PROFIdrive-specific parameters ...............................................................................92
9.5.6 Acyclic Data Access ........................................................................................................93
9.5.7 TIA Portal (STEP 7) Hardware Configuration Example.....................................................93
9.5.7.1 Register the GSDML file ...........................................................................................93
9.5.7.2 Add the device to the configuration...........................................................................94
9.5.7.3 Select the IO controller .............................................................................................94
9.5.7.4 Assign IO module .....................................................................................................94
9.5.7.5 Configure the device properties ................................................................................95
9.5.7.6 Online device discovery and configuration ................................................................96
9.5.7.7 Save the c onfiguration ..............................................................................................97
9.6 EtherCAT ................................................................................................................ 98
9.6.1 Overview .........................................................................................................................98
9.6.2 Device Settings................................................................................................................98
9.6.3 Transmit and Receive Process Data Word Settings .........................................................98
10 TROUBLESHOOTING ....................................................................... 100

8
1 PRE-OPERATION INSTRUCTIONS
1.1 Product Overview
The A1-ETHERNET Multiprotocol Ethernet interfac e allows information to be transferred seamlessly
between an iMASTER Standard A1 inverter and several Ethernet-based fieldbus networks with minimal
configuration requirements. The interface installs directly onto the inverter, and presents two RJ-45 jacks
with an embedded 10BASE-T/100BASE-TX Ethernet switch for connection to the Ethernet network. In
addition to the supported fieldbus protocols, the interface also hosts a fully-customizable embedded web
server, which provides access to inverter information via a standard web browser for remote monitoring
and control.
Before us ing the interface, please familiarize yourself with the product and be sure to thoroughly read
the instructions and precautions contained in this manual. In addition, please make sure that this
instruction manual is delivered to the end user of the interface, and keep this instruction manual in a safe
place for future reference or unit inspection.
Note that different interface firmware versions may provide varying levels of support for the various
protocols. When using this manual, therefore, always keep in mind the release date of the firmware
version running on your interface as it must correspond to this manual’s respective release date in order
for all documented aspects to apply.
Supported Protocols
The interface currently provides server support for the following fieldbus protocols:
•Modbus/TCP Server
•EtherNet/IP Server (DLR node)
•Allen Bradley CSP Server (also known as “PCCC” and “AB Ethernet”)
•BACnet/IP Server
•PROFINET IO Device (MRP client)
•EtherCAT Slave
1.2 Features and Specifications
Table 1: Features
Item
Description
Simultaneous Protocols
Supports all standard unmodified Ethernet (SUE) protocols
simultaneously
ADT Fieldbus Option
Configuration Studio
Graphical user interface for discovery, configuration, and firmware
update
WEB Server (HTTP)
Access all parameters, dashboard with gauges, customizable with
XTPro
Communication Loss Detection
Configurable actions for “fail-safe” conditions
Field Upgradeable
Firmware updates automatically handled by the studio
Parameter Management
Advanced management of parameter access and scan priority
Parameter Backup and Restore
Drive cloning

9
Table 2: General Hardware Specifications
Item
Description
Power Supply
Directly powered by the inverter
LED Indicators
Module Status, Network Status, 2 x Ethernet Link/Activity
USB Port
USB 2.0, mini-B 5-pin
Table 3: Ethernet Hardware Specifications
Item
Description
Number of Ports
2 (internal switch)
Standard
IEEE 802.3 10BASE-T/100BASE-TX Ethernet compliant
Communication Speed and
Duplex
10Mbps half/full, 100Mbps half/full (auto sense optimal speed and
duplex)
Connector Type
RJ-45 Shielded
Auto MDI-X
Yes (supports all straight-through and cross-over cables)
Cable Type
CAT5-type 8-conductor UTP patch cables
Cable Length
100m per segment max
Topologies
Star/Tree, Linear/Bus/Daisy-chain, Ring (MRP / DLR)
Table 4: Modbus/TCP Specifications
Item
Description
Conformance Class
Class 0, Class 1 (partial), Class 2 (partial)
Read Function Codes
Read coils (1), Read input status (2), Read multiple registers (3),
Read input registers (4), Diagnostics (8)
Write Function Codes
Write coil (5), Write single register (6), Force multiple coils (15),
Write multiple registers (16)
Number of Connections
8
Max Read Register Size
125 registers
Max W rite Register Size
123 registers
Register Data Type
16-bit integer
Unit (slave) ID
Ignored, echoed in response
TCP Port
502
Response Time
Min 160us, Typically less than 1ms

10
Table 5: EtherNet/IP Specifications
Item
Description
Conformance Tested
ODVA EtherNet/IP Conformance Test Software Version CT-13
Product Type Code
2 (AC Drive)
AC/DC Drive Profile
Yes
UCMM
Yes
Class 3 (Explicit) Messaging
Yes
Class 1 (Implicit I/O) Messaging
Yes
Class 1 Unicast T→O
Yes
Class 1 Multicast T→O
Yes
Number of Connections
16 (Total for both Class 1 and Class 3)
RPI
Min 1ms
I/O Input Size
Max 32 input words, user c onfigurable
I/O Output Size
Max 32 output words, user configurable
Generic (User Configurable)
Assembly Instances
100 (input) and 150 (output)
AC/DC Drive Profile Assembly
Instances
20 (input) and 70 (output), 21 (input) and 71 (output)
Data Table Read/Write
Yes
DLR
Device Level Ring Node
Class 1 UDP Port
2222 (0x08AE)
Explicit Messaging Port
44818 (0xAF12)
Explicit Messaging Response
Time
Min 160us, Typically less than 1ms

11
Table 6: Allen Bradley CSP (PCCC) Specifications
Item
Description
Read Services
PLC5 Read (DF1 protocol typed read, 0x68)
Write Services
PLC5 Write (DF1 protocol typed write, 0x67)
Data Type
16-bit Integer
File Type
N (Integer)
Logical ASCII Addressing
Yes
Logical Binary Addressing
Yes
Max Read Size
240 bytes (120 16-bit Integers)
Max W rite Size
240 bytes (120 16-bit Integers)
Table 7: BACnet/IP Specifications
Item
Description
BACnet IP
Annex J
Protocol Revision
2
Standard Device Profile
(Annex L)
BACnet Application Specific Controller (B-ASC)
BACnet Interoperability Building
Blocks (BIBB)
ReadProperty-B (DS-RP-B), ReadPropertyMultiple-B (DS-RPM-B),
WriteProperty-B (DW-WP-B), Dynamic Device Binding-B (DM-
DDB-B), Dynamic object Binding-B (DM-DOB-B)
Segmentation
No
Max APDU Length
1444 bytes
Character Sets
ANSI X3.4
Object Types
Analog Output, Analog Input, Analog Value, Binary Output, Binary
Input, Binary Value, Multi-state Output, Multi-state Input, Multi-state
Value
Priority Array
Yes
UDP Port
47808 (0xBAC0, configurable)
Response Time
Min 160us, Typical less than 1ms
Table 8: PROFINET Specifications
Item
Description
Protocol Level
RT (real-time)
RT Conformance Class
Class B
Netload Class
III

12
Item
Description
I/O Cycle Time
Min 1ms
I/O Input Size
Max 32 input words, user configurable
I/O Output Size
Max 32 output words, user configurable
MRP
Media Redundancy Protocol Client
DCP
Discovery, set station name, set IP address
LLDP
Yes
I&M
I&M0
Alarms
Plug, Pull
Number of Controllers
Allows access to only 1 controller
Table 9: EtherCAT Specifications
Item
Description
Conformance Tested
EtherCAT ET9400 Conformance Test Tool V1.20.80
Source Code
Beckhoff ET9300 EtherCAT Slave Source Code (SSC) V5.10
Slave Controller
Equivalent to Beckhoff ET1100
Process I/O Transmit Size
Max 32 transmit words, user configurable
Process I/O Receive Size
Max 32 receive words, user configurable
Operating Modes
FreeRun/SM-Synchron, DC-Synchron
FreeRun Cycle Time
Min 1ms
Distributed Clocks
SYNC0/1
Fieldbus Memory Management
Unit (FMMU)
8 max
Sync Managers (SM)
8 max
Mailbox
CoE
CoE Complete Access Support
Yes
CoE SDO Info Support
Yes
Latency
700ns end-to-end
Table 10: Applicable Inverters
Series
Model
ROM version
A1
A1-032A-2 ~ A1-310A-2
A1-016A-4 ~ A1-217A-4
1.000 and later

13
Table 11: Environmental Specifications
Item
Description
Operating Environment
Indoors, less than 1000m above sea level, do not expose to direct
sunlight or corrosive / explosive gasses
Operating Temperature
-10 ∼+50°C (+14 ∼+122°F)
Storage Temperature
-40 ∼+85°C (-40 ∼+185°F)
Relative Humidity
20% ∼90% (without condensation)
Vibration
5.9m/s2(0.6G) or less (10 ∼55Hz)
Cooling Method
Self-cooled
RoHS (Lead free)
Yes

14
1.3 Component Overview
Figure 1 provides an overview of the important interface card components.
Port 1 and Port 2 Ethernet Jacks
Either jack can freely be used in star topology networks (with external switch). In linear topologies, a
series of cards can be connected together by daisy-chaining one of the ports to the next inverter in line.
In ring topologies, the applicable redundancy protocol (MRP, DLR etc.) must be supported by all devices
on the network.
Connector CN1
The option connector is located on the bottom side of the interface card and is plugged directly onto the
inverter. This provides power to the option card and allows communication with the inverter.
USB Port
USB 2.0 port with mini-B connector. Used to access the card via the studio (refer to section 5) and as a
USB flash drive (refer to section 7).
Module Status and Network Status LEDs
These LEDs indicate the current status of the interface card and protocols in use. Refer to section 1.4.
Ethernet Link and Activity LEDs
One set of LEDs are provided for each Ethernet port. These LEDs provide insight into the Ethernet
network’s status and activity. Refer to section 1.4.
Figure 1: A1-ETHERNET Component Overview
Port 1 Ethernet jack
USB port
CN1 (bottom side)
MAC Address
Module Status LED
Network Status LED
Port 1 Link/Activity LED
Port 2 Link/Activity LED
Port 2 Ethernet jack

15
1.4 LED Indicators
1.4.1 Ethernet Link/Activity LEDs
LED Activity
Status
Note
Green On Link
A valid Ethernet link exists: communication is
possible on this port
Green Off No Link
A valid Ethernet link does not exist: communication is
not possible on this port
Red Blink Activity
Indicates when a packet is transmitted or received on
this port
1.4.2 Standard LED Description
1.4.2.1 Module Status LED
LED Activity
Status
Note
Off
Device Off
The inverter power is off
Green Blink /
Red Blink
Startup Startup blink sequence
Green On
Device On
Normal status
Green Blink
Discovery
identification
PROFINET discovery and identification (DCP)
Red Blink
Error Code
Refer to the TROUBLESHOOTING section
1.4.2.2 Network Status LED
LED Activity
Status
Note
Off
Device Off
The inverter power is off
Green Blink /
Red Blink
Startup Startup blink sequence
Green Blink
No Connection
EtherNet/IP connection is not established
Green Off
No Connection
PROFINET connection is not established
Green On
Connection
Established
EtherNet/IP or PROFINET connection is established

16
1.4.3 EtherCAT LED Description
1.4.3.1 Module Status LED (Run)
LED Activity
Slave State
Note
Off
Device Off or
INITIALISATION
The inverter power is off or the device is in the INIT
state
Green Blink,
Red Blink or
Red Flickering
INITIALISATION Startup blink sequence; the device is booting and
has not yet entered the INIT state
Green Blinking
PRE-
OPERATIONAL
The device is in the PRE-OPERATIONAL state
Single Green
Flash
SAFE-
OPERATIONAL
The device is in the SAFE-OPERATIONAL state
Green On
OPERATIONAL
The device is in the OPERATIONAL state
Red Blink
Error Code
Refer to the TROUBLESHOOTING section
1.4.3.2 Network Status LED (Error)
LED Activity
Status
Note
Off
Device Off or No
Error
The inverter power is off or the EtherCAT
communication of the device is in working condition
Green Blink,
Red Blink
Startup Startup blink sequence
Red On
Application
Controller Failure
A critical communication or application controller
error has occurred
Double Red
Flash
Process Data
Watchdog
Timeout or
EtherCAT
Watchdog
Timeout
An application watchdog timeout has occurred
Single Red
Flash
Local Error
Slave device application has changed the EtherCAT
state autonomously, due to local error
Red Blinking
Invalid
Configuration
General configuration error

17
2 INSTALLATION
2.1 Pre-Installation Instructions
TBD
2.2 Installation Procedure
TBD

18
3 INVERTER PARAMETER SETTINGS
The inverter parameters listed in Table 12 are required for proper operation of the end-to-end
communication system. Although there may be many other parameters that will require configuration for
your specific application, it is important to understand the manner in which the following parameters will
impact successful control of the inverter.

For further details regarding these parameters, please refer to the A1 Instruction Manual,
"A1 Parameters".
Table 12: Parameter Settings Overview
Parameter Name
Setting
Range
Required
Value
50.01
Modbus node ID
1 to 32
1
31.22 RS485 Modbus time out check enable 0 to 1
0: Always active
1: Active only when
VFD is running
31.23
RS485 Modbus time out time
0 to 60
0: Disabled
51.01
Fieldbus option type
0 to 4
3: Ethernet
20.02
Ext1 commands
0 to 9
8: Fieldbus
22.03
Frequency ref 1 source
0 to 7
4: Fieldbus

19
4 PARAMETER NUMBERING AND BEHAVIOR
4.1 Register Numbers
All accessible inverter parameters can be referenced by their Modbus register indices, as defined in the
A1 Instruction Manual and can be conveniently referenced in the studio (section 5.6) and the
embedded web server (section 6.2.3). These same register numbers are us ed when accessing
parameters via certain Ethernet protocols. The terms “parameter” and “register” refer to data stored on
the inverter and will be used interchangeably throughout this documentation. The relevant information
will be paraphrased here for the specific case of the A1.
All inverter parameters are exposed as register numbers according to a mathematical conversion
formula which combines two elements (a parameter group number and parameter index) to create a
unique register number for each parameter. The parameter groups are listed in Table 13. Each
parameter also has an index, which is the parameter without the leading group number (the index for
parameter 01.02, for example, is 2). To determine the register number for a given parameter, therefore,
the group number is first multiplied by 256, then added to the index plus 1. This operation is expressed
mathematically via Equation 1.
( )
1index256number xgroupregister ++=
Equation 1
As an example, let’s calculate the register number for deceleration time1 (parameter 23.05). The group
number is 23 and the index is 5. Inserting the group number and index into Equation 1, we arrive at the
result indicated in Equation 2.
( )
589415256x23 =++
Equation 2
While manually calculating all of the register numbers for the parameters of interest is certainly possible
by using Equation 1, it may be more convenient to simply reference the “Register” column on the
monitor tab of the default web interfac e (refer to section 6.2.3). The parameter to register mapping list is
also available in the studio.
Note that not all of the available registers that exist in the interface card’s register map have
corresponding parameters that exist in the inverter. In other words, if a read from or write to a register
number that does not correspond to an existing inverter parameter takes place, the read/write may be
successful (depending on the specific register accessed; refer to section 4.2), but the data will have no
meaning. This feature is beneficial in situations where the accessing of non-contiguous registers can be
made more efficient by accessing an all-inclusive block of registers (some of which correspond to
inverter parameters and some of which do not), while only manipulating those in your local programming
that are known to exist.
