ADTRAN Total Access 908e Manual

Total Access 900e Series
Hardware Installation Guide
Total Access 908e
Total Access 916e
Total Access 924e
64243916F1-34A
August 2013

Trademarks Total Access 900e Series Hardware Installation Guide
2 Copyright © 2013 ADTRAN, Inc. 64243916F1-34A
Trademarks
Any brand names and product names included in this manual are trademarks, registered trademarks, or
trade names of their respective holders.
Total Access® is a registered trademark of ADTRAN, Inc.
To the Holder of the Manual
The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change
the contents without prior notice.
In no event will ADTRAN be liable for any special, incidental, or consequential damages or for
commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication.
Software Licensing Agreement
Each ADTRAN product contains a single license for ADTRAN-supplied software. Pursuant to the
Licensing Agreement, you may: (a) use the software on the purchased ADTRAN device only and (b) keep
a copy of the software for backup purposes. This Agreement covers all software installed on the system as
well as any software available on the ADTRAN website. In addition, certain ADTRAN systems may
contain additional conditions for obtaining software upgrades.
Third-Party Software
The software included in this product contains copyrighted software that is licensed under the GNU
General Public License (GPL). For a list of third-party software and their licenses, go to
http://www.adtran.com/software/EULA. You can obtain the complete corresponding source code of such
software components from ADTRAN for a period of three years after our last shipment of this product by
sending a money order or check for $5 to:
ADTRAN, Inc, P.O. Box 933638, Atlanta, GA 31193-3638
Please write GPL Source for product Total Access 900e in the memo line of your payment.
This offer is valid to anyone in receipt of this information.
901 Explorer Boulevard
P.O. Box 140000
Huntsville, AL 35814-4000
Phone: [phone]
Copyright © 2013 ADTRAN, Inc.
All Rights Reserved.
Printed in U.S.A.
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

Total Access 900e Series Hardware Installation Guide Conventions
64243916F1-34A Copyright © 2013 ADTRAN, Inc. 3
Conventions
Notes provide additional useful information.
Cautions signify information that could prevent service interruption or damage to the
equipment.
Warnings provide information that could prevent injury or endangerment to human
life.

Safety Instructions Total Access 900e Series Hardware Installation Guide
4 Copyright © 2013 ADTRAN, Inc. 64243916F1-34A
Safety Instructions
When using your telephone equipment, please follow these basic safety precautions to reduce the risk of
fire, electrical shock, or personal injury:
1. Do not use this product near water, such as a bathtub, wash bowl, kitchen sink, laundry tub, in a
wet basement, or near a swimming pool.
2. Avoid using a telephone (other than a cordless type) during an electrical storm. There is a remote
risk of shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord, power supply, and batteries indicated in the manual. Do not dispose of
batteries in a fire. They may explode. Check with local codes for special disposal instructions.
5. The socket-outlet shall be installed near the equipment and shall be easily accessible.
If any of the following conditions occur, unplug the product from the electrical outlet and replace the part
or contact your qualified service personnel:
1. The power cable, extension cable, or plug is damaged.
2. An object has fallen into the product.
3. The product has been exposed to water.
4. The product has been dropped or damaged.
5. The product does not operate correctly when you follow the operating instructions.
Save These Important Safety Instructions
These units contain no user-serviceable parts. They should only be serviced by qualified
service personnel.
Additional safety guidelines, such as Waste Electrical and Electronic Equipment (WEEE),
are given in the document NetVanta Safety and Regulatory Information available online at
http://supportforums.adtran.com.

Total Access 900e Series Hardware Installation Guide FCC-Required Information
64243916F1-34A Copyright © 2013 ADTRAN, Inc. 5
FCC-Required Information
FCC regulations require that the following information be provided in this manual:
1. This equipment complies with Part 68 of Federal Communications Commission (FCC) rules and
requirements adopted by America’s Carriers Telecommunications Association (ACTA). Each
registered interface has a label that contains, among other information, a product identifier in the
format US:AAAEQ##TXXXX. If requested, provide this information to the telephone company.
2. If this equipment causes harm to the telephone network, the telephone company may temporarily
discontinue service. If possible, advance notification is given; otherwise, notification is given as
soon as possible. The telephone company will advise the customer of the right to file a complaint
with the FCC.
3. The telephone company may make changes in its facilities, equipment, operations, or procedures
that could affect the proper operation of this equipment. Advance notification and the opportunity
to maintain uninterrupted service are given.
4. If experiencing difficulty with this equipment, please contact ADTRAN for repair and warranty
information. The telephone company may require this equipment to be disconnected from the
network until the problem is corrected, or it is certain the equipment is not malfunctioning.
5. This unit contains no user-serviceable parts.
6. This equipment is designed to connect to the telephone network or premises wiring using an
FCC-compatible modular jack, which is compliant with Part 68 and requirements adopted by ACTA.
7. The following information may be required when applying to the local telephone company for
leased line facilities:
8. The ringer equivalency number (REN) is useful in determining the quantity of devices you may
connect to your telephone line and still have all of those devices ring when your number is called.
In most areas, the sum of the RENs of all devices should not exceed five. To be certain of the
number of devices you may connect to your line as determined by the REN, call your telephone
company to determine the maximum REN for your calling area.
9. This equipment may not be used on coin service provided by the telephone company. Connection
to party lines is subject to state tariffs. Contact your state public utility commission or corporation
commission for information.
Product Registration Number Service Type REN/SOC FIC USOC
Total Access 908e
T1 Products US: HDCIT00B4243908F2 1.544 Mbps - SF
1.544 Mbps - SF and B8ZS
1.544 Mbps - ESF
1.544 Mbps - ESF and B8ZS
N/A/6.0N
04DU9-BN
04DU9-DN
04DU9-1KN
04DU9-1SN
RJ-48C
Total Access
916e/924e
T1 Products US: HDCIS00B1700254F2
Total Access 924e
with optional FXO
ports US: HDCIS00B1700254F2 Analog Loop Start/Ground Start 0.1A/9.0F 02LS2/02GS2 RJ-11C

FCC Radio Frequency Interference Statement Total Access 900e Series Hardware Installation Guide
6 Copyright © 2013 ADTRAN, Inc. 64243916F1-34A
FCC Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio frequencies. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Industry Canada Compliance Information
Notice: The Industry Canada label applied to the product (identified by the Industry Canada logo or the
“IC:” in front of the certification/registration number) signifies that the Industry Canada technical
specifications were met.
Notice: The REN for this terminal equipment is supplied in the documentation or on the product
labeling/markings. The REN assigned to each terminal device indicates the maximum number of terminals
that can be connected to a telephone interface. The termination on an interface may consist of any
combination of devices subject only to the requirement that the sum of the RENs of all the devices should
not exceed five (5).
Canadian Emissions Requirements
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus
as set out in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of the
Department of Communications.
Cet appareil numérique respecte les limites de bruits radioelectriques applicables aux appareils numériques
de Class A prescrites dans la norme sur le materiel brouilleur: “Appareils Numériques,” NMB-003 edictee
par le ministre des Communications.
Toll Fraud Liability
Be advised that certain security risks are inherent in the use of any telecommunications or networking
equipment, including but not limited to, toll fraud, Denial of Service (DoS) attacks, loss or theft of data,
and the unauthorized or illegal use of said equipment. ADTRAN OFFERS NO WARRANTIES, EITHER
EXPRESSED OR IMPLIED, REGARDING THE PREVENTION, DETECTION, OR DETERRENCE
OF TOLL FRAUD, NETWORKING ATTACKS, OR UNAUTHORIZED, ILLEGAL, OR IMPROPER
USE OF ADTRAN EQUIPMENT OR SOFTWARE. THEREFORE, ADTRAN IS NOT LIABLE FOR
ANY LOSSES OR DAMAGES RESULTING FROM SUCH FRAUD, ATTACK, OR IMPROPER USE,
INCLUDING, BUT NOT LIMITED TO, HUMAN AND DATA PRIVACY, INTELLECTUAL
PROPERTY, MATERIAL ASSETS, FINANCIAL RESOURCES, LABOR AND LEGAL COSTS.
Ultimately, the responsibility for securing your telecommunication and networking equipment rests with
you, and you are encouraged to review documentation regarding available security measures, their
configuration and implementation, and to test such features as is necessary for your network.
Service and Warranty
For information on the service and warranty of ADTRAN products, visit the Support section of the
ADTRAN website at http://www.adtran.com.

64243916F1-34A Copyright © 2013 ADTRAN, Inc. 7
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Physical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Shipping Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Reviewing the Front Panel Design. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Front Panel Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Reviewing the Rear Panel Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Total Access 908e Rear Panel Interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Total Access 916e and Total Access 924e Rear Panel Interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . 17
LED Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Unit Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Tools Required. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Mounting Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Wall Mounting Total Access 900e Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Rack Mounting Total Access 900e Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Grounding Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Grounding for AC Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Supplying Power to the Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Battery Backup Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Total Access 908e BBU (P/N 1200641L1). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Total Access 916e/924e BBU (P/N 1175044L1/L2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Unpack and Inspect the BBU. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
BBU Safety Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Wall Mounting the BBU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Wall Mounting the Total Access 908e BBU (1200641L1). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Wall Mounting the Total Access 916e/924e BBU (1175044L1/L2). . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Appendix A. Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Table of Contents Total Access 900e Series Hardware Installation Guide
8 Copyright © 2013 ADTRAN, Inc. 64243916F1-34A

64243916F1-34A Copyright © 2013 ADTRAN, Inc. 9
List of Figures
Figure 1. Total Access 900e Series Front Panel Layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 2. Total Access 908e Rear Panel Layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 3. Total Access 916e/924e Rear Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 4. Wall Mounting the Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Figure 5. Wall Mounting the 1200641L1 BBU. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Figure 6. Wall Mounting the 1175044L1/L2 BBU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

List of Figures Total Access 900e Series Hardware Installation Guide
10 Copyright © 2013 ADTRAN, Inc. 64243916F1-34A

64243916F1-34A Copyright © 2013 ADTRAN, Inc. 11
List of Tables
Table 1. Front Panel LED Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Table 2. BBU Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Table A-1. VOICE Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Table A-2. FXO 0/0 Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Table A-3. NET 1 through NET 4 (T1 0/1 through T1 0/4) Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Table A-4. 10/100Base-T (ETH 0/1 through ETH 0/2) Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Table A-5. 1000Base-T Gigabit Ethernet Port Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Table A-6. CRAFT Port Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

12 Copyright © 2013 ADTRAN, Inc. 64243916F1-34A
List of Tables Total Access 900e Series Hardware Installation Guide

64243916F1-34A Copyright © 2010 ADTRAN, Inc. 13
1. INTRODUCTION
This hardware installation guide describes the Total Access 900e Series units’ physical characteristics, lists their
features and specifications, introduces basic functionality, and provides installation instructions.
•Physical Description on page 14
•Product Specifications on page 20
•Unit Installation on page 21
For additional information on shipping contents, mounting options, and power the unit, refer to the following
sections:
•Shipping Contents on page 14
•Mounting Options on page 22
•Supplying Power to the Unit on page 25
•Battery Backup Unit on page 26
For information on Total Access 900e Series configuration for a specific application, refer to the configuration
guides provided on the ADTRAN Support Community. For details on the command line interface (CLI), refer to
the AOS Command Reference Guide. All other related documents are also available online at
http://supportforums.adtran.com.

Physical Description Total Access 900e Series Hardware Installation Guide
14 Copyright © 2010 ADTRAN, Inc. 64243916F1-34A
2. PHYSICAL DESCRIPTION
The Total Access 900e Series products are high-bandwidth Internet Protocol (IP) business gateways
designed for cost-effective deployment of up to 60 channels of Voice over IP (VoIP) services. The analog
and digital (T1 robbed bit signaling (RBS) and primary rate interface (PRI) trunks) voice interfaces
perform a gateway function into the service provider's VoIP network.
The last two digits of the product name indicate the number of on-board FXS ports. The Total Access 908e
contains 8 FXS ports, the Total Access 916e contains 16 FXS ports, and the Total Access 924e contains 24
FXS ports or 16 FXS ports plus 8 FXO ports with octal FXO daughterboard. The units can provision, test,
and provide status for any of the voice and data interfaces.
Total Access 900e Series products all run ADTRAN Operating System (AOS) application firmware and
include the AOS built-in IP router and firewall features. The units includes a VOICE interface (up to 24
foreign exchange station (FXS) ports or 16 FXS plus 8 foreign exchange office (FXO) ports), an optional
FXO trunk (FXO 0/0), 4 DS1 network interfaces (T1 0/1 through T1 0/4), 2 routed 10/100Base-T
interfaces (ETH 0/1, ETH 0/2), a single routed 10/100/1000Base-T Ethernet port (GIG 0/1), a Universal
Serial Bus (USB) port, and a CRAFT port (management interface). A connection (BBU) is provided for an
optional battery backup unit. The Total Access 900e Series units are RoHS compliant.
In common packet-based applications, the wide area network (WAN) can be terminated using the T1
interfaces (T1 0/1 through T1 04) or the Ethernet interfaces (GIG 0/1 or ETH 0/1, ETH 0/2). This interface
connects to the service provider's or carrier's network and transmits packetized voice and data over a
Session Initiation Protocol (SIP) trunk(s). The customer's data traffic is terminated using the internal router
on the Total Access 900e and is routed out the local area network (LAN) using one of the Ethernet
interfaces (GIG 0/1 or ETH 0/1, ETH 0/2). The customer's voice traffic can remain IP, for applications such
as hosted IP centrex using IP handsets, or an IP public branch exchange (PBX), and will route out one of
the Ethernet interfaces (GIG 0/1 or ETH 0/1, ETH 0/2). The customer's voice can also connect to legacy
phone systems that are presented as time division multiplexing (TDM), which use the FXS ports or PRI/
CAS interfaces (T1 0/1 through T1 0/4). AOS supports the simultaneous use of the IP and TDM interfaces
for voice applications.
Shipping Contents
Each Total Access 900e Series unit is shipped in its own cardboard shipping carton. Open the carton
carefully, and avoid deep penetration into the carton with sharp objects.
After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit,
immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Support page on
the ADTRAN website at http://www.adtran.com/support).
Shipments of the Total Access 900e Series units include the following items:
• Total Access 900e Series base unit
• A detachable power cable with a grounded IEC three-prong power plug
• Two brackets and four screws
• Quick start guide

Total Access 900e Series Hardware Installation Guide Physical Description
64243916F1-34A Copyright © 2010 ADTRAN, Inc. 15
Reviewing the Front Panel Design
Figure 1 shows the Total Access 900e Series front panel.
Figure 1. Total Access 900e Series Front Panel Layout
Front Panel Features
Status LEDs
The status LEDs are located on the left side of the front panel. The VOICE LED indicates the status of
the voice ports. The STATUS LED indicates the unit’s status. The GIG 1 LED indicates the status of
the Gigabit Ethernet port. The USB LED indicates the status of the USB port. The T1 1 through 4
LEDs reflect the status of the network interfaces. The ETH 1 and ETH 2 LEDs reflect the status of the
LANs. Table 1 on page 19 below describes the front panel LEDs.
Reviewing the Rear Panel Design
Total Access 908e Rear Panel Interfaces
Figure 2 shows the Total Access 908e product’s rear panel, which contains identical interfaces regardless
of the model.
Figure 2. Total Access 908e Rear Panel Layout
VOICE Connection
A single 50-pin female amphenol connector, labeled VOICE, provides the interconnect wiring for the
analog FXS/FXO circuits. See Table A-1 on page 33 for voice connector pinouts. The status LED,
labeled VOICE, is located on the front panel.
FXO 0/0 Interface
The FXO 0/0 interface is an RJ-11 connector and provides a single analog trunk for local call routing.
See Table A-2 on page 32 for the FXO port pinouts.
Network Interfaces
The network interfaces (T1 0/1 through T1 0/4) interfaces are DS1 RJ-48C pin connections. See Table
A-3 on page 32 for the network interface pinouts. The status LEDs, labeled T1 1 through 4, are located
on the front panel.
The number of circuits used (1 through 24) is dependent on the Total Access 900e
Series model. FXO interfaces use circuits 17 through 24 depending on the model.
Total Access 900e
STATUS
VOICE
GIG 1
USB
1
T1
2
3
4
ETH 1
ETH 2
CRAFT
BBU
GIG 0/1
10/100/1000
BASE-T
T1 0/1
FXO
0/0
VOICE T1 0/3
ETH 0/2
AC INPUT
ETH 0/1
T1 0/2 T1 0/4
USB

Physical Description Total Access 900e Series Hardware Installation Guide
16 Copyright © 2010 ADTRAN, Inc. 64243916F1-34A
10/100Base-T Ethernet Interfaces and LEDs
The Ethernet ports (ETH 0/1 and ETH 0/2) are RJ-48 connectors. The status LEDs, labeled ETH 1 and
ETH 2, are located on the front panel.See Table A-4 on page 32 for the Ethernet port pinouts.
10/100/1000Base-T Ethernet Interface
The Gigabit Ethernet port (GIG 0/1) is an RJ-48C connector. That status LED, labeled GIG 1 is located
on the front panel. See Table A-5 on page 33 for the Gigabit Ethernet port pinouts.
USB Interface (Future Release)
The USB interface is Type A USB host connector and is provided for use with 3G/4G modems or flash
drives. The status LED, labeled USB, is located on the front panel. A USB power switch is used to
limit the current drawn by a device connected to the USB port.
CRAFT Interface
The CRAFT interface is an EIA-232 serial port (DCE) that provides for local management and
configuration (using a DB-9 female connector). Table A-6 on page 33 shows the CRAFT port pinouts.
Grounding Point
A grounding point is provided to connect the unit to a protective earth ground. Refer to Supplying
Power to the Unit on page 25 for connection details.
Battery Backup Connection
An optional battery backup unit (P/N 1200641L1) is available for use in case of power outages. The
battery backup unit connects to the BBU port, which also charges the unit during operation. Refer to
the documentation available for your specific battery backup unit for more information on this
connection, or refer to Battery Backup Unit on page 26 for a more details.
Power Connection
