Product Features
■ Improve productivity for
office staff through an
intuitive easy to use
user interface
■ Make more efficient and
productive calls with the
unparalleled voice clarity
of HD Voice
■ Reduce deployment and
maintenance costs—
Zero Touch Provisioning and
web-based configuration tool
makes the VVX 300 simple to
deploy, easy to administer,
upgrade, and maintain
■ Leverage previous IT
infrastructure investments—
deploy VVX 300 business
media phones on your existing
network without needing
to upgrade your call
control platform
■ Easily integrate with third-
party web-based UC and
productivity applications
for broad, standards-based,
open APIs
The ADTRAN®VVX 300 is an expandable
business media phone that delivers crystal
clear communications, enhanced collaboration
and personal productivity.
Simplicity and Ease-of-use
The VVX 300 phones bring high-quality, cost
effective solutions to business staff through
advanced UC telephony features. Building
on the behavior common to smartphones
and tablets, the intuitive user interface of the
VVX 300 makes navigation easy and requires
minimal training.
Unsurpassed Voice Quality and Clarity
The VVX 300 delivers breakthrough HD
Voice quality for life-like conversations
making calls more efficient and productive.
Maximize Productivity
Give your front line workers the best
experience with this high quality six-line
business media phone. The VVX 300 improves
personal productivity by complementing the
workplace applications on their computer.
Users can view and manage their Microsoft
Exchange Calendars, receive meeting
reminders and alerts, access the corporate
directory and Instant Messaging/presence2
status right on their phone display, even while
waiting for their PC to boot. They can also
extend their PC’s desktop to include the
VVX 300 phone’s screen for mouse/keyboard
navigation and interaction.
Best-in-class Deployment
and Administration
The VVX 300 phone is easy to deploy
and simple to manage. Using an enterprise-
grade, web-based configuration method
allows administrators to easily provision and
maintain even a small number of phones
throughout the entire enterprise. Additionally,
the extensive administrative feature set
ensures that IT departments have the latest
technologies to integrate the VVX 300
seamlessly into their environment while
minimizing cabling costs with an
integrated gigabit Ethernet (ADTRAN
VVX 310) connection.
Customizable and Expandable
The VVX 300 phone provides personalized
information at a glance, through built-in web
applications and custom backgrounds. The
VVX 300 phone also comes ready for future
expansion modules as your users’ needs and
business grows.
Market-leading Open Standards
Interoperability
Designed for enhanced interoperability,
the VVX 300 leverages and complements
the other existing IT investments in your
business becoming the flexible and future-
proof foundation for any organization’s
unified communications strategy.
ADTRAN VVX 300 and 310
Entry-level Business Media Phones
Smart Solutions for a
Connected World.
Product Specifications
User Interface Features
■Backlit 8-level Grayscale graphical LCD
(208 x 104) resolution
■Screen saver mode
■On-screen virtual keyboard
■Voicemail support2
■WebKit-based Browser
■Adjustable base height
■Unicode UTF-8 character support. Multilingual user
interface including Chinese, Danish, Dutch, English
(Canada/ US/UK), French, German, Italian, Japanese,
Korean, Norwegian, Polish, Portuguese, Russian,
Slovenian, Spanish, and Swedish
Audio Features
■HD Voice technology delivers life-like voice
quality for each audio path-handset, the hands-free
speakerphone, and the optional headset1
■Acoustic Clarity technology providing full-duplex
conversations, acoustic echo cancellation and
background noise suppression
mType 1 compliant (IEEE 1329 full duplex)
■Frequency response—150 Hz – 7 kHz for
handset, optional headset and hands-free
speakerphone modes
■Codecs: G.711 (A-law and μ-law), G.729AB,
G.722, G.722.1
■Individual volume settings with visual feedback
for each audio path
■Voice activity detection
■Comfort noise generation
■DTMF tone generation (RFC 2833 and in-band)
■Low-delay audio packet transmission
■Adaptive jitter buffers
■Packet loss concealment
Headset and Handset Compatibility
■Dedicated RJ-9 headset port
■Hearing aid compatibility to ITU-T P.370
and TIA 504A standards
■Compliant with ADA Section 508 Subpart B
1194.23 (all)
■Hearing aid compatible (HAC) handset for
magnetic coupling to hearing aids
■Compatible with commercially-available TTY
adapter equipment
Call Handling Features2
■6 lines (programmable line keys)
■Shared call/bridged line appearance
■Busy Lamp Field (BLF)
■Flexible line appearance (one or more line keys
can be assigned for each line extension)
■Distinctive incoming call treatment/call waiting
■Call timer and call waiting
■Call transfer, hold, divert (forward), pickup
■Called, calling, connected party information
■Local three-way audio conferencing
■One-touch speed dial, redial
■Remote missed call notification
■Do not disturb function
■Electronic hook switch capable
■Local configurable digit map/dial plan
Open Application Platform2
■WebKit enabled full browser that supports
HTML5, CSS, SSL security, and JavaScript
■Supports Polycom Apps SDK and API for
third-party business and personal applications
■Bundled with Polycom UC Software:
Corporate Directory Access using LDAP
Visual Conference Management
Entry-level Business Media Phones
ADTRAN VVX 300 and 310
Network and Provisioning
■SIP Protocol Support
■SDP
■IETF SIP (RFC 3261 and companion RFCs)
■Two-port Ethernet switch
m10/100Base-TX across LAN and PC ports (VVX 300)
m1000Base-TX available on VVX 310
mConforms to IEEE802.3-2005 (Clause 40)
for Physical Media Attachment
■Conforms to IEEE802.3-2002 (Clause 28) for link Partner
Auto-Negotiation
■Manual or dynamic host configuration protocol
(DHCP) network setup
■Time and date synchronization using SNTP
■FTP/TFTP/HTTP/HTTPS server-based central
provisioning for mass deployments
■Provisioning and call server redundancy supported2
■QoS Support – IEEE 802.1p/Q tagging (VLAN), Layer 3
TOS, and DHCP
■VLAN - CDP, DHCP VLAN discovery, LLDP-MED for
VLAN discovery
mNetwork Address Translation (NAT) support
for static configuration and “Keep-Alive”
SIP signaling
■RTCP and RTP support
■Event logging
■Syslog
■Hardware diagnostics
■Status and statistics reporting
■IPv4
■TCP
■UDP
■DNS-SRV
Security
■802.1X Authentication and EAPOL
■Media encryption via SRTP
■Transport Layer Security (TLS)
■Encrypted configuration files
■Digest authentication
■Password login
■Support for URL syntax with password for
boot server address
■HTTPS secure provisioning
■Support for signed software executables
Power
■Built-in auto sensing IEEE 802.3 at Power over
Ethernet (Class 2)
■External Universal AC Adapter (optional, 48V 12W DC)
Approvals
■FCC Part 15 (CFR 47) Class B
■ICES-003 Class B
■EN55022 Class B
■CISPR22 Class B
■VCCI Class B
■EN55024
■EN61000-3-2; EN61000-3-3
■NZ Telepermit
■Korea KC
■UAE TRA
■Russia GOST-R
■Brazil ANATEL
■Australia A & C Tick
■RoHS compliant
ADTRAN VVX 300 and 310
Entry-level Business Media Phones
61200853G1-8A March
Copyright
©
2013 ADTRAN, Inc.
All rights reserved.
Safety
■UL 60950-1
■CE Mark
■CAN/CSA C22.2 No 60950-1
■EN 60950-1
■IEC 60950-1
■AS/NZS 60950-1
■ICASA
■CITC
Operating Conditions
■Temperature: +32 to 104°F (0 to 40°C)
■Relative Humidity: 5% to 95%, noncondensing
Storage Temperature
■-40 to +160°F (-40 to +70°C)
ADTRAN VVX 300 and 310 Comes With:
■VVX 300 or VVX 310 console
■Handset with handset cord
■Network (LAN) cable
■Quick Start Guide
■A ferrite clamp is included in the box
ADTRAN, Inc.
Attn: Enterprise Networks
901 Explorer Boulevard
Huntsville, AL 35806
P.O. Box 140000
Huntsville, AL 35814-4000
256 963-8000
256 963-8699 fax
General Information
800 9ADTRAN
www.adtran.com
Pre-Sales
Technical Support
888 423-8726
www.adtran.com/presales
Where to Buy
888 423-8726
www.adtran.com/where2buy
Post-Sales
Technical Support
888 423-8726
www.adtran.com/support
ACES Installation &
Maintenance Service
888 874-2237
www.adtran.com/support
Global Inquiries
256 963-8000
256 963-6300 fax
Size
■7.5 x 6 x 7 in (19 x 15 x 18 cm) (W x H x D)
Weight
■Unit weight: 2.0 lbs (0.9 kg)
Unit Box Dimensions/Weight
■12 x 8.25 x 4.25 in
■3.1 lbs (1.4 kg)
Master Carton Quantity
■Ten
Country of Origin
■China
Warranty
■One year
Notes
1. To enjoy all the benefits of HD Voice when
using the phone in the headset mode, you
must use a wideband headset.
2. Most software-enabled features and capabilities
must be supported by the IP PBX/Softswitch.
Ordering Information
Equipment Part #
ADTRAN VVX 300 1200853G1
ADTRAN VVX 310 1200853G1#GB
ADTRAN is an ISO 9001, ISO 14001,
and a TL 9000 certified supplier.
ADTRAN VVX 300 and 310
Entry-level Business Media Phones
TL19.1270
ADTRAN believes the information in this publication to be accurate as of publication date, and is not responsible for error. Specifications subject to change
without notice. ADTRAN is a registered trademark of ADTRAN, Inc. and its affiliates in various countries. All other trademarks mentioned in this document
are the property of their respective owners.
ADTRAN warranty duration and entitlements vary by product and geography. For specific warranty information, visit www.adtran.com/warranty
ADTRAN products may be subject to U.S. export controls and other trade restrictions. Any export, re-export, or transfer of the products contrary to law is
prohibited. For more information regarding ADTRAN’s export license, please visit www.adtran.com/exportlicense
