Advantech Wireless SSPBM-K150-BRE User manual

INSTALLATION AND OPERATING MANUAL
150 W Ku-BAND HUB-MOUNT
SOLID STATE BLOCK UP-CONVERTER
SSPBM–K150–BRE

WARRANTY
This Advantech Wireless product is warranted against defects in material and workmanship for a
period of 2 years from the date of shipment. During the warranty period, Advantech Wireless
will, at its option, either repair or replace products that will prove to be defective.
To return a product for warranty or repair service, you must first request a Return Material
Authorization (RMA) number by contacting Advantech Wireless at:
Phone: [phone] or Fax: [phone]
Website: www.advantechwireless.com or e-mail: [e-mail]
The unit should be shipped to the following address, in original shipping container (box), with
shipping charges prepaid.
Advantech Wireless
657 Orly Avenue
Dorval, Quebec
H9P 1G1
CANADA
Please indicate the RMA number on all shipping documentation.
Units shipped without prior issued RMA, or shipped not in original packing, may be subject of
rejection and returned at sender’s own expense.
LIMITATIONS OF WARRANTY
Advantech Wireless warrants this product to be free of materials and workmanship defects.
The foregoing warranty shall not apply to defects resulting from improper handling or abuse by
the Buyer, unauthorized modification, operation outside of the environmental specifications for
the product, or improper installation or maintenance.
Advantech Wireless shall not be liable for any direct, indirect, special, incidental or
consequential damages.
1

CONTENTS
1. SAFETY.................................................................................................................................. 6
2. PACKING LIST..................................................................................................................... 9
3. GENERAL INFORMATION ............................................................................................. 10
4. MAJOR SUBSYSTEMS AND THEIR FUNCTIONS...................................................... 11
4.1 INTRODUCTION........................................................................................................... 11
4.2 DESCRIPTION............................................................................................................... 11
4.3 SINGLE UNIT MAJOR COMPONENTS...................................................................... 11
4.3.1 L-Band to Ku-Band Up-Converter Module .............................................................. 12
4.3.2 Power Amplifier Module........................................................................................... 12
4.3.3 Waveguide Assembly................................................................................................. 13
4.3.4 10 MHz REFERENCE OSCILLATOR...................................................................... 13
4.3.5 Main Controller Board............................................................................................. 13
4.3.6 Power Supply ............................................................................................................ 14
4.3.7 Cooling System.......................................................................................................... 15
4.4 SPECIFICATIONS (SINGLE UNIT)............................................................................. 18
5. INTERFACES......................................................................................................................21
5.1 RELAY INTERFACE............................................................................................................ 21
5.2 RS-232 INTERFACE...................................................................................................... 23
5.3 RS-485 INTERFACE...................................................................................................... 24
5.4 REDUNDANT INTERFACE ......................................................................................... 24
5.5 RF OUTPUT MONITOR INTERFACE ................................................................................... 24
6. UNPACKING AND INSTALLATION.............................................................................. 25
6.1 INITIAL INSPECTION .................................................................................................. 25
6.2 UNPACKING.................................................................................................................. 25
6.3 INSTALLATION............................................................................................................ 25
6.3.1 Relay, Serial Interfaces and AC Power Cables Construction .................................. 26
6.3.2 Environmental and Adequate Ventilation Considerations ....................................... 26
6.3.3 Mechanical, RF and Electrical Installation.............................................................. 27
7. PRE-POWER AND SYSTEM CHECKOUT.................................................................... 30
7.1 PRE-POWER PROCEDURES........................................................................................ 30
7.2 OPERATIONAL SETTINGS VERIFICATION ............................................................ 30
8. OPERATION........................................................................................................................ 31
8.1 INTRODUCTION........................................................................................................... 31
8.2 SAFETY CONSIDERATIONS ...................................................................................... 31
8.3 BASIC OPERATING PROCEDURE............................................................................. 31
2

8.4 OVERDRIVE PROTECTION........................................................................................ 32
8.5 AUTOMATIC LEVEL CONTROL (ALC).................................................................... 33
8.6 USING THE SSPB SOFTWARE ................................................................................... 34
8.6.1 Using the RS-232 Interface....................................................................................... 34
8.6.2 Using the RS-485 Interface....................................................................................... 41
9. MAINTENANCE................................................................................................................. 42
9.1 PREVENTIVE MAINTENANCE.................................................................................. 42
9.2 MECHANICAL PREVENTIVE MAINTENANCE....................................................... 42
9.3 COOLING FAN CHECK................................................................................................ 42
10. APPENDIX A: RS-485 SERIAL COMMUNICATION PROTOCOL........................ 43
10.1 FRAME STRUCTURE................................................................................................... 43
10.2 COMMANDS.................................................................................................................. 44
10.3 RESPONSE TO COMMANDS FROM SLAVE TO MASTER..................................... 47
11. APPENDIX B: SAFETY AND EMC COMPLIANCE ................................................. 52
3

FIGURES
FIGURE 1: PRODUCT OUTLINE ...................................................................................................... 16
FIGURE 2: BLOCK DIAGRAM......................................................................................................... 17
FIGURE 3: CONNECTORS ............................................................................................................... 20
FIGURE 4: HYPERTERMINAL MODE COMMUNICATION (AFTER PRESSING <ENTER>).................. 35
FIGURE 5: HYPERTERMINAL COMMUNICATION - LIST OF COMMANDS (AFTER PRESSING H
<ENTER> FOR HELP)............................................................................................................. 38
FIGURE 6: PROPOSED GRAPHIC USER INTERFACE (GUI) BASED ON RS-485 PROTOCOL WITH NO
ALC SET – SINGLE UNIT.......................................................................................................... 50
FIGURE 7: PROPOSED GRAPHIC USER INTERFACE (GUI) BASED ON RS-485 PROTOCOL WITH ALC
SET – SINGLE UNIT................................................................................................................... 51
4

TABLES
TABLE 1: ELECTRICAL SPECIFICATIONS........................................................................... 18
TABLE 2: MECHANICAL SPECIFICATIONS ........................................................................ 19
TABLE 3: POWER REQUIREMENTS...................................................................................... 19
TABLE 4: ENVIRONMENTAL CONDITIONS........................................................................ 19
TABLE 5: CONNECTORS......................................................................................................... 20
TABLE 6: RELAY INTERFACE – PIN ASSIGNMENT .......................................................... 22
TABLE 7: RS-232 INTERFACE – PIN ASSIGNMENT ........................................................... 23
TABLE 8: RS-485 INTERFACE – PIN ASSIGNMENT ........................................................... 24
TABLE 9: SERIAL INTERFACE RS-232 CONNECTION INFORMATION.......................... 28
TABLE 10: AC LINE (J5) CONNECTOR – PIN ASSIGNMENTS.......................................... 29
TABLE 11: RS-232 MENU ITEM DEFINITION ...................................................................... 36
TABLE 12: COMPUTER TERMINAL COMMANDS FOR RS-232 INTERFACE................. 39
TABLE 13: COMMAND FRAME STRUCTURE ..................................................................... 45
TABLE 14: CONDITION STATUS RESPONSE....................................................................... 47
TABLE 15: READ IDENTIFICATION RESPONSE................................................................. 47
TABLE 16: READ FREQUENCY RANGE RESPONSE .......................................................... 48
TABLE 17: READ GAIN RANGE RESPONSE........................................................................ 48
TABLE 18: READ FREQUENCY SHIFT RESPONSE............................................................. 48
TABLE 19: UNIT STATUS AND SWITCH POSITION AND STATUS RESPONSE............ 49
5

1. SAFETY
In addition to this section, included by reference are the following pertinent sections of the
International Standard IEC-215, ‘Safety requirements for radio transmitting equipment’:
Appendix D, ‘GUIDANCE ON ASSESSING THE COMPETENCE OF PERSONNEL FOR
DESIGNATION AS SKILLED’ and also Sub-clause 3.1 of the Standard.
Appendix E, ‘GUIDANCE ON SAFETY PRECAUTIONS TO BE OBSERVED BY
PERSONNEL WORKING ON RADIO TRANSMITTING EQUIPMENT’, also Sub-clauses 3.2,
3.7 and 22.1 of the Standard.
To prevent the risk of personal injury or loss related to equipment malfunction Advantech
Wireless uses the following symbols for safety related information. For your own safety, please
read the information carefully BEFORE operating the equipment.
Symbols used in manual:
WARNING: This indicates a hazardous procedure that could result in serious injury or death if
not performed properly.
CAUTION: This indicates a hazardous and dangerous procedure that could result in light-
to-severe injury or loss related to equipment malfunction, if proper precautions
are not taken.
6

----------------------------------------------- WARNING ---------------------------------------------------
When supplying power to this equipment, use the 3-pin connector provided, to connect to a
grounded power outlet. If power is supplied without grounding to the equipment, there is a risk
of receiving a severe or fatal electric shock.
In the context of this document any voltage that is lethal is viewed as ‘High Voltage’. Therefore,
even prime power (90 to 264 V AC) is dangerous because prime power potentials have been
known to cause death or injury.
----------------------------------------------- WARNING ---------------------------------------------------
This equipment can not be repaired by the operator. DO NOT attempt to remove the
equipment cover or to disassemble internal components. Only qualified service technicians
should service this equipment. There are high-voltage parts in this equipment presenting a risk of
severe injury to untrained personnel. In addition, there is a risk of damage to precision
components.
----------------------------------------------- WARNING ---------------------------------------------------
ALWAYS TERMINATE THE OUTPUT OF THE BLOCK UP-CONVERTER WITH A
RF LOAD CAPABLE OF DISSIPATING FULL CW RF POWER. SIMILARLY
TERMINATE THE INPUTS TO AVOID THE POSSIBILITY OF THE UNIT BEING
DRIVEN BY STRAY LEAKAGE SIGNALS. Incorporate the terminations prior to applying
prime power to the unit. This procedure prevents self-oscillation and irradiation of the local
environment. Even if a source is not connected to the unit you are working with, there are
situations where the block up-converter can go into a self-induced mode and generate high levels
of RF energy. Destruction caused under excessive load voltage standing wave ratio (VSWR) will
void the warranty. Although this equipment has internal protection for VSWR higher than 3:1
and will automatically go in shutdown (with a delay of 1 second), still it is a safe procedure to
avoid unwanted effects.
7

----------------------------------------------- WARNING ---------------------------------------------------
DO NOT LOOK INTO THE OUTPUT PORTS OF THE POWERED RF BLOCK UP-
CONVERTER.Treat the powered RF unit with extreme care. Keep in mind that levels of
microwave radiation that do not induce immediate physical discomfort in most individuals can
be sufficiently high to induce longer term effects. Your eyes are particularly vulnerable parts of
your body.
The permissible levels of exposure are quite low compared to the power levels of the amplifiers
built by Advantech Wireless (e.g. less than 10 mW versus 20 to 500 W delivered by various
units). The permissible levels are currently being studied by a number of organizations. In the
past the U.S. safety Code established a dosage rate of 10 mW/cm2. Currently there is
consideration being given to reducing the permissible level to 1 mW/cm2in the United States, as
has been the case for several European countries.
----------------------------------------------- CAUTION-----------------------------------------------------
THIS IS A HEAVY EQUIPMENT. USE TWO OR MORE PEOPLE TO LIFT AND
MOVE this equipment or use an equipment cart. There is a risk of back injury, if this equipment
is lifted by one person.
8

2. PACKING LIST
PACKING LIST
(Shipping Kit P/N 195-400155-001)
Item Quantity Description Part #
1. 1 Installation and Operating Manual PM GR0-3361A0-3N1 Rev. 1
2. 1 Ku-Band 150 W SSPB,
model SSPBMg-K150-BRE GR0-3361A0-3N1
3. 1
Connector Circular MIL C-5015,
Straight Cable Plug 3 Socket
MS3106F16-10S (Connector for AC
LINE connector J5)
631-310616-001
4. 2
Connector circular, MIL-C-26482, 6
contacts female, straight cable plug, shell
10, MS3116F10-6S (connectors for RS-
232 and RS-485 Serial Interfaces)
631-311606-001
5. 1 Connector circular, MIL-C-26482, 10
contacts female, straight cable plug, shell
12 (connector for RELAY Interface) 631-311612-003
6. 1 roll Tape Moisture Sealing/Insulating Flame
Retardant (Mastic Tape) 709-224200-001
7. 4 #6 - 32 x 1/2” Machine Screw Hex Head
18-8 SS (Stainless Steel) 802-632090-001
8. 4 #6 Split Washer 18-8 SS 803-600100-001
9. 1 Gasket D-Ring WR75 Conductive
(Water proof gasket for WR-75 flange) 820-075000-001
9

3. GENERALINFORMATION
This manual contains information that describes installation, operation and maintenance
procedures for the 150 W Ku-Band hub-mount (outdoor) Solid State Block Up-Converter, model
SSPBMg-K150-BRE. Because specialized training is required for some phases of installation
and operation, certain parts of this manual are directed only to trained personnel. Warnings
appear at the appropriate points to caution all users of potential RF and high-voltage hazards.
Built-in monitor and control features indicate the current status of the SSPB unit and provide
fault detection and protection when operating outside normal operating conditions. The SSPB
may be monitored and controlled by using the Discrete, or the RS-232 and the RS-485 Serial
Interfaces.
For a safe and versatile operation, please read the information carefully BEFORE using the
equipment.
Advantech Wireless has prepared this manual for use by customers as a guide for the proper
installation, operation and maintenance of Advantech Wireless equipment and computer
programs. The drawings, specifications, and information contained herein are property of
Advantech Wireless. Any unauthorized use or disclosure of these drawings, specifications and
information is prohibited; they shall not be reproduced, copied or used in whole or in part as the
basis for manufacturing or sale of the equipment or software programs without the prior written
consent of Advantech Wireless.
10

4. MAJOR SUBSYSTEMS AND THEIR FUNCTIONS
4.1 INTRODUCTION
This manual contains information required to install and operate the Redundant Ready 150 W Ku-
Band Hub-mount (Outdoor) Solid State Block Up-Converter model SSPBMg-K150-BRE.
4.2 DESCRIPTION
The Solid State Power Block Up-Converter unit is self-contained and is intended for mounting near
the hub of the antenna.. Each Up-Converter unit incorporates a DC main power supply and forced
air cooling system, see Figure 1: Product Outline at page 16. Each unit features a serial RS-485
interface that provides full remote monitor and control capabilities via a computer interface as well
as serial RS-232 interface (that may be used in Terminal mode) and a discrete interface (Relay) for
local or remote monitoring and control of selected functions. A functional block diagram of a
single unit is shown in
Figure 2at page 17.
4.3 SINGLE UNIT MAJOR COMPONENTS
The SSPB Up-Converter consists of the following major components:
• L-Band to Ku-Band Up-Converter Module,
• Power Amplifier Module,
• Waveguide Assembly,
• 10 MHz Reference Oscillator,
• Main Controller Board,
• Power Supply,
• Current Sensor, and
• Power Monitor Board.
These components are interconnected using dedicated wiring harnesses and coaxial cables.
To clarify the explanation of the components in the following paragraphs, refer to the block
diagram in
Figure 2at page 17.
11

4.3.1 L-BAND TO KU-BAND UP-CONVERTER MODULE
The L/Ku-Band Up-Converter Module converts and amplifies the incoming L-Band carrier
into the desired Ku-Band carrier.
The module has an internal synthesizer, which is fixed at 2175 MHz (virtual 13050 MHz).
The up-converter module has RS-485 communication port that connects to the main controller
board. It also provides a discrete ALARM signal to the Main Controller.
The Up-Converter converts the input L-Band carrier into a Ku-Band carrier. The 950 – 1450 MHz
L-Band input signals are fed at the input co-axial interface connector. Note that this unit has an
internal 10 MHz internal reference. The unit will work based on this internal 10 MHz reference. A
block up-converter using a low phase noise RF oscillator, which is phase locked to the 10 MHz
reference, translates the 950 - 14500 MHz L-Band frequency-range to 14.000 - 14.500 GHz Ku-
Band frequencies. A band-pass filter selects the appropriate up-converter term, which in turn drives
a Solid State Power Amplifier (SSPA). Integral to this module there is a variable attenuation
section used for global temperature compensation.
4.3.2 POWER AMPLIFIER MODULE
The Power Amplifier Module amplifies the RF signals from the L/Ku-Band
up-converter module over the frequency range of 14000 MHz to 14500 MHz. The power
amplifier has a fixed gain of 55 dB, typical.
The monitoring and control signals are the Alarm Output and the Relay Input for muting the
power amplifier.
Temperature sensors are installed at the module’s hot spots to prevent the RF devices from
overheating and operating at temperatures exceeding 85ºC.
The power amplifier also has the following functions:
1. Provides and removes the DC voltages to the GaAs FET devices within the module.
2. Provides a temperature dependent DC voltage to the L-C up-converter for temperature
compensation.
3. Sends a FAULT signal to the main controller board when detecting a fault.
4. Any Synthesizer is out of lock
The power amplifier will be in the Mute mode if:
1. The user sends a MUTE command through the Relay, RS-232, or RS-485 interfaces.
2. The hot spot temperature exceeds +85 °C.
3. Any of the GaAs FET devices failed (drain current out of range).
12

4.3.3 WAVEGUIDE ASSEMBLY
The Waveguide Assembly contains a forward and reflected power detector, an RF output
circulator and a waveguide receive reject filter.
The forward power detector and the reflected power detector monitor the RF output power level
and the reflected power level respectively. The detected voltage signals are delivered to the
Power Monitor Module that converts the analog signals in digital signals and delivers them to the
Main Controller Board.
Both the direct and the reverse power are available at the serial ports (RS-232 and RS-485).
The circulator provides a VSWR protection at the SSPB RF output port. The VSWR at the
circulator output is 1.25:1, minimum. The termination load of the isolator is capable of fully
absorbing any reflected power. A WR75 flat type waveguide flange is the unit output.
4.3.4 10 MHz REFERENCE OSCILLATOR
This module is used to generate a highly stable and very low phase noise 10 MHz reference
frequency with a high stability (of ±5 x 10-8 MHz/year typical), which is required by all
converter modules. A 10 MHz reference is sent to the converter module via a coaxial cable.
4.3.5 MAIN CONTROLLER BOARD
The Main Controller Board contains a microprocessor controller that performs all of the
monitoring and control, input/output communication and the decision-making. The main
controller board provides:
1. Fault detection and indication from each module of the unit
2. Mute control and indication
3. Forward RF power indication
4. Reflected RF power indication
5. Redundancy control (for redundant systems)
6. Unit Gain control (attenuation setting) –not available for these units
7. Relay, RS-232, and RS-485 customer interface
13

4.3.5.1 FAULT Detection and Indication
The unit will automatically go into a shutdown mode (MUTE) and send a message to all of the
external interfaces (including the red Tx LED) when any one of the following occurs:
1. The local oscillator within an up-converter module is out of lock.
2. The hotspot temperature exceeds 85°C.
3. Any of the GaAs FET or GaN devices failed.
4. Reflected power is greater than 44 dBm.
The SSPB continually monitors the internal temperature and the current consumption. It also has
an automatic shutdown feature to prevent operation at excessive temperatures. The unit will
automatically restart when the hotspot temperature falls below to 65°C.
A thermal alarm may result from any one of the following conditions:
1. High ambient temperature (the SSPB Up-Converter is designed to operate between -30°C
and +55°C ambient).
2. Blockage at the air intake or exhaust vents.
4.3.5.2 MUTE Control
The user can disable the RF output power remotely by:
1. Leaving unconnected pins G and H of the Relay interface connector the Transmit way will be
MUTE (see Section 5.1 at page 21).
2. Sending a mute command in terminal mode through the RS-232 interface for transmit.
3. Sending a mute command in packet mode through the RS-485 interface for transmit.
This feature is useful if the user wishes to perform a maintenance check or to check out the
transmission system.
4.3.6 POWER SUPPLY
The Power Supply Module provides +12 VDC output to the following modules:
1. Power amplifier module (high current),
2. L/Ku-Band up-converter module,
3. 10 MHz oscillator,
4. Power monitor module,
5. Current sensor,
6. Main controller board
14

The Power Supply Module provides also +24 VDC output to the Power Amplifier Module (for
GaN devices)
The power supply also provides the following outputs:
• - 9 V DC
• + 48 V DC for the cooling fan
The separate +48 VDC is necessary to operate the cooling fan. This will be a variable,
temperature dependent, voltage that will ensure a variable rotation speed of the cooling fan
related to the temperature (the fan will rotate slower when the temperature is low and faster when
the temperature is high).
The power supply is configured to operate from an 90-132 or 180-264 V AC (autoranging),
47-63 Hz, single phase supply. The overall typical power consumption, at the saturated RF
output power, is approximately 1400 W.
4.3.7 COOLING SYSTEM
The thermal conduction from the modules to the heatsink and the cooling fan provide a sufficient
cooling for the SSPB.
15

Figure 1: Product Outline
16

UP-CONVERTER ASSY
BOTTOM SHROUD
POWER AMPLIFIER ASSEMBLY OUTPUT WAVEGUIDE ARM ASSY
J1
Tx In
(L-BAND
INPUT)
J4
OUTPUT
MONITOR
J7
W/G
OUTPUT
COOLING
FAN
MAIN CONTROLLER BOARD
POWERSUPPLY
POWER CONDITIONER
BOARDASSEMBLY
+12V,
-9V
30 dB
MPA 50 dB
OUTPUT
POWER
DETECTOR
REFLECTED
POWER
DETECTOR
ISOLATOR FILTER
20 dB
TEMP.
SENSOR
HPA
J3
RELAY
I/F
J6
REDUNDANT
I/F
TH
+12V
COM
-9V
TH
BPF
0.950 - 1.450 GHz
(GLOBAL
TEMP.
COMPENS.)
VVA
2.175 GHz
10 MHz REF
13.050 GHz
J5
AC
LINE
A
B
C
LNA MPA
X 6 PHASE
LOCKED
OSCILLATOR
14.000 - 14.500 GHz
ALM_L-RF
-9V
+12 V
+12 V
Ku-Band
DIGITALPOWER
MONITOR
REF
RS-485_L-RF
MICROCONTROLLER
GND
10 MHz
REFERENCE
+12V
GND
OUT-OFLOCK
-9 V
(high current)
TRANSM
LED
LED
ALM_PA
RS-485_PA
GND
MUTE_PA ALM_PA
RS-485_PA
GND
MUTE_PA
ALM_L-RF
RS-485_L-RF
GND
RELAY
RS-232
RS-485_PM
RS-485_PM
LIGHTNING ARRESTER
RS-485 RS-485
J2
RS-232
I/F
J12
RS-485
I/F
REDUND + RS-485
+5 V
GAIN
CONTROL
VVA
+12 V
GND
GND
RP
FP
BOOST 12V &
DISTRIBUTIONBOARD
+12V
+12 V
-9V
-9V
LINE
GND NEUTRAL GND
+48 V
(VARIABLE)
+12 V
+24V,
-9V
+24 V
+24 V
CURR 12V CURR 24V
CURRENT
SENSOR
24 V
CURRENT
SENSOR
12 V
Figure 2: Block Diagram
17

4.4 SPECIFICATIONS (SINGLE UNIT)
The Block Up-Converters specified herein are capable of meeting or exceeding the performance
specifications listed in the following table over frequency range, operating temperature and line
voltage variation, unless otherwise specified. The units will meet all RF performance specifications
within thirty minutes of application of prime power.
TABLE 1: ELECTRICAL SPECIFICATIONS
L-Band Input Frequency 950 – 1450 MHz
RF Output Frequency Range 14.000 – 14.500 GHz
Frequency Stability Based upon 10 MHz Internal Reference
RF Saturated Output Power (PSAT) 53.0 dBm, typ
(RF Output Power @ 6 dB Gain Compression)
Linear Output Power (PLIN)* + 49.0 dBm, min
Linear Gain 72 ±3 dB
Gain Flatness: over 500 MHz
over 40 MHz 3.0 dB p–p, max 1.0 dB, max
Gain Variation Over Temperature 3 dB p-p, over the entire bandwidth
L-Band Input Impedance 50 Ω
L-Band Input Return Loss 16 dB, min
Output Return Loss 20 dB, min
Noise Power Density in-band
in receive band @ 12.750 GHz -70 dBm/Hz, max -145 dBm/Hz, max
Spurious at rated power - 55 dBc, max
Harmonics at rated power - 60 dBc, max
Third Order Intermodulation
(two equal tones 5 MHz apart) - 25 dBc, max @ 3 dB total back-off from Psat
Local Oscillator Frequency 2.175 GHz (virtual 13.050 GHz)
Local Oscillator Leakage -20 dBm, max
Output Phase Noise
@ Offset: 100 Hz
1 kHz
10 kHz
≥100 kHz
Ku-Band Single Side Band Phase Noise (max)
- 63 dBc/Hz
- 73 dBc/Hz
- 83 dBc/Hz
- 93 dBc/Hz
*NOTE: To establish PLIN measure third order intermodulation with two equal tones 5 MHz
apart to be – 25 dBc and note the total output power for this value of IMD3.
18

TABLE 2: MECHANICAL SPECIFICATIONS
See Figure 1: Product Outline at page 16Physical Dimensions
Approximate Weight 48 lbs (22 kg)
See Figure 1: Product Outline at page 16Mounting Requirements
TABLE 3: POWER REQUIREMENTS
Power Requirements 90-132 or 180-264 V AC (autoranging), 47-63 Hz, single phase
6.5 A typical @ 220 VAC (1400 W); 95% Power Factor Correction
(PFC)
Power Consumption
TABLE 4: ENVIRONMENTAL CONDITIONS
Temperature:
Non-operating (continuous exposure)
Operating (ambient)
- 50° C to + 85° C
- 30° C to + 55° C (with start-up at – 30 ° C)
Relative Humidity: 100% max., condensing; up to 2”/hr rain
Altitude: 10,000’ AMSL, derated 2° C / 1,000’ from AMSL
19
