Advantech VPS-3100 User manual

User Manual
VPS-3100
電腦
Vision System
限用物質含有情況標示聲明書

VPS-3100 User Manual ii
設備名稱： 電腦
Equipment name
型號 （型式）：VPS-3100 Series
VPS-3100I-10A ; VPS-3100L-10A ;
VPS-3100F-10A ; VPS-3100I10A-T ;
VPS3100I10A-ES
Type Designation (Type)
單元 Unit
限用物質及其化學符號
Restricted Substances
鉛Lead
(Pb)
汞Mercury
(Hg)
鎘
Cadmium
(Cd)
六價鉻
Hexavalent
chromium
(Cr+6)
多溴聯苯
Polybromina
ted
biphenyls
(PBB)
多溴二苯醚
Polybrominate
d diphenyl
ethers (PBDE)
電路板—○○○○ ○
內外殼○○○○○ ○
其它固定組件
( 螺絲、夾
具、卡榫 )
○○○○ ○
散熱模組 ○○○○○ ○
備考 1.“ 超出 0.1 wt%” 及 “ 超出 0.01 wt%” 係指限用物質之百分比含量超出百分比含量
基準值。
Note 1. “Exceeds 0.1 wt%” and “exceeds 0.01 wt%” indicate that the weight percentage con-
tent of the restricted substance exceeds the presence condition reference value.
備考 2.“ ○ ” 係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2. “○” indicates that the weight percentage content of the restricted substance does not
exceed the presence condition reference value.
備考 3.“—” 係指該項限用物質為排除項目。
Note 3. The “—” indicates that the restricted substance meets the exemption criteria.

iii VPS-3100 User Manual
Attention!
This package contains a hard copy of the user manual in Chinese for China CCC cer-
tification purposes. Please disregard the Chinese version if the product is not to be
sold and/or installed in China.

VPS-3100 User Manual iv
Copyright
The documentation and software included with this product are copyrighted 2017 to
Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to
make improvements on the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated, or transmitted
in any form or by any means without prior written permission from Advantech Co.,
Ltd. The information provided in this manual is intended to be accurate and reliable.
However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any
infringements of the rights of third parties, which may result from its use.
Acknowledgments
Award is a trademark of Award Software International, Inc.
Intel® and Pentium® are trademarks of Intel Corporation.
Microsoft Windows® is a registered trademark of Microsoft Corp.
Cooper is a trademark of Eaton Corporation.
Infineon is a trademark of Infineon Technologies.
TI is a trademark of Texas Instruments.
Asmedia is a trademark of Asmedia Technology INC.
Exar is a trademark of Exar Corporation.
INTERSIL is a trademark of Intersil Corporation.
Nuvoton is a trademark of Nuvoton Technology Corporation.
All other product names or trademarks are properties of their respective owners.
For more information on this and other Advantech products, please visit our website:
http://www.advantech.com/
http://www.advantech.com/ePlatform/
For technical support and service, please visit our support website:
http://support.advantech.com.tw/support/
P/N: 2003S31010 Edition 1
Printed in Taiwan November 2017

v VPS-3100 User Manual
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that this product will be free from
defects in materials and workmanship for 2 years from the date of purchase.
This warranty does not apply to products that have been repaired or altered by per-
sons other than repair personnel authorized by Advantech , nor does it apply to prod-
ucts that have been subject to misuse, abuse, accident, or improper installation.
Under the terms of this warranty, Advantech assumes no liability for consequences
arising from such events.
Because of Advantech's high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time, and freight. Please consult your dealer for more details.
If you believe that you have a defective product, follow these steps:
1. Collect all the information about the problem encountered (e.g., CPU speed,
Advantech products used, other hardware and software used, etc.). Note any-
thing abnormal and list any on-screen messages that appear when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain a return merchandize authori-
zation (RMA) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully completed Repair and Replacement
Order Card, and proof of purchase date (e.g., a photocopy of your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number clearly on the outside of the package and ship it prepaid
to your dealer.
Declaration of Conformity
FCC Class A
This equipment has been tested and found to comply with the limits for a Class A dig-
ital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate
radio-frequency energy and, if not installed and used in accordance with the instruc-
tion manual, may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his or her own expense.
警告使用者
這是甲類測試產品，在居住的環境中使用時，可能會造成射頻干擾，在這種情況下，
使用者會被要求採取某些適當的對策。
The power supply for this product is intended to be a UL-certified power supply or a
UL-certified DC power source (rating, 24 VDC, min. 3 A, min. 50°C). Please contact
Advantech for further information. Note: The power adapter is an optional accessory.

VPS-3100 User Manual vi
Technical Support and Assistance
1. Visit the Advantech website at www.advantech.com/support for the latest infor-
mation about this product.
2. Should you require additional assistance, contact your distributor, sales repre-
sentative, or Advantech's customer service center for technical support. Please
have the following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (OS, version, application software, etc.)
–A complete description of the problem
–The exact wording of any error messages
Packing List
Before installation, please ensure the following items have been shipped:
VPS-3100 barebone system x1
Startup manual x1
2-pin phoenix connector x 1
4-pin phoenix connector x 1
10-pin phoenix connector x 1
Wall mount bracket x 2
DIN rail mount bracket x 1
Ordering Information
Optional Accessories
Part Number Camera Interface Display USB 3.0 Isolated
Digital I/O COM 1 COM 2
VPS-3100I-10A 2-CH GigE PoE VGA
DP++ 42-ch input 4-ch output 11
Part Number Description
1950016395T102 DIN rail bracket
96PSA-A120W24T2 ADP 100–240-V 120-W 24-V end terminal (FSP120-AAAN2)
96FD-M064-PLG1 mSATA, A19nm, 64 GB, SATA 6 GB/s, 0~70°C
96FD-M128-PLG1 mSATA, A19nm, 128 GB, SATA 6 GB/s, 0~70°C

vii VPS-3100 User Manual
Warnings, Cautions, and Notes
Battery Information
Batteries, battery packs, and accumulators should not be disposed of as unsorted
household waste.
Please use your local public collection system to return, recycle, or treat them in com-
pliance with the local regulations.
Warning! Warnings indicate conditions, which if not observed, can cause personal
injury!
Caution! Cautions are included to help you avoid hardware damage or data loss.
Example:
New batteries may explode if incorrectly installed. Do not attempt to
recharge, force open, or heat the battery. Replace the battery only with
the same or equivalent type recommended by the manufacturer. Dis-
card used batteries according to the manufacturer's instructions.
Caution! Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer, discard
used batteries according to the manufacturer's instructions.
Caution! Danger d'explosion si la batterie est inexactement remplacee. Rem-
placez seulement avec la meme chose ou le type equivalent recom-
mande par le fabricant, jettent les batteries utilisees instructions de s
selon fabricant des'.
Note! Notes provide optional additional information.

VPS-3100 User Manual viii
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this user manual for later reference.
3. Disconnect the equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep the equipment away from humidity.
6. Place the equipment on a stable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. To protect the equipment
from overheating, do not cover the openings.
8. Ensure that the voltage of the power source is correct before connecting the
equipment to a power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. Pay attention to all cautions and warnings noted on the equipment.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage from transient overvoltage.
12. Never pour any liquid into the openings. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to
the user manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
15. Do not store this equipment in an environment where the temperature may go
below -20°C (-4°F) or above 60°C (140°F). This could damage the equipment.
The equipment should be kept in a controlled environment.
16. CAUTION: The battery may explode if it is incorrectly replaced. Replace only
with the same or equivalent type recommended by the manufacturer, and dis-
card used batteries in accordance with the manufacturer's instructions.
17. In accordance with IEC 704-1:1982, the sound pressure level at the operator’s
position will not exceed 70 dB (A).
18. RESTRICTED ACCESS AREA: The equipment should only be installed in a
restricted access area.
DISCLAIMER: This set of instructions is given in accordance with IEC 704-1. Advan-
tech disclaims all responsibility for the accuracy of any statements contained herein.

ix VPS-3100 User Manual
Contents
Chapter 1 Introduction..........................................1
1.1 Introduction ............................................................................................... 2
1.2 Product Features....................................................................................... 2
1.2.1 General ......................................................................................... 2
1.2.2 Display .......................................................................................... 2
1.2.3 Ethernet ........................................................................................ 2
1.3 Chipset ...................................................................................................... 3
1.3.1 Functional Specifications .............................................................. 3
1.4 Mechanical Specifications......................................................................... 4
1.4.1 Dimensions ................................................................................... 4
Figure 1.1 VPS-3100 dimensions ................................................ 4
1.4.2 Weight........................................................................................... 4
1.5 Power Requirements................................................................................. 4
1.5.1 System Power............................................................................... 4
1.5.2 RTC Battery .................................................................................. 4
1.6 Environmental Specifications .................................................................... 4
1.6.1 Operating Temperature................................................................. 4
1.6.2 System Safety Certification Test Temperature ............................. 4
1.6.3 Relative Humidity .......................................................................... 4
1.6.4 Storage Temperature.................................................................... 4
1.6.5 Vibration During Operation ........................................................... 5
1.6.6 Shock During Operation................................................................ 5
1.6.7 Safety............................................................................................ 5
1.6.8 EMC .............................................................................................. 5
Chapter 2 H/W Installation....................................7
2.1 Introduction ............................................................................................... 8
2.2 Jumpers .................................................................................................... 8
2.2.1 Jumper Description ....................................................................... 8
2.2.2 Jumper List ................................................................................... 8
Table 2.1: Jumper List ................................................................. 8
2.3 Connectors................................................................................................ 9
2.3.1 VPS-3100 External I/O Connectors .............................................. 9
Figure 2.1 VPS-3100 I/O connectors......................................... 10
Table 2.2: COM Connector Pin Assignment Chart.................... 10
Figure 2.2 Ethernet connector ................................................... 11
Table 2.3: Ethernet Connector Pin Assignment Chart............... 11
Figure 2.3 USB 3.0 connector ................................................... 11
Table 2.4: USB 3.0 Connector Pin Assignment Chart............... 11
Figure 2.4 VGA connector ......................................................... 12
Table 2.5: VGA Connector Pin Assignment Chart..................... 12
Figure 2.5 DP++ connector........................................................ 12
Table 2.6: DP Port Connector Pin Assignment Chart................ 12
Figure 2.6 2-pin header ............................................................. 13
Table 2.7: Power Connector Pin Header Pin Assignment Chart13
Figure 2.7 Power button ............................................................ 13
Figure 2.8 Strobe connector ...................................................... 13
Figure 2.9 Strobe timing settings ............................................... 14
Figure 2.10Digital I/O connector ................................................. 14
Table 2.8: Digital I/O Connector Pin Assignment Chart ............ 14
Figure 2.11Isolated digital input connection (dry contact) .......... 14
Figure 2.12Isolated digital input response time (dry contact) ..... 15
Figure 2.13Isolated digital input connection (wet contact).......... 15
Figure 2.14Isolated digital output connection ............................. 16

VPS-3100 User Manual x
Figure 2.15Isolated digital output response time........................ 16
2.4 Installation............................................................................................... 17
2.4.1 mSATA SSD Installation............................................................. 17
Figure 2.16Remove chassis screws and bottom cover .............. 17
Figure 2.17Install mSATA SSD .................................................. 18
Chapter 3 AMI BIOS Setup................................. 19
3.1 Introduction ............................................................................................. 20
3.2 How to Enter BIOS.................................................................................. 21
3.2.1 Main ............................................................................................ 21
3.2.2 Advanced.................................................................................... 23
3.2.3 Chipset........................................................................................ 34
3.2.4 Security....................................................................................... 37
3.2.5 Boot ............................................................................................ 38
3.2.6 Save & Exit ................................................................................. 39
Chapter 4 Software Installation......................... 41
4.1 Chipset Software Installation Utility......................................................... 42
4.1.1 Before You Begin........................................................................ 42
4.1.2 Introduction ................................................................................. 42
4.2 Integrated Graphics Device Setup .......................................................... 43
4.2.1 Introduction ................................................................................. 43
4.2.2 Windows 7/Windows 10 Driver Setup......................................... 43
4.3 LAN Configuration................................................................................... 43
4.3.1 Introduction ................................................................................. 43
4.3.2 Features...................................................................................... 43
4.3.3 Installation................................................................................... 43
4.4 Intel® TXE (Trusted Execution Engine) Setup........................................ 44
4.4.1 Introduction ................................................................................. 44
4.5 Install USB3.0 ......................................................................................... 44
4.5.1 Introduction ................................................................................. 44
4.6 CamNavi Driver Installation .................................................................... 44
4.6.1 Introduction ................................................................................. 44
4.6.2 Driver Setup................................................................................ 44
Figure 4.1 CamNavi driver in Device Manager.......................... 45
Chapter 5 Digital I/O Setting .............................. 47
5.1 I/O Control............................................................................................... 48
5.1.1 Digital Input................................................................................. 48
Figure 5.1 Isolated digital input response.................................. 48
5.1.2 Digital Output .............................................................................. 48
Figure 5.2 Isolated digital output response............................... 49
5.2 Camera Control....................................................................................... 49
5.2.1 Acquisition Start and Stop .......................................................... 49
5.3 Image Acquisition.................................................................................... 50
5.3.1 Software Trigger Mode ............................................................... 50
Figure 5.3 Configuring the camera in software trigger mode .... 51
Figure 5.4 Executing image acquisition..................................... 52
5.3.2 Hardware Trigger Mode.............................................................. 52
Figure 5.5 Configuring the camera in hardware trigger mode ... 53
5.3.3 ToE ............................................................................................. 54
Figure 5.6 Configuring the camera in ToE mode....................... 54
5.4 Lighting Control....................................................................................... 56
5.4.1 Light Intensity and Frequency..................................................... 56
Figure 5.7 Lighting control connection....................................... 57
5.4.2 Strobe Mode ............................................................................... 57

xi VPS-3100 User Manual
Figure 5.8 Strobe mode ............................................................. 57
5.4.3 On/Off Mode ............................................................................... 58
Figure 5.9 Strobe mode ............................................................. 58
5.4.4 Lighting Control PWM Output Specifications .............................. 59
Table 5.1: PWM Output Specifications...................................... 59
Appendix A Programming the Watchdog Timer..61
A.1 Programming the Watchdog Timer ......................................................... 62
A.1.1 Watchdog Timer Overview.......................................................... 62
A.1.2 Programming the Watchdog Timer ............................................. 62
Table A.1: Watchdog timer registers.......................................... 64
A.1.3 Example Program ....................................................................... 65

VPS-3100 User Manual xii

Chapter 1
1Introduction
This chapter gives background
information on the VPS-3100.

VPS-3100 User Manual 2
1.1 Introduction
The VPS-3100 is a compact fanless system incorporating an Intel® SoC. It is
designed specifically for machine vision applications. The system is an independent
embedded box with a rugged aluminum case that is resistant against thermal expo-
sure as well as high electromagnetic interference, shock, and vibration. It features an
Intel® quad-core processor and a proprietary 2-channel power-over-Ethernet (PoE)
camera module, making it a suitable solution for machine vision applications. It also
features a diverse I/O interface that includes Ethernet, USB 3.0, and serial ports.
1.2 Product Features
1.2.1 General
CPU: Intel® Celeron® Processor N3160
PCH: N/A
System Memory: Onboard DDR3L RAM, 1600 MHz, 4 GB
Storage: Supports one mSATA SSD
Graphics: VGA and DP++
Ethernet Port: 1 x RJ45
Watchdog Timer: Single-chip watchdog 255-level interval timer, setup by soft-
ware
I/O Interface: 1 x RS232/422/485 and 1 x RS-232
USB: 4 x USB 3.0
1.2.2 Display
Chipset: Intel® HD Graphics 400 (supports DirectX 12)
Graphics Video Max Memory: 4 GB
Resolution:
–VGA: Supports up to 1920 x 1080 @ 60 Hz
–DP: Supports up to 3840 x1080 @ 30 Hz
1.2.3 Ethernet
Chipset: LAN 1: Intel® i210IT
Speed: 10/100/1000 Mbps
Interface: 1 x RJ45
Standards: Compliant with IEEE 802.3, IEEE802.3U, IEEE 802.ab.

3 VPS-3100 User Manual
Chapter 1 Introduction
1.3 Chipset
1.3.1 Functional Specifications
Processor Intel® Celeron® Processor N3160
Lithography: 14 nm
Memory Supports onboard DDR3L RAM, 1600 MHz, 4 GB
Chipset Integrated
Intel® HD Graphic
Intel® HD Graphics 400
– Supports DirectX 12 (Windows 10)
– Supports DirectX 11.x (Windows 7/8.1)
– Supports OpenGL 4.2
– Supports Intel® Quick Sync Video
I/O interface
– VGA: Supports up to 1920 x 1200 @ 60 Hz
(VGA connector: Onboard D-SUB 15P)
– -DP++: Supports up to 3840 x 2160 @ 30 Hz
SATA Interface One SATA 3.0 port
USB Interface
USB host interface for 4 x USB 3.0 ports
Supports high-speed, full-speed, and low-speed modes
Supports legacy keyboard/mouse software
Power Management
Supports ACPI 5.0
Supports ACPI power management logic
Power connector: Plug-in block 2Px1
BIOS AMI 64Mb Flash BIOS via SPI
Serial Ports
Nuvoton NCT6106D supports up to 6 serial ports
High-speed NS16C550A-compatible UARTs with data rates
up to 1.5 Mbps
Supports IRQ sharing among serial ports on XPE
COM 1: Supports RS-232/422/485 with BIOS setup, supports
auto flow control
COM 2: Supports RS-232 serial port connector: D-SUB
CON.9P
LAN
LAN1: Intel® i210IT
Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.ab.
Supports 10/100/1000 Mbps
Supports wake-on-LAN
Battery BR2032 3 V/190 mAh

VPS-3100 User Manual 4
1.4 Mechanical Specifications
1.4.1 Dimensions
Figure 1.1 VPS-3100 dimensions
1.4.2 Weight
1.1 kg (2.43 lb)
1.5 Power Requirements
1.5.1 System Power
Minimum power input: 24VDC (+10%)
1.5.2 RTC Battery
BR2032 3 V/190 mAh
1.6 Environmental Specifications
1.6.1 Operating Temperature
0~50°C
1.6.2 System Safety Certification Test Temperature
0~50°C with mSATA
1.6.3 Relative Humidity
0~95% @ 40°C (non-condensing)
1.6.4 Storage Temperature
-40~85°C (-40~185°F)
Unit:mm

5 VPS-3100 User Manual
Chapter 1 Introduction
1.6.5 Vibration During Operation
When the system is equipped with an mSATA SSD: 3 Grms, IEC 60068-2-64, ran-
dom, 5~500 Hz, 1 octave/min, 1 hr/axis, 3 axes (x,y,z).
1.6.6 Shock During Operation
When the system is equipped with an mSATA SSD: 20 G, IEC 60068-2-27, half sine,
11-ms duration.
1.6.7 Safety
CCC, CB, UL
1.6.8 EMC
CE, FCC, CCC, KCC, BSMI

VPS-3100 User Manual 6

Chapter 2
2H/W Installation
This chapter introduces external
I/O and installation of the VPS-3100 hard-
ware.

VPS-3100 User Manual 8
2.1 Introduction
The following figures show the connectors on the equipment. The following sections
describe each peripheral.
2.2 Jumpers
2.2.1 Jumper Description
The VPS-3100 can be configured to match your application needs by adjusting the
jumper settings. To close a jumper, place the jumper over the jumper pins; to open a
jumper, remove the jumper from the pins. In the following example, the jumper block
has three pins (labeled 1, 2, and 3). In this case, the jumper can be closed by cover-
ing either Pins 1-2 or Pins 2-3.
The jumper settings described in this manual are depicted as follows:
A pair of needle-nose pliers may be helpful when working with jumpers. If you have
any doubts about the ideal hardware configuration for your application, contact your
local distributor or sales representative before making any changes.
2.2.2 Jumper List
closed 2-3closedopen
12 12
closed 2-3closedopen
Table 2.1: Jumper List
Label Function
JCMOS1 Clear CMOS
PSON1 System AT/ATX mode
JWDT1_JOBS1 Watchdog mode
