Advantech B+B SmartWorx Giga-MiniMc TX-SX User manual

Giga-MiniMc TX/FX, TX-SX
Giga-MiniMc TX/SFP
USER MANUAL

Giga-MiniMc, SFP, TX-SX, TX-LX
1
Advantech B+B SmartWorx - Americas
707 Dayton Road
Ottawa, IL 61350 USA
Phone [phone]
Fax [phone]
Advantech B+B SmartWorx - European Headquarters
Westlink Commercial Park
Oranmore, Co. Galway, Ireland
Phone [phone]
Fax [phone]
www.advantech-bb.com
B+B SMARTWORX TECHNICAL SUPPORT
USA/Canada: 1 [phone] (Ottawa IL USA location)
Monday - Friday
Europe: [phone] (Oranmore, Co Galway, Ireland location)
Monday - Friday
Email: [e-mail]
Web: www.advantech-bb.com

Giga-MiniMc, SFP, TX-SX, TX-LX
2
TABLE OF CONTENTS
FCC Radio Frequency Interference Statement........................................ 3
About This Manual................................................................................. 3
About the Giga-MiniMc. ............................................................................. 4
Installing the Giga-MiniMc ..................................................................... 4
Powering the Giga-MiniMc. ................................................................... 4
LED Operation....................................................................................... 5
Specifications ............................................................................................. 6
Fiber Optic Cleaning Guidelines............................................................... 7
Electrostatic Discharge Precautions ......................................................... 7
Safety Certifications ................................................................................... 8

Giga-MiniMc, SFP, TX-SX, TX-LX
3
FCC RADIO FREQUENCY INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class A
computing device, pursuant to Part 15 of the FCC Rules.
These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial
environment. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in
accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause
harmful interference in which the user will be required to correct the interference at his
own expense.
Any changes or modifications not expressly approved by the manufacturer
could void the user’s authority to operate the equipment.
The use of non-shielded I/O cables may not guarantee compliance with FCC RFI
limits. This digital apparatus does not exceed the Class A limits for radio noise
emission from digital apparatus set out in the Radio Interference Regulation of
the Canadian Department of
Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les
limites applicables aux appareils numériques de classe A prescrites dans le
Règlement sur le brouillage radioélectrique publié par le ministère des Communications
du Canada.
ABOUT THIS MANUAL
2018 B+B SmartWorx. All rights reserved. Information in this manual is subject
to change without notice and does not represent a commitment on the part of
B+B SmartWorx. B+B SmartWorx assumes no responsibility for errors that may
appear in this document. B+B SmartWorx shall not be liable for incidental or
consequential damages resulting from the furnishing, performance or use of this
manual.
No part of this publication may be reproduced or transmitted in any form or by
any means, electronic or mechanical, including photography, recording or any
information storage and retrieval system without written consent.
Other brands or product names used in this manual may be registered
trademarks and the property of their respective owners. The use of trademarks or
other designations in this publication is for reference purposes only and does not
constitute an endorsement by the trademark holder.

Giga-MiniMc, SFP, TX-SX, TX-LX
4
ABOUT THE GIGA-MINIMC
The Giga-MiniMc is a 10/100/1000 auto-negotiating, switching miniature media
converter. The fiber port available in one pairof SC fiber connectorsand/oran SFP
port which can support any fiber type; dual strand available in LC connectors, and
single strand fiber SFPs available in SC connectors. The Giga-MiniMc always operates
at 1000 Mbps FDX; the copper port auto-negotiates the connected device’s speed
and duplex mode: 10 Mbps, 100 Mbps or 1000 Mbps, and HDX or FDX (including
Flow Control).
The Giga-MiniMc TX/SFP requires a Gigabit SFP, with or without DDMI (sold
separately from B+B SmartWorx). SFPs must be MSA-compliant and meet the Class 1
Laser Safety Standard. The SFP model also offers “Link Fault Pass Through” (LFPT).
a diagnostic feature for troubleshooting. It is a permanently enabled feature.
The Giga-MiniMc offers plug-and-play operation, including the auto-cross feature which
automatically selects between a crossover work-station or pass-through
connection,n
depending on the connected device.
NOTE : Unless notedotherwise, all references tothe Giga-MiniMc in this manual are also applicable tothe
Giga-MiniMcTX/SFP.
INSTALLING THE GIGA-MINIMC
The Giga-MiniMc installs in a B+B SmartWorx PowerTray/18 or can be used as a
standalone media converter. As a standalone, the Giga-MiniMc/SFP uses a universal
external switching power cube with 100 – 240 ±10% VAC input and 5 VDC output.
NOTE: Some options require items that are sold separately, available from B+B SmartWorx.
POWERING THE GIGA-MINIMC
The Giga-MiniMc supports multiple powering options:
• A country-specific, high-reliability AC power adapter (included)
• IE-PowerTray/18 for Rack Mounting
NOTE: Some options require items that are sold separately, available from B+B SmartWorx.

Giga-MiniMc, SFP, TX-SX, TX-LX
5
LED OPERATION
Each Giga-MiniMc includes two LEDs located on the RJ-45 connector:
Giga-MiniMc, SC Giga-MiniMc, SFP
FX TX TX FX
LED functions are as follows (above illustrations are representative):
FX LNK/ACT
Glows GREEN when a link is established on the fiber port;
blinks GREEN when activity is detected on the fiber port.
TX LNK/ACT
Glows AMBER when a link is established on the copper port;
blinks GREEN when activity is detected on the copper port.

Giga-MiniMc, SFP, TX-SX, TX-LX
6
SPEFICATIONS
Ethernet Connections
10/100/1000 BaseT
Auto-Negotiation
Auto-Cross
Flow Control
1536 MTU for the Fixed Fiber versions
10240 MTU for the SFP version
Full
Line-Rate Forwarding
Fiber Port - SFP or Fixed Fiber
SFP port supports 100Mbps or 1000Mbps fiber SFPs
Fixed Fiber port is specifically 1000Mbps
AC Wall Adapter
100 to 240 ±10% VAC input, 5 VDC output, 2A maximum
Operating Temperature
0 to +50 °C (+32 to +122 °F)
Storage Temperature
-35 to +75 °C (-31 to +167 °F)
Humidity
5 to 95% (non-condensing); 0 to 10000 feet altitude
Dimensions
2.11H x 4.57W x 8.51D cm (0.83H x 1.80W x 3.35D in)

Giga-MiniMc, SFP, TX-SX, TX-LX
7
FIBER OPTIC CLEANING GUIDELINES
Fiber Optic transmitters and receivers are extremely susceptible to contamination by
particles of dirt or dust that can obstruct the optic path and cause performance
degradation. Good system performance requires clean optics and connector ferrules.
1.
Use fiber patch cords (or connectors if you terminate your own fiber) only from a
reputable supplier; low-quality components can cause many hard-to-diagnose
problems in an installation.
2.
Dust caps are installed at the factory to ensure factory-clean optical devices. These
protective caps should not be removed until the moment of connecting
the fiber
cable to the device. Should it be necessary to disconnect the fiber
device, reinstall
the protective dust caps.
3.
Store spare caps in a dust-free environment such as a sealed plastic bag or box so
that when reinstalled they do not introduce any contamination to the optics.
4.
If you suspect the optics have been contaminated, alternate between blasting with
clean, dry, compressed air and flushing with methanol to remove particles of dirt.
ELECTROSTATIC DISCHARGE PRECAUTIONS
Electrostatic discharge (ESD) can cause damage to any product, add-in modules or
stand-alone units, containing electronic components. Always observe the following
precautions when installing or handling these kinds of products.
1.
Do not remove unit from its protective packaging until ready to install.
2.
Wear an ESD wrist grounding strap before handling any module or component. If
the wrist strap is not available, maintain grounded contact with the system unit
throughout any procedure requiring ESD protection.
3.
Hold the units by the edges; do not touch the electronic components or gold
connectors.
4. After removal, always place the boards on a grounded, static-free surface, ESD
pad or in a proper ESD bag. Do not slide the modules or stand-alone units over
any surface.
WARNING!
Integrated circuits and fiber optic components are
extremely
susceptible to electrostatic discharge damage. Do not handle
these
components directly unless you are a qualified service technician
and
use tools and techniques that conform to accepted industry practices.

Giga-MiniMc, SFP, TX-SX, TX-LX
8
SAFETY CERTIFICATIONS
UL/cUL:
Listed to Safety of Information Technology Equipment, including
Electrical Business Equipment.
CE – Directives
2004/108/EC – Electromagnetic Compatibility Directive
2011/65/EU – Reduction of Hazardous Substances Directive (RoHS)
2006/95/EC – Low Voltage Directive
CE – Standards
EMC:
EN 55022 +AC Class A – Information Technology Equipment - Radio Disturbance Cdharacteristics - Limits and
Methods of Measurement
EN 55024 – Information Technology Equipment - Immunity Characteristics - Limits and Methods of
Measurement
European Directive 2002/96/EC (WEEE) requires that any equipment that bears this symbol on
product or packaging must not be disposed of with unsorted municipal waste. This symbol
indicates that the equipment should be disposed of separately
from regular household waste. It is
the consumer’s responsibility to dispose of this
and all equipment so marked through designated
collection facilities appointed by
government or local authorities. Following these steps through
proper disposal and
recycling will help prevent potential negative consequences to the
environment and
human health. For more detailed information about proper disposal, please
contact
local authorities, waste disposal services, or the point of purchase for this equipment.
Documentation Number: GigaMiniMc_SFP_TX-SX_TX-LX_4518m
Class 1 Laser product, Luokan 1 Laserlaite,
LaserKlasse 1, Appareil A’Laserde Classe 1
