Advantech ASMB-913I Installation and operation manual

ASMB-913I Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 ASMB-913I Startup Manual
• 1 Driver CD (user’s manual is included)
• 2 Serial ATA HDD data cables
• 2 Serial ATA HDD power cables
• 2 CPU power cables (8P)
• 1 I/O port bracket
• 1 Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
www.adobe.com/Products/acrobat/readstep2.
html (Acrobat is a trademark of Adobe)
ASMB-913I Intel Xeon® E5-2600 v3 series EATX Server
Board with 16 DDR4 DIMM, 3 PCIe x16, PME support, 4 GbE
Startup Manual
Standard SBC Functions
• CPU: Dual LGA2011-R3 Intel Xeon® E5-2600v3 series
• BIOS: AMI 128 Mb SPI BIOS
• Chipset: Intel® C612 PCH
• System Memory: 16* DDR4 REG 1600/1866/2133
DIMM, Max. 512 GB
Note: Due to the inherent limitations of PC architecture,
the system may not fully detect 512 GB RAM
when 512 GB RAM is installed.
• SATA Interface: 8 SATA3 6 Gb/s ports Intel Matrix
Storage (for Windows only) (SATA0-SATA5 and sSATA0-
sSATA1 Supports software RAID 0, 1, 10 & 5)
• Serial ports: Two serial ports, only support RS-232
• Keyboard/mouse connector (KBMS2): Supports the
standard PS/2 keyboard and mouse via PS/2 cable
• Watchdog timer: 255 level timer intervals
• USB port: Supports up to three USB 2.0 ports (1*Type-
A) and six USB 3.0 ports (4 ports from on-board 20pin
header)
VGA Interface
• Chipset: Aspeed AST2400/1400
• Display Memory: 64 MB
• Resolution: Supports VGA up to resolution 1920 x 1200
@ 60 Hz refresh rate
Ethernet Interface
• Interface: 10/100/1000 Mbps
• Controller: LLAN1_BMC:Intel I210 (only ASMB-913I
sku support BMC); LAN2: Intel I210; LAN3/4: Intel I210
(ASMB- 913I sku only)
Mechanical and Enviroment
• Dimensions (L x W): 330 x 304 mm (13” x 12”)
•Power supply voltage: +3.3 V, +5 V, ±12 V, +5 Vsb
•Power consumption (mainboard only, excluding IO
device): Max. load: +3.3 V @ 1.40 A, +5 V@ 0.50 A, +12
V@ 23.20 A,+5 Vsb@ 0.09 A, -12 V@ 0.05 A
•Operating temperature: 0 ~ 40° C (depending on CPU)
•Weight: 1.7 kg (weight of board)
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the ASMB-913I series Rev. A1
Part No. 2001913I10
Print in China
1st Edition
May 2015

2 ASMB-913I Startup Manual
The board has a number of jumpers that allow you to con-
figure your system to suit your application.
The table below lists the function of each of the jumpers and
connectors.
Connectors
Label Function
ATXPWR1
ATX 24 Pin main power connector
ATX12V1 Processor power connector
(for CPU0)
ATX12V2 Processor power connector(for
CPU1)
SLOT12V1 For PCIe slot 12V input only
SATA0~SATA5
sSATA0~sSATA1
Serial ATA0~5, Slave serial
ATA0~1
USB8_9 USB 2.0 header 8, 9
USB10 USB 2.0 port 10 (Type-A)
USB0_1, USB2_3,
USB4_5
USB 3.0 port 0, 1; USB 3.0 port
2, 3, 4, 5 (20-pin header)
EX_THR1 Connector for external thermis-
tor
SPI_CN1 Connector for BIOS update tool
LPC1 TPM connector
PCIE_PME1 PCIE x16 slot (For PME)
SLOT4 PCIE x16 slot
SLOT5 PCIE x16 slot
SLOT6 PCIE x16 slot
DIMMA1 ~ DIMMH1
DIMMA2 ~ DIMMH2 DDR4 slot
CPUFAN0,CPUFAN1 CPU FAN connector
SYSFAN0,SYSFAN1,
SYSFAN2 System FAN connector
LAN2, LAN3, LAN4 LAN connector
LAN1_BMC LAN connector and share link
for IPMI
VGA_COM1 VGA+COM connector
VOLT1 Voltage Display
KBMS2 External keyboard and mouse
connector (6 pin)
BIOS1 BIOS SPI ROM
LANLED1 LAN 1/2 LED extension con-
nector
SMBUS1 Front panel SMBus header
Jumpers and Connectors
Jumpers and Connectors
BMC1/BMC2 IPMI module header
SGPIO1/SGPIO2 SATA SGPIO header
JCASE1 Chassis case open alarm
header
HDAUD1 Audio header
COM2 Serial port: RS-232
JFP1, JFP2, JFP3 Front panel header
GPIO1 GPIO connector
PMBUS1 Power supply SMBbus I2C
Header
Jumper list
Label Function
JCMOS1
CMOS clear
JME1 ME update
JCMOS1/JME1: CMOS clear/ME update function
Closed pins Result
1-2
Keep CMOS data/Disable ME update*
2-3 Clear CMOS data/Enable ME update
*: Default
Keep CMOS data/Disable ME update Clear CMOS data/Enable ME update
JFP1, JFP2
Pin.3 #PWR_SW
Pin.6
GND
Pin.9 #RST_SW
Pin.12 GND
*Power button pin is located in Pin 3 & 6 of front panel
connector
1 2 3
1 2 3
3 6 9 12 PWRSW RESET
HDDLED
SNMP
JFP1
&
1(+) 4 7 10(-)
HDDLED
SM_BUS
SPEAKER
JPF2
&
PWRLED & KEYLOCK
12345JFP3
2(+) 5(-) 8 11
Installation Note

ASMB-913I Startup Manual 3
The device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference;
2. This device must accept any interference received,
including interference that may cause undesired opera-
tion.
The CD disc contains a driver installer program that will lead
you through the installation of various device drivers needed
to take full advantage of your motherboard.
The computer is supplied with a battery-powered realtime
clock circuit. There is a danger of explosion if battery is
incorrectly replaced. Replace only with same or equivalent
type recommended by the manufacturer. Discard used bat-
teries according to manufacturer’s instructions.
Software Installation Declaration of Conformity
Board Layout
Figure 1: Board Layout: Jumper and Connector Locations
