Advantech PCM-9365 User manual

User Manual
PCM-9365
Intel
®
Celeron
®
N2930&Atom
™
E3825,
3.5" SBC, 2GB/4GB On-board
Memory, VGA, 48-bit LVDS, 2GbE,
Mini PCIe, PCI-104, SUSI 4

PCM-9365 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2015
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
Intel® is a trademark of Intel® Corporation.
AMI is a trademark of American Megatrends, Inc.
IBM, PC, PS/2 and VGA are trademarks of International Business Machines Cor-
poration.
Microsoft Windows®, DirectX® is a registered trademark of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
For more information on this and other Advantech products, please visit our websites
at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our support website at:
http://support.advantech.com/
This manual is for the PCM-9365.
Part No. 2006936510 Edition 1
Printed in China May 2015

iii PCM-9365 User Manual
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.

PCM-9365 User Manual iv
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications. Test conditions
for passing included the equipment being operated within an industrial enclosure. In
order to protect the product from being damaged by ESD (Electrostatic Discharge)
and EMI leakage, we strongly recommend the use of CE-compliant industrial enclo-
sure products.
FCC Class A
This equipment has been tested and found to comply with the limits for a Class A dig-
ital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference when the equipment is oper-
ated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruc-
tion manual, may cause harmful interference to radio communications. Opera- thin of
this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
Battery Information
Batteries, battery packs, and accumulators should not be disposed of as unsorted
household waste.
Please use the public collection system to return, recycle, or treat them in compliance
with the local regulations.
Technical Support and Assistance
1. Visit the Advantech website at http://support.advantech.com where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages
Caution! There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
flatterer. Discard used batteries according to the manufacturer's instruc-
tions.

v PCM-9365 User Manual
Packing List
Before you begin installing your card, please make sure that the following materials
have been shipped:
If any of these items are missing or damaged, contact your distributor or sales repre-
sentative immediately.
Optional Accessories
Part number Description
1960070254T001 Heat spreader 15.0mm height
1653130421 PCI-104 connector 120-pin (Long pin)
1 x PCM-9365 SBC
1 x SATA Cable 32cm (p/n: 1700008941)
1 x SATA Power Cable 35cm (p/n: 1700018785)
1 x Audio Cable 20cm (p/n: 1700019584)
1 x COM Cable 22cm (p/n: 1701200220)
2 x USB cable 25cm (p/n:1700018730)
1 x COM2 cable 30cm (p/n:1700019414)
1 x Heatsink (19.5mm) (p/n: 1960067897T001)
1 x Startup manual (p/n: 2006936500)
1 x Mini Jumper(10pcs package) (p/n: 9689000002)
1 x SUSIAccess Pro package (p/n: 968EMLSAP1)

PCM-9365 User Manual vi

vii PCM-9365 User Manual
Contents
Chapter 1 General Information ............................1
1.1 Introduction ...............................................................................................2
1.2 Specifications............................................................................................2
1.2.1 Functional Specifications..............................................................2
1.2.2 OS support....................................................................................3
1.2.3 Mechanical Specifications.............................................................4
1.2.4 Electrical Specifications................................................................4
1.2.5 Environmental...............................................................................4
1.3 Block Diagram...........................................................................................5
1.4 Board layout: dimensions..........................................................................6
Figure 1.1 PCM-9365 Mechanical Drawing (Top Side)...............6
Figure 1.2 PCM-9365 Mechanical Drawing (Bottom Side)..........7
Figure 1.3 PCM-9365 Mechanical Drawing (Coastline)...............7
Chapter 2 Installation............................................9
2.1 Jumpers & Switches................................................................................10
Table 2.1: Jumpers & Switches.................................................10
2.2 Connectors..............................................................................................10
Table 2.2: Connectors...............................................................10
2.3 Locating Connectors ...............................................................................11
Figure 2.1 PCM-9365 Connector Locations (Top Side).............11
Figure 2.2 PCM-9365 Connector Locations (Bottom Side) .......12
2.4 Setting Jumpers ......................................................................................12
2.4.1 Auto Power On Setting (J1)........................................................12
Table 2.3: Auto Power On Setting (J2)......................................13
2.4.2 PCI-104 VIO (J2) ........................................................................13
Table 2.4: PCI-104 VIO (J2)......................................................13
2.4.3 LVDS1 Power (J4)......................................................................13
Table 2.5: LVDS1 Power (J4)....................................................13
2.4.4 LVDS2 Power (J5)......................................................................13
Table 2.6: LVDS2 Power (J5)....................................................13
2.4.5 Clear CMOS (J6) ........................................................................14
Table 2.7: Clear CMOS (J6)......................................................14
2.4.6 LVDS JEIDA/VESA Selection (J7)..............................................14
Table 2.8: LVDS JEIDA/VESA Selection (J7) ...........................14
Chapter 3 AMI BIOS Setup .................................15
3.1 Entering Setup ........................................................................................17
3.1.1 Main Setup..................................................................................17
3.1.2 Advanced BIOS Features Setup.................................................18
3.1.3 Chipset Configuration .................................................................30
3.1.4 Security.......................................................................................38
3.1.5 Boot.............................................................................................39
3.1.6 Save & Exit .................................................................................40
Appendix A Pin Assignments ...............................41
A.1 Jumper List..............................................................................................42
A.2 Connector Pin Definition .........................................................................44

PCM-9365 User Manual viii
Appendix B System Assignments........................67
B.1 System I/O Ports..................................................................................... 68
Table B.1: System I/O Ports...................................................... 68
B.2 1st MB Memory Map............................................................................... 68
Table B.2: 1st MB Memory Map................................................ 68
B.3 Interrupt Assignments............................................................................. 69
Table B.3: Interrupt assignments............................................... 69
Appendix C EC Watchdog Timer Sample Code.. 71
C.1 EC Watchdog Timer sample code .......................................................... 72

Chapter 1
1General Information
This chapter gives background
information on the PCM-9365.
Sections include:
Introduction
Specifications
Block diagram
Board layout and dimensions

PCM-9365 User Manual 2
1.1 Introduction
PCM-9365 is 3.5" form factor (146 x 102 mm) and powered by the latest generation
of Intel®Celeron®N2930 and Atom™ E3825 processors which have low power fea-
tures but also good performance computing, especially for multimedia capabilities
compared to earlier generations. Meanwhile, PCM-9365 offers flexible expansion
possibilities: two full-size mini PCIe, PCI-104, and the 2nd LVDS by request.
PCM-9365 supports various display interfaces including HDMI, VGA, and 48-bit
LVDS, and rich I/O: 2 x GbE, SATA, mSATA, 4xSerial Ports, USB 3.0 and 5 x USB
2.0.
1.2 Specifications
1.2.1 Functional Specifications
Processor:
–Celeron®N2930 1.83GHz (burst frequency 2.16GHz), Quad Cores, Four
Threads
–Atom™ E3825 1.33GHz, Dual Cores, Two Threads
–Cache Hierarchy
* 32 KB 8-way L1 instruction cache and 24 KB 6-way L1 data cache per core
* 1 MB, 16-way L2 cache, shared per two cores
–Supported C-states: C0, C1, C6, C7
–Advanced Technologies
* Intel®Virtualization Technology (VT-x)
* Intel®64 Architecture
* Enhanced Intel SpeedStep Technology
* Intel®Trusted Execution Engine (TXE)
–Power Management
* ACPI 5.0
* System sleep states: S0, S3, S4, S5
System Memory Support
–Non-ECC, DDR3L 2G or 4G on-board memory
–64-bit data bus
–DDR3L with 1066 MT/s data rates for E3825, total memory bandwidth 8.5GB/s
–DDR3L with 1333 MT/s data rates for N2930, total memory bandwidth can be
scalable to 21.3GB/s
–Aggressive power management to reduce power consumption
Graphic and Media Engine
–Intel®7th generation (Gen 7) graphics and media encode/decode engine
–GFX: Normal 688 MHz / Burst 854 MHz for N2930, Normal 533 MHz for
E3825
–Graphic Features:
* 3D HW Acceleration: DirectX11, OpenGL3.2, OpenCL1.2
* HW Video Decode: H.264, MPEG2, MVC, VC-1, WMV9, MJPEG and VP8
* HW Video Encode: H.264, (MPEG2 and MVC only for N2930)
–Multi-display interfaces: VGA, HDMI/DisplayPort, 48-bit LVDS.
* Supports Extend/ Clone Mode with multi-display device
* Dual display: any two combination between VGA, HDMI, LVDS
–Specification and Resolution
* VGA: 2560 x 1600 at 60Hz
* HDMI/DisplayPort: HDMI 1.4a with audio, up to 1080P at 60Hz.

3 PCM-9365 User Manual
Chapter 1 General Information
* LVDS: 48-bit dual channel LVDS up to WUXGA 1920x1200 at 60Hz
* Inverter power: 1A @ 5V/12V for each LVDS
–3D HW Acceleration: OGL4.0, DirectX 11.1
–HW Video Decode: H.264, MPEG2, VC-1, VP8
–HW Video Encode: H.264, MPEG2 (max at 1080p)
Gigabit Ethernet
–Controller: Realtek RTL8111E-VL-CG
* 10/100/1000 BASE-T
*
Fully compliant with IEEE802.3, IEEE802.3u, IEEE802.3ab
* 9 KB Jumbo frames supported (Full-duplex)
* Full duplex flow control supported
Peripheral interface
–1 Serial-ATA port, up to 3.0Gb/s transfer rate (300 MB/s), supports indepen-
dent DMA operation
* SATA Power: 1A @ 5V/12V
–1 x USB 3.0 & 5 x USB2.0
* One USB3.0 and one USB2.0 on rear I/O, four internal USB2.0
* USB3.0 SuperSpeed (SS), implements xHCI software host controller interface
* Multiplexed with EHCI controller that are High-Speed/Full-Speed (HS/FS)
* Supports wake-up from sleeping state S3
* Power supply: 0.5A @ 5V for USB2.0, 0.9A @ 5V for USB3.0
–1 RS-232/422/485 for COM1, 3 RS-232 for COM2/3/4 (ESD protection: air
gap ±15kV, contact ±8kV
–8-bit Programmable General Purpose Input/ Output from iManager (5V tolerance)
–1 SMBus / I2C channel from iManager
–Watchdog timer: Output System Reset, Programmable counter from 1 ~ 255
minutes/ seconds
–Mini PCIe / mSATA
1 Full-size Mini PCIe (with PCIe and USB interface)
1 Full-size mSATA (with SATA and USB interface)
Power supply: 1.1 A @ 3.3 V or 0.375A @ 1.5V for miniPCIe, 0.2 A @ 3.3 V or 0.1
A @ 1.5 V for mSATA
High Definition Audio:
–Intel®High Definition Audio Interface
–High Definition Audio Codec with Realtek proprietary loss-less content pro-
tection technology
–Supports 1 Line-input, 1 Line output, 1 Mic-input
BIOS
–AMI UEFI 64 Mbit, BIOS for 64 or 32bit is different, default version is for 64bit
–Default setting is Legacy boot, that can be manually changed to UEFI boot. If
default setting to UEFI is needed, that can be done by T-P/N
1.2.2 OS support
PCM-9365 supports Win8, Win7, WES8, WES7, WEC7, Linux kernel 3.x, VxWorks
6.9.3.3, Android Kit Kat 4.4
Win7 only supports Legacy mode and Win8 for UEFI mode.
For further information about OS support of PCM-9365, please check Advantech
website:
http://support.advantech.com.tw/ or contact the technical support center.

PCM-9365 User Manual 4
1.2.3 Mechanical Specifications
Dimensions: 146 x 102 mm (5.7 x 4 inches)
Height: top side 19.5mm, PCB 1.6mm, bottom side 7.8mm, total 28.9mm
Weight: 0.5 kg (reference weight of total package)
1.2.4 Electrical Specifications
Power Requirement: Single +12V DC ± 10% power input
Power Consumption:
–Max load
* PCM-9365E-2GS3A1E: 0.49A @ 12V (5.88W)
* PCM-9365EV-4GS3A1E: 0.554A @ 12V (6.648W)
* PCM-9365N-4GS8A1E: 0.745A @ 12V (8.94W)
–Idle mode
* PCM-9365E-2GS3A1E: 0.39A @ 12V (4.68W)
* PCM-9365EV-4GS3A1E: 0.44A @ 12V (5.28W)
* PCM-9365N-4GS8A1E: 0.509A @ 12V (6.108W)
Power Consumption Conditions:
–Test software: Burn In Test V7.1Pro
–Max. load: Measure the maximum current value which system under maxi-
mum load (CPU: Top speed, RAM &Graphic: Full loading)
–Idle mode: Measure the current value when system in windows mode and
without running any program
RTC Battery:
–Typical Voltage: 3.0 V
–Normal discharge capacity: 210 mAh
1.2.5 Environmental
Operating Temperature: 0 ~ 60°C (32 ~ 140°F)
Operating Humidity: 40°C @ 85% RH Non-Condensing
Storage Temperature: Storage temperature: -40~85°C
Storage Humidity: Relative humidity: 95% @ 60°C

5 PCM-9365 User Manual
Chapter 1 General Information
1.3 Block Diagram
Intel
N2930 / E3825
ITE 8768
8-bit GPIO
DP
4GB/ 2GB DDR3L
on-board memory
Full size
Mini PCIe
Line-in/out
Mic-in
USB2.0/USB3.0
HD Audio
1 x USB3.0
ALC888S-VD2-GR
EC EC
LPC
Transmittor
2 x USB2.0
Single
Chaneel
USB HUB
USB2514B
RTL8111E-VL-CG
SMBus/ I2C
Bridge IT8892
PCIex1
PCIex1
PCI PCI-104
LVDS
VGA
1 x SATAII
SATA
SATAII 300MB/s
Full Size
mSATA RJ45
RTL8111E-VL-CG
PCIex1 RJ45
18/24bit LVDS
DP
Transmittor
LVDS
18/24bit LVDS
ITE 8528
USB2.0
1 x USB2.0
DP
2 x USB2.0
HDMI
VGA
COM 2/3/4: RS-232 COM1: RS-232/422/485
USB HUB
USB2514B USB2.0USB2.0
PCIex1
USB2.0 USB2.0
USB2.0USB2.0
(note1)

PCM-9365 User Manual 6
1.4 Board layout: dimensions
Figure 1.1 PCM-9365 Mechanical Drawing (Top Side)

7 PCM-9365 User Manual
Chapter 1 General Information
Figure 1.2 PCM-9365 Mechanical Drawing (Bottom Side)
Figure 1.3 PCM-9365 Mechanical Drawing (Coastline)
BOT H<10

PCM-9365 User Manual 8

Chapter 2
2Installation
This chapter explains the setup
procedures of the PCM-9365 hard-
ware, including instructions on
setting jumpers and connecting
peripherals, switches and indica-
tors. Be sure to read all safety pre-
cautions before you begin the
installation procedure.

PCM-9365 User Manual 10
2.1 Jumpers & Switches
The PCM-9365 has a number of jumpers that allow you to configure your system to
suit your application. The table below lists the functions of the various jumpers.
2.2 Connectors
Onboard connectors link the PCM-9365 to external devices such as hard disk drives,
a keyboard, or floppy drives. The table below lists the function of each of the connec-
tors.
Table 2.1: Jumpers & Switches
J1 Auto Power On
J2 PCI-104 VIO
J4 LVDS1 Power
J5 LVDS2 Power
J6 Clear CMOS
J7 LVDS JEIDA/VESA Selection
Table 2.2: Connectors
Label Function
CN1 12V Power Input
CN2 Battery
CN3 EC Debug Port
CN4 Power Switch
CN5 Reset
CN6 GPIO
CN7 VGA
CN8 HDMI
CN9 SATA
CN10 HDD & PWR LED
CN11 SATA Power
CN12 Mini PCIE
CN13 mSATA
CN14 Internal USB
CN15 Internal USB
CN16 External USB3.0
CN17 External USB
CN18 COM1
CN19 COM2
CN22 LAN1
CN23* LAN1 & LAN2 (Dual LAN connector)
CN24 Internal LAN LED
CN25 LAN2
CN26 Audio
CN27 PCI-104
CN28 Inverter Power (LVDS1)
CN29 48 bits LVDS1
CN30 Inverter Power (LVDS2)
CN31 48 bits LVDS2

11 PCM-9365 User Manual
Chapter 2 Installation
* represents default configuration
2.3 Locating Connectors
Figure 2.1 PCM-9365 Connector Locations (Top Side)
CN33 SMBus
CN37 COM3/COM4
J3 PCI-104 -12V Input
Table 2.2: Connectors

PCM-9365 User Manual 12
Figure 2.2 PCM-9365 Connector Locations (Bottom Side)
2.4 Setting Jumpers
You may configure your card to match the needs of your application by setting jump-
ers. A jumper is a metal bridge used to close an electric circuit. It consists of two
metal pins and a small metal clip (often protected by a plastic cover) that slides over
the pins to connect them. To “close” a jumper, you connect the pins with the clip. To
“open” a jumper, you remove the clip. Sometimes a jumper will have three pins,
labeled 1, 2 and 3. In this case you would connect either pins 1 and 2, or 2 and 3.
The jumper settings are schematically depicted in this manual as follows:
A pair of needle-nose pliers may be helpful when working with jumpers. If you have
any doubts about the best hardware configuration for your application, contact your
local distributor or sales representative before you make any changes. Generally, you
simply need a standard cable to make most connections.
2.4.1 Auto Power On Setting (J1)
closed 2-3closedopen
