Advantech AIMB-787 Installation and operation manual

AIMB-787 Startup Manual 1
AIMB-787 LGA1200 Intel® Core™ i9/i7/i5/i3 ATX with
Triple Display, Dual GbE LAN, M.2, USB 3.2, DDR4
Startup Manual
Specications (Cont.)
Packing List
For more information on this and other Advantech prod-
ucts, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our sup-
port website for AIMB-787 at:
http://advt.ch/aimb787spt
Register your products on our website and get 2 months
extra warranty for Free at:
http://www.register.advantech.com
This manual is for the AIMB-787 series Rev. A1.
Part No. 2041078700
Printed in China
1st Edition
Aug 2020
• SATA interface: Four on-board Serial ATA 3.0 connectors
support data transmission rates up to 600 MB/s. All four
SATA 3.0 ports support Advanced Host Controller Inter-
face (AHCI) technology.
• PCIe and PCI slot: 1 PCIe x16 expansion slot, 4 PCIe
x4 expansion slots (three x4 link, one x1 link), 2 PCI slots
32-bit/33 MHz PCI 2.2 compliant.
• USB 3.2/2.0: 2 USB 3.2 Gen 2 ports on rear with up to
10 Gb/s data rate, 4 USB 3.2 Gen 1 ports (2 rear, 2 via
header), 8 USB 2.0 ports (4 rear, 2 via header, 2 internal
Type-A).
• LPC interface: Advantech-designed LPC connector sup-
ports TPM module.
• Serial port: Six serial ports: COM1, COM2 and COM4 ~
6 are RS-232; COM3 is RS-232/422/485 with jumper and
BIOS menu options.
• Parallel port: One parallel port, which supports SPP/
EPP/ECP mode.
• Keyboard/mouse connector: The motherboard is not
equipped with rear PS/2 connector for keyboard/mouse.
A 6-pin onboard header is supported for an optional PS/2
keyboard/mouse cable.
• Watchdog timer: 255 sec timer level intervals.
Graphic Interface
• Chipset: CPU integrated graphics controller.
• Display memory: 1 GB maximum shared memory with 2
GB and above system memory installed.
• DisplayPort: Resolution up to 4096 x 2304 @ 60 Hz
refresh rate.
• DVI-D: Resolution up to 1920 x 1200 @ 60 Hz refresh
rate.
• VGA: Resolution up to 1920 x 1200 @ 60 Hz refresh rate.
Ethernet interface
• Interface: 10/100/1000 Mbps.
• Controller: LAN1: Intel
®
I219-LM; LAN2: Intel
®
I210-AT.
Mechanical and Environmental
• Dimensions (L x W): 304.8 x 244 mm (12” x 9.6”)
• Power supply voltage: +3.3 V, +5 V, ±12 V, +5 Vsb
• Power consumption:
Intel Core i5-10500E; DDR4 16 GB x 4
Maximum: +3.3 V at 5.56 A, +5 V at 4.02 A, +12 V at 6.28 A,
+5 Vsb at 0.16 A, -12 V at 0.1 A
• Operating temperature: 0 ~ 60° C (depending on CPU)
• Weight of board: 0.7 kg (1.54 lb)
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 AIMB-787 Startup Manual
• 2 Serial ATA HDD data cables
• 1 I/O port bracket
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Standard Functions
• CPU: LGA1200 socket supporting 10th generation Intel®
Core™ i9/i7/i5/i3/Pentium/Celeron processor.
• BIOS: AMI 256 Mbit SPI BIOS.
• Chipset: Intel® Q470E PCH.
Note: Legacy platforms are not supported.
• System memory: Up to 128 GB in four 288-pin DIMM
sockets supporting dual-channel DDR4 2400/2666/2933
SDRAM.AIMB-787supportsnon-ECCunbu󰀨eredDIMMs
anddoesnotsupportanymemorycongurationthat
mixesnon-ECCwithECCunbu󰀨eredDIMMs.
• M.2 socket: One M.2 socket supports up to PCIe x4 M-
key 2280 type storage devices.
Specications

2 AIMB-787 Startup Manual
The board has a number of jumpers that allow you to con-
gureyoursystemtosuityourapplication.Thetablebelow
lists the function of each jumper and connector.
Connector / Jumper List
Label Function
LPT1 Parallel port, supporting SPP/EPP/
ECP mode
LAN1 ~ LAN2 GbE LAN
USB3C1 USB 3.2 Gen 2 port *2
USB3C2 USB 3.2 Gen 1 port *2
USB3H1 USB 3.2 Gen 1 port *2
(20-pin header)
USB2C1 USB 2.0 port *4
USB2A1 ~
USB2A2 USB 2.0 port (internal Type-A)
USB2H2 USB 2.0 port *2 (10-pin header)
VGA1+DVI1 VGA connector / DVI-D connector
COM1+DP1 Serial port: RS-232 (DB-9 connec-
tor) / DP connector
COM2,
COM4 ~ COM6 Serial port: RS-232 (9-pin header)
COM3 Serial port: RS-232/422/485 (9-pin
header)
KBMS1 External keyboard/mouse connec-
tor (6-pin header)
CPUFAN1 CPU fan connector (4-pin)
SYSFAN1 ~
SYSFAN3 System fan connector (4-pin)
JFP3
Keyboard lock and power LED
Suspend:fastash(ATX/AT)
Systemon:on(ATX/AT)
Systemo󰀨:o󰀨(ATX/AT)
JFP2 External speaker / HDD LED con-
nector / SMBus connector
JFP1 Power switch / reset connector
AUDIO1+AUDIO2 Audio connector (Line Out, Mic In)
VOLT1 Alarm board power connector
JCASE1 Case open connector
LANLED1 Front panel LAN indicator con-
nector
NVME1 M.2 2280 M-key socket
SATA1 ~ SATA4 Serial ATA 3.0 port
PCI1 ~ PCI2 PCI slot
PCIE1 PCIe x16 slot (Gen 3 x16 link)
PCIE2 , PCIE4 ~
PCIE5 PCIe x4 slot (Gen 3 x4 link)
PCIE3 PCIe x4 slot (Gen 3 x1 link)
DIMMA1 Channel A DIMM1
DIMMA2 Channel A DIMM2
DIMMB1 Channel B DIMM1
DIMMB2 Channel B DIMM2
ATX12V1 ATX12Vauxiliarypowerconnec-
tor (for CPU)
EATXPWR1 ATX24-pinmainpowerconnector
(for system)
SPDIF_OUT1 SPDIF audio out pin header
GPIO1 8 bit GPIO from super I/O
SMBUS1 SMBus connector from PCH
FPAUD1 Front panel audio connector
LPC1 Low pin count connector
JCMOS1: CMOS clear
JME1: Intel ME update
Closed Pins Result
1-2 *Keep CMOS data
*Enable ME update
2-3
Clear CMOS data
Disable ME update
* Default
*Keep CMOS data Clear CMOS data
*Enable ME update Disable ME update
JWDT1+JOBS1: Watchdog timer output and OBS alarm
Closed Pins
Result
2-4, 8-10 Watchdogtimerdisable(2-4)
OBS beep (8-10)
4-6, 8-10 *Watchdogtimerreset(4-6)
OBS beep (8-10)
* Default
Watchdogtimerdisable(2-4)*Watchdogtimerreset(4-6)
OBS beep (8-10) OBS beep (8-10)
1 2 3
1 2 3
Jumpers and Connectors Jumpers and Connectors (Cont.)

AIMB-787 Startup Manual 3
PSON1: ATX/AT mode selection
Closed Pins
Result
1-2 AT mode
2-3 *ATXmode
* Default
ATmode*ATXmode
JUSB_1 (rear USB), JUSB_2 (onboard USB): USB
power source switch between +5V and +5V_DUAL
Closed Pins
Result
1-2 *USB +5V_DUAL power
2-3 USB +5V power
* Default
*USB +5 V_DUAL power USB +5 V power
JPCICLK1: PCI clock selection
Closed Pins
Result
1-2 66 MHz
2-3 *33 MHz
* Default
66 MHz 33 MHz
SMB1 (clock), SMB2 (data): PCIe SMBus connec-
tion setting
Closed Pins
Result
1-2 *Enable PCIe SMBus connection
2-3 Disable PCIe SMBus connection
* Default
*Enable PCIe SMBus connection Disable PCIe SMBus connection
Note! Both SMB1 and SMB2 jumpers should be
switched to the same setting, either 1-2 closed or
2-3 closed.
1 2 3
1 2 3
1 2 3
1 2 3
1 2 3
1 2 3
JSETCOM3: COM3 RS-232/422/485 jumper setting
Closed Pins
Result
5-6, 7-9, 8-10,
13-15, 14-16 *RS-232
3-4, 9-11,
10-12, 15-17,
16-18
RS-422
1-2, 9-11,
10-12, 15-17,
16-18
RS-485
* Default
Note!
BIOS setting change is necessary if RS-422 or RS-485
is selected. Please refer to Chapter 3 of user manual for
further setting.
JT1(TX signal), JR1(RX signal): COM3 RS-422/485
termination resistor
Closed Pins
Result
1-2 Disable termination
2-3 *Enable termination
* Default
Disable termination *Enable termination
*RS-232
RS-422
RS-485
Jumpers and Connectors (Cont.) Jumpers and Connectors (Cont.)

4 AIMB-787 Startup Manual
JFV1: VGA dummy load setting
Closed Pins
Result
1-2 Enable VGA dummy load
2-3 *Disable VGA dummy load
* Default
Enable VGA dummy load *Disable VGA dummy load
Note! It is recommended to leave this function disabled
if you use DVI/DP as your main display.
Declaration of Conformity
Jumpers and Connectors (Cont.)
Caution! The computer is supplied with a battery-powered
realtime clock circuit. There is a danger of explo-
sion if battery is incorrectly replaced. Replace
only with same or equivalent type recommended
by the manufacturer. Discard used batteries ac-
cording to manufacturer’s instructions.
This device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired opera-
tion.
Figure 1: Board Layout: Jumper and Connector Locations
COM2
SATA1 SATA3
SATA2 SATA4
DIMMB2
DIMMB1
DIMMA2
DIMMA1
PCI1
PCIE4
PCIE1
Intel Q470E PCH
Intel LGA1200 Core i9/i7/i5/i3
USB2A1
USB3H1
COM3
USB2H2
AUDIO1+AUDIO2
LAN2
USB3C2
LAN1
USB3C1
VGA1
DVI1
USB2C1
COM1
DP1
SYSFAN1
SYSFAN3
VOLT1 EATXPWR1 PSON1 GPIO1
LPT1
SMBUS1
JCASE1
COM4
COM5
COM6
LPC1
JSETCOM3
JT1, JR1
JWDT1+JOBS1
JFP3
JFP1+JFP2
CPUFAN1
JUSB_2
JCMOS1
JME1
PCIE2
PCIE3
PCIE5
PCI2
JPCICLK1
SPDIF_OUT1 FPAUD1
LANLED1
KBMS1
SYSFAN2
NVME1
ATX12V1
JUSB_1
SMB1, SMB2
USB2A2
3 6 9 12
25811
PWRSW RESET
HDDLED
SNMP
JFP1
&
2 5 8 11
1 4 7 10
HDDLED
SM_BUS
SPEAKER
JFP2
&
PWRLED & KEYLOCK
12345
JFP3
Board Layout
