Advantech MIO-3150 Installation and operation manual

MIO-3150 Startup Manual 1
MIO-3150 Mini-PCI Interface to Video Capture Module 430TX/SODIMM/LAN/USB/CRT/LCD/COM/DOC
CM-3351
S
B
MIO-3150 Mini-PCI interface to
video capture module
Startup Manual
Advantech introduces its new MIO module, MIO-3150 with
Mini-PCI interface to video capture module.Supports ana-
log TV output applications like CCTV surveillance system.
Ruggedly designed for high reliability surveillance systems
in transport, aviation and defense applications.
Before you begin installing your card, please make sure
that the following materials have been shipped:
If any of these items are missing or damaged,
contact your distributor or sales representative
immediately
.
• Supports NTSC/PAL/SECAM video decoding
• Multiple composite and S-video inputs
• Fully PCI Rev. 2.1 compliant
• Auxiliary GPIO port to support external devices
• Multiple YCbCr and RGB pixel formats supported on out-
put
Mechanical and Environmental
• Power requirement: +12V DC for CCD from power
CONN cable; +3.3V DC from power mother-
board[miniPCI slot]
• Size: 44.6mm x 59.75mm
• Operating Temperature: 32°F ~ 140°F (0°C ~ 60°C)
• OS support: Windows 2000, XP, CE
• API:Simple User Interface
Introduction Specifications
Packing list
• 1 MIO-3150 Mini-PCI interface to video capture module
• 1 Startup manual
• 1 CD ROM for MIO-3150 Driver
• 2 Cables
• 1 WIRE 6P/4P/4P 1.25mm 13cm p/n: 1700002047
• 1 WIRE 4P power/4P 1.25mm 10cm p/n: 1700002049
Note 1: Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at:
www.adobe.com/products/acrobat/
readstep2.html(Acrobat is a trademark of
Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the MIO-3150 series Rev. A1.
Part No.2006315000 1st Edition
Oct. 2006

2 MIO-3150 Startup Manual
The table below lists the function of each of the jumpers
and connectors
Jumpers & Connectors
VIDEO IN Connector (CN2)
Pin Signal Pin Signal
1 CCD_VCC 2 GND
3 CCD1 4 GND_SIGNAL
5 VIDEO2(CCD2) 6 GND_SIGNAL
+12V Power In Connector (CN4)
Pin Signal Pin Signal
1 +12V 2 +12V
3 GND 4 GND
Board Layout
Mechanical Drawing (component side)

3 MIO-3150 Startup Manual
Mechanical Drawing (solder side)
FCC This device complies with the requirements in part 15 of the FCC rules: Operation is subject to the fol-
lowing two conditions:
1.This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undes-
ired operation
This equipment has been tested and found to comply with the limits for a Class A digital device, pur-
suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. Operation of
this device in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his/her own expense. The user is advised that any equipment
changes or modifications not expressly approved by the party responsible for compliance would void
the compliance to FCC regulations and therefore, the user's authority to operate the equipment.
Caution!
Achtung!
There is a danger of a new battery exploding if it is incorrectly installed. Do not attempt to recharge,
force open, or heat the battery. Replace the battery only with the same or equivalent type recom-
mended by the manufacturer. Discard used batteries according to the manufacturer’s instructions.
