Advantech PCIE-1154 Installation and operation manual

PCIE-1154 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
1. 1 x PCIE-1154, 4-port PCIe USB Vision Frame Grabber
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
General
• Chipset:
4 Fresco FL1100 host controllers
Compliant with USB 3.0 Specication Revision 1.0
Compliant with Intel® xHCI Specication Revision 1.0
• Interface:
PCIe 2.0 4x
• DataTransferRate:
SuperSpeed (5.0 Gbps); High Speed (480.0 Mbps); Full
Speed (12.0 Mbps); Low Speed (1.5 Mbps)
• CurrentProtection:
1500 mA per-port current limit
Note: For better compatibility, please change the
PCIe settings to Gen 2.0 on device card slot.
Mechanical and Environmental
• Dimensions(LxW):
118 x 111 mm (MB);
• PowerRequirements:
Slot: PCIe 2.0 standard
• NetWeight:
100 g
PCIE-1154 4-port PCI Express USB Vision Frame
Grabber
Startup Manual
MainBoardConnectors
Label Function
USB1~USB4 USB3.0 Ports 1~4
Connector1 PCIe 2x4-pin auxiliary power connector
Connector2 ATX 5 & 12 V 4-pin power connector
AuxiliaryPowerConnectorPin-OutAssignment
Label Function
Pin 1 +12 V
Pin 2 +12 V
Pin 3 +12 V
Pin 4 N/C
Pin 5 Ground
Pin 6 N/C
Pin 7 Ground
Pin 8 Ground
Figure 1: Auxiliary Power Connector
ConnectorsPackingList
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/default.
aspx
This manual is for the PCIE-1154 Series Rev. A1
Part No. 2003115400
Printed in China
1st Edition
March 2018
Specications

2 PCIE-1154 Startup Manual
ATX5V&12V4-pinpowerconnector
Label Function
Pin 1 +12 V
Pin 2 GND
Pin 3 GND
Pin 4 N/C
Figure 2: ATX 4-pin Power Connector

DeclarationofConformity
This device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditions:
1. The device may not cause harmful interference;
2. The device must accept any interference received,
including interference that may cause undesired opera-
tion.
Under certain circumstances, you may need to change the
ring buffer size from 128 to 256 KB. To do this, execute
PCIE-1154_RingBuffer_256.reg from the download installer
archive.
Connectors (Cont.)
BoardLayout

 Caution
