Advantek Networks ANS-05P User manual

5 Port 10/100Mbps Ethernet
Switch
Quick Installation Guide
Model # A S-05P

FCC Warning
This equipment has been tested and found to comply with the limits for a class B digital device,
pursuant to Part 15 of the FCC ules. These limitations are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
* eorient or relocate the receiving antenna.
*Increase the separation between the equipment and receiver.
*Connect the equipment into a different outlet from that the receiver is connected.
*Consult your local distributors or an experienced radio/TV technician for help.
*Shielded interface cables must be used in order to comply with emission limits
Changes or modifications to the equipment, which are not approved by the party
responsible for compliance could affect the user's authority to operate the equipment.
Copyright _ 1999 All ights eserved.
Company has an on-going policy of upgrading its products and it may be possible
that information in this document is not up-to-date.
Please check with your local distributors for the latest information.
No part of this document can be copied or reproduced in any form without written
consent from the company.
Trademarks:
All trade names and trademarks are the properties of their respective companies.
General Description

Advantek Networks ANS-05P is a powerful, high-performance Fast Ethernet switch, with all 5
ports capable of 10 or 100Mbps auto-negotiation operation (Nway) which means the switch could
automatically negotiate with the connection on the network speed and in duplex mode. It is ideal
for micro-segmenting large networks into smaller connected subnets; for improving performance,
enabling the bandwidth demanding contents, multimedia and imaging applications to be
transferred efficiently. Moreover, the 10/100Mbps auto-sensing ability provides an easy way to
migrate 10Mbps to 100Mbps network with no hassle. Compared to the shared 10Mbps or
100Mbps networks, the Ethernet Switch delivers a dedicated 10/100Mbps connection to every
attached client with no bandwidth congestion issue.
Product Features
*Complies with 10BASE-T specifications of the IEEE802.3 standard
*Complies with 100BASE-TX specifications of the IEEE802.3u standard
*5 x J-45 ports for 100Base-TX and 10Base-T connectivity
*Supports Nway protocol for speed (10/100Mbps) and duplex mode
(Half/Full) auto-detection
*Supports full and half duplex operation on all ports
*Supports back-pressure (half duplex) and flow control (IEEE802.3x)
*Wire speed packet filtering and forwarding rate
*Store-and-forward architecture filters fragment & C C error packets
*Supports extensive LED indicators for network diagnostics
*External power adapter
*Supports MDI/MDI-X auto crossover
*FCC Class B, CE
Package contents
5 port 10/100Mbps Ethernet Switch
AC power adapter
Quick installation guide
* If any of the items is damaged or missing, please contact your retailer immediately.
Front panel LED indicators

After installing the switch, you can check its status from the LED indicators on the front panel
shown below.
Front View
LED Color Status Indication
POWE (PW )
G EEN ON The switch is power on
OFF The switch is power off
LINK / ACT G EEN ON A link is established
BLINKING A link is established and data is being
transmitted or received
Rear panel ports
Back View
Ports 1x - 5x :The switch has five 10/100Mbps J-45 ports where you can connect computers or
network devices to the switch.
AC IN : This port connects the AC power adapter (AC 9V / 1A).
Power Connecting
Plug the circle end of the power adapter firmly into the power port on the switch’s rear panel, and
the other end into an electrical outlet, then the system is ready.
Connecting computers to the switch
The switch features auto-MDI/MDIX crossover detection function and provides plug-and-play
capability. Users can immediately use any of the features of this product simply by plugging the
network cables ( J-45) into the computers and the switch.
Uplink

All Ports can be used as an uplink port for connecting to another unit without using crossover
cable. When using the uplink port, you can extend the distance to 100m for linking another switch
or hub.
To prolong the operational life of your units
*Never stack units more than eight high if freestanding
*Do not place objects on top of any unit or stack
*Do not obstruct any vents at the sides of the case
! WAR I G !: Use only the AC power adapter that came with the
switch to prevent damage to the unit.
..
.
