AEG AXP26U339CW User manual

Portable Air conditioner
User Manual
USER
MANUAL
AXP26U339CW
AXP26U559HW
AXP34U339CW
AXP34U339BW
AXP34U339HW
AXP35U539CW

3
9
12
12
13
14
14
17
18
19
PORTABLE AIR CONDITIONER FEATURES
Subject to change without notice.
FOR PERFECT RESULTS
CUSTOMER CARE AND SERVICE
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler
– features you might not find on ordinary appliances. Please spend a few minutes
reading to get the very best from it.
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
Warning / Caution-Safety information.
General information and tips.
Environmental information.
2 www.aeg.com

Cleaning and user maintenance shall not be made
by children without supervision. Children shall not
play with the unit.
This manual explains the proper use of your new portable
air conditioner. Please read this manual carefully before
using the product.This manual should be kept in a safe
place for handy reference.

regulations
louvres swing.
The portable air conditioner is not intended for use by
young children of infirmed persons without supervision.
Young children should be supervised to ensure that
they do not play with the portable air conditioner.
4 www.aeg.com

In the event of any abnormality with the portable air
conditioner(eg. a burning smell),do not pull out the
plug directly, open the window for ventilation firstly,
then turn the unit off and disconnect the power supply.
applianceappliance

(only for Switzerland)
Do not use this portable air conditioner for non-specified
special purposes(e.g. preserving precision devices,
food, pets, plants, and art objects). Usage in such a
manner could harm such property.
dry mode or heat mode.
6 www.aeg.com

The appliance shall be stored in a room without
continuously operating ignition sources (for example:
open flames, an operating gas appliance or an
operating electric heater.)
Do not pierce or burn.
appliance

8 www.aeg.com

portable air conditioner
Dry mode decreases room temperature.
Warm air will be blown out from the
exhaust air outlet, but this is normal and
does not indicate a problem with the unit.
WiFi Working frequency and maximum
output power: 2412-2472 MHz, 15.72dBm
portable air conditioner.
portable air conditioner

10 www.aeg.com

portable air conditioner

OPTIONAL ACCESSORIES
Window Kit AXP26U559HW (incl.)
Extension Piece
www.aeg.com
Continuous drain outlet (Heat pump mode)
Wheels
Continuous drain outlet (Dry mode)
12 www.aeg.com

1
2
1(Fig.3)
(Fig.4)
(Fig.1) (Fig.5)
(Fig.6)
(Fig.2)
Lock
unit
close to a power socket.
Lock the adaptor A into the unit. (Fig.4)
and is
A
B
B
2
Affix the adaptor B into the window.
(Fig.5)
Note: If need to install the window kit, please
refer to the Window Kit Instruction Manual.

Louver swing
(Only available in Auto, Cool or Heat mode)
WiFi Indicator
Scheduler Indicator
(Not available in Auto or Dry Mode)
10
11
10 11
PORTABLE AIR CONDITIONER FEATURES
Cooling Mode
Dry Mode
“Auto” “Min” “Mid” “Max” “Auto”
Power ON/OFF
Power on the unit by gently touching the
ON/OFF icon “ ” on the control panel of
the unit.
Heating Mode (on some models)
“Auto” “Min” “Mid” “Max” “Auto”
“MODE”
“MODE”
“MODE”
7.3
14 www.aeg.com

Fan Mode
Auto Mode
Timer Mode
Sleep Mode
Louver Swing Function
You can delay shutdown when the unit is on.
Filter Reset
Auto
Louver swing
WiFi
The unit is equipped with a WiFi module.
When the unit is connected to the home
WiFi, this icon “ ” will light up. If the icon is
Child Lock
Turn on child lock by pressing the “MODE”
button for 5 seconds, until the display
shows “LC”. To turn off child lock, press
the “MODE” button again for 5 seconds.
blinking, it indicates a temporary loss of WiFi
connectivity – please refer to the AEG App
for more details.
To manually initiate the onboarding process.
Press “ ” for 5 seconds.
“MODE”
Note: Fan speed can not be changed in
Auto mode or Dry mode.
“MODE”
“on/off ”
“on/off ”

(Fig.8)
(Fig.9)
Continuous Drainage
Dry Heat
(Fig.8)
(Fig.9)
Note:
If the display reads “P1”, bottom tray is
full. Turn off and unplug the unit, then
carefully move the unit to a drain
location. Remove the bottom drain plug
and let the water drain away. Restart the
unit until the “P1” symbol disappears. If
error repeats, call for service.
If the display reads“E4”, the communication
between display PCB and main control PCB
is faulty. Contact your Authorized AEG
Service Center.
If the display reads “AS”, the ambient
temperature sensor has failed. Contact
your Authorized AEG Service Center.
If the display reads “ES”, the evaporator
temperature sensor has failed. Contact
your Authorized AEG Service Center.
If the display reads “L3”, the condenser
DC fan motor has failed. Contact your
Authorized AEG Service Center.
The unit is equipped with a WiFi module.
When the unit is connected to the home
WiFi, this icon “ ” will light up. If the icon is
Scheduler
To show a scheduled event from the app
is running.
Bluetooth
The unit uses Bluetooth when onboarding.
Make sure to have the mobile phone’s
Bluetooth turned on when onboarding.
Note: Download our AEG App and follow
the step-by-step onboarding instructions
to bring the unit online.
blinking, it indicates a temporary loss of WiFi
connectivity – please refer to the AEG App
for more details.
To manually initiate the onboarding process.
Press “ ” for 5 seconds.
16 www.aeg.com

Clean your portable air conditioner
occasionally to keep it looking new.
Be sure to unplug the unit before
cleaning to prevent shock or fire
hazards.
Note:
(Fig.10)
(Fig.11)
1
2
3
4
portable air conditioner
air filters every two weeks of operation
with a vacuum cleaner.
portable air-
conditioner.
17

If ice forming cooling coil behind decorative
front.-Outdoor temperature below 16°C. To
defrost the coil,set Fan mode.
Air filter may be dirty. Clean filter. Refer to
8.Care and cleaning sectionTo defrost, set
to Fan mode.
If ice forming on cooling coil behind
decorative front. Temperature is set too low
for nighttime cooling. To defrost the coil,set
to Fan mode. Then, set temperature to a
higher setting.
Exhaust duct not connected or blocked.
See 5.1 Exhausting Hot Air Section.
portable air conditioner
portable air conditioner
portable air conditioner
Install the portable air conditioner as
described in the operating instructions.
Make sure the air filter and drain cap are
in place.
Portable air conditioner
Portable air conditioner
If the air filters are severely dirty, you
can also wash the air filters buy using
warm water under 40˚C and liquid
dishwashing dtergent. Rinse filter
thoroughly. Gently shake excess
water from the filter. Be sure filter is
thoroughly dry before replacing.
Press the filter reset button “ ”
after having cleaned the filters.
18 www.aeg.com

Unable to connect to the WiFi
Check that the Wi-Fi router is
connected and is turned ON and
working properly by checking that other
appliances or you mobile phone can
connect with the router.
Need to reboot the router. Unplug the
router, then plug it back, try rebooting
the router. Wait a few minutes and
check again.
The WiFi chip in the unit operates only
at 2.4Ghz so please ensure your home
WiFi is operating at this bandwidth.
Room temperature may not reach the
set target value on the display
When using this portable air conditioner
the warm air is evacuated through the
hose to the outside through the window
kit. This creates an under pressure in
the room, which results in air from
neighboring rooms / leakages from
outside to enter the room. For this
reason it is normal that you may not
always fully reach the set target
temperature on the product display.
The software in the unit is partly based on free and open source software. To see
the full copyright information and applicable license terms, please visit:
https://emtech.delta.electrolux.com/license
For more information visit
www.electrolux.com
Portable air conditioner
Portable air conditioner
19
