AEG 49002VMN User manual

49002VMN
EN
COOKER USER MANUAL

FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have
created it to give you impeccable performance for many
years, with innovative technologies that help make life
simpler – features you might not find on ordinary
appliances. Please spend a few minutes reading to get the
very best from it.
ACCESSORIES AND CONSUMABLES
In the AEG webshop, you’ll find everything you need to
keep all your AEG appliances looking spotless and
working perfectly. Along with a wide range of accessories
designed and built to the high quality standards you
would expect, from specialist cookware to cutlery baskets,
from bottle holders to delicate laundry bags…
Visit the webshop at:
www.aeg.com/shop
2

CONTENTS
4 Safety information
7 Product description
8 Before first use
9 Hob - Daily Use
12 Hob - Helpful hints and tips
13 Hob - Care and Cleaning
14 Oven - Control panel
15 Oven - Daily Use
17 Oven - Clock functions
18 Oven - Additional functions
19 Oven - Using the accessories
20 Oven - Helpful hints and tips
33 Oven - Care and Cleaning
37 What to do if…
38 Installation
40 Environment concerns
The following symbols are used in this user
manual:
Important information concerning your
personal safety and information on how to
avoid damaging the appliance.
General information and tips
Environmental information
Subject to change without notice
Contents 3

SAFETY INFORMATION
Before the installation and use, read this manual carefully:
• For your own safety and the safety of your property
• For the protection of the environment
• For the correct operation of the appliance.
Always keep these instructions with the appliance also if you move or sell it.
The manufacturer is not responsible if incorrect installation or use results in damage.
Children and vulnerable people safety
• This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in safe
way and understand the hazards involved. Children shall not play with the appliance.
• Keep all packaging away from children. There is the risk of suffocation or physical injury.
• Keep children and animals away from the appliance when the door is open or the appli-
ance is in operation. There is the risk of injury or other permanent disability.
• If the appliance has Child lock or Key lock function, use it. It prevents children and ani-
mals from accidental operation of the appliance.
General safety
• Do not change the specifications of this appliance. There is the risk of injury and damage
to the appliance.
• Do not let the appliance stay unattended during operation.
• Switch off the appliance after each use.
Installation
• Only an approved technician can install and connect the appliance. Contact an approved
service centre. This is to prevent the risks of structural damage or physical injury.
• Make sure that the appliance is not damaged because of transport. Do not connect a
damaged appliance. If necessary, contact the supplier.
• Remove all packaging, stickers and layers from the appliance before first use. Do not re-
move the rating plate. It can invalidate the guarantee.
• Fully obey the laws, ordinances, directives and standards in force in the country where
you use the appliance (safety regulations, recycling regulations, electrical or gas safety
rules etc.).
• Be careful when you move the appliance. The appliance is heavy. Always use safety
gloves. Do not pull the appliance by the handle.
• Make sure that the appliance is disconnected from the power supply during the installa-
tion (if applicable).
• Keep the minimum distances to the other appliances and units.
• Do not put the appliance on a base.
4Safety information

Electrical connection
• Only an approved electrician can install and connect the appliance. Contact an approved
service centre. This is to prevent the risks of structural damage or physical injury.
• The appliance must be earthed.
• Make sure that the electrical data on the rating plate agree with your domestic power
supply.
• Information on the voltage is on the rating plate.
• You must have the correct isolation devices: line protecting cut-outs, fuses (screw type
fuses removed from the holder), earth leakage trips and contactors.
• The electrical installation must have an isolation device which lets you disconnect the
appliance from the mains at all poles. The isolation device must have a contact opening
width of minimum 3 mm.
• The shock protection parts must be fixed in such a way that they cannot be undone
without tools.
• Always use a correctly installed shockproof socket.
• When you connect electrical appliances to mains sockets, do not let cables touch or
come near the hot appliance door.
• Do not use multi-way plugs, connectors and extension cables. There is a risk of fire.
• Make sure not to squash or cause damage to the mains plug (if applicable) and cable
behind the appliance.
• Make sure that the mains connection is accessible after the installation.
• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug (if
applicable).
• Do not replace or change the mains cable. Contact the service centre.
Use
• Only use the appliance for domestic cooking tasks. Do not use the appliance for commer-
cial and industrial use. This is to prevent physical injury to persons or prevent damage to
property.
• Always monitor the appliance during operation.
• Always stay away from the appliance when you open the door while the appliance is in
operation. Hot steam can release. There is a risk of burns.
• Do not use this appliance if it is in contact with water. Do not operate the appliance with
wet hands.
• Do not use the appliance as a work surface or storage surface.
• The cooking surface of the appliance becomes hot during use. There is a risk of burns. Do
not put metallic objects, for example cutlery or saucepans lids, on the surface, as they
can become hot.
• The interior of the appliance becomes hot during use. There is a risk of burns. Use gloves
when you insert or remove the accessories or pots.
• Open the door carefully. The use of ingredients with alcohol can cause a mixture of alco-
hol and air. There is the risk of fire.
• Do not let sparks or open flames come near the appliance when you open the door.
Safety information 5

• Do not put flammable products or items that are wet with flammable products, and/or
fusible objects (made of plastic or aluminium) in, near or on the appliance. There is a risk
of explosion or fire.
• Set the cooking zones to "off" after each use.
• Do not use the cooking zones with empty cookware or without cookware
• Do not let cookware boil dry. This can cause damage to the cookware and hob surface.
• If an object or cookware falls on the hob surface, the surface can be damaged.
• Do not put hot cookware near to the control panel because the heat can cause a damage
to the appliance.
• Be careful when you remove or install the accessories to prevent damage to the appli-
ance enamel.
• Cookware made of cast iron, cast aluminium or with damaged bottoms can scratch the
hob surface if you move them on the surface.
• Discoloration of the enamel has no effect on the performance of the appliance.
• To prevent damage or discoloration to the enamel:
– do not put any objects directly on the appliance floor and do not cover it with alumi-
nium foil;
– do not put hot water directly into the appliance;
– do not keep moist dishes and food in the appliance after you finish the cooking.
• Do not apply pressure on the open door.
• Do not put flammable materials in the compartment below the oven. Keep there only
heat-resistant accessories (if applicable).
• Do not cover oven steam outlets. They are at the rear side of the top surface (if applica-
ble).
• If there is a crack on the surface, disconnect the power supply. There is a risk of electric
shock.
• Do not put heat-conducting materials (e.g. thin metal mesh or metal-plated heat con-
ductors) under the cookware. Excessive heat reflection can damage the cooking surface.
• Do not use the appliance during a power cut.
Care and cleaning
• Before maintenance, make sure that the appliance is cold. There is a risk of burns. There
is a risk that the glass panels can break.
• Keep the appliance clean at all times. A build-up of fats or other foodstuff can result in a
fire.
• Regular cleaning prevents the surface material from deteriorating.
• For your personal safety and the safety of your property, only clean the appliance with
water and soap. Do not use flammable products or products that can cause corrosion.
• Do not clean the appliance with steam cleaners, high-pressure cleaners, sharp objects,
abrasive cleaning agents, abrasive sponges and stain removers.
• If you use an oven spray, follow the instructions from the manufacturer. Do not spray
anything on the heating elements and the thermostat sensor (if applicable).
6Safety information

• Do not clean the glass door with abrasive cleaning agents or metal scraper. Heat resist-
ant surface of the inner glass can break and shatter.
• When the door glass panels are damaged they become weak and can break. You must
replace them. Contact the service centre.
• Be careful when you remove the door from the appliance. The door is heavy.
• Bulb lamps used in this appliance are special lamps selected for household appliances use
only. They cannot be used for the full or partial illumination of a household room.
• If it becomes necessary to replace the lamp use one of the same power and specifically
designed for household appliances only.
• Disconnect the appliance from the power supply before the replacement of the oven
lamp. There is the risk of electrical shock. Cool down the appliance. There is a risk of
burns.
• Do not clean catalytic enamel.
Service centre
• Only an approved engineer can repair or work on the appliance. Contact an approved
service centre.
• Use only original spare parts.
Disposal of the appliance
• To prevent the risk of physical injury or damage:
– Disconnect the appliance from the power supply.
– Cut off the mains cable and discard it.
– Discard the door catch. This prevents children or small animals from being closed in-
side of the appliance. There is a risk of suffocation.
PRODUCT DESCRIPTION
General overview
1
5
2
6
2
3
5
7
1
2
33
4
4
1
2
3
4
5
7
Product description 7

1Hob
2Grill
3Oven lamp
4Shelf support
5Bottom heat
6Fan and heating element
7Shelf positions
Cooking surface layout
145
mm
180
mm
120/180
mm
120/175/210
mm 4
67
1 32
5
1Cooking zone 1200 W
2Steam outlet
3Cooking zone 700/1700 W
4Cooking zone 1800 W
5Oven control panel
6Hob control panel
7Cooking zone 800/1600/2300 W
Accessories
•Oven shelf
For cookware, cake tins, roasts.
•Deep roasting pan
To bake and roast or as pan to collect fat.
•The roasting pan grid
To put in the deep roasting pan.
BEFORE FIRST USE
WARNING!
Refer to "Safety information" chapter.
Initial Cleaning
• Remove all parts from the appliance.
• Clean the appliance before first use.
CAUTION!
Do not use abrasive cleaning agents! This can damage the surface. Refer to chapter "Care
and Cleaning".
8Before first use

Setting the time
The oven only operates after time set.
When you connect the appliance to the electrical supply or in case of a power cut, the Time
function indicator flashes automatically.
To set the current time use or button.
After approximately 5 seconds, the flashing stops and the display shows the time of day set.
You can only change the Time of day if :
• the switch-on lock is not on
• none of the clock functions Duration or End is set
• no oven function is set.
Pre-heating
1. Set function and maximum temperature.
2. Let the appliance operate without the food for approximately 1 hour.
3. Set function and maximum temperature.
4. Let the appliance operate without the food for approximately 10 minutes.
5. Set function and maximum temperature.
6. Let the appliance operate without the food for approximately 10 minutes.
This is to burn off the residue in the appliance. The accessories can become more hot than
usually. When you pre-heat the appliance for the first time, the appliance can make an
odour and smoke. This is the usual effect. Make sure the airflow is sufficient.
HOB - DAILY USE
WARNING!
Refer to "Safety information" chapter.
Control panel layout
1 2 73 4 5 6
891011
Hob - Daily Use 9

Use the sensor fields to operate the appliance. Indicators, displays and sounds tell which
functions operate.
sensor field function
1
starts and stops the hob
2
locks/unlocks the control panel
3
a heat setting display shows the heat setting
4
cooking zones' indicators of timer show for which zone you set the time
5
the timer display shows the time in minutes
6
/ increase or decrease heat setting
7
starts and stops the outer ring
8
/ increase or decrease the time
9
selects the cooking zone
10
starts and stops the outer rings
11
starts and stops STOP+GO
The heat setting
Touch to increase the heat setting. Touch to decrease the heat setting. The display
shows the heat setting. Touch and at the same time to switch off the cooking zone.
Heat setting displays
Display Description
The cooking zone is off
- The cooking zone operates
Keep Warm / function is on
The automatic heat-up function is on
There is a malfunction
A cooking zone is still hot (residual heat)
Lock/Child safety function is on
The automatic switch off is active
On and Off
Touch for 2 seconds to start the appliance. Touch for 1 second to stop the appliance.
/ Switching the outer rings on and off
You can match the effective heating surface to the size of the cookware.
To switch on the outer ring touch the sensor field / . The indicator comes on. For
more outer rings touch the same sensor field again. The next indicator comes on.
Do the procedure again to switch off the outer ring. The indicator goes out.
10 Hob - Daily Use

Timer
Use the timer to set how long the cooking zone operates for one cooking session.
Set the timer after the selection of the cooking zone.
You can set the heat setting before or after you set the timer.
•Selection of the cooking zone:touch again and again until the indicator of a neces-
sary cooking zone comes on.
•Starting or changing the timer: touch or of the timer to set the time (
00
-
99
minutes). When the indicator of the cooking zone flashes slower, the time counts down.
•Stopping the timer: select the cooking zone with and touch to switch off the
timer. The remaining time counts backwards to
00
. The indicator of the cooking zone
goes out.
•Checking the remaining time: select the cooking zone with . The indicator of the
cooking zone flashes faster. Display shows the remaining time.
When the time elapses, the sound operates and
00
flashes. The cooking zone switches off.
•Stopping the sound: touch
You can use the timer as a minute minder while cooking zones do not operate. Touch .
Touch or to select the time. When the time elapses, the sound operates and
00
flashes
Starting the STOP+GO
The function sets all cooking zones that operate to a keep warm setting.
•Touch to start this function. The symbol comes on.
•Touch to stop this function. The heat setting that you set before comes on.
does not stop the timer function.
locks the control bars.
Locking / unlocking the control panel
You can lock the control panel, but not . It prevents an accidental change of the heat
setting during a cooking session.
First set the heat setting.
Touch the symbol . The symbol comes on for 4 seconds.
The Timer still operates.
Touch the symbol to switch off this function. The heat setting that you set before comes
on.
When you switch off the appliance, you also switch off this function.
When you activate the appliance, SAFE shows up in the oven display.
The locking / unlocking function locks or unlocks the oven interface at the same time.
Residual heat indicator
The residual heat indicator comes on when a cooking zone is hot.
WARNING!
Risk of burns from residual heat!
Hob - Daily Use 11

The child safety device
This function prevents an accidental operation of the hob and oven.
Starting the child safety device
• Start the hob with . Do not set the heat settings.
• Touch for 4 seconds. Acoustic signal appears. The symbol comes on the hob and
the symbol "SAFE"on the oven display.
• Stop the hob with .
Switching off the child safety device
• Start the hob with . Do not set the heat settings. Touch for 4 seconds. Acoustic
signal appears. The symbol comes on the hob and the symbol "SAFE" goes out of the
oven display.
• Stop the hob with .
The child safety device function locks the hob and oven at this same time.
Automatic Switch Off
The function stops the hob automatically if:
• all cooking zones are off .
• you do not set the heat setting after you start the hob.
• you cover a sensor field with an object (a pan, a cloth, etc.) for longer than 10 seconds.
The sound operates until you remove the object.
• the hob gets too hot (e.g. when a saucepan boils dry). Before you use the hob again, the
cooking zone must be cool.
• you use incorrect cookware. comes on in the display and after 2 minutes the cooking
zone stops automatically.
• you do not stop a cooking zone or change the heat setting. After some time comes on
and the hob stops. See the table.
Automatic Switch Off times
Heat setting - - -
Stops after 6 hours 5 hours 4 hours 1.5 hours
HOB - HELPFUL HINTS AND TIPS
WARNING!
Refer to "Safety information" chapter.
Cookware
• The bottom of the cookware must be as thick and flat as possible.
• Cookware made of enamelled steel and with aluminium or copper bottoms can cause
discoloration on glass ceramic surface.
12 Hob - Helpful hints and tips

Energy saving
• If it is possible, always put the lids on the cookware.
• Put cookware on a cooking zone before you start it.
• Stop the cooking zones before the end of the cooking time to use residual heat.
• The bottom of pans and cooking zones must have the same dimension.
Examples of cooking applications
The data in the table is for guidance only.
Heat
setting
Use to: Time Hints
1 Keep cooked foods warm as re-
quired
Cover
1-2 Hollandaise sauce, melt: butter, choco-
late, gelatine
5-25
min
Mix occasionally
1-2 Solidify: fluffy omelettes, baked eggs 10-40
min
Cook with a lid on
2-3 Simmer rice and milkbased dishes, heat-
ing up ready-cooked meals
25-50
min
Add at least twice as much liquid as
rice, stir milk dishes part way
through
3-4 Steam vegetables, fish, meat 20-45
min
Add a few tablespoons of liquid
4-5 Steam potatoes 20-60
min
Use max. ¼ l water for 750 g of po-
tatoes
4-5 Cook larger quantities of food, stews
and soups
60-150
min
Up to 3 l liquid plus ingredients
6-7 Gentle fry: escalope, veal cordon bleu,
cutlets, rissoles, sausages, liver, roux,
eggs, pancakes, doughnuts
as re-
quired
Turn halfway through
7-8 Heavy fry, hash browns, loin steaks,
steaks
5-15
min
Turn halfway through
9Boil large quantities of water, cook pasta, sear meat (goulash, pot roast), deep fry chips
HOB - CARE AND CLEANING
WARNING!
Refer to "Safety information" chapter.
Clean the appliance after each use.
Always use cookware with clean bottom.
Scratches or dark stains on the glass ceramic have no effect on how the appliance operates.
Hob - Care and Cleaning 13

To remove the dirt:
1. – Remove immediately:melted plastic, plastic foil, and food with sugar. If not, the dirt
can cause damage to the appliance. Use a special scraper for the glass . Put the
scraper on the glass surface at an acute angle and move the blade on the surface .
–Remove after the appliance is sufficiently cool:limescale rings , water rings, fat
stains, shiny metallic discolorations. Use a special cleaning agent for glass ceramic
or stainless steel.
2. Clean the appliance with a moist cloth and some detergent.
3. At the end rub the appliance dry with a clean cloth.
OVEN - CONTROL PANEL
Control panel
2 3 5 6
1
4
Number Button Function Description
1
–Display To show the current settings of the oven.
2
On/Off To activate or deactivate the oven.
3
Oven selection To switch between top and main oven.
4
Down,Up To set an oven function or programme.
5
Selection/Clock
function
To move between the oven functions and clock func-
tions.
6
Setting buttons To set the temperature and time.
Indicators of display
21 5 6 43 7 8
14 Oven - Control panel

Number Name Description
1
Top/Main oven indicator Shows which oven operates.
2
Oven function indicator Shows the function.
3
Lamp/Defrost indicator Shows the Lamp/Defrost function is active.
4
Heat indicator Shows the heat setting.
5
Temperature/Clock indi-
cator
Shows the temperature and the time in minutes.
6
Keep warm indicator Shows that keep warm function is active.
7
Cooking time/End time/
Period of operation
Shows the time setting for clock functions.
8
Clock function indicator To set the clock function and minute minder.
OVEN - DAILY USE
WARNING!
Refer to "Safety information" chapter.
Switching the appliance on and off
Press the On/Off button to switch the appliance on or off.
Top oven functions
Oven function Application
Conventional To bake and roast on one oven level.
Browning To brown.
Base Heat To bake cakes with crispy or crusty bases. To preserve
food.
Dual Grill To toast or grill flat food in large quantities.
Light To light up the oven interior.
Main oven functions
Oven function Application
True Fan To bake on 3 oven levels maximum at the same time.
Set the oven temperatures 20-40 °C lower than for
Conventional.
Oven - Daily Use 15

Oven function Application
Conventional To bake and roast on one oven level.
Pizza Setting To bake on one oven level with a more intensive
browning and a crispy base. Set the oven tempera-
tures 20-40 °C lower than when using Conventional.
Low temperature cook-
ing
To prepare very lean, tender roasted food.
Rotitherm To roast larger joints of meat or poultry on one shelf
position. To brown.
Dual Grill To grill flat food in large quantities. To toast bread.
Keep Warm To keep food warm.
Drying To dry food.
Defrost To defrost frozen food.
Light To light up the oven interior.
Selecting an oven
1. Switch on the appliance using the On/Off button.
2. Press the button repeatedly until the desired oven appears (Top / Main )
Setting the oven function
Use to set the oven function.
The display shows the recommended temperature.
If you do not change this temperature in less than approximately 5 seconds, the appliance
starts to heat.
When the appliance operates at the set temperature, an acoustic signal sounds.
You can change the oven function while the oven operates.
Changing the oven temperature
Use or to set the temperature.
Switching off an oven function
Press the oven function selection buttons or repeatedly until no oven function
shows in the display.
16 Oven - Daily Use

Heat- up indicator
If you switch on an oven function, the bars on the display come on one by one. The bars
show that the oven temperature increases.
Residual heat indicator
When you switch off the oven, the bars on the display show the residual heat.
OVEN - CLOCK FUNCTIONS
Clock functions
1
7 6 5
2 3 4
1Time of day
2Duration
3End
4Minute Minder
5Setting button (Plus)
6Setting button (Minus)
7Selection button
SYMBOL FUNCTION DESCRIPTION
Minute Minder To set a countdown (max. 99 minutes). This function has no
effect on the operation of the appliance.
Duration To set how long the appliance has to be in operation.
End To set the switch-off time for an oven function.
You can use Duration and End at the same time, if the ap-
pliance is to be switched on and off automatically later.
Time of day To set, change or control the time of day.
• If you set a clock function, the symbol flashes for approximately 5 seconds. In these 5
seconds, touch or to set the time.
• If you set the time, the symbol continues to flash for approximately 5 seconds. After
these 5 seconds, the symbol comes on. The time starts to count down.
Setting the clock functions
1. Switch on the appliance.
2. Use again and again until the display shows the necessary clock function and the
related symbol, for example Minute Minder .
3. Use or to set the necessary time.
Oven - Clock functions 17

You can hear an acoustic signal for 2 minutes when the time is completed, “00.00” and
the related function indicator flash. The appliance switches off.
4. Use any button to switch off the acoustic signal.
With Minute Minder the oven must be switched on to set the clock function.
With Duration and End the oven switches off automatically.
With Duration and End you must set the oven function and the temperature first,
then you can set the clock function.
Heat+Hold
To keep the prepared food warm for 30 minutes, after the cooking is completed.
Switching on Heat+Hold
1. Set clock functions Duration and/or End .
2. Use Selection again and again, until the display shows the symbol Keep warm
.
3. Use , the display shows “00:30”
4. When the set oven function is completed, a signal sounds and Heat+Hold starts. The
set oven function operates at 80°C for 30 minutes. The oven then switches off auto-
matically.
The temperature for the set oven function must be above 80°C.
OVEN - ADDITIONAL FUNCTIONS
Cooling fan
When the appliance operates, the cooling fan switches on automatically to keep the surfa-
ces of the appliance cool. If you switch off the appliance, the cooling fan continues to op-
erate until the appliance cools down.
The child safety device
Refer to "Hob - Daily Use" chapter and "The child safety device" section.
Automatic cut-out
The appliance switches off after some time:
• if you do not switch off the appliance;
• if you do not change the oven temperature.
The last temperature set flashes in the temperature display.
Oven temperature Switch-off time
30 °C -120 °C 12.5 h.
120 °C - 200 °C 8.5 h.
200 °C -250 °C 5.5 h.
18 Oven - Additional functions

Oven temperature Switch-off time
250 °C -maximum °C 3.0 h.
After an automatic cut-out, switch off the oven fully. Then you can switch it on again.
If you set the clock function Duration or End , the automatic cut-out switches off.
OVEN - USING THE ACCESSORIES
WARNING!
Refer to "Safety information" chapter.
Inserting the Oven Accessories
Put in the slide-in accessories so that the double side edges are at the back of the oven and
point down to the bottom. Push the slide-in accessories between the guide-bars of one of
the oven levels.
The deep roasting pan and the oven shelf have
double side edges. These edges and the shape of
the guide-bars causes the anti-tilt safety for the
oven accessories.
Inserting the oven shelf and deep roasting pan
together
Put the oven shelf on the deep roasting pan. Push
the deep roasting pan between the guide-bars of
one of the oven levels.
Grilling set
The grilling set includes the roasting pan grid and the deep roasting pan.
You can use the roasting pan grid in two positions: turned up and down.
Oven - Using the accessories 19

To roast larger pieces of meat or poultry on one level:
1. Put the roasting pan grid in the deep
roasting pan. The supports of the roast-
ing pan grid must point up.
2. Put the deep roasting pan in the appli-
ance, on the necessary shelf level.
To grill flat dishes in large quantities and to toast:
1. Put the roasting pan grid in the deep
roasting pan. The supports of the roast-
ing pan grid must point down.
2. Put the deep roasting pan in the appli-
ance, on the necessary shelf level.
OVEN - HELPFUL HINTS AND TIPS
WARNING!
Refer to "Safety information" chapter.
The temperature and baking times in the tables are guidelines only. They depend on the
recipes, quality and quantity of the ingredients used.
CAUTION!
Use a deep baking tray for very moist cakes. Fruit juices can cause permanent stains on the
enamel.
Top oven
The top oven is the smaller of the two ovens. It has 3 shelf levels. Use is to cook smaller
quantities of food. It gives especially good results when used to cook fruitcakes, sweets and
savoury flants or quiche.
20 Oven - Helpful hints and tips
