AEG BCE558070M User manual

USER
MANUAL
EN User Manual
Oven
BCE558070M
BCK558270M

FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler – features
you might not find on ordinary appliances. Please spend a few minutes reading to get the very
best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
For more recipes, hints, troubleshooting download My AEG Kitchen app.
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
CONTENTS
1. SAFETY INFORMATION............................. 3
1.1 Children and vulnerable people
safety..................................................... 3
1.2 General Safety.................................4
2. SAFETY INSTRUCTIONS........................... 5
2.1 Installation........................................5
2.2 Electrical connection........................6
2.3 Use.................................................. 6
2.4 Care and cleaning............................7
2.5 Internal lighting................................ 7
2.6 Service.............................................8
2.7 Disposal........................................... 8
3. PRODUCT DESCRIPTION.......................... 8
3.1 General overview.............................8
3.2 Accessories..................................... 9
4. HOW TO TURN OVEN ON AND OFF......... 9
4.1 Control panel................................... 9
5. BEFORE FIRST USE.................................10
5.1 Initial cleaning................................ 11
5.2 Initial preheating............................ 11
5.3 Wireless connection ..................11
5.4 Software licences...........................12
6. DAILY USE................................................ 12
6.1 How to set: Heating functions........ 12
6.2 Heating functions........................... 13
6.3 Notes on: Moist Fan Baking...........15
6.4 How to set: Assisted Cooking........ 15
6.5 Assisted Cooking with recipes....... 16
7. CLOCK FUNCTIONS.................................21
7.1 Clock functions.............................. 21
7.2 How to set: Clock functions........... 21
2/40

8. HOW TO USE: ACCESSORIES................ 22
8.1 Inserting accessories..................... 23
8.2 Using Trivet and Grill- /
Roasting pan........................................23
8.3 Food Sensor.................................. 24
9. ADDITIONAL FUNCTIONS....................... 25
9.1 Lock............................................... 26
9.2 Automatic switch-off.......................26
9.3 Cooling fan.....................................26
10. HINTS AND TIPS..................................... 26
10.1 Moist Fan Baking......................... 26
10.2 Moist Fan Baking -
recommended accessories..................27
10.3 Cooking tables for test institutes..27
11. CARE AND CLEANING...........................29
11.1 Notes on cleaning........................ 30
11.2 How to clean: Cavity
embossment........................................ 30
11.3 How to remove: Shelf supports ...30
11.4 How to use: Catalytic cleaning ....31
11.5 How to remove and install: Door..31
11.6 How to replace: Lamp..................32
12. TROUBLESHOOTING............................. 33
12.1 What to do if.................................33
12.2 Service data.................................34
13. ENERGY EFFICIENCY............................ 35
13.1 Product Information and Product
Information Sheet*............................... 35
13.2 Energy saving.............................. 36
14. MENU STRUCTURE................................36
14.1 Menu............................................36
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
1.1 Children and vulnerable people safety
•Children should be supervised to ensure that they do not
play with the appliance and mobile devices with My AEG
Kitchen.
•Keep all packaging away from children and dispose of it
appropriately.
•WARNING: Keep children and pets away from the appliance
when it operates or when it cools down. Accessible parts
become hot during use.
•If the appliance has a child safety device, it should be
activated.
3/40
SAFETY INFORMATION

•Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
1.2 General Safety
•Only a qualified person must install this appliance and
replace the cable.
•Do not use the appliance before installing it in the built-in
structure.
•Disconnect the appliance from the power supply before
carrying out any maintenance.
•If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service Centre
or similarly qualified persons to avoid an electrical hazard.
•The means for disconnection must be incorporated in the
fixed wiring in accordance with the wiring rules.
•WARNING: Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric shock.
•WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements.
•Always use oven gloves to remove or put in accessories or
ovenware.
•Use only the food sensor (core temperature sensor)
recommended for this appliance.
•To remove the shelf supports first pull the front of the shelf
support and then the rear end away from the side walls.
Install the shelf supports in the opposite sequence.
•Do not use a steam cleaner to clean the appliance.
•Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the glass door since they can scratch the surface,
which may result in shattering of the glass.
4/40
SAFETY INFORMATION

2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must install this appliance.
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Follow the installation instructions supplied with the appliance.
• Always take care when moving the appliance as it is heavy. Always use safety gloves and
enclosed footwear.
• Do not pull the appliance by the handle.
• Install the appliance in a safe and suitable place that meets installation requirements.
• Keep the minimum distance from other appliances and units.
• Before mounting the appliance, check if the oven door opens without restraint.
• The appliance is equipped with an electric cooling system. It must be operated with the
electric power supply.
Cabinet minimum height (Cabinet under the work‐
top minimum height)
578 (600) mm
Cabinet width 560 mm
Cabinet depth 550 (550) mm
Height of the front of the appliance 594 mm
Height of the back of the appliance 576 mm
Width of the front of the appliance 595 mm
Width of the back of the appliance 559 mm
Depth of the appliance 567 mm
Built in depth of the appliance 546 mm
Depth with open door 1027 mm
Ventilation opening minimum size. Opening placed
on the bottom rear side
560 x 20 mm
Mounting screws 4 x 25 mm
5/40
SAFETY INSTRUCTIONS

2.2 Electrical connection
WARNING!
Risk of fire and electric shock.
• All electrical connections should be made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the rating plate are compatible with the electrical ratings
of the mains power supply.
• Always use a correctly installed shockproof socket.
• Do not use multi-plug adapters and extension cables.
• Make sure not to cause damage to the mains plug and to the mains cable. Should the mains
cable need to be replaced, this must be carried out by our Authorised Service Centre.
• Do not let mains cables touch or come near the appliance door or the niche below the
appliance, especially when it operates or the door is hot.
• The shock protection of live and insulated parts must be fastened in such a way that it
cannot be removed without tools.
• Connect the mains plug to the mains socket only at the end of the installation. Make sure
that there is access to the mains plug after the installation.
• If the mains socket is loose, do not connect the mains plug.
• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.
• Use only correct isolation devices: line protecting cut-outs, fuses (screw type fuses removed
from the holder), earth leakage trips and contactors.
• The electrical installation must have an isolation device which lets you disconnect the
appliance from the mains at all poles. The isolation device must have a contact opening
width of minimum 3 mm.
• This appliance is supplied without a main plug and a main cable.
2.3 Use
WARNING!
Risk of injury, burns and electric shock or explosion.
• This appliance is for household (indoors) use only.
• Do not change the specification of this appliance.
• Make sure that the ventilation openings are not blocked.
• Do not let the appliance stay unattended during operation.
• Deactivate the appliance after each use.
• Be careful when you open the appliance door while the appliance is in operation. Hot air can
release.
• Do not operate the appliance with wet hands or when it has contact with water.
• Do not apply pressure on the open door.
• Do not use the appliance as a work surface or as a storage surface.
• Open the appliance door carefully. The use of ingredients with alcohol can cause a mixture
of alcohol and air.
• Do not let sparks or open flames to come in contact with the appliance when you open the
door.
• Do not put flammable products or items that are wet with flammable products in, near or on
the appliance.
• Do not share your Wi-Fi password.
6/40
SAFETY INSTRUCTIONS

WARNING!
Risk of damage to the appliance.
• To prevent damage or discoloration to the enamel:
– do not put ovenware or other objects in the appliance directly on the bottom.
– do not put aluminium foil directly on the bottom of cavity of the appliance.
– do not put water directly into the hot appliance.
– do not keep moist dishes and food in the appliance after you finish the cooking.
– be careful when you remove or install the accessories.
• Discoloration of the enamel or stainless steel has no effect on the performance of the
appliance.
• Use a deep pan for moist cakes. Fruit juices cause stains that can be permanent.
• This appliance is for cooking purposes only. It must not be used for other purposes, for
example room heating.
• Always cook with the oven door closed.
• If the appliance is installed behind a furniture panel (e.g. a door) make sure the door is never
closed when the appliance operates. Heat and moisture can build up behind a closed
furniture panel and cause subsequent damage to the appliance, the housing unit or the floor.
Do not close the furniture panel until the appliance has cooled down completely after use.
2.4 Care and cleaning
WARNING!
Risk of injury, fire, or damage to the appliance.
• Before maintenance, deactivate the appliance and disconnect the mains plug from the mains
socket.
• Make sure the appliance is cold. There is the risk that the glass panels can break.
• Replace immediately the door glass panels when they are damaged. Contact the Authorised
Service Centre.
• Be careful when you remove the door from the appliance. The door is heavy!
• Clean regularly the appliance to prevent the deterioration of the surface material.
• Clean the appliance with a moist soft cloth. Use only neutral detergents. Do not use abrasive
products, abrasive cleaning pads, solvents or metal objects.
• If you use an oven spray, follow the safety instructions on its packaging.
• Do not clean the catalytic enamel with detergents.
2.5 Internal lighting
WARNING!
Risk of electric shock.
• Concerning the lamp(s) inside this product and spare part lamps sold separately: These
lamps are intended to withstand extreme physical conditions in household appliances, such
as temperature, vibration, humidity, or are intended to signal information about the
operational status of the appliance. They are not intended to be used in other applications
and are not suitable for household room illumination.
• Use only lamps with the same specifications.
7/40
SAFETY INSTRUCTIONS

2.6 Service
• To repair the appliance contact the Authorised Service Centre.
• Use original spare parts only.
2.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the mains supply.
• Cut off the mains electrical cable close to the appliance and dispose of it.
• Remove the door catch to prevent children or pets from becoming trapped in the appliance.
3. PRODUCT DESCRIPTION
3.1 General overview
1
2
3
4
5
2 4
5
11 8
6
7
31
9
10
1Control panel
2Knob for the heating functions
3Display
4Control knob
5Socket for the food sensor
6Heating element
7Lamp
8Fan
9Shelf support, removable
10 Cavity embossment
11 Shelf positions
8/40
PRODUCT DESCRIPTION

3.2 Accessories
Wire shelf
For cookware, cake tins, roasts.
Grill- / Roasting pan
To bake and roast or as a pan to collect fat.
Trivet
For roasting and grilling.
Use the trivet only with the Grill- / Roasting pan.
Food sensor
To measure the temperature inside food.
4. HOW TO TURN OVEN ON AND OFF
4.1 Control panel
Control panel sensor fields Press Turn the knob
Timer Fast Heat
Up Light Food Sensor
Select a heating function to turn on the oven.
Turn the knob for the heating functions to the off position to turn the oven off.
9/40
HOW TO TURN OVEN ON AND OFF

When the knob for the heating functions is in
the off position, the display goes to standby.
When you cook, the display shows the set tem‐
perature, time of day and other available op‐
tions.
The display with the maximum number of func‐
tions set.
Display indicators
Lock Assisted Cook‐
ing
Cleaning Settings Fast Heat Up
Timer indi‐
cators:
Wi-Fi indicator - flashes when the oven can be
connected to Wi-Fi.
Remote operation indicator - the oven
can be controlled remotely.
Wi-Fi connection is turned on. Remote operation is turned on.
Progress bar - for temperature or time.
Steam cooking indicator
Food sensor indicator
10/40
BEFORE FIRST USE

5. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
5.1 Initial cleaning
Before the first use clean the empty oven and set the time:
00:00
Set the time. Press .
5.2 Initial preheating
Preheat the empty oven before the first use.
Step 1 Remove all accessories and removable shelf supports from the oven.
Step 2 Set the maximum temperature for the function: .
Let the oven operate for 1 h.
Step 3 Set the maximum temperature for the function: .
Let the oven operate for 15 min.
The oven can emit an odour and smoke during preheating. Make sure that the room is ventila‐
ted.
5.3 Wireless connection
To connect the oven you need:
• Wireless network with the Internet connection.
• Mobile device connected to your wireless network.
Step 1 Download the mobile app My AEG Kitchen and follow the instructions for the next
steps.
Step 2 Turn the knob to select: .
11/40
BEFORE FIRST USE

Frequency 2.4 GHz WLAN 5 GHz WLAN
2400 - 2483.5 MHz 5150 - 5350 MHz
5470 - 5725 MHz
Protocol IEEE 802.11b DSSS,
802.11g/n OFDM
IEEE 802.11 a/n OFDM
Max Power EIRP < 20 dBm (100 mW) EIRP < 23 dBm (200 mW)
Wi-Fi module NIU5-50
Frequency Bluetooth 2400 - 2483.5 MHz
Protocol LE: DSSS
Max Power EIRP < 4 dBm (2.5 mW)
EU member states covered by the provision of Directive 2014/53/EU: Belgium, Bulgaria, Czech
Republic, Denmark, Germany, Estonia, Ireland, Greece, Spain, France, Croatia, Italy, Cyprus,
Latvia, Lithuania, Luxemburg, Hungary, Malta, Netherlands, Austria, Poland, Portugal,
Romania, Slovenia, Slovakia, Finland, Sweden, Norway, Switzerland, United Kingdom, Turkey.
5.4 Software licences
The software in this product contains components that are based on free and open source soft‐
ware. AEG gratefully acknowledges the contributions of the open software and robotics communi‐
ties to the development project.
To access the source code of these free and open source software components whose license
conditions require publishing, and to see their full copyright information and applicable license
terms, please visit: http://aeg.opensoftwarerepository.com (folder NIU5).
6. DAILY USE
WARNING!
Refer to Safety chapters.
6.1 How to set: Heating functions
Start cooking
Step 1 Step 2
12/40
DAILY USE

Start cooking
Set a heating function. Set the temperature.
Steam cooking
Make sure that the oven is cold.
Step 1 Step 2 Step 3 Step 4
Preheat the empty
oven for 10 min to
create humidity.
Put food in the
oven.
Fill the cavity embossment with tap
water.
Set the steam
heating func‐
tion.
Set the tem‐
perature.
The maximum capacity of the cavity embossment is 250 ml. Do not refill the cavity emboss‐
ment during cooking or when the oven is hot.
When the steam cooking ends:
Step 1 Step 2 Step 3
Turn the knob for the heating
functions to the off position to
turn off the oven.
Carefully open the door. Re‐
leased humidity can cause
burns.
Make sure that the oven is
cold. Remove the remaining
water from the cavity em‐
bossment.
6.2 Heating functions
13/40
DAILY USE

Standard heating functions
Heating function Application
True Fan Cooking
To bake on up to three shelf positions at the same time and to dry food.
Set the temperature 20 - 40 °C lower than for Conventional Cooking.
Conventional
Cooking
To bake and roast food on one shelf position.
SteamBake
To add humidity during the cooking. To get the right colour and crispy
crust during baking. To give more juiciness during reheating. To preserve
fruit or vegetables.
Pizza Function
To bake pizza. To make intensive browning and a crispy bottom.
Bottom Heat
To bake cakes with crispy bottom and to preserve food.
Frozen Foods
To make convenience food (e.g., french fries, potato wedges or spring
rolls) crispy.
Moist Fan Baking
This function is designed to save energy during cooking. When you use
this function, the temperature in the cavity may differ from the set temper‐
ature. The residual heat is used. The heating power may be reduced. For
more information refer to "Daily Use" chapter, Notes on: Moist Fan Bak‐
ing.
Grill
To grill thin pieces of food and to toast bread.
Turbo Grilling
To roast large meat joints or poultry with bones on one shelf position. To
make gratins and to brown.
14/40
DAILY USE

Heating function Application
Menu
To enter the Menu: Assisted Cooking, Cleaning, Settings.
6.3 Notes on: Moist Fan Baking
This function was used to comply with the energy efficiency class and ecodesign requirements
according to EU 65/2014 and EU 66/2014. Tests according to EN 60350-1.
The oven door should be closed during cooking so that the function is not interrupted and the
oven operates with the highest energy efficiency possible.
When you use this function the lamp automatically turns off after 30 sec.
For the cooking instructions refer to "Hints and tips" chapter, Moist Fan Baking. For general
energy saving recommendations refer to "Energy Efficiency" chapter, Energy Saving.
6.4 How to set: Assisted Cooking
Every dish in this submenu has a recommended function and temperature. You can adjust the
time and the temperature during cooking.
For some of the dishes you can also cook
with:
The degree to which a dish is cooked:
• Food Sensor • Rare
• Medium
• Well done
Assisted Cooking - use it to prepare a dish quickly with default settings:
Step 1 Step 2 Step 3 Step 4
1 - 45
Enter the menu. Select Assisted
Cooking. Press .
Select the dish. Press
.
Insert the dish to the
oven. Confirm setting.
15/40
DAILY USE

6.5 Assisted Cooking with recipes
Legend
Food sensor available. Place the Food sensor in the thickest part of the
dish.
The oven turns off when the set Food sensor temperature is reached.
The amount of water for the steam function.
Preheat the oven before you start cooking.
Shelf level.
When the function ends check if the food is ready.
Dish Weight Shelf level / Accessory Duration
time
Beef
P1 Roast Beef,
rare
1 - 1,5 kg; 4
- 5 cm thick
pieces
2; baking tray
Fry the meat for a few minutes on a hot
pan. Insert to the oven.
~ 40 min
P2 Roast Beef,
medium ~ 50 min
P3 Roast Beef,
well done ~ 60 min
P4 Steak, medi‐
um
180 - 220 g
per piece; 3
cm thick sli‐
ces
3; roasting dish on wire shelf
Fry the meat for a few minutes on a hot
pan. Insert to the oven.
~ 15 min
P5 Beef roast /
braised (prime
rib, top round,
thick flank)
1,5 - 2 kg 2; roasting dish on wire shelf
Fry the meat for a few minutes on a hot
pan. Add liquid. Insert to the oven.
~ 120 min
16/40
DAILY USE

Dish Weight Shelf level / Accessory Duration
time
P6 Roast Beef,
rare (slow
cooking)
1 - 1,5 kg; 4
- 5 cm thick
pieces
2; baking tray
Use your favourite spices or simply salt
and fresh grounded pepper. Fry the meat
for a few minutes on a hot pan. Insert to
the oven.
~ 75 min
P7 Roast Beef,
medium (slow
cooking)
~ 85 min
P8 Roast Beef,
well done
(slow cooking)
~ 130 min
P9 Fillet, rare
(slow cooking)
0,5 - 1,5 kg;
5 - 6 cm
thick pieces
2; baking tray
Use your favourite spices or simply salt
and fresh grounded pepper. Fry the meat
for a few minutes on a hot pan. Insert to
the oven.
~ 75 min
P10 Fillet, medium
(slow cooking) ~ 90 min
P11 Fillet, done
(slow cooking) ~ 120 min
Veal
P12 Veal roast
(e.g. shoulder)
0,8 - 1,5 kg;
4 cm thick
pieces
2; roasting dish on wire shelf
Use your favourite spices. Add liquid.
Roast covered.
~ 80 min
Pork
P13 Pork roast
neck or
shoulder
1,5 - 2 kg 2; roasting dish on wire shelf
Turn the meat after half of the cooking
time.
~ 120 min
P14 Pulled pork
LTC
1,5 - 2 kg 2; baking tray
Use your favourite spices. Turn the meat
after half of the cooking time to get an
even browning.
~ 215 min
P15 Loin, fresh 1 - 1,5 kg; 5
- 6 cm thick
pieces
2; roasting dish on wire shelf
Use your favourite spices.
~ 55 min
17/40
DAILY USE

Dish Weight Shelf level / Accessory Duration
time
P16 Spare Ribs 2 - 3 kg; use
raw, 2 - 3
cm thin
spare ribs
3; deep pan
Add liquid to cover the bottom of a dish.
Turn the meat after half of the cooking
time.
90 min
Lamb
P17 Lamb leg with
bones
1,5 - 2 kg; 7
- 9 cm thick
pieces
2; roasting dish on baking tray
Add liquid. Turn the meat after half of the
cooking time.
~ 130 min
Poultry
P18 Whole chick‐
en
1 - 1,5 kg;
fresh 2; 200 ml; casserole dish on
baking tray
Use your favourite spices. Turn the
chicken after half of the cooking time to
get an even browning.
~ 60 min
P19 Half chicken 0,5 - 0,8 kg 3 ; baking tray
Use your favourite spices.
~ 40 min
P20 Chicken
breast
180 - 200 g
per piece 2; casserole dish on wire
shelf
Use your favourite spices. Fry the meat
for a few minutes on a hot pan.
~ 25 min
P21 Chicken legs,
fresh
- 3; baking tray
If you marinated chicken legs first, set
lower temperature and cook them longer.
~ 30 min
P22 Duck, whole 2 - 3 kg 2; roasting dish on wire shelf
Use your favourite spices. Put the meat
on roasting dish. Turn the duck after half
of the cooking time.
~ 100 min
P23 Goose, whole 4 - 5 kg 2; deep pan
Use your favourite spices. Put the meat
on deep baking tray. Turn the goose af‐
ter half of the cooking time.
~ 110 min
18/40
DAILY USE

Dish Weight Shelf level / Accessory Duration
time
Other
P24 Meat loaf 1 kg 2; wire shelf
Use your favourite spices.
~ 60 min
Fish
P25 Whole fish,
grilled
0,5 - 1 kg
per fish 2 ; baking tray
Fill the fish with butter and use your fa‐
vourite spices and herbs.
~ 30 min
P26 Fish fillet - 3; casserole dish on wire shelf
Use your favourite spices.
20 min
Sweet baking / desserts
P27 Cheesecake - 2; 28 cm springform tin on wire
shelf
90 min
P28 Apple cake - 2; 100 - 150 ml; baking tray 60 min
P29 Apple tart - 2; pie form on wire shelf 40 min
P30 Apple pie - 2; 100 - 150 ml; 22 cm pie
form on wire shelf
60 min
P31 Brownies 2 kg 3; deep pan 30 min
P32 Chocolate
muffins
- 2; 100 - 150 ml; muffin tray on
wire shelf
30 min
P33 Loaf cake - 2; loaf pan on wire shelf 50 min
Vegetable / Side dishes
19/40
DAILY USE

Dish Weight Shelf level / Accessory Duration
time
P34 Baked pota‐
toes
1 kg 2; baking tray
Put the whole potatoes with skin on bak‐
ing tray.
50 min
P35 Wegdes 1 kg 3; baking tray lined with baking pa‐
per
Use your favourite spices. Cut potatoes
into pieces.
35 min
P36 Grilled mixed
vegetables
1 - 1,5 kg 3; baking tray lined with baking pa‐
per
Use your favourite spices. Cut the vege‐
tables into pieces.
30 min
P37 Croquets, fro‐
zen
0,5 kg 3; baking tray 25 min
P38 Pommes, fro‐
zen
0,75 kg 3; baking tray 25 min
Gratins, bread and pizza
P39 Lasagna /
Noodle cas‐
serole
1 - 1,5 kg 2; casserole dish on wire shelf 45 min
P40 Potato gratin 1 - 1,5 kg 1; casserole dish on wire shelf 50 min
P41 Pizza fresh,
thin - 2; 100 ml; baking tray lined
with baking paper 15 min
P42 Pizza fresh,
thick - 2; 100 ml; baking tray lined
with baking paper 25 min
P43 Quiche - 2; baking tin on wire shelf 45 min
P44 Baguette /
Ciabatta /
White bread
0,8 kg 3; 150 ml; baking tray lined
with baking paper
More time needed for white bread.
30 min
20/40
DAILY USE
