AEG BP730410MM User manual

BP730410MM
24” Built-in Multi-function Oven

Specifications are subject to change without notice
V1.2
BP730410MM
24” Built-in Multi-function Oven
•Grill/roasting pan
•Baking tray
•Meat Temperature Probe
•2 chrome oven racks : 183/8” W x 153/16” D
•Optional full extension telescopic rails (TR3LFTV
OVEN ACCESSORIES
OVEN FEATURES
•MaxiKlasse™ 74L (2.61 cu. ft) capacity
•ThermiC° hot air cooking technology for perfect
cooking
•Isoftont® Triple glazed glass door
•SoftMotion® Soft close door
•ProSight® Interactive digital information display
•FloodLight® inclined flood light
•Pyroluxe® Plus self cleaning system
•Isoftont® Quadruple glazed glass door
•ProFrame° Anti-fingerprint stainless steel
•12 cooking functions including True Fan Convection
•Panoramic view window
•Metric and Imperial baking chart on interior of door
•Cooling fan
•Child safety lock
OVEN PROGRAMS
•Ventitherm®/True Fan Convection
•Pizza Mode
•Slow Cook
•Conventional Cooking
•Frozen Foods
•Turbo Grilling
•Fast Grilling
•Grilling
•Keep Warm
•Defrost
•Bottom Heat
•ECO Roasting
•Automatic programmes (x20)
•Pyroluxe®PLUS enables you to meet even
professional standards of cleanliness. By
heating the oven to 500°C, this self-cleaning
system reduces all food residue to a fine ash,
which you can wipe away completely with a
damp cloth
•Removable door and glass panes for easy
cleaning
OVEN CLEANING FEATURES

Specifications are subject to change without notice
V1.2
Specifications
BP730410MM
221/2”
571mm
215/8”
550mm
2213/16”
580mm
9/16”
15mm
237/16”
595mm
233/8”
594mm
213/8”
543mm
13/4”
45mm
43/4”
120mm
13/16”
21mm
D: 221/2” • W: 237/16” • H: 233/8”
D: 571 mm • W: 595 mm • H: 594 mm
OVEN DIMENSIONS

Specifications are subject to change without notice
V1.2
Specifications (Column Installation)
BP730410MM
•Install false backs for storage
spaces. This will prevent contents
from falling through the vent
space. In addition, warm air will
not interfere with your stored
contents
FALSE BACKS
•A minimum of 3mm of clearance
space is needed above the
cabinet or appliance below to
allow the oven door to open
OVEN DOOR CLEARANCE
•D: 221/2” • W: 237/16” • H: 233/8”
•D: 571 mm • W: 595 mm • H: 594 mm
OVEN DIMENSIONS
•220 / 240 Volt, 60Hz, 20 AMP, 3500W
ELECTRICAL REQUIREMENTS
•D: min. 235/8” x W: min.221/16” x H: 231/4”
•D: min. 600mm x W: min.560mm x H: 590mm
CUT-OUT DIMENSIONS •AEG ovens are supplied with a 5’ long electrical
cable and must be hard wired to the electrical
supply
•AEG ovens uses the following wires:
RED & BLACK: Live Wires
GREEN: Ground
The Neutral (White) wire is not required for the
electrical installation.
*IMPORTANT*

Specifications are subject to change without notice
V1.2
BP730410MM
•If the oven is being placed under the counter, there must be a minimum gap of 19/16” (4cm) cut out of the shelf
behind the oven to allow air to flow freely.
•If sufficient air flow is not provided, the life of the appliance will be shortened.
•Cut-out in the toe kick is optional and recommended.
•Bottom vent grill (7427640) available
AIR FLOW REQUIREMENTS
Specifications (Under Counter Installation)
•A minimum of 3mm of clearance
space is needed above the
cabinet or appliance below to
allow the oven door to open
OVEN DOOR CLEARANCE
